Samsung SL-M4080FX User manual

MonoLaserMFP
ProXpressM4080series
SL-M4080FX
(Ver1.00)
SERVICEMANUAL
MonoLaserMFPContents
1.Precautions
2.ProductSpecicationsandDescription
3.DisassemblyandReassembly
4.Troubleshooting
5.SystemDiagram
6.ReferenceInformation
RefertotheservicemanualintheGSPN(seetherearcover)formoreinformation.

Contents
Contents
1.Precautions........................................................................................................................................1−1
1.1.Safetywarning..........................................................................................................................1−1
1.2.Cautionforsafety......................................................................................................................1−2
1.2.1.Toxicmaterial...............................................................................................................1−2
1.2.2.Electricshockandresafetyprecautions...........................................................................1−2
1.2.3.Handlingprecautions.....................................................................................................1−4
1.2.4.AssemblyandDisassemblyprecautions.............................................................................1−4
1.2.5.Disregardingthiswarningmaycausebodilyinjury..............................................................1−5
1.3.ESDprecautions........................................................................................................................1−6
2.ProductSpecicationsandDescription....................................................................................................2−1
2.1.ProductOverview......................................................................................................................2−1
2.2.Specications............................................................................................................................2−2
2.2.1.General.......................................................................................................................2−2
2.2.2.Printspecication..........................................................................................................2−4
2.2.3.Scanspecication..........................................................................................................2−5
2.2.4.Copyspecication.........................................................................................................2−6
2.2.5.Faxspecication...........................................................................................................2−7
2.2.6.PaperHandlingspecication............................................................................................2−8
2.2.7.SoftwareandSolution..................................................................................................2−10
2.2.8.Supplies.....................................................................................................................2−11
2.2.9.MaintenancePart.........................................................................................................2−11
2.2.10.Option.......................................................................................................................2−12
2.3.SystemConguration...............................................................................................................2−13
2.4.FeedingSystem.......................................................................................................................2−17
2.4.1.FeedingSystemOverview.............................................................................................2−17
2.4.2.Cassette.....................................................................................................................2−20
2.4.3.Pick-UpUnit..............................................................................................................2−21
2.4.4.MPF(Multi-PurposeFeeder)Unit...................................................................................2−21
2.5.ImageCreation........................................................................................................................2−22
2.5.1.Printingprocessoverview.............................................................................................2−22
2.5.2.TonerCartridge...........................................................................................................2−23
2.6.Fuserunit...............................................................................................................................2−24
2.7.LaserScanningUnit(LSU)........................................................................................................2−25
2.7.1.LaserScanningUnitOverview.......................................................................................2−25
2.7.2.LaserScanningOpticalpath..........................................................................................2−26
2.8.DriveSystem..........................................................................................................................2−27
2.8.1.DriveMotors..............................................................................................................2−27
2.8.2.MainDriveUnit..........................................................................................................2−28
iCopyright©1995-2013SAMSUNG.Allrightsreserved.

Contents
2.8.3.ExitDriveUnit...........................................................................................................2−29
2.8.4.TrayLiftingDriveUnit.................................................................................................2−30
2.9.ScannerSystem.......................................................................................................................2−31
2.9.1.Scannersystemoverview..............................................................................................2−31
2.9.2.ScannerSystemComponents.........................................................................................2−32
2.10.HardwareConguration............................................................................................................2−33
2.10.1.Mainboard.................................................................................................................2−35
2.10.2.OPE..........................................................................................................................2−37
2.10.3.SO-DIMMPBA..........................................................................................................2−39
2.10.4.CRUMPBA...............................................................................................................2−39
2.10.5.LIUPBA(Faxboard)....................................................................................................2−40
2.10.6.SCFboard..................................................................................................................2−41
2.10.7.NFCOptionalBoard(SL-NWE001X).............................................................................2−42
2.10.8.SMPSboard...............................................................................................................2−43
2.10.9.HVPSboard...............................................................................................................2−45
2.10.10.ElectricalPartsLocation...............................................................................................2−47
3.DisassemblyandReassembly................................................................................................................3−1
3.1.Precautionswhenreplacingparts..................................................................................................3−1
3.1.1.Precautionswhenassemblinganddisassembling.................................................................3−1
3.1.2.PrecautionswhenhandlingPBA.......................................................................................3−1
3.1.3.ReleasingPlasticLatches................................................................................................3−2
3.2.Replacingthemaintenancepart....................................................................................................3−3
3.2.1.FuserUnit....................................................................................................................3−3
3.2.2.TransferRoller..............................................................................................................3−5
3.2.3.SeparationRoller...........................................................................................................3−6
3.2.4.Pick-upRollerandForwardRoller....................................................................................3−7
3.2.5.SCFSeparationRoller....................................................................................................3−8
3.2.6.SCFPick-upRollerandForwardRoller.............................................................................3−9
3.3.ReplacingthemainSVCpart.....................................................................................................3−10
3.3.1.RightCover................................................................................................................3−10
3.3.2.LeftCover..................................................................................................................3−11
3.3.3.RearCover.................................................................................................................3−12
3.3.4.MainBoard................................................................................................................3−13
3.3.5.HDD.........................................................................................................................3−14
3.3.6.HVPSBoard...............................................................................................................3−15
3.3.7.SMPSBoard...............................................................................................................3−16
3.3.8.DuplexMotor.............................................................................................................3−17
3.3.9.FuserDriveUnit.........................................................................................................3−18
3.3.10.MainDriveUnit..........................................................................................................3−19
3.3.11.CST-LiftingDriveUnit.................................................................................................3−20
Copyright©1995-2013SAMSUNG.Allrightsreserved.ii

Contents
3.3.12.PaperSizeSensor........................................................................................................3−21
3.3.13.OPEUnit...................................................................................................................3−22
3.3.14.ScannerUnit...............................................................................................................3−23
3.3.15.DSDFUnit.................................................................................................................3−24
3.3.16.FaxBoard..................................................................................................................3−25
3.3.17.MiddleCover.............................................................................................................3−26
3.3.18.LSU..........................................................................................................................3−27
3.3.19.ExitUnit....................................................................................................................3−28
3.3.20.Bin-FullSensor...........................................................................................................3−29
3.3.21.MPUnit....................................................................................................................3−30
3.3.22.MPRoller..................................................................................................................3−32
3.3.23.SecondCassetteFeeder(OptionalTray)...........................................................................3−33
3.3.23.1.PBA-SCF....................................................................................................3−33
3.3.23.2.LiftUnit......................................................................................................3−34
3.3.23.3.Clutch.........................................................................................................3−35
3.3.23.4.DriveUnit...................................................................................................3−36
4.Troubleshooting..................................................................................................................................4−1
4.1.Controlpanel............................................................................................................................4−1
4.1.1.Introducingthedisplayscreenandusefulbuttons................................................................4−2
4.2.UnderstandingtheLEDs.............................................................................................................4−4
4.3.UpdatingFirmware....................................................................................................................4−6
4.3.1.UpdatingfromthePrinterControlPanel............................................................................4−6
4.3.2.UpdatingfromtheNetwork............................................................................................4−7
4.4.ClearingJams.........................................................................................................................4−10
4.4.1.Clearingpaperjams.....................................................................................................4−10
4.4.2.Clearingoriginaldocumentjams....................................................................................4−27
4.5.Usefulmanagementtools..........................................................................................................4−31
4.5.1.SyncThru™WebService..............................................................................................4−31
4.5.2.SamsungEasyPrinterManager......................................................................................4−36
4.6.ServiceMode..........................................................................................................................4−38
4.6.1.Entering/ExitingServiceMode......................................................................................4−38
4.6.2.ServiceModeMenuTree.............................................................................................4−38
4.6.3.Information................................................................................................................4−41
4.6.4.MaintenanceCounts.....................................................................................................4−42
4.6.5.Diagnostics................................................................................................................4−43
4.6.6.ServiceFunctions........................................................................................................4−55
4.7.Troubleshooting......................................................................................................................4−60
4.7.1.Procedureofcheckingthesymptoms...............................................................................4−60
4.7.2.ErrorCodeandTroubleshooting.....................................................................................4−61
4.7.2.1.11–2Txx(PaperMismatcherror)......................................................................4−65
iiiCopyright©1995-2013SAMSUNG.Allrightsreserved.

Contents
4.7.2.2.Ax-xxxx(Motor_Fan_Sensorerror)..................................................................4−66
4.7.2.3.Cx-xxxx(TonerCartridgeerror).......................................................................4−69
4.7.2.4.H1-xxxx(OptionalCassetteerror)....................................................................4−72
4.7.2.5.Mx-xxxx(Jam_Paperhandlingerror)................................................................4−81
4.7.2.6.Sx-xxxx(Systemerror)..................................................................................4−88
4.7.2.7.U1-xxxx(Fusererror)....................................................................................4−94
4.7.2.8.U2-xxxxtype(LSU)errorcode........................................................................4−95
4.7.2.9.U3-xxxx(DSDFerror)...................................................................................4−96
4.7.3.Imagequalityproblem..................................................................................................4−98
4.7.4.Othererrors..............................................................................................................4−112
5.SystemDiagram..................................................................................................................................5−1
5.1.BlockDiagram..........................................................................................................................5−1
5.2.ConnectionDiagram...................................................................................................................5−2
6.ReferenceInformation..........................................................................................................................6−1
6.1.ToolforTroubleshooting.............................................................................................................6−1
6.2.Glossary...................................................................................................................................6−2
6.3.TheSamplePatternfortheTest....................................................................................................6−8
6.4.ModelNameandCode...............................................................................................................6−9
6.5.DocumentRevisionList............................................................................................................6−10
Copyright©1995-2013SAMSUNG.Allrightsreserved.iv

1.Precautions
1.Precautions
Inordertopreventaccidentsanddamagestotheequipmentpleasereadtheprecautionslistedbelowcarefullybefore
servicingtheproductandfollowthemclosely.
1.1.Safetywarning
1)Onlytobeservicedbyafactorytrainedservicetechnician.
Highvoltagesandlasersinsidethisproductaredangerous.Thisproductshouldonlybeservicedbyafactorytrained
servicetechnician.
2)UseonlySamsungreplacementparts.
Therearenouserserviceablepartsinsidetheproduct.Donotmakeanyunauthorizedchangesoradditionstothe
productasthesecouldcausetheproducttomalfunctionsandcreateanelectricshocksorrehazards.
3)LaserSafetyStatement
TheprinteriscertiedintheU.S.toconformtotherequirementsofDHHS21CFR,chapter1SubchapterJfor
ClassI(1)laserproducts,andelsewhereiscertiedasaClassIlaserproductconformingtotherequirementsofIEC
60825-1.ClassIlaserproductsarenotconsideredtobehazardous.Thelasersystemandprinteraredesignedso
thereisneveranyhumanaccesstolaserradiationaboveaClassIlevelduringnormaloperation,usermaintenance
orprescribedservicecondition.
•Wavelength:800nm
•Beamdivergence
-Parallel:11degrees
-Perpendicular:35degrees
•Maximumpowerofenergyoutput:12mW
WARNING
NeveroperateorservicetheproductwiththeprotectivecoverremovedfromLaser/Scannerassembly.Thereected
beam,althoughinvisible,candamageyoureyes.
Whenusingthisproduct,thesebasicsafetyprecautionsshouldalwaysbefollowedtoreduceriskofre,electric
shock,andpersonalinjury.
4)Lithiumbatterynotreplaceablebyuser
1-1Copyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.2.Cautionforsafety
1.2.1.Toxicmaterial
Thisproductcontainstoxicmaterialsthatcouldcauseillnessifingested.
1)Pleasekeepimagingunitandtonercartridgeawayfromchildren.Thetonerpowdercontainedintheimagingunitand
tonercartridgemaybeharmful,andifswallowed,youshouldcontactadoctor.
1.2.2.Electricshockandresafetyprecautions
Failuretofollowthefollowinginstructionscouldcauseelectricshockorpotentiallycauseare.
1)Useonlythecorrectvoltage,failuretodosocoulddamagetheproductandpotentiallycauseareorelectricshock.
2)Useonlythepowercablesuppliedwiththeproduct.Useofanincorrectlyspeciedcablecouldcausethecableto
overheatandpotentiallycauseare.
3)Donotoverloadthepowersocket,thiscouldleadtooverheatingofthecablesinsidethewallandcouldleadtoare.
4)Donotallowwaterorotherliquidstospillintotheproduct,thiscancauseelectricshock.Donotallowpaperclips,pins
orotherforeignobjectstofallintotheproduct,thesecouldcauseashortcircuitleadingtoanelectricshockorrehazard.
5)Nevertouchtheplugsoneitherendofthepowercablewithwethands,thiscancauseelectricshock.Whenservicing
theproduct,removethepowerplugfromthewallsocket.
6)Usecautionwheninsertingorremovingthepowercord.Whenremovingthepowercord,gripitrmlyandpull.The
powercordmustbeinsertedcompletely,otherwiseapoorcontactcouldcauseoverheatingleadingtoare.
7)Takecareofthepowercable.Donotallowittobecometwisted,bentsharplyaroundcornersorpowercablemaybe
damaged.Donotplaceobjectsontopofthepowercable.Ifthepowercableisdamageditcouldoverheatandcausea
re.Exposedcablescouldcauseanelectricshock.Replacethedamagedpowercableimmediately,donotreuseor
repairthedamagedcable.Somechemicalscanattackthecoatingonthepowercable,weakeningthecoverorexposing
cablescausingreandshockrisks.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-2

1.Precautions
8)Ensurethatthepowersocketsandplugsarenotcrackedorbrokeninanyway.Anysuchdefectsshouldberepaired
immediately.Takecarenottocutordamagethepowercableorplugswhenmovingthemachine.
9)Usecautionduringthunderorlightningstorms.Samsungrecommendsthatthismachinebedisconnectedfromthe
powersourcewhensuchweatherconditionsareexpected.Donottouchthemachineorthepowercordifitisstill
connectedtothewallsocketintheseweatherconditions.
10)Avoiddampordustyareas,installtheproductinacleanwellventilatedlocation.Donotpositionthemachineneara
humidierorinfrontofanairconditioner.Moistureanddustbuiltupinsidethemachinecanleadtooverheatingand
causeareorcausepartstorust.
11)Donotpositiontheproductindirectsunlight.Thiswillcausethetemperatureinsidetheproducttorisepossiblyleading
totheproductfailingtoworkproperlyandinextremeconditionscouldleadtoare.
12)Donotinsertanymetalobjectsintothemachinethroughtheventilatorfanorotherpartofthecasing,itcouldmake
contactwithahighvoltageconductorinsidethemachineandcauseanelectricshock.
13)WhenreplacingtheSMPSboard,pleasewait5minutesafterunpluggingthepowercord,thenreplaceit.You
cangetashockbytheelectricdischarge.
1-3Copyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.2.3.Handlingprecautions
Thefollowinginstructionsareforyourownpersonalsafetytoavoidinjuryandsoasnottodamagetheproduct.
1)Ensuretheproductisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcause
theproducttotiporfall.
2)Theproductcontainsmanyrollers,gearsandfans.Takegreatcaretoensurethatyoudonotcatchyourngers,hairor
clothinginanyoftheserotatingdevices.
3)Donotplaceanysmallmetalobjects,containersofwater,chemicalsorotherliquidsclosetotheproductwhichifspilled
couldgetintothemachineandcausedamageorashockorrehazard.
4)Donotinstallthemachineinareaswithhighdustormoisturelevels,besideonopenwindoworclosetoahumidieror
heater.Damagecouldbecausedtotheproductinsuchareas.
5)Donotplacecandles,burningcigarettes,etcontheproduct,Thesecouldcauseare.
6)Ensurethatthemachineisinstalledandusedinproperareatomeetthetemperatureandhumidityspecications.
•IfthemachineisstoredatbelowzeroCelsiusforalongtime,donotusethemachineinstantlyaftermovement.It
canmalfunction.Takecareofthemachinestorage.IfthemachineisstoredatbelowzeroCelsiusforalongtime,
keepthemachineatroomtemperatureandinstallit.
1.2.4.AssemblyandDisassemblyprecautions
1)ReplacepartscarefullyandalwaysuseSamsungparts.Takecaretonotetheexactlocationofpartsandalsocable
routingbeforedismantlinganypartofthemachine.Ensureallpartsandcablesarereplacedcorrectly.Pleasecarryout
thefollowingproceduresbeforedismantlingtheproductorreplacinganyparts.
2)Ensurethatpowerisdisconnectedbeforeservicingorreplacinganyelectricalparts.
3)Disconnectinterfacecablesandpowercables.
4)Onlyuseapprovedspareparts.Ensurethatpartnumber,productname,anyvoltage,currentortemperaturerating
arecorrect.
5)Whenremovingorre-ttinganypartsdonotuseexcessiveforce,especiallywhenttingscrewsintoplastic.
6)Takecarenottodropanysmallpartsintothemachine.
7)HandlingoftheOPCDrum
•TheOPCDrumcanbeirreparablydamagedifitexposedtolight.TakecarenottoexposetheOPCDrumeither
todirectsunlightortouorescentorincandescentroomlighting.Exposureforaslittleas5minutescandamage
thesurfaceofthephotoconductivepropertiesandwillresultinprintqualitydegradation.Takeextracarewhen
servicingtheproduct.RemovetheOPCDrumandstoreitinablackbagorotherlightproofcontainer.Take
carewhenworkingwiththeCovers(especiallythetopcover)openaslightisadmittedtotheOPCareaandcan
damagetheOPCDrum.
•TakecarenottoscratchthegreensurfaceofOPCDrumUnit.IfthegreensurfaceoftheDrumCartridgeis
scratchedortouchedtheprintqualitywillbecompromised.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-4

1.Precautions
1.2.5.Disregardingthiswarningmaycausebodilyinjury
1)Becarefulwiththehightemperaturepart.
Thefuserunitworksatahightemperature.Usecautionwhenworkingontheprinter.Waitforthefuserunitto
cooldownbeforedisassembly.
2)Donotputngersorhairintotherotatingparts.
Whenoperatingaprinter,donotputhandorhairintotherotatingparts(Paperfeedingentrance,motor,fan,etc.).
Ifdo,youcangetharm.
3)Whenyoumovetheprinter,usesafeliftingandhandlingtechniques.
Thisprinterisheavy.Usetheliftinghandleslocatedoneachsideofthemachine.Backinjurycouldbecausedif
youdonotliftcarefully.
4)Ensuretheprinterisinstalledsafely.
Ensuretheprinterisinstalledonalevelsurface,capableofsupportingitsweight.Failuretodosocouldcausethe
printertotiporfallpossiblycausingpersonalinjuryordamagingtheprinter.
5)Donotinstalltheprinteronaslopingorunstablesurface.Afterinstallation,doublecheckthattheprinterisstable.
1-5Copyright©1995-2013SAMSUNG.Allrightsreserved.

1.Precautions
1.3.ESDprecautions
Certainsemiconductordevicescanbeeasilydamagedbystaticelectricity.Suchcomponentsarecommonlycalled
“ElectrostaticallySensitive(ES)Devices”orESDs.ExamplesoftypicalESDsare:integratedcircuits,someeldeffect
transistors,andsemiconductor“chip”components.Thetechniquesoutlinedbelowshouldbefollowedtohelpreducethe
incidenceofcomponentdamagecausedbystaticelectricity.
CAUTION
Besurenopowerisappliedtothechassisorcircuit,andobserveallothersafetyprecautions.
1)Immediatelybeforehandlingasemiconductorcomponentorsemiconductor-equippedassembly,drainoffany
electrostaticchargeonyourbodybytouchingaknownearthground.Alternatively,employacommerciallyavailable
wriststrapdevice,whichshouldberemovedforyourpersonalsafetyreasonspriortoapplyingpowertotheunit
undertest.
2)AfterremovinganelectricalassemblyequippedwithESDs,placetheassemblyonaconductivesurface,suchas
aluminumorcopperfoil,orconductivefoam,topreventelectrostaticchargebuildupinthevicinityoftheassembly.
3)UseonlyagroundedtipsolderingirontosolderordesolderESDs.
4)Useonlyan“anti-static”solderremovaldevice.Somesolderremovaldevicesnotclassiedas“anti-static”can
generateelectricalchargessufcienttodamageESDs.
5)DonotuseFreon-propelledchemicals.Whensprayed,thesecangenerateelectricalchargessufcienttodamageESDs.
6)DonotremoveareplacementESDfromitsprotectivepackaginguntilimmediatelybeforeinstallingit.Most
replacementESDsarepackagedwithallleadsshortedtogetherbyconductivefoam,aluminumfoil,oracomparable
conductivematerial.
7)ImmediatelybeforeremovingtheprotectiveshortingmaterialfromtheleadsofareplacementESD,touchtheprotective
materialtothechassisorcircuitassemblyintowhichthedevicewillbeinstalled.
8)MaintaincontinuouselectricalcontactbetweentheESDandtheassemblyintowhichitwillbeinstalled,until
completelypluggedorsolderedintothecircuit.
9)MinimizebodilymotionswhenhandlingunpackagedreplacementESDs.Normalmotions,suchasthebrushingtogether
ofclothingfabricandliftingone’sfootfromacarpetedoor,cangeneratestaticelectricitysufcienttodamageanESD.
Copyright©1995-2013SAMSUNG.Allrightsreserved.1-6

2.ProductSpecicationsandDescription
2.ProductSpecicationsandDescription
2.1.ProductOverview
1)Speed
•Upto40ppminA4(42ppminLetter)
2)Processor
•DualCore1GHz
3)Memory(Std/Max)
•1GB/2GB
4)320GBHDD
5)DualScanDocumentFeeder(DSDF)
6)Interfaces
•High-SpeedUSB2.0
•10/100/1000BaseTXEthernet
•7inchTouchLCD
7)Tonercartridgeyield
•Initial:6,000pages
•Standard:10,000pages
•Highyield:20,000pages
2-1Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.2.Specications
ProductSpecicationsaresubjecttochangewithoutnotice.
NOTE
Thespecicationinthismanualisthereferenceinformationforserviceengineer.Donotusethisspecicationforsales.
2.2.1.General
ItemSpecication
ProcessorCPUDualCore1GHz(C4N+A1000)
OperationalPanel7"TouchScreenPanel
LED2EA(Power/Status)
UserInterface
Key/Button19EA(3x4NumericKeys/Power/Stop/Start/Reset/Clear/
Help/OnHookDial)
Standard1GB
MemoryMax.(Option)2GB
StorageStandard320GBHDD*UserAvailableSpace:279GB
USB(Device)Hi-SpeedUSB2.0
USB(Host)Hi-SpeedUSB2.0
USB(EDI)Yes
WiredLANStd(Ethernet10/100/1000BaseTX)
WirelessLANOption(IEEE802.11b/g/n)
NFCOption(Active)
Interface
RJ11ConnectorYes
FromSleepLessthan30sec
WarmupTimePowerOffLessthan45sec
Operating10to30°C(50to86°F) Temperature
Storage-20to40°C(-4to104°F)
Operating20to80%RH Humidity
Storage10to90%RH
PrintModeLessthan53dB(A)
CopyModeLessthan56dB(A)
NoiseLevel
StandbyLessthan30dB(A)
ReadyLessthan50W
Normaloperation700W
Max/Peak1100W
Sleep1.21W
PowerOff0.1W
PowerConsumption
TEC2.08KWh/week
Dimension(WxDxH)530x481.4x576mm(20.86"x18.95"x22.67")
WeightMachinewithsupplies25kg(55.1lb)
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-2

2.ProductSpecicationsandDescription
ItemSpecication
RecommendedMonthly
PrintingV olume(AMPV)
1,500~14,000pages Reliability&Service
Max.MonthlyPrint
V olume
120,000pages
2-3Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.2.2.Printspecication
ItemSpecication
SimplexUpto40ppminA4(42ppminLetter) PrintSpeed
DuplexUpto20ipminA4(20ipminLetter)
ReadyModeAsfastas7sec FPOT
SleepModeLessthan18.5sec
Optical(Standard)1200x600dpi Resolution
EnhancedUpto1,200x1,200dpieffectiveoutput(1,200x600x2bit)
PrinterLanguagesPCL5e/PCL6/PostScript3/PDFDirectV1.7/XPS/TIFF/URF
/PWG
PCL111ScalableFonts(IncludeOCR-A/OCR-B)/1Bitmap Font
Postscript3136ScalableFonts
WindowsWindowXP(32/64bit)/Vista(32/64bit)/2003Server(32/64bit)/
2008Server(32/64bit)/Win7(32/64bit)/2008ServerR2(64bit)/
Win8(32/64bit)/Win8.1(32bit/64bit)/2012Server(64bit)/2012
ServerR2(64bit)
Linux•RedHatEnterpriseLinux5,6,7
•Fedora13,14,15,16,17,18,19,20,21
•openSUSE11.3,11.4,12.1,12.2,12.3,13.1,13.2
•Ubuntu10.04,10.10,11.04,11.10,12.04,12.10,13.04,13.10,
14.04,14.10
•SUSELinuxEnterpriseDesktop11,12
•Debian6,7
•Mint13,14,15,16,17
UNIX•SunSolaris9,10,11(x86,SPARC)
•HP-UX11.0,11iv1,11iv2,11iv3(PA-RISC,Itanium)
•IBMAIX5.1,5.2,5.3,5.4,6.1,.7.1(PowerPC)
ClientOSSupport
MacOSMacOS:X10.6-10.10
BasicStandardTCP/IP(Raw),IPassign(DHCP ,BOOTP,AutoIP),
HTTP,HTTPs,IPP ,IPPs,WSD,SNMPv1/v2c/v3,SetIP ,SLP,DNS,
DDNS,Bongjour,WINS,LPD/LPR,ThinPrint,GoogleCloudPrint,
SMTP,SMTPs,UPnP,LDAP,Kerberos,SMB,IPSec,802.1x
NetworkProtocol
Advanced(Wi-Fisupport:Opensystem,SharedKey,WPAPersonal,WPA2
Personal(PSK),WPAEnterprise,WP A2Enterprise,WEP64,
WEP128,TKIP,AES)
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-4

2.ProductSpecicationsandDescription
2.2.3.Scanspecication
ItemSpecication
B/W(Lineart,
Halftone)
•Duplex:upto60ipm(@300dpi)
•Simplex:upto35ipm(@300dpi)
Gray•Duplex:upto60ipm(@300dpi)
•Simplex:upto35ipm(@300dpi)
ScanSpeed
Color•Duplex:upto60ipm(@300dpi)
•Simplex:upto35ipm(@300dpi)
ColorModeMono/Gray/Color
Compatibility•Windows:TW AIN/WIA
ScanmethodColorCISModule
FileFormatsTIFF-S/TIFF-M/JPEG/S-PDF/M-PDF
Optical(DSDF)Upto600x600dpi
Optical(Platen)Upto600x600dpi
Enhanced(DSDF)Upto4,800x4,800dpi
Resolution
Enhanced(Platen)Upto4,800x4,800dpi
ScanDestinationsHDD(SharedFolder)/USB/Email
CommunicationProtocolSMTP/MIME(Base64)
ADFMax.216mmx356mm(8.5"x14")
ScanSizePlatenMax.216mmx356mm(8.5"x14")
ScanOriginalTypesText
Text/Photo
2-5Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.2.4.Copyspecication
ItemSpecication
SDMC(SingleDocument
MultipleCopy)
Upto40cpminA4(Upto42cpminLetter) CopySpeed
MDMC(Multiple
DocumentMultipleCopy)
Upto35cpminA4(Upto36cpminLetter)
FromReadyAsfastas7sec@Platen FCOT
FromSleepLessthan40sec@Platen
DSDF•Scan:600x600dpi(Optical)
•Printing:upto600x600x4bit
Resolution
Platen•Scan:600x600dpi(Optical)
•Printing:upto600x600x4bit
DSDF25-400% Reduce/Enlarge
Platen25-400%
Reduction25%/50%/70%A4→A5/78%Legal→Letter/81%B5→A5/
86%A4→B5
Preset
Enlargement104%Executive→Letter/141%A5→A4/150%/200%/400%
DarknessControl11Levels
ContrastControl11Levels
MultiCopy1-9999
DuplexCopyBuilt-in
CopyOriginalTypeText/Text/Photo/Photo
CopyFeaturesN-Up/IDCardCopy/PosterCopy/CloneCopy/Booklet/Covers
/Transparencies/BookCopy/RotationCopy/JobBuild/Margin
Shift/Program/WatermarkCopy/EraseBackground/EraseEdge/
BookCenterErase/Time&DateStamp/IDStamp/SavetoFile
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-6

2.ProductSpecicationsandDescription
2.2.5.Faxspecication
ItemSpecication
CompatibilityITU-TG3
CommunicationSystemPSTN/P ABN/A
ModemSpeed33.6Kbps
TXSpeed3Sec(Mono/Standard/ECM-MMR/MemoryTx/ITU-TG3No.1
Chart)
Standard35ipm/60ipm(@300dpi)
Fine35ipm/60ipm(@300dpi)
Scanspeed
S.Fine35ipm/60ipm(@300dpi)
Std203x98dpi
Fine203x196dpi
Resolution(Mono)
S.Fine300x300dpi
CompressionMethodMH/MR/MMR/JBIG
FaxMemory(Standard/Max.)HDDShared(50MB)
HandsetNo
OnhookDialYes
SearchYes(AddressBook)
1-TouchDialNo
SpeedDial500locations
TADI/FY es
Tone/PulseY es
PauseYes
AutoRedialY es
LastNumberRedialYes
DistinctiveRingYes
CallerIDY es
ExternalPhoneInterfaceYes
FaxForwardtoE-MailY es
FaxtoPCN/A
Broadcasting500Locations
FaxFeatures
DelayedFaxY es
2-7Copyright©1995-2013SAMSUNG.Allrightsreserved.

2.ProductSpecicationsandDescription
2.2.6.PaperHandlingspecication
ItemSpecication
StandardCapacity•550sheetCassetteTray@75g/m²
•100sheetMultiPurposeTray@75g/m²
Max.Capacity2300sheet(550standardcassette+100MP+3x550SCF)
Capacity550sheet@75g/m²(520sheet@80g/m²)
Mediasizes
A4/A5/A6/Letter/Legal/Ocio/Folio/JISB5/ISOB5/
Executive/Statement/PostCard4x6/EnvelopeMonarch/Envelope
No9/EnvelopeNo10/EnvelopeDL/EnvelopeC5/Envelope
C6/Custom
MediatypesPlain/Thin/Bond/Punched/Pre-Printed/Recycled/Envelope
/Label/CardStock/Letterhead/Thick/Colored/Archive/Cotton
Mediaweight
SupportedWeight:60to163g/m²(16~43lb)
•ThinPaper(60~69g/m²)
•PlainPaper(70~90g/m²)
•ThickPaper(91~105g/m²)
•BondPaper(105~120g/m²)
•Cardstock(106~163g/m²)
StandardCassetteTray
Sensing
•H/WInstallDetect:Y es
•PaperEmpty:Y es
•Paperlowleveldetect:Y es
•PaperTypeDetect:No
•PaperSizeDetect:Yes
Capacity•PlainPaper:100sheets@75g/m²
•Envelope:10sheets
MediasizesMin:76.2mmx127mm(3"x5")
Max:216mmx356mm(8.5"x14.0")
Mediatype
Plain/Thin/Bond/Pre-printed/Recycled/Envelope/Label/
Cardstock/Thick/Cotton/Colored/Archive/Thicker/Punched/
Letterhead
Mediaweight
SupportedWeight:60-220g/m²(16~59lb)
•ThinPaper(60-69g/m²)
•PlainPaper(70-90g/m²)
•ThickPaper(91-105g/m²)
•BondPaper(105-120g/m²)
•Cardstock(106-163g/m²)
•ThickerPaper(164-220g/m²)
Multi-purposetray
SensingPaperEmpty
Copyright©1995-2013SAMSUNG.Allrightsreserved.2-8

2.ProductSpecicationsandDescription
ItemSpecication
Capacity550sheet@75g/m²(520sheet@80g/m²)
Mediasizes
A4/A5/Letter/Legal/Ocio/Folio/JISB5/ISOB5/Executive
/Statement/EnvelopeNo9/EnvelopeNo10/EnvelopeDL/
EnvelopeC5/Custom
MediatypesPlain/Thin/Bond/Punched/Pre-Printed/Recycled/Envelope
/Label/CardStock/Letterhead/Thick/Colored/Archive/Cotton
Mediaweight
SupportedWeight:60-163g/m²(16-43lb)
•ThinPaper(60-69g/m²)
•PlainPaper(70-90g/m²)
•ThickPaper(91-105g/m²)
•BondPaper(105-120g/m²)
•Cardstock(106-163g/m²)
OptionalCassetteTray
Sensing
•H/WInstallDetect:Y es
•PaperEmpty:Y es
•Paperlowleveldetect:Y es
•PaperTypeDetect:No
•PaperSizeDetect:Yes
Capacity50Sheets
DuplexDocument
Scanning
Yes(DSDF)
DocumentSize•Width:105-216mm(4.1"-8.5")
•Length:148-356mm(5.8"-14")
DocumentWeight60-120g/m²(14-32lb)
SensorD-CIS
ADF
AutoDetectedSizeN/A
CapacityFace-Down:250sheets
OutputStackingOutputFullsensingYes
Max.Size216x356mm(8.5"x14")
Min.Size76.2x127mm(3"x5") Printingsize
Margin(T/B/L/R)T/B/L/R:1mm
SupportBuilt-in
MediasizesA4/Letter/Ocio/Folio/Legal/JISB5/ISOB5/Executive/
Statement/A5
MediatypesPlain/Thin/Thick/Recycled/Bond/Pre-printed/Cotton/Colored
DuplexPrinting
Mediaweight60~120g/m²(16-32lb)
2-9Copyright©1995-2013SAMSUNG.Allrightsreserved.
