Samsung SyncMaster 510S User manual

510/710

Main > Index
Main Page On-Screen Display
Safety Instructions Troubleshooting
Notational Check List
Power Q & A
Installation Self-Test Feature Check
Cleaning
Other
Introduction Specifications
Unpacking General Specifications
Front Preset Timing Modes
Rear PowerSaver
Bottom
Setup Information
Connecting Your Monitor Terms
Base Installation

Main > Safety Instructions > Notational
Notational
Power
Installation
Clean
Other
Failure to follow directions noted by this symbol could result in bodily harm or damage to
equipment.
Prohibited Important to read and understand at all times
Do not disassemble Disconnect the plug from the outlet
Do not touch Grounding to prevent an electric shock

Main > Safety Instructions > Power
Notational
Power
Installation
Clean
Other
When not used for extended periods of time, set your PC to DPMS. If using
a screen saver, set it to the active screen mode.
zIf the size of your monitor is small, or if the same image is present for long
periods of time, you may see afterimages due to damage to the
fluorescent substance on the inside of the CRT.
Do not use a damaged or loose plug.
zThis may cause an electric shock or fire.
Do not pull the plug out by the wire nor touch the plug with wet
hands.
zThis may cause an electric shock or fire.
Use only a properly grounded plug and recepticle.
zAn improper ground may cause electric shock or equipment
damage.
Do not excessively bend the plug and wire nor place heavy objects
upon them, which could cause damage.
zFailure to do so may cause an electric shock or fire.
Disconnect the plug from the outlet during storms or lightening or
if it is not used for a long period of time.
zFailure to do so may cause an electric shock or fire.
Do not connect too many extension cords or plugs to an outlet.
zThis may cause a fire.

Main > Safety Instructions > Installation
Notational
Power
Installation
Clean
Other
Do not cover the vents on the monitor cabinet.
zBad ventilation may cause a breakdown or fire.
Put your monitor in a location with low humidity and a minimum of
dust.
zAn electric shock or fire could result inside the monitor.
Do not drop the monitor when moving it.
zThis may cause damage to the product or human body.
Place the monitor on a flat and stable surface.
zThe monitor can cause injury by falling.
Set down the monitor carefully.
zIt could be damaged or broken.
Do not place the monitor face down.
zThe CRT surface may be damaged.
Do not use the monitor without the monitor stand.
zIt could break down or cause a fire due to bad ventilation.
zIf the monitor must be used without the supplied stand, take steps
to insure proper ventilation.

Main > Safety Instructions > Clean
Notational
Power
Installation
Clean
Other
When cleaning the monitor case or the surface of the CRT, wipe with a
slightly moistened, soft fabric.
Do not clean Flat monitor with water. Use a water-diluted mild
detergent.
(Some detergents contain significant amounts of alcohol-based solvents,
which can damage (color change) or crack the monitor case. The
antiglare/anti-static surface coating on the CRT may also be affected.)
Dilute the detergent (1:10 ratio) with water before using.
Do not spray detergent directly on the monitor.
Use the recommended detergent with a smooth cloth.
zYou can prevent the coated CRT from being damaged or the
monitor cabinet from being dissolved, cracked or discolored.
If the connector between the plug and the pin is dusty or dirty,
clean it properly with a dry cloth.
zA dirty connector can cause an electric shock or fire.
Do not set a glass of water, chemicals or any small metal objects
on the monitor.
zThis may cause damage, electric shock or a fire.
zIf a foreign substance gets into the monitor, disconnect the plug
and then contact a service center.

Main > Safety Instructions > Other
Notational
Power
Installation
Clean
Other
Do not remove cover(or back). No user serviceable parts inside.
zThis may cause an electric shock or a fire.
zRefer servicing to qualified service personnel.
If your monitor does not operate normally - in particular, if there are
any unusual sounds or smells coming from it - unplug it
immediately and contact an authorized dealer or service.
zThis may cause an electric shock or a fire.
Do not place any heavy objects on the monitor.
zThis may cause an electric shock or a fire.
For each hour of looking at the monitor, you should let your eyes
rest for 5 minutes.
zThis will reduce eye fatigue.
Do not use or store inflammable substances near the monitor.
zThis may cause an explosion or fire.
Do not try to move the monitor by pulling on the wire or the signal
cable.
zThis may cause a breakdown, electric shock or a fire due to
damage to the cable.
Do not move the monitor right or left by pulling only the wire or the
signal cable.
zThis may cause a breakdown, electric shock or a fire due to
damage to the cable.
Never insert anything metallic into the monitor openings.
zThis may cause an electric shock, fire or injury.

Keep the monitor away from any magnetic substances.
zThis may cause discoloring or distortion of the image.

Main > Introduction > Unpacking
Unpacking
Front
Rear
Bottom
Monitor and Stand
(Some models include a stand attached. )
Please make sure the following items are included
with your monitor. If any items are missing,
contact your dealer.
Power Code
Stand
Quick Setup Guide
User's GuideCD
2002-09-16file://\\Ssj\an15vt\ver02\MANUAL\EN\product\index.htm

Unpacking
Front
Rear
Bottom
1. Exit button Use this button to Exit the active menu or the OSD.
2,3. Adjust buttons These buttons allow you to highlight and adjust items in the menu.
4. Menu button Use this button to open the OSD and activate a highlighted menu item.
5. Power indicator This light glows green during normal operation, and blinks green once as
the monitor saves your adjustments.
6. Power button Use this button to turn the monitor on and off.
Note: See PowerSaver described in the manual for further information regarding power saving
functions. For energy conservation, turn your monitor OFF when it is not needed, or when
leaving it unattended for long periods.

Unpacking
Front
Rear
Bottom
(The configuration at the back of the monitor may vary from product to product.)
1. Power port Connect the power cord for your monitor to the power port on the back of
the monitor.
2. Signal Cable Connect the signal cable to the video port on your computer, video board,
video card, or graphics card.
Note: See Connecting Your Monitor for further information regarding cable connections.

Unpacking
Front
Rear
Bottom
1. Signal Cable Connect the signal cable to the video port on your computer, video board,
video card, or graphics card.
2. Power port Connect the power cord for your monitor to the power port on the back of
the monitor.
3. Tilt/Swivel Base You can separate the base from the monitor.

Connecting
Your Monitor
Base Installation
1. Connect the power cord for your monitor to the power port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
2. Connect the signal cable to the video port on your computer, video board, video card, or
graphics card.
3. If you are using a Macintosh computer, connect the cable to a Macintosh adapter, and set the
pins on your adapter(Adapter not included). A PC-compatible computer does not need an
adapter.
4. Turn on your computer and monitor. If your monitor displays an image, installation is complete.

Connecting Your
Monitor
Base Installation
Tilt/Swivel Base | Attaching and Removing the Base
With the built-in pedestal, you can tilt and/or swivel the monitor for the most comfortable
viewing angle.
Note: The base is detachable.
If your monitor was supplied with the base detached, attach the base as follows.
Remove the twist-tie before attaching the base to the monitor.

Attaching the Base
1. Place the monitor upside-down on a flat work surface.
2. Align the tabs on the base with the corresponding slots on the bottom of the monitor.
3. Press the base onto the monitor until the tabs are fully engaged in the slots.
4. Push the base toward the front of the monitor until the release latch clicks into the locked
position.
* Do not bend the snap.
Removing the Base
5. Squeeze and pull up on the release latch on the base.
6. Push the base toward the back of the monitor and lift up to remove the base.
Note: The base will align with the monitor slots in only one position.

On Screen Display (OSD) Menu System
1
E
x
it
b
u
tt
on:
U
se
thi
s
b
u
tt
on
t
o
E
x
it
th
e ac
ti
ve menu or
th
e
OSD.
2,3 Adjust buttons: These buttons allow you to highlight and
adjust items in the menu.
4 Menu button: Use this button to open the OSD and activate
a highlighted menu item.
1E itb tt
U thi b tt t E it th ti th

On Screen Display (OSD) Menu System
With the menu off, push the menu button.
Push the - button or + button until the Brightness
screen is displayed.
Push the menu button to open the Brightness adjustment screen.
Use the + button to increase the brightness or - button to decrease the
brightness.
Menu How to adjust
Brightness
Contrast
With the menu off, push the menu button.
Push the - button or + button until the Contrast
screen is displayed.
Push the menu button to open the Contrast adjustment screen.
Use the + button to increase the contrast or - button to decrease the
contrast.
Adjust the Brightness.
Adjust the Contrast.

On Screen Display (OSD) Menu System
Follow these instructions to change the Position of
the monitor’s entire display.
With the menu off, push the menu button.
Push the - button or + button until the H-Position screen is
displayed.
Push the menu button to open the H-Position adjustment screen.
Use the - and + buttons to change the Horizontal
position of the monitor’s viewing area.
Menu How to adjust
H-Position
V-Position
With the menu off, push the menu button.
Push the - button or + button until the V-Position screen is
displayed.
Push the menu button to open the V-Position adjustment screen.
Use the - and + buttons to change the vertical
position of the monitor’s viewing area.
Follow these instructions to change the Position of
the monitor’s entire display.

On Screen Display (OSD) Menu System
Follow these instructions to change the Size of
the monitor’s entire display.
Menu How to adjust
H-Size
Follow these instructions to change the Size of
the monitor’s entire display.
V-Size
With the menu off, push the menu button.
Push the - button or + button until the H-Size screen is displayed.
Push the menu button to open the H-Size adjustment screen.
Use the - and + buttons to change the Horizontal
Size of the monitor’s viewing area.
With the menu off, push the menu button.
Push the - button or + button until the V-Size screen is displayed.
Push the menu button to open the V-Size adjustment screen.
Use the - and + buttons to change the Vertical
Size of the monitor’s viewing area

On Screen Display (OSD) Menu System
Menu How to adjust
Adjust the pincushion setting when the sides of the display
are bowed in or bowed out
Pincushion
With the menu off, push the menu button.
Push the - button or + button until the Pincushion
screen is displayed.
Push the menu button to open the Pincushion
adjustment screen.
Use the - button or + button to adjust the pincushion setting.
Adjust the trapezoid setting when the top or bottom of the
display is too large or small.
Trapezoid
With the menu off, push the menu button.
Push the - button or + button until the Geometry
screen is displayed.
Push the menu button again and then press the - or + button until
the Trapezoid screen appears.
Push the menu button to open the Trapezoid adjustment screen.
Use the - button or + button to adjust the trapezoid setting.
