Samsung 2333HD - SyncMaster - 23" LCD Monitor User manual

SyncMaster 2333HD
LCD TV Monitor
User Manual

Safety Instructions
Notational
Note
These safety instructions must be followed to ensure your safety and prevent property dam-
age.
Make sure to read the instructions carefully and use the product in the correct manner.
Warning / Caution
Otherwise, it may result in death or personal injury.
Otherwise, it may result in personal injury or property damage.
Notational Conventions
Prohibited Important to read and under-
stand at all times
Do not disassemble Disconnect the plug from the
outlet
Do not touch Ground to prevent an electric
shock
Power
When not used for extended period of time, set your computer to DPM.
If using screen saver, set it to active screen mode.
The images here are for reference only, and are not applicable in all cases
(or countries).
Shortcut to Anti-Afterimage Instructions
Do not use a damaged power cord or plug or a damaged or
loose power outlet.
• Otherwise, this may result in electric shock or fire.
Do not touch the power plug with wet hands when removing or
plugging the plug into the outlet.
•Otherwise, this may result in electric shock.
Make sure to connect the power cord to a grounded power out-
let.
•Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet
firmly and correctly.
•Otherwise, this may result in fire.
Do not forcefully bend or pull the power plug and do not place
any heavy material on it.
•Otherwise, this may result in fire.
Do not connect multiple appliances to the same power outlet.
• Otherwise, this may cause fire due to overheating.
Do not disconnect the power cord while using the product.
• Otherwise, this may result in damage to the product due to
electric shock.
To disconnect the apparatus from the mains, the plug must be
pulled out from the mains socket, therefore the mains plug shall
be readily operable.
• This may cause electric shock or fire.
Use only the power cord provided by our company. Do not use
the provided power cord of another product.
•Otherwise, this may result in fire or electric shock.
Installation
Be sure to contact an authorized Service Center when installing your
monitor in a location with heavy dust, high or low temperatures, high hu-
midity, and exposed to chemical substances and where it operates for 24
hours such as at airports, train stations etc.
Failure to do so may cause serious damage to your monitor.
Do not drop the monitor when moving it.
• This may cause damage to the product or the person carrying
it.
When installing the product in a cabinet or rack, make sure that
the front end of the bottom of the product does not project out.
• Otherwise, it may fall or cause personal injury.
• Use a cabinet or rack of a size appropriate to the product.
Do not place candles, mosquito repellant, cigarettes and any
heating appliances near the product.
• Otherwise, this may result in fire.
Safety Instructions

Keep heating appliances as far away from the power cord or the
product as possible.
•Otherwise, this may result in electric shock or fire.
Do not install it in a badly ventilated location such as a bookcase
or closet.
• Otherwise, this may result in fire due to an increase in the in-
ternal temperature.
Put down the monitor carefully.
•Failing to do so may damage the monitor.
Do not place the front of the product on the floor.
• Otherwise, this may result in damage to the screen display.
Ensure that an authorized installation company installs the wall
mount.
•Otherwise, it may fall and cause personal injury.
• Make sure to install the specified wall mount.
Install your product in a well ventilated location. Ensure that
there is a clearance of more than 10 cm from the wall.
• Otherwise, it may result in fire due to an increase in the internal
temperature.
Bend the outdoor antenna cable downwards at the location
where it goes in so that rainwater does not flow in.
• If rainwater enters the product, it may result in electric shock
or fire.
Install the antenna far away from any high voltage cables.
• If the antenna touches or falls onto a high voltage cable, it may
result in electric shock or fire.
Ensure that the packaging vinyl is kept away from children.
• Otherwise, it may result in serious harm (suffocation) if children
play with it.
If the height of your monitor is adjustable, do not place any ob-
ject or part of your body on the stand when lowering it.
• This may cause damage to the product or the person carrying
it.
Clean
When cleaning the monitor case or the surface of the TFT-LCD screen,
wipe with a slightly moistened, soft fabric.
Safety Instructions

Do not spray cleaner directly onto the surface of the product.
• Otherwise, this may result in the discoloration and distortion of
the structure and the screen surface may peel off.
Clean the product using a soft cloth with a monitor cleaner only.
If you must use a cleaner other than the monitor cleaner, dilute it
with water at a ratio of 1:10.
When cleaning the power plug pins or dusting the power outlet,
clean it with a dry cloth.
• Otherwise, it may result in fire.
When cleaning the product, make sure to disconnect the power
cord.
•Otherwise, it may result in electric shock or fire.
When cleaning the product, disconnect the power cord and
clean it softly with a dry cloth.
•(Do not use chemicals such as wax, benzene, alcohol, thinner,
mosquito repellant, lubricant, or cleaner.) These may change
the appearance of the product surface and peel off the indica-
tion labels on the product.
Since the product housing is easily scratched, make sure to use
the specified cloth only.
• Use the specified cloth adding only a little water. As the product
may be scratched if there is any foreign material on the cloth,
make sure to shake it thoroughly before using it.
When cleaning the product, do not spray water directly onto the
main body of the product.
•Ensure that water does not enter the product and that it is not
wet.
• Otherwise, this may result in electric shock, fire or a malfunc-
tion.
Others
The product is a high voltage product. Ensure that users do not
disassemble, repair or modify the product themselves.
• Otherwise, this may result in electric shock or fire. If the product
needs to be repaired, contact a Service Center.
If there is a strange smell or a strange sound or smoke is coming
from the product, disconnect the power plug immediately and con-
tact a Service Center.
• Otherwise, this may result in electric shock or fire.
Safety Instructions

Do not place this product in a location exposed to moisture, dust,
smoke, water, or in a car.
•Otherwise, this may result in electric shock or fire.
When you drop the product or the case is broken, turn the power
off and disconnect the power cord. Contact a Service Center.
• Otherwise, this may result in electric shock or fire.
If thunder or lightening is occurring, do not touch the power cord
or antenna cable.
• Otherwise, this may result in electric shock or fire.
Do not try to move the monitor by pulling only the wire or the
signal cable.
• Otherwise, it may fall and result in electric shock, damage to
the product or fire due to damage to the cable.
Do not lift or move the product back and forwards or right and
left while only holding the power cord or signal cables.
• Otherwise, it may fall and result in electric shock, damage to
the product or fire due to damage to the cable.
Make sure that the ventilating opening is not blocked by a table
or curtain.
• Otherwise, it may result in fire due to an increase in the internal
temperature.
Do not place any containers containing water, vases, flower-
pots, medicines as well as any metal on the product.
• If water or a foreign material enters the product, disconnect the
power cord and contact a Service Center.
• This may result in a product malfunction, electric shock, or fire.
Do not use or keep combustible spray or flammable material
near the product.
•Otherwise, this may result in an explosion or fire.
Do not insert any metal, such as chopsticks, coins, pins and
steel, or flammable objects, such as matches or paper, inside the
product (through the ventilating openings, input and output termi-
nals, etc).
• If water or foreign material enters the product, disconnect the
power cord and contact a Service Center.
• Otherwise, this may result in electric shock or fire.
When using a fixed screen for a long time, an afterimage or stain
may occur.
• If you are not using your product for a long period of time, put
it into sleep mode or use a moving screen saver.
Safety Instructions

Set a resolution and frequency appropriate to the product.
•Otherwise, your eyesight may be damaged.
When using headphones or earphones, do not turn the volume
too high.
•Having the sound too loud may damage your hearing.
If you continually move closer to the product screen, your eye-
sight may be failing.
To ease eye strain, take at least a five-minute break after every
hour of using the monitor.
Do not install it in an unstable location such as an unstable rack
or uneven surface or a location exposed to vibrations.
• Otherwise, it may fall and cause personal injury and/or damage
the product.
• If you use the product in a location exposed to vibrations, it may
damage the product and result in fire.
When moving the product, turn the power off and disconnect
the power plug, antenna cable, and all the cables connected to the
product.
• Otherwise, it may result in electric shock or fire.
Ensure that children do not hang onto the product or climb up
onto the product.
•The product may fall and cause personal injury or death.
If you do not use the product for a long period of time, disconnect
the power cord from the power outlet.
• Otherwise, this may result in overheating or fire due to dust,
and may result in fire due to electric shock or leakage.
Do not place any heavy items or toys or confectionery, such as
cookies etc. that may attract the attention of children and to the
product.
• Your children may hang onto the product causing it to fall and
this may result in personal injury or death.
Be careful that children do not place the battery in their mouths
when removed from the remote control. Place the battery in a lo-
cation that children or infants cannot reach.
• If children have had the battery in their mouths, consult your
doctor immediately.
Safety Instructions

When replacing the battery, insert it with right polarity (+, -).
• Otherwise, the battery may become damaged or it may cause
fire, personal injury or damage due to leakage of the internal
liquid.
Use only specified standard batteries. Do not use new and used
batteries together.
• This may cause a battery to break or leak and may cause fire,
injury, or contamination (damage).
The batteries (and rechargeable batteries) are not ordinary re-
fuse and must be returned for recycling purposes. The customer
is responsible for returning the used or rechargeable batteries for
recycling.
• The customer can return used or rechargeable batteries to a
nearby public recycling center or to a store selling the same
type of the battery or rechargeable battery.
Do not turn the product upside down or move it while holding
only the stand.
• Otherwise, it may fall and result in personal injury and/or dam-
age to the product.
Do not place the product in a location exposed to direct sunlight
or near any heat such as a fire or heater.
• This may reduce the lifetime of the product, and may result in
fire.
Do not drop any objects onto the product or cause any impact
to the product.
•Otherwise, this may result in electric shock or fire.
Do not use a humidifier or kitchen table near the product.
•Otherwise, this may result in electric shock or fire.
When there is a gas leak, do not touch the product or the power
plug but ventilate immediately.
•If a spark occurs, it may cause an explosion or fire.
If the product has been turned on for a long time, the display
panel becomes hot. Do not touch it.
Be careful when adjusting the angle of the product or the height
of the stand.
• This may result in personal injury as your hand or fingers may
become caught.
• Also, if you tilt the product too far, it may fall and cause personal
injury.
Safety Instructions

Do not install the product in a location low enough for children
to reach.
•Otherwise, it may fall and result in personal injury.
• Since the front part of the product is heavy, install the product
on a level and stable surface.
Do not put any heavy objects on the product.
• This may result in personal injury and/or damage to the prod-
uct.
Good Postures When Using the Monitor
When using the product, use it in the correct posi-
tion.
• Keep your back straight while looking at the prod-
uct.
• The distance between your eyes and the screen
should be between 45 to 50 cm. Look at the screen
from a slightly higher location than the height of the
screen.
• When using the product, use it in the correct posi-
tion.
• Adjust the angle so that light is not reflected on the
screen.
• Place your arms perpendicular to your sides and
allow your arms to be level with the back of the
hand.
• Keep your elbow at 90 degrees.
• Keep your knees at greater than 90 degrees, and
keep your heels firmly on the floor. Keep your arms
lower than your heart.
Safety Instructions

Introduction
Package Contents
Note
Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Unpacking
Without stand With stand
Monitor Monitor
Manuals
Quick Setup Guide Warranty Card
(Not available in all loca-
tions)
User Manual
(CD, Book)
Cables
HDMI Cable Power Cord

Others
Remote Control
BN59-00678A
Batteries (AAA X 2)
(Not available in all loca-
tions)
Cleaning Cloth
Cable holding ring
Note
Cleaning Cloth is only provided for highly polished black products as a product feature.
Sold separately
DVI Cable D-Sub Cable Headphones
USB Cable TV Antenna Cable
(Coaxial Cable)
Component(PR, PB, Y) Ca-
ble
Audio cable Digital audio optic output
cable
Stereo Cable
Introduction

Your Monitor
Front
Activates a highlighted menu item.
Push the ' ', button to change the input signal source.
Changing the source is only allowed for external devices connected to the
product at the time.
To switch Screen modes:
[PC] → [DVI] → [TV] → [Component] → [HDMI1] → [HDMI2]
>> Click here to see an animation clip
Use this button to open the on-screen menu and to exit from the on-screen
menu or to close the screen adjustment menu.
+ / -
Moves from one menu item to another horizontally or adjusts selected
menu values. Adjusts the audio volume.
Moves from one menu item to another vertically or adjusts selected menu
values. In TV mode, selects TV channels.
Power button [ ]
Use this button for turning the product on and off.
Remote Control Sensor
Aim the remote control towards this spot on the Monitor.
Introduction

Power indicator
This light is lit when operating normally, and blinks once when your ad-
justments are saved.
Note
See PowerSaver described in the manual for further information regarding
power saving functions. For energy conservation, turn your monitor OFF
when it is not needed or when leaving it unattended for long periods.
Speaker
You can hear sound by connecting the soundcard of your PC to the mon-
itor.
Rear
Note
The configuration at the back of the product may vary from product to product.
POWER
Connect the power cord for your monitor to
the
POWER port on the back of the product.
PC IN
Introduction

Connect the
PC terminal at the back of your
monitor to your computer.
HDMI/PC/DVI-D AUDIO
IN , DIGITAL AUDIO OUT
(OPTICAL) , EX-LINK
HDMI/PC/DVI-D AUDIO IN
Connect the [ HDMI/PC/DVI-D AUDIO IN ]
terminal at the back of your product to your
computer’s sound card.
DIGITAL AUDIO OUT(OPTICAL)
Connect the [DIGITAL AUDIO OUT(OPTI-
CAL)] terminal of your product to the digital
sound output or standard sound output ter-
minal of the DVD home theater (or amplifier)
using a digital audio optical output cable.
EX-LINK
This is a reserved terminal used for servicing.
SERVICE
This is a reserved terminal used for servicing.
DVI-D IN / HDMI IN 1
DVI-D IN
Connect the DVI cable to the DVI-D IN port
on the back of your product.
HDMI IN 1
Introduction

Connect the [HDMI IN 1] terminal at the back
of your monitor to the HDMI terminal of your
digital output device using a HDMI cable.
COMPONENT IN
R - AUDIO - L
Connect the port of the DVD, VCR (DVD /
DTV Set-Top Box) to the [ R - AUDIO - L] port
of the product.
PR, PB,Y
Connect the VIDEO OUT port of the DVD /
DTV Set-Top Box to the [ PR, PB,Y ] input
ports using a component video cable ( PR,
PB,Y ).
ANT IN
Connect the CATV cable or TV antenna ca-
ble to the "ANT IN" port on the rear side of
the product. Make sure to use a TV antenna
cable (sold separately) as the antenna cable.
Kensington Lock
The Kensington Lock is a device used to
physically fix the system when using it in a
public place. The locking device has to be
purchased separately. The appearance and
locking method may differ from the illustra-
tion depending on the manufacturer. Refer to
the manual provided with the Kensington
Lock for proper use. The locking device has
to be purchased separately.
Note
The location of the Kensington Lock may be
different depending on its model.
Using the Anti-Theft Kensington Lock
1. Insert the locking device into the Ken-
sington slot on the Monitor ( ) and turn
it in the locking direction ( ).
2. Connect the Kensington Lock cable.
3. Fix the Kensington Lock to a desk or a
heavy stationary object.
Introduction

HDMI IN 2 /
HDMI IN 2
Connect the [HDMI IN 2] terminal at the back
of your product to the HDMI terminal of your
digital output device using a HDMI cable.
Connect your headphones to the Head-
phone connection terminal.
Cable holding ring
Fix the cables using the holding ring, as
shown in the figure.
Note
See Connecting Cables for further information regarding cable connections.
Remote Control
Introduction

POWER
TV
Number Buttons
- button
+ VOL -
TOOLS
Down-Up Left-Right buttons
INFO
COLOR BUTTONS
CC
MTS
MENU
SOURCE
PRE-CH
CH
MUTE
RETURN
ENTER
EXIT
SRS
FAV.CH
P.SIZE
1. POWER Turns the product On/Off.
2. TV Selects the TV mode directly.
3. Number Buttons Press to change the channel.
4. - button The "-" button operates only for TV. It is used to select MMS
(multi-channel) for a TV.
5. + VOL - Adjusts the audio volume.
6. TOOLS Use to quickly select frequently used functions.
7. Down-Up Left-
Right buttons
Moves from one menu item to another horizontally, vertically
or adjusts selected menu values.
8. INFO Current picture information is displayed on the upper left
corner of the screen.
9. COLOR BUTTONS Press to add or delete channels and to store channels to the
favorite channel list in the “Channel List” menu.
10. CC Controls the caption decoder.
Introduction

11. MTS You can select the MTS (Multichannel Television Stereo)
mode.
Mono, Stereo, SAP (Separate Audio Program)
Set 'MTS' to ON to choose Mono, Stereo or SAP.
12. MENU Opens the on-screen menu and exits from the menu or
closes the adjustment menu.
13. SOURCE Press the button to change the input signal SOURCE.
Changing the SOURCE is only allowed for external devices
that are connected to the monitor at the time.
14. PRE-CH This button is used to return to the immediately previous
channel.
15. CH In TV mode, selects TV channels.
16. MUTE Pauses (mutes) the audio output temporarily. This is dis-
played on the lower left corner of the screen. The audio
resumes if MUTE or - VOL + is pressed in the Mute mode.
17. RETURN Returns to the previous menu.
18. ENTER Activates a highlighted menu item.
19. EXIT Exits from the menu screen.
20. SRS Not Available.
21. FAV.CH Press to switch to your favorite channels.
22. P.SIZE Press to change the screen size.
Introduction

Connections
Connecting Cables
Connecting to a Computer
Connect the power cord for your monitor to the POWER port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
Use a connection appropriate for your computer.
Using the D-sub (Analog) connector on the video card.
•Connect the signal cable to the [PC IN] port on the back of your monitor.
[PC IN]
Using the DVI (Digital) connector on the video card.
•Connect the DVI Cable to the [DVI-D IN] Port on the back of your Monitor.
[DVI-D IN]
Connect the [HDMI / PC / DVI-D AUDIO IN] port on the rear side of the monitor to the
sound card of the PC.
Note
•You may enjoy clear and quality sound from the computer sound card using the monitor
speakers. (You don't need to install any separate speakers for your computer.)
• You may get a blank screen depending on the type of video card you are using, if you
connect simultaneously both the D-sub and DVI cables to one computer.
• If you connect properly your monitor using the DVI connector but get a blank or fuzzy
screen, check to see if the monitor status is set to analogue. Press 'SOURCE [ ]' button
to have the monitor double-check the input signal source.

Connecting to a Macintosh
Connect the power cord for your monitor to the POWER port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
Using the D-sub (Analog) connector on the video card.
• Connect the signal cable to the D-SUB port on the back of your monitor.
[PC IN]
Note
Turn on the monitor and Macintosh.
Connecting to Other devices
Note
•This monitor allows the user to connect it to such input devices as a DVD player, a VCR
or camcorder, or a DTV or TV without disconnecting the PC.
• The configuration at the back of the monitor may vary from product to product.
• The DVI to HDMI cable, digital audio optic output cable, and RCA to stereo (for PC) cable
are all sold separately.
Contact a Service Center to purchase any products sold separately.
Connecting TV
Note
You may view television programs on the monitor if it is connected to an antenna or CATV
cable without installing any separate TV reception hardware or software on your computer.
Connections
