Samsung NE58 943 Series User manual

Electric Range
User manual
NE58*943***
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 1 2018-12-17  4:50:38

2 English
WARNING
To reduce the risk of tipping the range, the range must be secured
by a properly installed Anti-Tip device. AFTER THE RANGE HAS
BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN
PROPERLY INSTALLED AND VERIFY THAT THE ANTI-TIP DEVICE
IS PROPERLY ENGAGED. Refer to the installation manual for
instructions.
a) If the Anti-Tip device is not installed, a child or adult can tip
the range and be killed.
b) Verify that the Anti-Tip device has been properly installed
and engaged at the rear right (or rear left) of the range
bottom.
c) If you move the range and then move it back into place,
ensure the Anti-Tip device is re-engaged at the right or left
rear of the range bottom.
d) Do not operate the range without the Anti-Tip device in
place and engaged.
e) Failure to do so can result in death or serious burns to
children or adults.
WARNING
Do not step, lean, or sit on the doors of the range. You can cause
the range to tip, resulting in burns or serious injuries.
Conrm that the Anti-Tip device is installed properly. Then, to
verify that the Anti-Tip device is engaged, grasp the top rear
edge of the range and carefully attempt to tilt it forward. The
Anti-Tip device should prevent the range from tilting forward
more than a few inches.
If you pull the range out from the wall for any reason, make
sure the Anti-Tip device is properly engaged when you push
the range back against the wall. If it is not, there is a risk of the
range tipping over and causing injury if you or a child stand, sit,
or lean on the open door.
Never completely remove the leveling legs. If you remove the
leveling legs, the range will not be secured to the Anti-Tip device
properly.
Anti-tip device
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 2 2018-12-17  4:50:38

English 3
Contents
Contents
Important safety instructions 4
Introducing your new range 18
Overview 18
What’s included with your range 18
Before you begin 19
Energy saving tips 19
Surface cooking 19
About surface cooking 19
How to set the appliance for cooktop cooking 21
Using the proper cookware 22
Choosing the proper cookware 23
Protecting the cooktop 23
Operating the oven 24
The oven control panel 24
Setting the clock 24
Setting the kitchen timer 25
Timed cooking 25
Delay Start 26
Turning the oven light on and off 26
Minimum and maximum settings 26
Using the oven racks 27
Baking 28
Convection baking 28
Convection roasting 29
Broiling 30
Using the easy cook feature 31
Using the favorite cook feature 32
Using the keep warm feature 32
Using the sabbath feature 33
Extra features 34
Maintaining your appliance 35
Self-cleaning 35
Steam-cleaning 37
Care and cleaning of the oven 37
Care and cleaning of the glass cooktop 39
Removing and re-installing the oven door 40
Removing and re-installing the storage drawer 41
Changing the oven light 42
Troubleshooting 42
Troubleshooting 42
Information codes 47
Warranty (U.S.A) 48
Warranty (CANADA) 49
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 3 2018-12-17  4:50:38

4 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
Important safety instructions
Read and follow all instructions before using your oven to prevent
the risk of re, electric shock, personal injury, or damage when using
the range. This guide does not cover all possible conditions that may
occur. Always contact your service agent or the manufacturer about
problems that you do not understand.
WHAT YOU NEED TO KNOW ABOUT
SAFETY INSTRUCTIONS
Warnings and Important safety instructions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury
or property damage.
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury
when using your range, follow these basic safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 4 2018-12-17  4:50:38

English 5
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as described in
this Owner’s Manual.
• Potentially hot surfaces include the cooktop, areas facing the
cooktop, the oven vent opening, surfaces near the opening, and
crevices around the oven door.
Be sure your appliance is properly installed and grounded by a
qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual. All
other servicing should be referred to a qualied technician.
Always disconnect the power to the appliance before servicing
by removing the fuse or switching off the circuit breaker.
• Do not enter the oven.
• Do not store items of interest to children in cabinets above a
range or on the back guard of a range. Children climbing on
the range to reach items could be seriously injured.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the room.
• Do not use water on grease res. Turn off the oven to avoid
spreading the ames. Smother the re or ames by closing
the door or use a dry chemical, baking soda, or foam-type
extinguisher.
• Avoid scratching or striking the glass door, cooktop, or
control panel. Doing so may lead to glass breakage. Do not
cook on a product with broken glass. Shock, re, or cuts may
occur.
• If there is a re in the oven during self clean, turn the oven
off and wait for the re to go out. Do not force the door
open. Introduction of fresh air at self-clean temperatures
may lead to a burst of ame from the oven. Failure to follow
this instruction may result in severe burns.
• If the oven is heavily soiled with oil, self clean the oven
before using the oven again. Leaving the oil in place creates
a risk of re.
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 5 2018-12-17  4:50:38

6 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
• Do not lean on the range as you may turn the control knobs
inattentively.
SURFACE COOKING UNITS
• Never leave surface units unattended at high heat settings.
Boilovers cause smoking and greasy spillovers that may ignite.
• Protective Liners – Do not use aluminum foil to line surface
unit drip bowls or oven bottoms, except as suggested in the
manual. Improper installation of these liners may result in a
risk of electric shock or re.
• To avoid oil spillover and re, use a minimum amount of oil
when shallow pan-frying and avoid cooking frozen foods
that have excessive amounts of ice.
• Do not lift the cooktop. Lifting the cooktop can damage the
range and cause the range to malfunction.
• Wipe up heavy soil on the oven bottom with a paper tower
or rag before self cleaning. Self cleaning the oven when
there is heavy soil on the oven bottom requires longer
cleaning cycles and produces more smoke.
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure all
packing materials are removed from the appliance before
operating it. Keep plastics, clothes, and paper away from
parts of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
• Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not
let the potholder touch hot heating elements. Do not use a
towel or other bulky cloth.
• Teach children not to play with the controls or any other
part of the range.
• For your safety, do not use high-pressure water cleaners or
steam jet cleaners to clean any part of the range.
• If the power cord is damaged, it must be replaced by
the manufacturer, its service agent, or similarly qualied
persons to avoid creating a hazard.
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 6 2018-12-17  4:50:38

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
• Glazed cookware. Only certain types of glass, glass/ceramic,
ceramic, earthenware, or other glazed cookware can be
used for rangetop service without breaking due to sudden
changes in temperature.
• Cleaning. Read and follow all instructions and warnings on
the cleaning cream labels.
• Be sure you know which control knob operates each surface
unit. Make sure you turned on the correct surface unit.
• Always turn the surface units off before removing cookware.
• When preparing aming foods under the hood, turn the fan
on.
• Keep an eye on foods being fried at high or medium high
heat settings.
• Do not store heavy items above the cooktop surface that
could fall and damage it.
• Do not Use Decorative Surface Element Covers – If an
element is accidentally turned on, the decorative cover
will become hot and possibly melt. Burns will occur if the
hot covers are touched. Damage may also be done to the
cooktop.
• Do not operate the cooktop without cookware. If the cooktop
operates without cookware, the control knobs will become hot.
• Never use the glass cooktop surface as a cutting board.
• Use care when touching the cooktop. The glass surface of
the cooktop will retain heat after the controls have been
turned off.
• Be careful when placing spoons or other stirring utensils
on the glass cooktop surface when it is in use. They may
become hot and could cause burns.
• Use proper pan sizes. This appliance is equipped with
surface units of different size. Select pots and pans that
have at bottoms large enough to cover the surface area of
the heating element. Using undersized cookware will expose
a portion of the heating element to direct contact and may
result in the ignition of clothing. Matching the size of the
pot or pan to the burner will also improve efciency.
• Cookware Handles Should Be Turned Inward and Not
Extend Over Adjacent Surface Units – To reduce the risk
of burns, ignition of ammable materials, or spillage due
to unintentional contact with cookware, position cookware
handles so that they are turned inward and do not extend
over adjacent surface units.
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 7 2018-12-17  4:50:38

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
WARNING
• Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
• The range should not be placed on a base.
CHILD SAFETY
WARNING
• This appliance is not intended for use by young children or inrm
persons without the adequate supervision of a responsible adult.
• Young children should be supervised to ensure that they do not
play with the appliance.
• Keep children away from the door when opening or closing it as
they may bump themselves on the door or catch their ngers in
the door.
• The cooking zones will become hot when you cook. To keep small
children from being burned, always keep them away from the
appliance while you are cooking.
• During self cleaning, the surfaces may get hotter than usual.
Keep small children away from the range when it is in the self-
cleaning mode.
ELECTRICAL SAFETY
• Proper Installation - Be sure your appliance is properly installed and
grounded by a qualied technician.
• The appliance should be serviced only by qualied service
personnel. Repairs carried out by unqualied individuals may cause
injury or a serious malfunction. If your appliance is in need of repair,
contact a Samsung authorized service center. Failure to follow these
instructions may result in damage and void the warranty.
• Flush - mounted appliances may be operated only after they have
been installed in cabinets and workplaces that conform to the
relevant standards. This ensures that the appliances are installed in
compliance with the appropriate safety standards.
• If your appliance malfunctions or if fractures, cracks, or splits appear:
-switch off all cooking zones
-unplug the range from the AC wall outlet
-contact your local Samsung service center.
WARNING
If the surface is cracked, switch off and unplug the appliance to avoid
the possibility of electrical shock. Do not use your cooktop until the
glass surface has been replaced.
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 8 2018-12-17  4:50:39

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
• Use care when opening the door. Let hot air or steam escape
before you remove food from or put food into the oven.
• Protective liners. Do not use aluminum foil to line the oven
bottoms, except as suggested in the manual. Improper
installation of these liners may result in a risk of electric
shock or re.
• Keep oven vent ducts unobstructed. The oven vent is
located above the right rear surface unit. This area could
become hot during oven use. Never block this vent or place
plastic or heat-sensitive items on it.
• Placement of oven racks. Always place oven racks in the
desired location while the oven is cool. If the rack must be
moved while the oven is hot, use potholders. Do not let the
potholders come in contact with the hot heating element in
the oven.
• Do not allow aluminum foil or a meat probe to contact the
heating elements.
• During use, the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the oven.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass. They can scratch the surface
which may result in the glass shattering.
WARNING
Accessible parts may become hot during use. To avoid burns, young
children should be kept away.
OVEN
• DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR
SURFACES OF THE OVEN. Heating elements may be hot even
though they are dark in color. Interior surfaces of an oven
become hot enough to cause burns. During and after use, do
not touch or let clothing or other ammable materials contact
the heating elements or interior surfaces of the oven until
they have had sufcient time to cool. Other surfaces of the
appliance may become hot enough to cause burns. Among
these surfaces are oven vent openings and surfaces near these
openings, the oven door, and the window of the oven door.
• Do not heat unopened food containers. The build-up of
pressure may cause the container to burst and result in injury.
• Do not use the oven to dry newspapers. If overheated,
newspapers can catch on re.
• Do not use the oven for a storage area. Items stored in an
oven can ignite.
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 9 2018-12-17  4:50:39

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
• Do not use any commercial oven cleaner or oven liner
protective coating of any kind in or on the outside of the
oven.
• Remove the nickel oven shelves from the oven before you
begin the self cleaning cycle or they may discolor.
• If the self-clean mode malfunctions, turn the oven off and
disconnect the power supply. Have it serviced by a qualied
technician.
• Excess spillage must be removed before you run the self
cleaning cycle.
VENTILATING HOOD
• Clean ventilating hoods frequently. Do not let grease
accumulate on the hood or lter.
• When aming foods under the hood, turn the fan on.
CAUTION
Do not attempt to operate the oven during a power failure. If the
power fails, always turn the oven off. If the oven is not turned off
and the power returns, the oven may begin to operate again. Food
left unattended could catch re or spoil.
SELFCLEANING OVENS
Do not clean the door gasket. The door gasket is essential for
a good seal. Care should be taken not to rub, damage, or move
the gasket.
• Never keep pet birds in the kitchen. Birds are extremely
sensitive to the fumes released during an oven self-clean
cycle. Fumes may be harmful or fatal to birds. Move birds to
a well-ventilated room.
• Clean only the parts listed in this manual in the self-clean
cycle. Before self-cleaning the oven, remove the partition,
rack, utensils, and any food.
• Before operating the self-clean cycle, wipe grease and food
soils from the oven. Excessive amounts of grease may
ignite, leading to smoke damage to your home.
NE58K9430SS_AA_AC_DG68-00721A-06_EN+CFR.indb 10 2018-12-17  4:50:39
