Samsung 215TW - SyncMaster - 21" LCD Monitor User manual

SERVICEManual
TFT-LCD Monitor Fashion Feature
LCD-Monitor
Chassis LDP21WS
Model 215TW
- Applying MFM UI
- Applying HDCP / PIP
- Supporting Magic Tune 4.0
- Supporting Analog / Digital / AV / S-Video /
Component

Samsung Electronics Co.,Ltd.
416, Maetan-3Dong, Yeongtong-Gu, Suwon City,
Gyeonggi-Do, Korea, 443-742
Printed in Korea
P/N : BN82-00137G-00
URL : http://itself.sec.samsung.co.kr/
-This Service Manual is a property of Samsung
Electronics Co., Ltd.
Any unauthorized use of Manual can be punished
under applicable International and/or domestic
law.

2 Product Specifications
2-1
2 Product Specifications
2-1 Fashion Feature
- Support Analog/Digital/AV/S-Video/Component
- Improved Response Time by Adopting 16ms
- Support PIP when the sources are Anaolg and Digital
- Magic Bright2 : 6steps used
Custom/Text/Internet/Game/Sports/Movie
- Magictune 4.0 and Pivot software installed
- Auto Pivot : When the monitor is rotated in 90 degree, the display LED and OSD also are autimatically rotates
accordingly. This can be performed only when Magictune 4.0 and the Pivot software are running.
LCD Panel TFT-LCD panel, RGB vertical stripe, normally black transmissive,
21-Inch viewable, 0.270 (H) x 0.270 (V) mm pixel pitch
Scanning Frequency Horizontal : 31 kHz ~ 80 kHz (Automatic)
Vertical : 56 Hz ~ 75 Hz (WSXGA+ : 60 Hz)
Display Colors 16.7 Million colors
Maximum Resolution Horizontal : 1680 Pixels
Vertical : 1050 Pixels
Input Signal Analog / Digital / AV / S-Video / Component
Input Sync Signal Seperate H/V sync, Composite H/V, Sync-on-Green, Automatic synchroniza
tion whitout external swith of sync type
Support Video mode : NTSC / PAL / SECAM / PAL M / PAL N / NT43 / PAL60
support DVI mode : 480i/p,720p@50Hz, 720p@60Hz , 1080i@50Hz
1080i@60Hz (Support HDCP)
Level : TTL level
Maximum Pixel Clock rate 165 MHz
Active Display
Horizontal/Vertical 453.6(H) X 283.5(V) mm
AC power voltage & Frequency AC 90 ~ 264 Volts, 60/50 Hz ±3 Hz
Power Consumption 63W (Max)
Dimensions
Set (W x H x D) 19.3x8.65x14.8 Inches (490x219.8x377mm) State of stand installed
Package
23.1x10.3x17.7 Inches (587x262x450mm) State of stand pivoted
Weight (Set/Package) 7.5 kg(
After installation of Stand, Head weight : 5.5kg )/ 9.0 kg
Environmental Considerations Operating Temperature : 0˚F ~ 122˚F (0℃ ~ 50℃)
Operating Humidity : 20% ~ 90%
Storage temperature : -4˚F ~ 149˚F (-20℃ ~ 65℃)
Storage Humidity : 5% ~ 90%
- Designs and specifications are subject to change without prior notice.
Description
Item
2-2 Specifications

2 Product Specifications
2-2
2-3 LDP21WS feature
No Feature Feature
Operating method
It must be installed Magic
tune 4.0 and Pivot Software
to the PC
If Doppler turns on in some resolution for the first time, it can execute
Auto adjustment automatically for the high Quality
Doppler can check the change of Source
Automatically and change the source to the active Input
Doppler supports Wall mount
(100mmx100mm VESA-compliant mounting interface pad.)
Doppler supports 6 Different Brightness Mode
(Custom / Text / Internet / Game / Sports / Movie)
As Doppler has sensor IC for Pivot,
1) if Doppler rotates 90˚,
2) MCU can detect the current status through sensor IC,
3) Magic tune 4.0 &Pivot Software can make change Screen to the
rotated degrees automatically
Auto Auto
Auto Power
on/off
Wall mount
Magic Bright
Adjust the Sharpness
Sharpness
Auto Pivot
1
2
3
4
5
6

2 Product Specifications
2-3
2-4 Spec Comparison
KKey Specification
Model LS21BRBS LDP21WS
214T 215TW
Screen Size 21.3" 21.0"
Brightness 300 cd/㎡300 cd/㎡
Contrast 700:1 900:1
Response Time 16ms 16ms ( G to G : 8ms )
Input Source Analog / Original Analog / Digitla / AV
/ AV / S-Video / S-Video / Component
Magic Color OX
Magic Pivot OO
Magic Tune Ver 4.0 Ver 4.0
6-Color OX
Color Weakness OX
Gamma 8 steps
-0.2 / -0.1 / 0 / +0.1 / +0.2 / +0.3 X
/ +0.4 / +0.5 / +0.6
Magic Bright 4 steps 6 steps
Text / Internet / Entertain / Custom Custom/Text/Internet/Game/Sports/Movie
Color Tone 6 steps 4 steps
Warm2 / Warm1 / Normal / Cool1 Cool / Normal / Warm / Custom
/ Cool2 / Cool3 / Cool4
Key Specification

2 Product Specifications
2-4
2-5 Spec Comparison to the Other Models
SDVL_MC
OEDIV
REDOCED
Model LS21BRBS LDP21WS
214T 215TW
Response 21.3" 21.0"
Input Source 300 cd/㎡300 cd/㎡
Magic Pivot AUTO (Pivot program + Aensor IC) AUTO (Pivot Program + Sensor IC)
Magic Color O X
Magic Tune Ver 4.0 Ver 4.0
6-Color OX
Color Weakness OX
PBA
Additional portion

2 Product Specifications
2-5
2-6 Option Specification
Item Item Name CODE.NO Remark
Quick Setup Guide BN96-03197A
BH68-00261F
BN59-00520A
BN39-00244B
3903-000085
Warranty Card
(Not available in all locations)
User's Guide,
Monitor Driver,
Natural Color software,
MagicTune™software
D-Sub(15 Pin)
Cable
Power Cord

2 Product Specifications
2-6
2-7 Option Specification(Sold separately)
Item Item Name CODE.NO Remark
S-Video Cable
RCA Cable (Video-Yellow,
Audio-Red and White)
Component Cable
DVI Cable
Audio Cable

3 Alignments and Adjustments
3-1
3-1 Required Equipment
The following equipment is necessary for adjusting the monitor:
·Computer with Windows 95, Windows 98, Windows NT, Windows 2000, or Windows XP.
·MTI-2050/MTI-2055 DDC MANAGER JIG
3-2 Automatic Color Adjustment
To input video, use 16 gray or any pattern using black and white.
1. Press and hold down both the MENU and the ▲keys at the same time for about 5 seconds.
2. A blinking display informs you that the automatic color adjustment process is completed.
3. The automatic color adjustment feature is also available in the service function.
3-3 DDC EDID Data Input
1. Input DDC EDID data when replacing AD PCB.
2. Receive/Download the proper DDC file for the model from HQ quality control department.
Install the below jig (Figure 1) and enter the data.
3-4 OSD Adjustment When Replacing Panel
1. Set the Brightness and Contrast to zero,
and push the MENU button more than 5 seconds.
The Function OSD is displayed like Figure 2.
2. Select the Panel Information.
3. Select a panel that you want to replace with.
3-5 OSD Adjustment When Replacing Lamp Only
1. Set the Brightness and Contrast to zero,
and push the MENU button more than 5 seconds.
The Function OSD is displayed like Figure 2.
2. Select the Panel Information.
3. Select the upper lamp/ lower lamp.
--. Note : Please perform Automatic Color Adjustment when replacing the panel and main board.
3 Alignments and Adjustments
This section of the service manual explains how to use the RS232 JIG.
This function is needed for AD board change and program memory (IC200) change.
M
TI-2
031
DDC Mana
g
er
Parallel Connector
(25P Cable) Connect Monitor
(Signal Cable)
Figure 1.
MTI-2050 /
MTI-2055
DDC MANAGER

3 Alignments and Adjustments
3-2
3-6 Service Function Spec.
3-6-1 How to Display Service Function OSD
1. The OSD is displayed just like in 3-2.
2. To exit the service function, press the POWER key and restart the Monitor.
Figure 2. The example of service function OSD
Figure 3. The display of the Panel Information in the Function OSD
3-6-2 How to Control Service Function OSD
Use the ▲or ▼buttons to select an item that you want and press the Enter button.

3 Alignments and Adjustments
3-3
3-7 Hidden Key list

3 Alignments and Adjustments
3-4

3 Alignments and Adjustments
3-5
3-8 EDID Installation with Windows Program
1. Execute "WinDDC.exe"
2. Click "Sys Config"
Select "Station : Write station"
Check "Serial No and Week : Don't change"
Click "Save"
3. Click "Open" icon.
Select "Connected Port #1" and Next "OK".
* File Name - SM215TWA.DDC
SM215TWD.DDC
Press enter key on your keyboard.
4. Confirm the "DDC OK".
- After Replacing the Main Board
- EDID Installation (Analog and Digital)

3 Alignments and Adjustments
3-6
Memo

5 Exploded View & Parts List
5-1
5 Exploded View and Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself. sec. samsung.co.kr
5-1 LDP21WS Exploded View
T0003
M0001
T0022
M0215
M0006
M0174
M0014 T0376
M0006
M0003

5 Exploded View & Parts List
5-2
5-2 LDP21WS Parts List
Location.No CODE-NO SPECIFICATION & DESCRIPTION Q'TY REMARK
T0003 BN96-03194B ASSY COVER P-FRONT;LS21DP,ABS HB GR70,SV 1 S.A
M0001 BN90-00898A ASSY COVER FRONT;LS21DPWASQ/EDC 1 S.N.A
T0022 BN64-00479B KNOB CONTROL;LS21DP,ABS,T1.0,HB,GR70 (CL 1 S.N.A
M0215 BN07-00230A LCD-PANEL;LTM210M2-L02,Dvorak,8BIT,477.6 1 SA
M0006 BN96-03195A ASSY SHIELD P-COVER;LS21DPW,SECC,T0.8 1 SNA
M0174 BN44-00127B IP BOARD;FSP060-1PI01,214T,2.0 ~3.0mA,7. 1 SA
M0014 BN94-00846P ASSY PCB MAIN-SPZ,W/W;LS21DPW* 1 SA
T0376 BN63-02473A SHIELD-VIDEO;LS215TW,SPTE,T0.3 1 SNA
M0006 BN63-02470A COVER-REAR;LS215TW,HIPS,T2.3,HB,BK24 1 SNA
M0003 BN96-03196A ASSY STAND P;LS21DPW,HIPS HB,BK24 1 SA

6 Electrical Parts List
6-1
0 LS21DPWASQ/EDC 215TW,WSA1/S21A2-LDP,21,LCD-MO,NETHERLAN
0.1 M0002 BN90-00823S ASSY COVER REAR;LS21DPWAB/XAA 1 S.N.A
..2 M0013 BN96-03390A ASSY COVER P-REAR;LS21DP,HIPS HB BK24 1 S.A
...3 M0006 BN63-02470A COVER-REAR;LS215TW,HIPS,T2.3,HB,BK24 1 S.N.A
0.1 M0001 BN90-00898A ASSY COVER FRONT;LS21DPWASQ/EDC 1 S.N.A
..2 T0003 BN96-03194B ASSY COVER P-FRONT;LS21DP,ABS HB GR70,SV 1 S.A
...3 BN61-02120A BRACKET-SPEAKER;LS07BTT,SECC,T2.0,W70,W2 2 S.N.A
...3 M0112 BN63-02471B COVER-FRONT;LS21DP(S/M215TW),ABS,T2.0,HB 1 S.N.A
...3 T0022 BN64-00479B KNOB CONTROL;LS21DP,ABS,T1.0,HB,GR70 (CL 1 S.N.A
...3 M0145 BN96-03270A ASSY BOARD P-FUNCTION;LS21DPWAB,SJ06-01- 1 S.A
...3 C/F BN96-03296A ASSY BOARD P-AUDIO;LS21DPWAB,SJ05-01-006 1 S.N.A
...3 T0175 BN96-01660B ASSY SPEAKER P;8ohm,Doppler,1 W,30mm 1 S.A
...3 T0175 BN96-01660C ASSY SPEAKER P;8ohm,Doppler,1 W,350mm 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.N.A
0.1 M0216 BN90-00899A ASSY STAND;LS21DPWASQ/EDC 1 S.N.A
..2 M0003 BN96-03196B ASSY STAND P;LS21DP,ABS HB,GR70+BK24 1 S.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.N.A
...3 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 4 S.N.A
...3 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
...3 M0081 6003-001238 SCREW-TAPTITE;FH,+,S,M4,L8,ZPC(BLK),SWRC 2 S.N.A
...3 HC+CW 6009-001370 SCREW-SPECIAL;PWH,+,-,M4,L8,ZPC(YEL),SWR 1 S.N.A
...3 BN61-01396A HOLDER-SWIVEL RING;MJ17MS,ACETAL,NTR 1 S.N.A
...3 CIS4 BN61-01438A HOLDER-STAND;MATISSE HAS-STAND,SWRCH18A 1 S.N.A
...3 BN61-02398A BRACKET-STAND LIFT;LS215TW,SECC,T2.0 1 S.N.A
...3 BN61-02399A GUIDE-STAND LIFT;LS215TW,P.O.M,WHT 2 S.N.A
...3 BN61-02400A BRACKET-STAND FRAME;LS215TW,SECC,T2.0 1 S.N.A
...3 BN61-02401A GUIDE-STAND BODY;LS215TW,P.O.M,WHT 1 S.N.A
...3 BN61-02402A BRACKET-STAND BOTTOM;LS215TW,SECC,T2.0 1 S.N.A
...3 BN63-02476A COVER-STAND FRONT;LS215TW,HIPS,T2.5,HB,B 1 S.N.A
...3 BN63-02477A COVER-STAND REAR;LS215TW,HIPS,T2.5,HB,BK 1 S.N.A
...3 BN63-02481A COVER-STAND TOP;LS215TW,HIPS,T2.5,HB,BK2 1 S.N.A
...3 BN63-02482A COVER-STAND VESA;LS215TW,HIPS,T2.5,HB,BK 1 S.N.A
...3 BN63-02483A COVER-STAND TILT;LS215TW,HIPS,T2.5,HB,BK 1 S.N.A
...3 BN63-02484A COVER-STAND LIFT FRONT;LS215TW,HIPS,T2.5 1 S.N.A
...3 BN63-02485A COVER-STAND LIFT REAR;LS215TW,HIPS,T2.5, 1 S.N.A
...3 T0081 BN73-00085A RUBBER CUSHION;MATISSE,##4.5(IN SIDE),CL 1 S.N.A
...3 T0054 BN96-03193A ASSY HINGE P;LS215TW,ZNDC 1 S.N.A
...3 CCM1 6001-001547 SCREW-MACHINE;BH,+,M4,L10(5),ZPC(BLK),SW 2 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 BN61-02437A SPRING ETC-SPIRAL;LS215TW,SUS,18.5,130,T 2 S.N.A
...3 T0514 BN61-02454A BRACKET-SUPPORT;LS21DPW,SECC,T1.0 1 S.N.A
...3 T0004 BN63-02478B COVER-STAND BASE;LS21DPW,HIPS,T2.5,HB,GR 1 S.N.A
...3 T0003 BN63-02480A COVER-STAND BOTTOM;LS215TW,HIPS,T2.5,HB, 1 S.N.A
...3 T0132 BN73-00077A RUBBER FOOT;MATISSE,BUMPON,##13.5,T2.0,6 4 S.N.A
...3 M0007 BN96-01524A ASSY STAND P-STOPPER;MJ17BS,SUS T1.0,L26 1 S.N.A
0.1 T0852 BN91-00939U ASSY LCD-SPZ;LS21DPW* 1 S.N.A
..2 M0215 BN07-00230A LCD-PANEL;LTM210M2-L02,Dvorak,8BIT,477.6 1 S.A
6 Electrical Parts List
-You can search for updated part codes through ITSELF web site.
URL : http://itself.sec.samsung.co.kr/
6-1 LS21DPWASQ/EDC Parts list
Level Loc. No. Code No. Description & Specification EA SA/SNA

6 Electrical Parts List
6-2
Level Loc. No. Code No. Description & Specification EA SA/SNA
0.1 M0112 BN91-01001W ASSY SHIELD;DP21WS 1 S.N.A
..2 M0081 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC(BLK),S 3 S.N.A
..2 BN63-02474A SHIELD-LAMP;LS215TW,SPTE,T0.3 1 S.N.A
..2 T0279 BN63-02475B COVER-JACK;LS215TW,HIPS,T2.0,V0,BK24 1 S.N.A
0.1 M0017 BN91-01021F ASSY CHASSIS-SPZ,W/W;LS21DPW*,W/W 1 S.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,S,M4,L8,ZPC(YEL) 1 S.N.A
..2 T0376 BN63-02473A SHIELD-VIDEO;LS215TW,SPTE,T0.3 1 S.N.A
..2 M0146 BN63-02505A SHIELD-PCB SMPS;LS215TW,SPTE,T0.3 1 S.N.A
..2 M0014 BN94-00846P ASSY PCB MAIN-SPZ,W/W;LS21DPW* 1 S.A
...3 T0245 0202-001522 SOLDER-WIRE FLUX;LFA3-107,-,D1.2,96.5Sn/ 0.025 S.N.A
...3 CN102 3701-001173 CONNECTOR-DVI;24P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN101 3701-001219 CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN604 3722-001782 JACK-PIN;1P,SN,WHT,ANGLE 1 S.A
...3 CN605 3722-001784 JACK-PIN;1P,SN,RED,ANGLE 1 S.A
...3 CN603 3722-002081 JACK-EAR PHONE;5P/2C,-,SnPb,L-BLU,- 1 S.A
...3 CN103 3722-002267 JACK-PIN;3P,AU,RED/WHT/YEL,ANGLE 1 S.A
...3 CN104 3722-002275 JACK-DIN;4P,-,SN,BLK,- 1 S.A
...3 CN705 3722-002389 JACK-PIN;3P,AU,RED/BLU/GRN,ANGLE 1 S.A
...3 HDCP KEY BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-00832A ASSY SMD;LS21DPWAB/XAA 1 S.N.A
....4 CIS5 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45?,96.5Sn/3 2.572 S.N.A
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D103 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D104 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D105 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D106 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D107 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D108 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D109 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D110 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D111 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D113 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D114 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D117 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D118 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D119 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D712 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D713 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D501 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 D502 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 D503 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 ZD106 0402-000553 DIODE-RECTIFIER;SS24,40V,2A,DO-214AA,TP 1 S.A
....4 D115 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD102 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD103 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD104 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 ZD105 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 D606 0403-001016 DIODE-ZENER;RLZ6.2B,5.96-6.27V,500mW,LL- 1 S.A
....4 ZD401 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 ZD731 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 ZD732 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 ZD502 0403-001411 DIODE-ZENER;-,5.49-5.73V,200mW,SOD-323,T 1 S.A
....4 ZD101 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1 S.A

6 Electrical Parts List
6-3
....4 ZD107 0403-001435 DIODE-ZENER;QZX363C5V6,5.32-5.88V,200MW, 1 S.A
....4 ZD501 0406-001061 DIODE-TVS;MMQA5V6T3,5.32/5.6/5.88V,24W,S 1 S.A
....4 D120 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D121 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D122 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D123 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D602 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D603 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D604 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 D605 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 ZD109 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 ZD733 0406-001163 DIODE-TVS;CDS3C05GTA,6.4V/-/-,-,SMD 1 S.A
....4 Q506 0501-000342 TR-SMALL SIGNAL;KSC1623-Y,NPN,200mW,SOT- 1 S.A
....4 Q101 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q102 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q501 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q502 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q503 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q504 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q602 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q603 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q604 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q605 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q607 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q608 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q609 0501-002080 TR-SMALL SIGNAL;2SC2412K,NPN,200mW,SC-59 1 S.A
....4 Q409 0505-001170 FET-SILICON;SI9933ADY-T1,P,-20V,3.4A,0.0 1 S.A
....4 IC104 0801-002267 IC-CMOS LOGIC;74LCX14,-,SOIC,14P,150MIL, 1 S.A
....4 IC104 0801-002404 IC-CMOS LOGIC;74VHC4066,ANALOG SWITCH,SO 1 S.A
....4 IC104 0801-002404 IC-CMOS LOGIC;74VHC4066,ANALOG SWITCH,SO 1 S.A
....4 IC104 0801-002404 IC-CMOS LOGIC;74VHC4066,ANALOG SWITCH,SO 1 S.A
....4 IC104 0801-002478 IC-CMOS LOGIC;7SZ14,SCHMITT TRIGGER,SOT2 1 S.A
....4 IC104 0801-002709 IC-CMOS LOGIC;74HC373,D FLIP-FLOP,TSSOP, 1 S.A
....4 IC520 0903-001423 IC-MICROCONTROLLER;WT6600F,-,QFP,128P,20 1 S.A
....4 IC108 1002-001398 IC-A/D CONVERTER;MST9883CR-110,24Bit(8x3 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
....4 IC112 1103-001314 IC-EEPROM;24C16,2Kx8,SOP,8P,5x4mm,2.7/5. 1 S.A
....4 IC202 1105-001538 IC-VIDEO RAM;K4D263238,-,128M,4x1Mx32Bit 1 S.N.A
....4 T0085 1201-002271 IC-AUDIO AMP;APA2068,SOP,16P,150MIL,DUAL 1 S.A
....4 IC508 1202-000164 IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, 1 S.A
....4 IC304 1203-001559 IC-RESET;DS1834A,SOIC,8P,150MIL,PLASTIC, 1 S.A
....4 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
....4 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
....4 T0087 1203-002351 IC-POSI.FIXED REG.;LF25C,DPAK,3P,240MIL, 1 S.A
....4 IC502 1203-002796 IC-DC/DC CONVERTER;AP1501-33K5A,TO-263-5 1 S.A
....4 IC501 1203-002843 IC-DC/DC CONVERTER;AP1501-50K5A,TO-263-5 1 S.A
....4 IC504 1203-002889 IC-DC/DC CONVERTER;AP1501-K5A,TO263-5L,5 1 S.A
....4 T0087 1203-003704 IC-POSI.FIXED REG.;G953-18T6U,SOT-223,3P 1 S.A
....4 IC402 1204-002419 IC-VIDEO DECODER;TW9906,TQFP,80P,12x12mm 1 S.A
....4 IC109 1205-002823 IC-LCD CONTROLLER;MST6281LA-LF-165-1,LQF 1 S.A
....4 R237 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 S.A
....4 R307 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R536 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R537 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 JP601 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R108 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
Level Loc. No. Code No. Description & Specification EA SA/SNA

6 Electrical Parts List
6-4
Level Loc. No. Code No. Description & Specification EA SA/SNA
....4 R109 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R111 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R114 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R202 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R230 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R231 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R232 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R233 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R234 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R235 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R248 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R271 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R272 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R274 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R275 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R301 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R302 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R303 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R304 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R316 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R317 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R318 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R319 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R320 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R321 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R322 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R323 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R324 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R325 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R354 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R355 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R362 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R363 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R364 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R365 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R376 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R377 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R378 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R379 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R380 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R381 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R382 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R384 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R396 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R397 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R4007 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R4011 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R4012 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R4015 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R410 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R411 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R412 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R413 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R414 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R415 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R416 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
7-2 Others
