Samsung SyncMaster C24A650X User manual

User Manual
C24A650X
C27A650X
C24A650U
C27A650U
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00082D-02

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
7 Copyright
7 Icons used in this manual
7 Symbols for safety precautions
8 Cleaning
8 Cleaning
9 Securing the Installation Space
9 Precautions for storage
9 Safety Precautions
9 Electricity and Safety
11 Installation
13 Operation
17 Correct posture to use the product
PREPARATIONS 18 Checking the Contents
18 Removing the Packaging
19 Checking the Components
21 Parts
21 Frontal Buttons
23 Reverse Side
25 Installation
25 Attaching the Stand
26 Adjusting the Product Tilt and Height
26 Rotating the Monitor
27 Attaching and detaching the wireless-
connection dongle (Rx)
28 Installing a Wall-mount Kit or Desktop Stand
29 Anti-theft Lock
30 "MagicRotation Auto"
USING "CENTRAL
STATION"
31 About "Central Station"
32 Software Installation for Using "Central
Station"
32 Installing "Samsung Central Station Setup"

Table Of Contents
Table Of Contents 3
34 Connecting the Product to a PC to Use
"Central Station"
34 Connecting to a PC via Wireless USB
38 Connecting to a PC via the USB Cable
39 Utilizing "Central Station"
39 Using the Product as a USB HUB
41 Connecting to a LAN
42 Configuring the Central Station Monitor
IP
42 Dynamic IP
43 Static IP
46 Notice before your use of Wireless USB
or USB Mode
CONNECTING AND USING
A SOURCE DEVICE
47 Before Connecting
47 Pre-connection Checkpoints
48 Connecting and Using a PC
48 Connecting to a PC
50 Driver Installation
51 Setting Optimum Resolution
52 Changing the Resolution Using a PC
54 Connecting Headphones
55 Connecting the Power
SCREEN SETUP 56 MAGIC
56 SAMSUNG MAGIC Bright
58 SAMSUNG MAGIC Color
59 Brightness
59 Configuring Brightness
60 Contrast
60 Configuring Contrast
61 Sharpness
61 Configuring Sharpness

Table Of Contents
Table Of Contents 4
62 Coarse
62 Adjusting Coarse
63 Fine
63 Adjusting Fine
64 Response Time
64 Configuring Response Time
CONFIGURING TINT 65 Red
65 Configuring Red
66 Green
66 Configuring Green
67 Blue
67 Configuring Blue
68 Color Tone
68 Configuring the Color Tone Settings
69 Gamma
69 Configuring Gamma
RESIZING OR
RELOCATING THE
SCREEN
70 Image Size
70 Changing the Picture Size
71 H-Position & V-Position
71 Configuring H-Position & V-Position
72 Menu H-Position & Menu V-Position
72 Configuring Menu H-Position & Menu V-
Position

Table Of Contents
Table Of Contents 5
SETUP AND RESET 73 HUB
73 Auto Wireless Detection
74 Wireless Connection
75 USB Connection
76 Analog
77 HDMI
78 USB Super Charging
78 Wireless ID
79 ECO
79 Eco Motion Sensor
81 Eco Light Sensor
84 Eco Saving
85 Eco Icon Display
87 Menu Transparency
87 Changing Menu Transparency
88 Language
88 Changing the Language
89 PC/AV Mode
89 Configuring PC/AV Mode
90 Auto Source
90 Configuring Auto Source
91 Display Time
91 Configuring Display Time
92 Key Repeat Time
92 Configuring Key Repeat Time
93 Customized Key
93 Configuring Customized Key
94 Off Timer On/Off
94 Configuring Off Timer On/Off
95 Off Timer Setting
95 Configuring Off Timer Setting

Table Of Contents
Table Of Contents 6
96 Reset
96 Initializing Settings (Reset)
INFORMATION MENU AND
OTHERS
97 INFORMATION
97 Displaying INFORMATION
97 Configuring Brightness in the Startup
Screen
TROUBLESHOOTING
GUIDE
98 Requirements Before Contacting
Samsung Customer Service Center
98 Testing the Product
98 Checking the Resolution and Frequency
99 Check the followings.
101 Q & A
SPECIFICATIONS 103 General
104 PowerSaver
105 Standard Signal Mode Table
APPENDIX 106 Contact SAMSUNG WORLD WIDE
110 Terminology
INDEX

7
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2012 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Icons used in this manual
Symbols for safety precautions
The following images are for reference only. Real-life situations may
differ from what is shown in the images.
Warning A serious or fatal injury may result if instructions are not followed.
Caution Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

8
Before Using the Product
Before Using the Product
Cleaning
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1. Power off the monitor and computer.
2. Disconnect the power cord from the monitor.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the monitor with a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the monitor.
5. Connect the power cord to the product after cleaning the product.
6. Power on the monitor and computer.
!
!

9
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. A rise in the internal temperature may cause
a fire and damage the product. Be sure to allow the amount of space as shown below or greater
when installing the product.
The exterior may differ depending on the product.
Precautions for storage
High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used
nearby.
Be sure to contact Samsung Customer Service Center (page 106) if the inside of the monitor needs
cleaning. (service fee will be charged).
Safety Precautions
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
10 cm
10 cm 10 cm
10 cm
10 cm

10
Before Using the Product
Before Using the Product
Warning
Do not use a damaged power cord or plug, or a loose power socket.
An electric shock or fire may result.
Do not plug many products into the same power socket.
Otherwise, the socket may overheat and cause a fire.
Do not touch the power plug with wet hands.
Otherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
An unstable connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices
only).
An electric shock or injury may result.
Do not bend or pull the power cord with force. Do not weigh the power cord
down with a heavy object.
A damaged power cord may cause an electric shock or fire.
Do not place the power cord or product near heat sources.
An electric shock or fire may result.
Remove foreign substances such as dust around the plug pins and power socket
with a dry cloth.
Otherwise, a fire may result.
!
!
!

11
Before Using the Product
Before Using the Product
Caution
Installation
Warning
Do not unplug the power cord when the product is in use.
The product may become damaged by an electric shock.
Do not use the power cord for products other than authorized products supplied
by Samsung.
An electric shock or fire may result.
Keep the power socket where the power cord is connected unobstructed.
If any problem occurs in the product, unplug the power cable to completely
cut the power to the product.
Power to the product cannot be completely cut off with the power button.
Hold the plug when disconnecting the power cord from the power socket.
An electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
Otherwise, a fire may result.
Avoid installing the product in a narrow space with bad ventilation, such as a
bookshelf or wall closet.
Otherwise, a fire may result due to an increased internal temperature.
Keep the plastic packaging bag for the product in a place that cannot be reached
by children.
Children may suffocate.
!
!
!
!

12
Before Using the Product
Before Using the Product
Caution
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.).
The product may fall and break or cause a personal injury.
Using the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
An electric shock or fire may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
Otherwise, the product lifespan may be reduced, or a fire may result.
Do not install the product within the reach of young children.
The product may fall and injure children.
Take care not to drop the product when moving it.
Otherwise, product failure or personal injury may result.
Do not set down the product on its front.
The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
The product may fall and break or cause a personal injury.
Install the product only on cabinets or shelves of the right size.
!
!

13
Before Using the Product
Before Using the Product
Operation
Warning
Put down the product carefully.
The product may fall and break or cause a personal injury.
Installing the product in an unusual place (a place exposed to a lot of fine
particles, chemical substances or extreme temperatures, or an airport or train
station where the product should operate continuously for an extended period of
time) may seriously affect its performance.
Be sure to consult Samsung Customer Service Center (page 106) before
installation if you want to install the product at such a place.
High voltage runs through the product. Do not attempt to disassemble, repair, or
modify the product on your own.
An electric shock or fire may result.
Contact Samsung Customer Service Center (page 106) for repair.
Before moving the product, turn off the power switch and disconnect the power
cable and all other connected cables.
Otherwise, the power cord may be damaged and a fire or electric shock may
result.
If the product generates a strange noise, a burning smell, or smoke, remove the
power cord immediately and contact Samsung Customer Service Center (page
106).
An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
The product may fall, and your child may become injured or seriously
harmed.
If the product falls or the exterior is damaged, power off the product, remove the
power cord, and contact Samsung Customer Service Center (page 106).
Otherwise, an electric shock or fire may result.
Do not put a heavy object, toy, or sweets on top of the product.
The product or heavy objects may fall as children try to reach for the toy or
sweets resulting in a serious injury.
!
SAMSUNG
!
!
!

14
Before Using the Product
Before Using the Product
During a lightning or thunderstorm, power off the product and remove the power
cable.
An electric shock or fire may result.
Do not drop objects on the product or apply impact.
An electric shock or fire may result.
Do not move the product by pulling the power cord or any cable.
Otherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
Sparks can cause an explosion or fire.
During a lightning or thunderstorm, do not touch the power cord or antenna
cable.
Do not lift or move the product by the power cord or any cable.
Otherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
Do not use or keep combustible spray or an inflammable substance near the
product.
An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
Otherwise, a fire may result from an increased internal temperature.
!
!
!
GAS
!

15
Before Using the Product
Before Using the Product
Caution
Do not insert a metallic object (a chopstick, coin, hair pin, etc.) or inflammable
object (paper, match, etc.) into the vent or ports of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 106).
Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 106).
Product failure, an electric shock or fire may result.
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
If you are not going to use the product for an extended period of time,
activate power-saving mode or a moving-picture screen saver.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
Otherwise, a fire may result from accumulated dust, overheating, an electric
shock, or electric leakage.
Use the product at the recommended resolution and frequency.
Your eyesight may deteriorate.
Do not put DC power adapters together.
Otherwise, a fire may result.
Remove the plastic bag from the DC power adapter before you use it.
Otherwise, a fire may result.
100
!
!
-_-
!
!

16
Before Using the Product
Before Using the Product
Do not let water enter the DC power device or get the device wet.
An electric shock or fire may result.
Avoid using the product outdoors where it can be exposed to rain or snow.
Be careful not to get the DC power adapter wet when you wash the floor.
Do not put the DC power adapter near to any heating apparatus.
Otherwise, a fire may result.
Keep the DC power adapter in a well-ventilated area.
Looking at the screen too close for an extended period of time can deteriorate
your eyesight.
Do not hold the monitor upside-down or move it by holding the stand.
The product may fall and break or cause a personal injury.
Do not use humidifiers or stoves around the product.
An electric shock or fire may result.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
Eye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended
period of time as it will become hot.
Store the small accessories used with the product out of reach of children.
Exercise caution when adjusting the product angle or stand height.
Otherwise, children's fingers or hands may become stuck and injured.
Tilting the product excessively may cause it to fall and result in personal
injury.
!
!
!
!
!

17
Before Using the Product
Before Using the Product
Correct posture to use the product
Do not place heavy objects on the product.
Product failure or personal injure may result.
Do not increase the volume too high when using headphones (earphones).
Sound particularly at a higher volume could potentially affect long-term
hearing.
Use the product in the correct posture as follows:
Straighten your back.
Allow a distance of 45 to 50cm between your eye and the screen, and look slightly
downward at the screen.
Keep your eyes directly in front of the screen.
Adjust the angle so light does not reflect on the screen.
Keep your forearms perpendicular to your upper arms and level with the back of
your hands.
Keep your elbows at about a right angle.
Adjust the height of the product so you can keep your knees bent at 90 degrees or
more, your heels attached to the floor, and your arms lower than your heart.

18
1 Preparations
1 Preparations
1.1 Checking the Contents
1.1.1 Removing the Packaging
1Open the packaging box. Be careful not to damage the product when you open the packaging with
a sharp instrument.
2Remove the Styrofoam from the product.
3Check the components and remove the Styrofoam and plastic bag.
The appearance of actual components may differ from the image shown.
This image is for reference only.
4Store the box in a dry area so that it can be used when moving the product in the future.

19
Preparations
1
1 Preparations
1.1.2 Checking the Components
Contact the dealer from whom you purchased the product if any item is missing.
The appearance of the components and items sold separately may differ from the image shown.
Components
Components may differ in different locations.
Quick setup guide Warranty card
(Not available in some
locations)
User manual
Wireless Connection
Dongle(Tx)
(Sold separately for C24A650U
and C27A650U models)
Wireless Connection
Dongle(Rx)
(Sold separately for C24A650U
and C27A650U models)
Stand base
Power cable DC power adapter USB 3.0 cable
D-SUB cable HDMI cable (optionally) USB gender changer
(Sold separately for C24A650U
and C27A650U models)

20
Preparations
1
1 Preparations
USB gender changer (Sold separately for C24A650U and C27A650U models)
When the wireless-connection dongle cannot connect to your notebook PC, connect it using the USB
gender changer.
Items sold separately
The following items can be purchased at your nearest retailer.
LAN cable HDMI-DVI cable
