PlasmaTV
ChassisF5AA
ModelCodePS51E450A1WXRU
SERVICEMANUAL
PlasmaTV
PS51E450A1W
Contents
1.Precaution
2.ProductSpecication
3.DisassemblyandReassembly
4.Troubleshooting
5.WiringDiagram
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

Contents
Contents
1.Precaution........................................................................................................................................1−1
1.1.SafetyPrecautions...................................................................................................................1−1
1.2.ServicingPrecautions...............................................................................................................1−3
1.3.StaticElectricityPrecautions......................................................................................................1−4
1.4.InstallationPrecautions.............................................................................................................1−5
2.ProductSpecication.........................................................................................................................2−1
2.1.ModelComparison...................................................................................................................2−1
2.2.Feature&Specications...........................................................................................................2−3
2.3.SpecicationsAnalysis.............................................................................................................2−6
2.4.Accessories............................................................................................................................2−10
2.4.1.SuppliedAccessories...................................................................................................2−10
2.4.2.SoldSeparately...........................................................................................................2−11
2.5.3DTV...................................................................................................................................2−12
2.5.1.Whatis3DTV............................................................................................................2−12
2.5.2.Howtooperate...........................................................................................................2−12
2.5.3.3DFormat..................................................................................................................2−13
2.6.Content..................................................................................................................................2−15
2.7.AllShare...............................................................................................................................2−16
3.DisassemblyandReassembly..............................................................................................................3−1
3.1.OverallDisassemblyandReassembly..........................................................................................3−1
4.Troubleshooting................................................................................................................................4−1
4.1.Troubleshooting......................................................................................................................4−1
4.1.1.FirstChecklistforTroubleshooting.................................................................................4−1
4.1.2.CheckpointsbyErrorMode...........................................................................................4−2
4.1.3.AnalogPartTroubleshooting.........................................................................................4−7
4.1.4.DigitalPartTroubleshooting..........................................................................................4−10
4.1.5.FaultsandCorrectiveActions........................................................................................4−12
4.1.6.OperatingLogicLED...................................................................................................4−14
4.1.7.AdjustSMPSV oltagewhenchangeSMPS.......................................................................4−15
4.2.FactoryModeAdjustments........................................................................................................4−16
4.2.1.EnteringFactoryMode.................................................................................................4−16
4.2.2.FactoryData...............................................................................................................4−18
4.3.ServiceAdjustment..................................................................................................................4−41
4.4.SoftwareUpgrade....................................................................................................................4−44
4.5.RS-232C................................................................................................................................4−46
4.6.A VControlCode.....................................................................................................................4−47
4.7.RearCoverDimension..............................................................................................................4−52
5.WiringDiagram................................................................................................................................5−1
iCopyright©1995-2012SAMSUNG.Allrightsreserved.

Contents
5.1.OverallWiring........................................................................................................................5−1
5.1.1.PinConnection...........................................................................................................5−3
Copyright©1995-2012SAMSUNG.Allrightsreserved.ii

1.Precaution
1.Precaution
Toavoidpossibledamage,electricshocksorexposuretoradiation,followtheinstructionsbelowwithregardtosafety,
installation,serviceandESD.
1.1.SafetyPrecautions
1)Makesureallprotectivedevicesareproperlyinstalledincludingnon-metallichandlesandcompartmentcoverswhen
installingorre-installingthechassisorchassisassemblies.
2)Makesurethatnogapsexistbetweenthecabinetsforchildrentoinserttheirngersintopreventchildrenfrom
receivingelectricshocks.GapsmentionedaboveincludeventilationholesofatoogreatmagnitudebetweenthePDP
moduleandthecabinetmask,andtheimproperinstallationoftherearcabinet.
Errorsmayoccurwhentheresistanceisbelow1.0MΩorover5.2MΩ.Inthesecases,makesurethatthedeviceis
repairedbeforesendingitbacktothecustomer.
3)CheckforElectricityLeakage(ACLeakageTest)
WARNING
Donotuseaninsulatedtransformerforcheckingtheleakage.Useonlythosecurrentleakagetestersormirroring
systemsthatcomplywithANSIC101.1andtheUnderwriterLaboratory’sspecications(UL1410,59.7).
DEVICE
UNDER
TEST
LEAKAGE
CURREN T
TESTER
TES T ALL
EXPOSED ME TAL
SUR FACES
2-WIRE CORD
ALSO TES T WITH
PLUG REVERSED
(US ING AC
ADAPTER PLUG
AS REQU IRED)
EARTH
GROUND
( R E A D I N G
SHOULD NOT BE
ABOVE 0.5mA)
Figure1.1ACLeakageTest
4)Ahighvoltageismaintainedwithinthespeciedlimitsusingsafetyparts,calibrationandtolerances.Whenvoltage
exceedsthespeciedlimits,checkeachspecialpart.
5)WarningforEngineeringChanges:
Nevermakeanychangesoradditionstothecircuitdesignortheinternalpartforthisproduct.
Ex:Donotaddanyaudioorvideoaccessoryconnectors.Thismightcausephysicaldamage.
Furthermore,anychangesoradditionstotheoriginaldesign/engineeringwillinvalidatethewarranty.
6)Warning-HotChassis:
SomeTVchassisaredirectlyconnectedtooneendoftheACpowercordforelectricalreasons.Withoutinsulated
transformers,theproductcanonlyberepairedsafelywhenthechassisisconnectedtotheearthedendoftheAC
powersource.
TomakesuretheACpowercordisproperlyconnected,followtheinstructionsbelow.Usethevoltmetertomeasurethe
voltagebetweenthechassisandtheearthedground.Ifthemeasurementisover1.0V ,unplugtheACpowercordand
changethepolaritybeforereinsertingit.Measurethevoltagebetweenthechassisandthegroundagain.
1-1Copyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precaution
7)SomeTVchassisareshippedwithanadditionalsecondarygroundingsystem.Thesecondarysystemisadjacentto
theACpowerline.Thesetwogroundingsystemsareseparatedinthecircuitusinganunbreakable/unchangeable
insulationmaterial.
8)Whenanyparts,materialorwiringappearoverheatedordamaged,replacethemwithnewregularonesimmediately.
Whenanydamageoroverheatingisdetected,correctthisimmediatelyandmakearegularcheckofpossibleerrors.
9)Checkfortheoriginalshapeofthelead,especiallythatoftheantennawiring,anysharpedges,theACpowerandthe
highvoltagepower.Carefullycheckifthewiringistootight,incorrectlyplacedorloose.Neverchangethespace
betweenthepartandtheprintedcircuitboard.ChecktheACpowercordforpossibledamages.Keepthepartorthe
leadawayfromanyheat-emittingmaterials.
10)SafetyIndication:
Someelectricalcircuitsordevicerelatedmaterialsrequirespecialattentiontotheirsafetyfeatures,whichcannotbe
viewedbythenakedeye.Ifanoriginalpartisreplacedwithanotherirregularone,thesafetyorprotectivefeatureswill
belostevenifthenewonehasahighervoltageormorewatts.
Criticalsafetypartsshouldbebracketedwith(,).Useonlyregularpartsforreplacements(inparticular,ame
resistanceanddielectricstrengthspecications).Irregularpartsormaterialsmaycauseelectricshockorre.
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-2

1.Precaution
1.2.ServicingPrecautions
WARNING
1)Firstcarefullyreadthe“SafetyInstruction”inthisservicemanual.
Whenthereisaconictbetweentheserviceandthesafetyinstructions,followthesafetyinstructionatalltimes.
2)Anyelectrolyticcapacitorwiththewrongpolaritywillexplode.
1)Theserviceinstructionsareprintedonthecabinet,andshouldbefollowedbyanyservicepersonnel.
2)MakesuretounplugtheACpowercordfromthepowersourcebeforestartinganyrepairs.
a)Removeorre-installpartsorassemblies.
b)Disconnecttheelectricplugorconnector,ifany.
c)Connectthetestpartinparallelwiththeelectrolyticcapacitor.
3)Somepartsareplacedatahigherpositionthantheprintedboard.Insulatedtubesortapesareusedforthispurpose.
Theinternalwiringisclampedusingbucklestoavoidcontactwithheatemittingparts.Thesepartsareinstalledback
totheiroriginalposition.
4)Aftertherepair,makesuretocheckifthescrews,partsorcablesareproperlyinstalled.Makesurenodamageiscaused
totherepairedpartanditssurroundings.
5)CheckforinsulationbetweenthebladeoftheACplugandthatofanyconductivematerials(i.e.themetalpanel,
inputterminal,earphonejack,etc).
6)InsulationCheckProcess:
UnplugthepowercordfromtheACsourceandturntheswitchon.Connecttheinsulatingresistancemeter(500V)to
theACplugblade.TheinsulatingresistancebetweenthebladeoftheACplugandthatoftheconductivematerial
shouldbemorethan1MΩ.
7)AnyB+interlockshouldnotbedamaged.
Ifthemetalheatsinkisnotproperlyinstalled,noconnectiontotheACpowershouldbemade.
8)Makesurethegroundingleadofthetesterisconnectedtothechassisgroundbeforeconnectingtothepositivelead.
Thegroundleadofthetestershouldberemovedlast.
9)Bewareofrisksofanycurrentleakagecomingintocontactwiththehigh-capacitycapacitor.
10)Thesharpedgesofthemetalmaterialmaycausephysicaldamage,soprotectyourselfbywearingglovesduringthe
repair.
11)Duetothenatureofplasmadisplaypanels,partialafter-imagesmayappearifastillpictureisdisplayedonthescreen
foralongperiodoftime.
Thisiscausedbybrightnessdeteriorationduetothestorageeffectofthepanel,andtopreventthisfromhappening,we
recommendthatthebrightnessandcontrastarereduced.(e.g.)Contrast:25,Brightness:50
1-3Copyright©1995-2012SAMSUNG.Allrightsreserved.

1.Precaution
1.3.StaticElectricityPrecautions
1)Somesemi-conductive(“solidstate”)devicesarevulnerabletostaticelectricity.ThesedevicesareknownasESD.
ESDincludestheintegratedcircuitandtheeldeffecttransistor.Toavoidanymaterialsdamagefromelectrostatic
shock,followtheinstructionsdescribedbelow.
2)Removeanystaticelectricityfromyourbodybyconnectingtheearthgroundbeforehandlinganysemi-conductiveparts
orassemblies.Alternatively,wearadischargeablewrist-belt.
(Makesuretoremoveanystaticelectricitybeforeconnectingthepowersource-thisisasafetyinstructionfor
avoidingelectricshock)
3)RemovetheESDassemblyandplaceitonaconductivesurfacesuchasaluminumfoiltopreventaccumulatingstatic
electricity.
4)DonotuseanyFreon-basedchemicals.SuchchemicalswillgeneratestaticelectricitythatcausesdamagetotheESD.
5)Useonlygrounded-tipironsforsolderingpurposes.
6)Useonlyanti-staticsolderremovaldevices.
Mostsolderremovaldevicesdonotsupportananti-staticfeature.Asolderremovaldevicewithoutananti-staticfeature
canstoreenoughstaticelectricitytocausedamagetotheESD.
7)DonotremovetheESDfromtheprotectiveboxuntilthereplacementisready.MostESDreplacementsarecoveredwith
lead,whichwillcauseashorttotheentireunitduetotheconductivefoam,aluminumfoilorotherconductivematerials.
8)RemovetheprotectivematerialfromtheESDreplacementleadimmediatelyafterconnectingittothechassisor
circuitassembly.
9)TakeextremecautioninhandlinganyuncoveredESDreplacements.Actionssuchasbrushingclothesorliftingyourleg
fromthecarpetoorcangenerateenoughstaticelectricitytodamagetheESD.
CAUTION
Theseservicinginstructionsareforusebyqualiedservicepersonnelonly.
Toreducetheriskofelectricshockdonotperformanyservicingotherthanthatcontainedintheoperatinginstructions
unlessyouarequaliedtodoso.
Copyright©1995-2012SAMSUNG.Allrightsreserved.1-4

1.Precaution
1.4.InstallationPrecautions
1)Forsafetyreasonsaminimumoftwopeoplearerequiredtocarrythisproduct.
2)Keepthepowercordawayfromanyheatemittingdevices,asameltedcoveringmaycausereorelectricshock.
3)Donotplacetheproductinareaswithpoorventilationsuchasabookshelforcloset.Theincreasedinternaltemperature
maycausere.
4)Bendtheexternalantennacablewhenconnectingittotheproduct.Thisisameasuretoprotectitfrombeingexposedto
moisture.Otherwise,itmaycauseareorelectricshock.
5)Makesuretoturnthepoweroffandunplugthepowercordfromtheoutletbeforerepositioningtheproduct.Also
checktheantennacableortheexternalconnectorsiftheyarefullyunplugged.Damagetothecordmaycausere
orelectricshock.
6)Keeptheantennafarawayfromanyhigh-voltagecablesandinstallitrmly.Contactwiththehigh-voltagecableorthe
antennafallingovermaycausereorelectricshock.
7)WhenconnectingtheRFantenna,checkforaDTVreceivingsystemandinstallaseparateDTVreceptionantennafor
areaswithnoDTVsignal.
8)Wheninstallingtheproduct,leaveenoughspace(4”)betweentheproductandthewallforventilationpurposes.A
riseintemperaturewithintheproductmaycausere.
9)WhenmovingaPDPwithremovablespeakers,detachthespeakersrstbeforemovingthemainbody.MovingthePDP
mainbodywithoutseparatingthespeakersmaycausethespeakerstodetach,possiblycausingdamageorinjury.
1-5Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
2.ProductSpecication
2.1.ModelComparison
InchPE450
FrontView
FrontColorSteamMold
WithoutStand1011.8x622.4x56.0mm
43"
WithStand1011.8x675.9x262.0mm
WithoutStand1187.8x706.6x56.0mm
Dimensions
WxDxH
(inch)51"
WithStand1187.8x760.1x262.0mm
WithoutStand16.0kg
43"
WithStand19.0kg
WithoutStand22.5kg
Weight
(lbs)
51"
WithStand25.5kg
FeatureZeroBlackPanel/ConnectShare
InchPE490
FrontView
FrontColorSteamMold
WithoutStand1011.8x622.4x56.0mm
43"
WithStand1011.8x698.7x305.0mm
WithoutStand1187.8x706.6x56.0mm
Dimensions
WxDxH
(inch)51"
WithStand1187.8x782.9x305.0mm
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-1

2.ProductSpecication
WithoutStand16.0kg
43"
WithStand20.3kg
WithoutStand22.5kg
Weight
(lbs)
51"
WithStand26.8kg
FeatureZeroBlackPanel/ConnectShare
2-2Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
2.2.Feature&Specications
■Features
•Digital-TV ,RF,2-HDMI,1-Component(A V),1-USB2.0,Optical
•Brightness:1500cd/m2
•ContrastRatio:1000000:1
•3D(PE490),AllShare,Content
ModelP*43E450
P*51E450
P*43E490
P*51E490
PDPPanelClearImagePanel
ScanningFrequencyHorizontal:60kHz~73kHz(Automatic)
Vertical:47Hz~63Hz(Automatic)
DisplayColors16.7Mcolor
MaximumresolutionHorizontal:1920Pixels
Vertical:1080Pixels
InputSignalAnalog0.7Vp-p±5%positiveat75Ω,internallyterminated
InputSyncSignalH/VSeparate,TTL,P .orN.
MaximumPixelClockrate74.25MHz
ACPowerVoltage&FrequencyAC110V~120V ,60Hz
PowerConsumption205W(43")
210W(51")
220W(43")
230W(51")
TVSystem
Tuning:FrequencySynthesize(RefertodetailedFrequencyTable)
System:A TSC&ClearQAM
Sound:NTSC-M,DolbyDigital+
EnvironmentalConsiderations
OperatingTemperature:32˚F~122˚F(0˚C~50˚C)
OperatingHumidity:20%~90%
StorageTemperature:-4˚F~140˚F(-20˚C~60˚C)
StorageHumidity:10%~90%
AudioSpec.
MAXInternalAudioOutputPower:Each3W(Left/Right)
Equalizer:5band
OutputFrequency:RF:20Hz~15.4kHz
A V/Componet/HDMI:20Hz~20kHz
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-3

2.ProductSpecication
■43”Specication
ModelP*43D450P*43E450
WithStand39.8x27.5x12inches39.8x26.6x12inches
Dimensions
(WxHxD)WithoutStand39.8x24.5x2.2inches39.8x24.5x2.2inches
WithStand41.8lbs41.8lbs
Weight
WithoutStand35.2lbs35.2lbs
ScreenSize43Inches(16:9)43Inches(16:9)
PanelResolution1024x7681024x768
PCResolution1920(H)x1080(V)
PowerConsumption43HD:200W±10%andLess43HD:200W±10%andLess
AntennaInputANT-AIR/CABLEIN75Ωunbalanced
VideoInput
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
PC
HDMI1:480p/720p/1080i/1080p
HDMI2(DVICompatible):
480p/720p/1080i/1080p
HDMI3(SIDEA V):
480p/720p/1080i/1080p
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
HDMI1:480p/720p/1080i/1080p
HDMI2:480p/720p/1080i/1080p
AudioInput
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
COMPONENT2:
480i/480p/720p/1080i/1080p
PC
DVI
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
DVI
AudioOutputAUDIO(L/R)
SpeakerOutput10W+10W(40dB+40dB)
NewFeaturesAllShare,ContentsZeroBlackPanel/ConnectShare
2-4Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
■51”Specication
ModelP*51D490P*51E490
WithStand46.7x30.8x12inches46.7x30.8x12inches
Dimensions
(WxHxD)WithoutStand46.7x27.8x2.2inches46.7x27.8x2.2inches
WithStand56.2lbs56.2lbs
Weight
WithoutStand49.6lbs49.6lbs
ScreenSize51Inches(16:9)51Inches(16:9)
PanelResolution1365x7681024x768
PCResolution1920(H)x1080(V)
PowerConsumption51HD:280W±10%andLess51HD:280W±10%andLess
AntennaInputANT-AIR/CABLEIN75Ωunbalanced
VideoInput
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
PC
HDMI1:480p/720p/1080i/1080p
HDMI2(DVICompatible):
480p/720p/1080i/1080p
HDMI3(SIDEA V):
480p/720p/1080i/1080p
480icanbedisplayedonHDMI,
howeveritisnotcontainedinEDIDdata
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
HDMI1:480p/720p/1080i/1080p
HDMI2(SIDEA V):
480p/720p/1080i/1080p
480icanbedisplayedonHDMI,
howeveritisnotcontainedinEDIDdata
AudioInput
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
PC
HDMI1:480p/720p/1080i/1080p
HDMI2(DVICompatible):
480p/720p/1080i/1080p
HDMI3(SIDEA V):
480p/720p/1080i/1080p
480icanbedisplayedonHDMI,
howeveritisnotcontainedinEDIDdata
A V
COMPONENT1:
480i/480p/720p/1080i/1080p
HDMI1:480p/720p/1080i/1080p
HDMI2(SIDEA V):
480p/720p/1080i/1080p
480icanbedisplayedonHDMI,
howeveritisnotcontainedinEDIDdata
AudioOutputAUDIO(L/R)
SpeakerOutput10W+10W(40dB+40dB)
NewFeaturesAllShare,ContentsZeroBlackPanel/ConnectShare
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-5

2.ProductSpecication
2.3.SpecicationsAnalysis
ModelP*43D450P*43E450
Design
DisplayTypePDPTVPDPTV
Buil-InTunerOO
Resolution1024x7681024x768
PDPModuleDHEH
ScreenSize43inches43inches
Basic
PictureRatio16:916:9
Brightness1,500Cd/m21,500Cd/m2
ContrastRatio10000:110000:1 Picture
PictureEnhancerDNIe(SEMS20)DNIe(SEMS23)
Equalizer5Band5Band
AutoVolumeControlOO
SurroundSoundSRSTheaterSoundSRSTheaterSound
Audio
SpeakerOutput10W+10W10W+10W
PIPOX
DoubleScreenXX
CaptionOO
StillImageXX
EPGOO
MyColorControlXX
EnergySavingOO
ScreenBurnProtectionOO
Features
AnynetXX
Antenna1(Cable/Air)1(Cable/Air)
A VInput1Input1Input
S-VideoXX
Component2Input1Input
PC(D-SUB)1InputX
DVI1Input1Input
HDMID490–3Input
D450–2Input
E490–2Input
E450–2Input
USB11
Connections
2-6Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
SubWooferXX
Optical11
ETCSpeaker/StandBuilt-inSpeakerBuilt-inSpeaker
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-7

2.ProductSpecication
ModelP*51D490P*51E490
Design
DisplayTypePDPTVPDPTV
Buil-InTunerOO
Resolution1365x7681024x768
PDPModuleDHEH
ScreenSize51inches51inches
Basic
PictureRatio16:916:9
Brightness1,500Cd/m21,500Cd/m2
ContrastRatio10000:110000:1 Picture
PictureEnhancerDNIe(SEMS20)DNIe(SEMS23)
Equalizer5Band5Band
AutoVolumeControlOO
SurroundSoundSRSTheaterSoundSRSTheaterSound
Audio
SpeakerOutput10W+10W10W+10W
PIPO1TunerPIP
DoubleScreenXX
CaptionOO
StillImageXX
EPGOO
MyColorControlXX
EnergySavingOO
ScreenBurnProtectionOO
Features
AnynetXX
Antenna1(Cable/Air)1(Cable/Air)
A VInput1Input1Input
S-VideoXX
Component2Input1Input
PC(D-SUB)1InputX
DVI1Input1Input
HDMID490–3Input
D450–2Input
E490–2Input
E450–2Input
USB11
SubWooferXX
Connections
Optical11
2-8Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
ETCSpeaker/StandBuilt-inSpeakerBuilt-inSpeaker
TIP
O:Supported,X:NotSupported
NOTE
Forthepowersupplyandpowerconsumption,refertothelabelattachedtotheproduct.
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-9

2.ProductSpecication
2.4.Accessories
2.4.1.SuppliedAccessories
AccessoriesItemItemcodeRemark
FerriteCore3301-002049
3301-002053
PowerCord3903-000551
Batteries(AAAx2)4301-000103
RemoteControlAA59-00602A
CleaningClothBN63-01798B
Owner`sInstructionsBN68-03998M
GuideStandBN61-08051A
StandP-BASEBN96-22005A
StandP-BASE-
4EA(M4XL12 )
Stand+GuideStandScrew
Stand+SetScrew6003-001782
SamsungServiceCenter
2-10Copyright©1995-2012SAMSUNG.Allrightsreserved.

2.ProductSpecication
2.4.2.SoldSeparately
AccessoriesItemItemcodeRemark
RS232Cable-
HDMI-
HDMI-DVI-
Audio-
Component-
Composite(A V)-
Coaxial(RF)-
SamsungServiceCenter
Copyright©1995-2012SAMSUNG.Allrightsreserved.2-11

2.ProductSpecication
2.5.3DTV
2.5.1.Whatis3DTV
•Asystemthatdisplay3Dimagesarticially
•How?Usingbinoculartimedisplay
1)Lefteyerecognizesleftimage,righteyerecognizes
rightimage.
2)Humaneyesbefarawayeachother65mm
horizontally.Soeacheyefeelsalittlebit
oftimedelayofleftandrightinformation.
Humanbrainmergesthoseimagesandcanfeel
three-dimensional.
LEFT Image RIGHT Image
Sidebyside
2.5.2.Howtooperate
•3DTVshowsleftandrightimagebyturns.
•Atthesametime,TVgivessynchronizingsignalto3D
glassesthroughBluetooth
•3Dglassesshuttereachlensbyturnsaccordingtothis
signal.
3
3
5
5
1
1
I
I
{
{
M
M
S
S
M
M
S
S
M
M
S
S
Blu e to o th
240Hz
M
M
S
S
2-12Copyright©1995-2012SAMSUNG.Allrightsreserved.
