932GW/BW
2032NW
2232GW/BW
19", 20" and 22" Widescreen LCD Monitors
20.4"
16.5"
©2008 Samsung Electronics America, Inc. Samsung is a registered mark of Samsung Electronics Corp., Ltd.
Specifications and design are subject to change without notice. See www.samsung.com for detailed information.
Printed in USA. 932GW/BW2032NW2232GW/BW2/08R2
Product Information: 1-866-SAM-4BIZ www.samsung.com/monitor
Product Support: 1-800-SAMSUNG
Features
Widescreen Format
Spread out on your desktop with the
wide 16:10 aspect ratio. See everything
clearly with up to 1680 x 1050 resolution.
Modern Minimalist Design
Softly sculpted curves and a high-gloss
bezel combine in a dynamically styled,
uniquely attractive desktop centerpiece.
iF Award-Winning Design and
Functionality
The 2007 International
Forum (iF) Design Awards
recognized these cutting-
edge monitors with the iF Product
Design Award and, for their elastomer
ball-hinge swivel and tilt mechanism, the
iF Material Gold Award.
MagicSpeed™up to 2 ms (G to G)
Response Time
Fast pixel response means fast
gaming, movie and multimedia
action with virtually no blurring or ghosting.
MagicClear™Screen Technology
The hard clear-coating on the 932GW
and 2232GW delivers true colors,
intense blacks, and perfect details
without diffuse refraction for unmatched
vividness and realistic picture quality.
Certified for Windows Vista™
Operating System
Premium certification is reserved
only for products proven to take
full advantage of everything the
Microsoft Windows Vista operating
system offers.
2232GW/BW Dimensions
Specifications 932GW/BW 2032NW 2232GW/BW
Display Type a-si TFT/TN a-si TFT/TN a-si TFT/TN
Viewable Size 19" Wide 20" Wide 22" Wide
Native Resolution 1440 x 900 1680 x 1050 1680 x 1050
Pixel Pitch (mm) 0.284 0.258 0.282
Aspect Ratio 16:10 16:10 16:10
Contrast Ratio (Typical/Dynamic) 1000:1/3000:1 1000:1/3000:1 1000:1/3000:1
Viewing Angle (Horizontal/Vertical) 170°/170° (CR>5) 170°/170° (CR>5) 170°/170° (CR>5)
Response Time 2 ms (GTG) 5 ms 2 ms (GTG)
Light Source CCFL CCFL CCFL
Brightness (Typical) 300 cd/m2300 cd/m2300 cd/m2
Panel Surface Matte (932BW)/MagicClear (932GW) Matte Matte (2232BW)/ MagicClear (2232GW)
Maximum Color Supported 16.7M 16.7M 16.7M
Video Input Signal Analog Analog RGB Analog RGB Analog RGB
Digital DVI with HDCP N/A DVI with HDCP
Frequency (H/V) 30~81kHz(H) / 56~75Hz(V) 30~81kHz(H) / 56~75Hz(V) 30~81kHz(H) / 56~75Hz(V)
Sync H/V Separated, Composite H/V, Sync
on Green
H/V Separated, Composite H/V, Sync
on Green
H/V Separated, Composite H/V, Sync
on Green
Compatibilty PC Windows Vista Basic Certification,
XP, 2000, 98
Windows Vista Basic Certification,
XP, 2000, 98
Windows Vista Basic Certification,
XP, 2000, 98
Mac Mac OS Leopard, X, 9 Mac OS Leopard, X, 9 Mac OS Leopard, X, 9
Input Connectors 15-pin D-sub, DVI-D, 3-pin AC
plug (CEE22)
15-pin D-sub, 3-pin AC plug
(CEE22)
15-pin D-sub, DVI-D, 3-pin AC
plug (CEE22)
Power Voltage AC 100-240 ~ VAC ( ± 10 %),60 /
50 Hz ± 3 Hz
AC 100-240 ~ VAC ( ± 10 %),60 /
50 Hz ± 3 Hz
AC 100-240 ~ VAC ( ± 10 %),60 /
50 Hz ± 3 Hz
Consumption (Max/Standby) 42 watts (max)/<1 watts (DPMS mode) 50 watts (max)/<1 watts (DPMS mode) 50 watts (max)/<1 watts (DPMS mode)
Controls Basic Power, Auto Adjustment, Source,
Brightness up/down, MagicBright 3
presets, OSD Menu
Power, Auto Adjustment, Source,
Brightness up/down, MagicBright 3
presets, OSD Menu
Power, Auto Adjustment, Source,
Brightness up/down, MagicBright 3
presets, OSD Menu
Advanced Picture (Brightness, Contrast, Magic
Bright), Color (MagicColor, Color
Tone, Color Control, Gamma), Image
(Coarse, Fine, Sharpness, H position,
V position), OSD (Language, H position,
V position, Transparency, Display
Time), Setup (Auto Source, Reset)
Picture (Brightness, Contrast, Magic
Bright), Color (MagicColor, Color
Tone, Color Control, Gamma), Image
(Coarse, Fine, Sharpness, H position,
V position), OSD (Language, H position,
V position, Transparency, Display
Time), Setup (Auto Source, Reset)
Picture (Brightness, Contrast, Magic
Bright), Color (MagicColor, Color
Tone, Color Control, Gamma), Image
(Coarse, Fine, Sharpness, H position,
V position), OSD (Language, H position,
V position, Transparency, Display
Time), Setup (Auto Source, Reset)
Features Plug & Play DDC 2B/DDC-CI DDC 2B/DDC-CI DDC 2B/DDC-CI
Stand Tilt Tilt Tilt
Wall Mount (VESA) N/A N/A N/A
Cabinet Color High-gloss Black High-gloss Black High-gloss Black
Magic Technologies MagicColor (Full and Intelligent Mode) n n n
MagicBright 3 (Custom, Text,
Internet, Game, Sports, Movie,
Dynamic Contrast)
n n n
MagicTune (On-Screen Asset
Management)
n n n
MagicClear (Clear-Coating on Screen) n (932GW only) N/A n (2232GW only)
MagicStand HAS (Height
Adjustable, Swivel, Tilt, Pivot)
N/A N/A N/A
MagicRotation (Image Rotation
With Software)
N/A N/A N/A
Operating
Conditions
Temperature 10°C ~ 40°C 10°C ~ 40°C 10°C ~ 40°C
Humidity 10% ~ 80%, non-condensing 10% ~ 80%, non-condensing 10% ~ 80%, non-condensing
Dimensions and
Weight
Product Dimension (With Stand,
W x H x D)
17.7" x 14.7" x 7.8" 18.7" x 15.4" x 7.8" 20.4" x 16.5" x 8.3"
Product Dimension (Without Stand,
W x H x D)
17.7" x 12.8" x 2.6" 18.7" x 13.5" x 2.8" 20.4" x 14.6" x 2.8"
Shipping Carton Dimension
(W x H x D)
20.4" x 15.4" x 5.1" 21.6" x 16.2" x 5.2" 23.6" x 17.2" x 5.2"
Product Weight Product Weight (With Stand) 9.0 lbs. 10.6 lbs. 11.0 lbs.
Shipping Weight 11.9 lbs. 13.9 lbs. 14.3 lbs.
Environmental Emission Standard MPR-II EMC MPR-II
RoHS Compliant n n n
Energy Star Compliant n n n
Product Recyclability CCFL panel contains mercury,
please dispose of properly
CCFL panel contains mercury,
please dispose of properly
CCFL panel contains mercury,
please dispose of properly
Packaging Recyclability All packing materials are recyclable All packing materials are recyclable All packing materials are recyclable
Package Contents Monitor, Power Cable, 15-pin D-sub
Cable, DVI-D Cable, Manuals, Driver CD
Monitor, Power Cable, 15-pin D-sub
Cable, DVI-D Cable, Manuals, Driver CD
Monitor, Power Cable, 15-pin D-sub
Cable, DVI-D Cable, Manuals, Driver CD
Warranty 3 years parts and labor 3 years parts and labor 3 years parts and labor
