Samsung UE46C User manual

Messages should hit the wall.
Not budgets.
Elegant Video Walls for Maximum Impact
at an Aordable Price
Cost should never prevent you from enjoying the maximum impact of a
video wall. That’s the whole idea behind the Samsung UE-C Series LCD
displays. With a narrow bezel-to-bezel measurement of only 11mm, you
can create dynamic video walls that are large, clean and cost-effective. And
that means impactful video wall messaging like never before. Screen quality
is typical Samsung: Edge-lit LEDs with Full HD resolution and ultra-fast
240Hz panel refresh rates for crystal-clear images and razor-sharp type. It’s
a high-impact presentation that’s ideal for retail environments and public
spaces. Or anyplace where you want to make a big statement. At a budget-
conscious cost. Business. Innovated.
Samsung UE-C Series Commercial LED LCD Displays
Follow us: @SamsungBizUSA
|
youtube.com/samsungbizusa
Learn more }1-800-SAMSUNG
|
1-866-SAM4BIZ
|
samsung.com/prodisplay or samsung.com/business
Edge-Lit, Ultra-Slim LED Screen
The edge-lit 46” and 55” displays feature 1920 x 1080
Full HD resolution with 500 nits brightness and 5000:1
contrast ratio for detail-rich images and crisp type. And
the stylish 1.2” thin chassis gives video walls maximum
impact. It also helps simplify installation while meeting
ADA compliance requirements.
Narrow Bezels
The thin bezels of 5.5mm on the UE-C Series add
sophisticated good looks and make more seamless
video walls.
Lower TCO
LED technology consumes an average of 40% less power,
for lower total cost of ownership. LED technology also
contains no mercury, which is easier on the environment.
SMART Signage Platform
This integrated, open platform provides a powerful
streamlined solution that reduces TCO for digital signage
deployments, providing savings in hardware, installation
and operating costs.

Display Model Number UE46C UE55C
Screen Size 46" 55"
Panel Technology 240Hz (Edge-LED Backlight) 240Hz (Edge-LED Backlight)
Resolution 1920 x 1080 1920 x 1080
Brightness (cd/m2)500 nit 500 nit
Contrast Ratio (Typical) 5000:1 5000:1
Viewing Angle 178°/178° 178°/178°
Orientation Landscape/Portrait Landscape/Portrait
Response Time 4ms 4ms
Connectivity Input VGA (D-sub 15 pin), DVI-D, 2 HDMI, DisplayPort 1.2, Component (CVBS common), USB, Stereo Mini Jack VGA (D-sub 15 pin), DVI-D, 2 HDMI, DisplayPort 1.2, Component (CVBS common), USB, Stereo Mini Jack
Output DP1.2 (loop-out), Stereo Mini Jack DP1.2 (loop-out), Stereo Mini Jack
External Control RS232C (in/out) thru stereo jack, RJ45 RS232C (in/out) thru stereo jack, RJ45
External Sensor N/A N/A
Power Power Supply AC 100 - 240 V~ (+/- 10 %), 50/60 Hz AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Typical/Max) 89W / 132W 103W / 154W
Power Consumption (Standby) <0.5W <0.5W
Environmental
Conditions
Operating Temperature 0º~ 40º 0º~ 40º
Operating Humidity 10~80% 10~80%
Features Special ACM Support (Advanced Color Management), Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, Super Clear Coating, Temperature Sensor, RS232C/RJ45 MDC, Plug and Play (DDC2B),
Pivot Display, Clock Battery, PIP/PBP, Video Wall (10x10), Image Rotation, Button Lock, DP 1.2 Digital Daisy
Chain (Supporting 2x2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F/W update, Built-In
MagicInfo (Lite, Premium-S, VideoWall-S)
ACM Support (Advanced Color Management), Magic Clone (to USB), Auto Source Switching & Recovery,
Lamp Error Detection, Super Clear Coating, Temperature Sensor, RS232C/RJ45 MDC, Plug and Play (DDC2B),
Pivot Display, Clock Battery, PIP/PBP, Video Wall (10x10), Image Rotation, Button Lock, DP 1.2 Digital Daisy
Chain (Supporting 2x2 UHD Resolution, HDCP Support), Smart Scheduling, Smart F/W update, Built-In
MagicInfo (Lite, Premium-S, VideoWall-S)
SMART Signage Platform Compliant Yes (no video wall support) Yes (no video wall support)
Tuner N/A N/A
Internal Media Player Cortex-A9 1Ghz Dual Core, 1GB DDR3, 8GB FDM, USB (2) Cortex-A9 1Ghz Dual Core, 1GB DDR3, 8GB FDM, USB (2)
VESA Standard Wall Mount Interface 400 x 400mm 400 x 400mm
Dimensions Product Dimensions (without stand) 40.6" x 23.0" x 1.18" 48.1" x 27.3" x 1.18"
Packaging Dimensions 46.1" x 27.8" x 7.8" 53.7" x 33.4" x 7.8"
Bezel Width 5.5mm 5.5mm
Weight Product Weight 25.6 lbs. 34 lbs.
Shipping Weight 34.1 lbs. 45.4 lbs.
Service Standard Warranty 3 Years On-Site (Parts/Labor) 3 Years On-Site (Parts/Labor)
Accessories Included Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power Cord, Remote Controller, Batteries Quick Setup Guide, Warranty Card, Application CD, D-Sub cable, Power Cord, Remote Controller, Batteries
Optional Stand STN-L4055AD STN-L4055AD
Optional Mount WMN-4270SD, WMN-250MD, WMN-4675MD (video wall mount) WMN-4270SD, WMN-250MD, WMN-4675MD (video wall mount)
Optional Media Player SBB-C, SBB-CD7, SBB-CQ7 SBB-C, SBB-CD7, SBB-CQ7
Green
Management
Emission Standard EMC EMC
ENERGY STAR®5.0 Compliant Yes Yes
RoHS Compliant Yes Yes
Packaging Recyclability Packing Materials Recyclable Packing Materials Recyclable
CONNECTIVITY
1. RS232C In
2. RS232C Out
3. IR/Ambient Sensor In
4. Audio Out
5. Audio In
6. USB
7. HDMI In 2
8. DisplayPort In
9. HDMI In 1
10. DVI In
11. DisplayPort Out
12. RGB in
13. AV In
14. IR Out
15. RJ45 In
Samsung UE-C Series
Commercial LED
LCD Displays
KEY SpECIfICaTIONS For complete product specifications, visit samsung.com/prodisplay
Follow us: @SamsungBizUSA
|
youtube.com/samsungbizusa
Samsung Electronics has been named 2012 ENERGY STAR Partner of the Year in the product manufacturing category by the U.S. Environmental Protection Agency (EPA).
Product Support: 1-800-SAMSUNG
1-866-SAM4BIZ
©2013 Samsung Electronics America, Inc. Samsung is a registered mark of Samsung Electronics Corp., Ltd. Specifications and designs are
subject to change without notice. Non-metric weights and measurements are approximate. All other brand, product, service names and logos
are trademarks and/or registered trademarks of their respective manufacturers and companies. Simulated screen images. See samsung.com
for detailed information. Printed in USA. LFD-UECSERIESB2BDSHT-JUN13T
For complete product information and accessories, visit samsung.com/prodisplay or samsung.com/business
1 42 5 6 7 8 9 103
11 12 13 14 15
