Samsung SCC-4235(P) User manual

512X POWER ZOOM CAMERA
SCC-С4233(P)/С4333(P)/
 С4235(P)/С4335(P)
User Manual
ENG RUS POL
SCC-C4333_Eng-EURO_cover.indd 1 2007-11-12 오전 8:55:11

2
2
This symbol indicates that
dangerous voltage consisting
a risk of electric shock is
present within this unit.
This symbol indicates
that there are important
operating and maintenance
instructions in the literature
accompanying this unit.
WARNING
• To reduce the risk of re or electric
shock, do not expose this appliance
to rain or moisture.
WARNING
1. Be sure to use only the standard
adapter that is specied in the
specication sheet. Using any
other adapter could cause re,
electrical shock, or damage to
the product.
2. Incorrectly connecting the power
supply or replacing battery may
cause explosion, re, electric
shock, or damage to the product.
3. Do not connect multiple cameras
to a single adapter. Exceeding
the capacity may cause
abnormal heat generation or re.
4. Securely plug the power cord into
the power receptacle. Insecure
connection may cause re.
5. When installing the camera,
fasten it securely and rmly.
A falling camera may cause
personal injury.
6. Do not place conductive objects
(e.g. screwdrivers, coins, metal
things, etc.) or containers lled
with water on top of the camera.
Doing so may cause personal
injury due to re, electric shock,
or falling objects.
7. Do not install the unit in humid,
dusty, or sooty locations. Doing so
may cause re or electric shock.
8. If any unusual smells or smoke
come from the unit, stop using
the product. In such case,
immediately disconnect the
power source and contact the
service centre. Continued use in
such a condition may cause re
or electric shock.
SafetyPrecautions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
SCC-C4333_Eng-EURO.indd 2 2007-11-12 오전 10:18:21

3
ENG
SafetyPrecautions
9. If this product fails to operate
normally, contact the nearest
service centre. Never
disassemble or modify this
product in any way. (SAMSUNG
is not liable for problems caused
by unauthorized modications or
attempted repair.)
10. When cleaning, do not spray
water directly onto parts of the
product. Doing so may cause re
or electric shock.
CAUTION
1. Do not drop objects on the
product or apply strong shock
to it. Keep away from a location
subject to excessive vibration or
magnetic interference.
2. Do not install in a location
subject to high temperature (over
122°F), low temperature (below
14°F), or high humidity. Doing so
may cause re or electric shock.
3. If you want to relocate the
already installed product, be
sure to turn off
the power and then move or
reinstall it.
4. Remove the power plug from the
outlet when then there is a lightning.
Neglecting to do so may cause re
or damage to the product.
5. Keep out of direct sunlight and
heat radiation sources. It may
cause re.
6. Install it in a place with good
ventilation.
7. Avoid aiming the camera directly
towards extremely bright objects
such
as sun, as this may damage the
CCD image sensor.
8. Apparatus shall not be exposed
to dripping or splashing and no
objects lled with liquids, such
as vases, shall be placed on the
apparatus.
9. The Mains plug is used as a
disconnect device and shall stay
readily operable at any time.
SCC-C4333_Eng-EURO.indd 3 2007-11-12 오전 10:18:21

4
ImportantSafetyInstructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, or
other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the provided
plug does not t into your outlet, consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus.
13. Unplug this apparatus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from tip-over.
14. Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or been dropped.24. Wall or Ceiling
Mounting – The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
SCC-C4333_Eng-EURO.indd 4 2007-11-12 오전 10:18:21

5
ENG
Contents
Safety Precautions...... 2
Important Safety
Instructions..................... 4
Overview........................... 6
Special Features........... 7
Part Names and
Functions ......................... 8
Installation ....................... 11
Before Installation......... 11
Checking the contents
of the package.................. 11
Things to keep in mind during
installation and use.............11
Installing the Camera... 12
Power Adapter Cable........ 12
Video Cable ...................... 12
Connecting the Cables .. 13
Camera Setup ................ 16
CAMERA ID ........................ 17
IRIS...................................... 17
WDR... ............................. 18
ALC.................................. 18
MANU... ........................... 19
SHUTTER ......................... 19
AGC ................................... 20
MOTION ............................ 21
WHITE BAL...................... 21
FOCUS MODE................. 23
MOTION DET................... 24
DAY/NIGHT ...................... 26
DAY... ............................... 27
NIGHT... ........................... 27
AUTO... ............................ 28
EXT .................................. 29
PRIVACY........................... 29
SPECIAL........................... 30
LANGUAGE..................... 31
VIDEO SET...................... 31
RS-485............................. 32
ZOOM SPEED................. 33
DIGITAL ZOOM ............... 33
DISPLAY ZOOM .............. 34
SYSTEM INFO ................ 34
CTRL TYPE ..................... 35
V-SYNC............................ 35
PRESET ............................ 36
Product
Specifications ................ 37
SCC-C4333_Eng-EURO.indd 5 2007-11-12 오전 10:18:22

6
Overview
This enriched WDR (Wide Dynamic Range) Day/Night camera can
clearly implement both dark and bright parts on the screen with the
dual shutter.
When a bright object such as window occupies a part of the
screen, it appears white in conventional cameras. But using the
state-of-the-art WDR function that this camera provides, you can
see the clear image. This Day/Night camera activates the colour
mode when in the illumination over the normal value. Otherwise it
activates B/W (Black/White) mode by removing the IR cut function,
which can improve the sensitivity for identifying objects even in a
dark area. It also incorporated the low speed shutter and Sens-Up
(Uses the field accumulation method) functions to enhance the low
illumination feature.
This camera can be mainly used in the dark places such as
basement parking lots under comparatively low illumination. In
daytime, it displays the colour screen with a horizontal resolution of
540 lines but at night, it uses the Day/Night feature along with the
Sens-Up function to identify objects in a dark area. You can also
connect the infrared ray emission equipment to this camera.
Moreover, this camera has more various functions for surveillance.
White Balance function that provides accurate colour rendition under
any light conditions. Auto Focus function that automatically tracks
and focuses on the moving subject. Privacy Zone function to hide
a special area for privacy protection. RS485/ Wired remote control
function.
Note
SCC-C4233(P)/C4333(P) does not support for WDR function.
SCC-C4233(P)/C4235(P) does not support for V-SYNC function.
SCC-C4333_Eng-EURO.indd 6 2007-11-12 오전 10:18:22

7
ENG
Special Features
High Sensitivity
It implements images of high sensitivity using the up-to-date
Super-HAD IT CCD(SCC-C4233(P)/C4333(P))/ExView-HAD PS
CCD(SCC-C4235(P)/C4335(P)).
WDR
The WDR function of this camera is the state-of-the-art technology
that can effectively enlarge the range for screen gain. It is mainly
used for taking photos for window scenes inside a building. Using
this technology, you can clearly see both indoor and outdoor
images, and can enjoy the excellent picture quality, which is
enabled by automatically adjusting the WDR level.
Note
SCC-C4233(P)/C4333(P) does not support for WDR function.
Low Illumination
It uses the digital signal technologies such as low illumination and
Day/Night functions that make your camera identify objects even in
the worst environment.
Superior Backlight Adjustment
When an object has a bright illumination or sunlight behind it, this
camera automatically improves the shaded object picture quality.
Digital Power Synchronization
The full digital Line Lock function directly adjusts the vertical
camera synchronization to enhance the operation ability and
reliability of this camera.
Note
SCC-C4233(P)/C4235(P) dose not support for Line Lock function.
High Resolution
This camera has realized high resolution of 540 lines using the
top-notch full digital image processing and special algorithm technologies.
Output Signal Setting
You can set the following Video output signals: Image reversion
(Horizontal, Vertical, or both), Privacy, Horizontal/Vertical profiling,
POSI/NEGA function, and digital zooming.
White Balance
It uses to automatically adjust light levels to improve colour balance
depending on the illumination.
Auto Focus
It enables to capture clear images by adjusting the automatic focus
on the subject movement.
SCC-C4333_Eng-EURO.indd 7 2007-11-22 오후 2:38:17

8
PartNamesandFunctions
1Input/Output Connector
This connector has input and output jacks for RS-485 control
signals.
RS-485 DATA+
Jack for connection to RS-485 DATA+ signal line.
RS-485 DATA-
Jack for connection to RS-485 DATA- signal line.
1. ALARM OUT
Alarm out jack for motion detection. (Open Collector, On Gnd)
2. GND
Grounding jack.
3. 5V OUT
Power supply jack for RS-485 JIG. Use within typical DC +5V
100mA.
4. DAY/NIGHT IN
This is a function to receive the external DAY/NIGHT signal from
the sensor(option) and convert the signal into BW.
SCC-C4233(P)/C4235(P) SCC-C4333(P)/C4335(P)
SCC-C4333_Eng-EURO.indd 8 2007-11-12 오전 10:18:22

9
ENG
5-7. ZOOM/ FOCUS REMOTE terminals
This port is used for ZOOM/FOCUS, MENU CONTROL, HOME
RETURN, and ONEAF by using an external controller.
Depending on the input condition, 4 modes, A, B, C, and D are
available. (SPECIAL - CTRL TYPE)
(Operation Voltage Range : +3V~+13V, -3V~-13V)
1) When the voltage is supplied to either ZOOM or FOCUS port
Function
*1
Code
Tele(Up) Wide(Down) Near(Left) Far(Right)
ZOOM Port FOCUS Port
A-6V +6V -6V +6V
B-6V +6V +6V -6V
C+6V -6V -6V +6V
D+6V -6V +6V -6V
*1: During MENU OFF, controls ZOOM/FOCUS and during
MENU ON, changes the direction, Up/Down/Left/Right
SETUP switch.
SCC-C4333_Eng-EURO.indd 9 2007-11-12 오전 10:18:22

10
2) When the voltage is supplied to both ports
Function
Code
ENTER/AF *2 HOME RETURN *3
ZOOM Port FOCUS Port ZOOM Port FOCUS Port
A-6V -6V +6V +6V
B-6V +6V +6V -6V
C+6V -6V -6V +6V
D+6V +6V -6V -6V
* 2 : For short voltage supply during MENU OFF, executes
ONEAF and for more than 2 second
* 3 : For more than 2 second long voltage supply, moves to the
PRESET 0(HOME) position.
2SETUP Switch
This switch is used to set the function or property. When this switch
is pressed for at least 2 seconds, the Setup menu appears.
n [Left/Right] movement or changing the displayed value: By
pressing this switch left or right, you can move left or right on
the menu or change the displayed value.
n [Up/Down] movement: By pressing this switch up or down, you
can move up or down on the menu.
n
Setting: When you press this switch in the menu, the selected
value or function is confirmed. To enter a submenu, press this
button.
3Power Display LED
When the power is normally connected, the red LED lights.
4Video OUT Jack
This is connected to the Video Input jack of the monitor and it
outputs the Video signals.
5Power Connection Jack
This is connected to the Power cable.
SCC-C4333_Eng-EURO.indd 10 2007-11-12 오전 10:18:23

11
ENG
Installation
❚Before Installation
Checking the contents of the package
Make sure that the following items are included in the package.
Things to keep in mind during installation and use
n Do not disassemble the camera on your own.
n Always be careful when handling the camera. Do not strike the
camera by your fists or shake it. Please be careful not to be
careless when storing and operating it.
n Do not place or operate the camera in any wet environment
such as rain or wet surfaces.
n Do not clean the camera with rough sandpaper. Please always
use a dry cloth when cleaning it.
n Put the camera in a cool area free from direct sunlight.
Otherwise, the camera may be damaged.
Camera Camera Holder
(Power Adapter)
2 Screws
User's Manual
SCC-C4333_Eng-EURO.indd 11 2007-11-12 오전 10:18:23

12
❚Installing the Camera
To install and use the camera, rst prepare the following cables.
Power Adapter Cable (sold separately)
The requirements for the power adapter, which connects to the
camera’s POWER IN terminal, are as follows:
- SCC-C4233(P)/C4235(P) : DC 12V 600mA
- SCC-C4333(P)/C4335(P) : AC 24V 300mA
DC 12V 600mA
Video Cable
Use a BNC cable, such as the one shown below, to connect the
camera’s VIDEO OUT to the monitor.
SCC-C4333_Eng-EURO.indd 12 2007-11-12 오전 10:18:23

13
ENG
❚Connecting the Cables
1. Connect one end of the BNC cable to the VIDEO OUT.
2. Connect the other end of the BNC cable to the VIDEO IN of the
monitor.
Video In Terminal of
Monitor Rear Surface
BNC cable
Video Out Terminal
SCC-C4333_Eng-EURO.indd 13 2007-11-12 오전 10:18:24

14
3. Plug in the power adapter. Use a “minus” screwdriver to connect one
part of the power adapter, which consists of two lines, to the POWER
terminal of the camera as follows :
4. Determine the type of power supply and set the POWER
SELECTION switch accordingly. Next, plug the power adapter into a
wall outlet.
SCC-C4333(P)/C4335(P) SCC-C4233(P)/C4235(P)
SCC-C4333_Eng-EURO.indd 14 2007-11-12 오전 10:18:24

15
ENG
5. If the camera operates normally, the following screen will be
displayed for 5 seconds and then disappears.
* ROM VER and EEP VER may change without notice.
6. The requirements for RS485 control is as follows :
- Signaling Speed: 9600 bps
- Data Bit : 8 bits
- Stop Bit : 1 bit
- Parity Bit : none
SAMSUNG PROTOCOL
ADDRESS 0
TYPE RS-485, HALF
BAUD RATE 9600
ROM VER 1.000
EEP VER 1.000
LENS OK.
SCC-C4333_Eng-EURO.indd 15 2007-11-12 오전 10:18:24

16
CameraSetup
CAMERA ID OFF/ON...
IRIS WDR...*1/ALC.../MANU...
SHUTTER OFF/AUTO X2 ~ AUTO X256
/1/100(1/120) ~ 1/10K
AGC/MOTION OFF/LOW/HIGH
S.SLOW/SLOW/NORM/
FAST/F.FAST
WHITE BAL ATW1/ATW2/AWC/MANU...
FOCUS MODE AF/MF/ONEAF
MOTION DET OFF/ON...
DAY/NIGHT DAY.../NIGHT.../AUTO.../EXT
PRIVACY OFF/ON...
SPECIAL ... LANGUAGE *2
VIDEO SET ...
RS-485 ...
ZOOM SPEED 1~4
DIGITAL ZOOM OFF/X2~X16
DISPLAY ZOOM OFF/ON
SYSTEM INFO ...
CTRL TYPE A/B/C/D
V-SYNC *3INT/LINE...
RET
PRESET ...
Note
*1 SCC-C4233(P)/C4333(P) does not support for WDR function.
*2The language may vary depending on sales region.
*3 SCC-C4233(P)/C4235(P) does not support for V-SYNC function.
This chapter describes how to congure the camera-related settings. If you
press the SETUP switch for at least 2 seconds, the Setup menu appears.
The Setup OSD (On-screen Display) map brief is like the following:
SCC-C4333_Eng-EURO.indd 16 2007-11-12 오전 10:18:24

17
ENG
❚CAMERA ID
The [CAMERA ID] menu is used to assign a camera ID to this
camera. If you press the SETUP switch when the [CAMERA ID]
menu is selected, the corresponding setup screen appears.
You can input a camera ID composed of alphabets, numbers, and
special characters up to 20 characters long. The input camera
ID can be displayed at the desired location when using the
[LOCATION…] submenu. When you press the SETUP switch in
[RET], the screen returns to the upper menu.
❚IRIS
The [IRIS] menu is used to set the automatic light control method
for this camera.
CAMERA ID ON...
IRIS ALC...
SHUTTER OFF
AGC HIGH
WHITE BAL ATW2
FOCUS MODE AF
MOTION DET OFF
DAY/NIGHT DAY...
PRIVACY OFF
SPECIAL ...
PRESET ...
EXIT QUIT
(CAMERA ID)
ABCDEFGHIJKLMNOPQRSTUVWXYZ
0123456789 : ! - + *() /
RET
SP▶▶ ◀◀SP LOCATION...
CAMERA-1...........
SCC-C4333_Eng-EURO.indd 17 2007-11-12 오전 10:18:25

18
WDR...
If you press the SETUP switch when the [WDR…] submenu is
selected, the corresponding screen appears.
You can adjust the shutter speed in [LEVEL1] and the brightness in
[LEVEL2]. You can also select any of [ALL], [OUTDOOR], and [IN-
DOOR] in [WHITE BAL]. In case of [ALL], this camera controls both
indoor and outdoor images.
Note
SCC-C4233(P)/C4333(P) does not support for WDR function.
ALC...
If you press the SETUP switch when the [ALC…] submenu is se-
lected, the corresponding screen appears.
CAMERA ID OFF
IRIS ALC...
SHUTTER OFF
AGC HIGH
WHITE BAL ATW2
FOCUS MODE AF
MOTION DET OFF
DAY/NIGHT DAY...
PRIVACY OFF
SPECIAL ...
PRESET ...
EXIT QUIT
(ALC)
BLC OFF
LEVEL ( 0) – – – – I – – – –
RET
CAMERA ID OFF
IRIS WDR...
SHUTTER OFF
AGC HIGH
WHITE BAL ATW2
FOCUS MODE AF
MOTION DET OFF
DAY/NIGHT DAY...
PRIVACY OFF
SPECIAL ...
PRESET ...
EXIT QUIT
(WDR)
LEVEL1 L– – – I – – – H
LEVEL2 L– – – I – – – H
WHITE BAL INDOOR
RET
SCC-C4333_Eng-EURO.indd 18 2007-11-12 오전 10:18:25

19
ENG
You can make the BLC (Back Light Compensation) function active or
not. For setting the BLC zone, you can select any of [BOTTOM…],
[TOP…], [LEFT…], [RIGHT…], and [CENTER…]. The actual location
is displayed when you enter each item.
In case of [USER…], you can set the desired BLC zone by defining
the size and location. You can set the Video output level in [LEVEL].
Its selectable range is from -9 to +9.
MANU…
If you press the SETUP switch after selecting MANU in the IRIS
item, an additional screen appears in which you can set manually
opening or closing the IRIS.
❚SHUTTER
The [SHUTTER] menu is used to set the high speed electronic
shutter and AUTO low speed shutter. The high speed electronic
shutter can be used 7 different speeds and is commonly used for
imaging fast moving objects. (NTSC: from 1/100 to 1/10K, PAL:
from 1/120 to 1/10K ). The AUTO low speed electronic shutter can
be any of 13 speeds from X2 to X256 and it slows the shutter speed
to make images clearer in dark illumination. If you select an AUTO
low speed, the shutter speed is automatically lowered depending on
the darkness level.
CAMERA ID OFF
IRIS MANU...
SHUTTER OFF
AGC HIGH
WHITE BAL ATW2
FOCUS MODE AF
MOTION DET OFF
DAY/NIGHT DAY...
PRIVACY OFF
SPECIAL ...
PRESET ...
EXIT QUIT
(MANUAL)
LEVEL ( 00) – – – – I – – – –
RET
SCC-C4333_Eng-EURO.indd 19 2007-11-12 오전 10:18:25

20
If you keep pressing the Left/Right SETUP switch, shutter speeds
toggles in the following order:
OFF à AUTO X2 à AUTO X4 à AUTO X6 à AUTO X8 à AUTO X12
à AUTOX16 à AUTO X24 à AUTO X32 à AUTO X48
àAUTO X64 àAUTO X96 àAUTO X128 àAUTO X256 àOFF
à 1/100(1/120) à1/250 à1/500 à1/1000 à1/2000 à1/4000 à1/10K
❚AGC
The AGC (Auto Gain Control) menu is used to set the AGC level
of the camera. When the AGC is active, the camera automatically
increases the sensitivity by amplifying the Video signal when the
strength of the signal falls below the normal value.
Only when [OFF] or a high speed shutter is selected in the
[SHUTTER] menu, you can set the AGC level.
You can select any of [OFF], [LOW], and [HIGH].
Note
When the DAY/NIGHT is set to AUTO, the AGC is displayed with
[---] so you cannot change its setting.
CAMERA ID OFF
IRIS ALC...
SHUTTER AUTO X2
MOTION F.FAST
WHITE BAL ATW2
FOCUS MODE AF
MOTION DET OFF
DAY/NIGHT DAY...
PRIVACY OFF
SPECIAL ...
PRESET ...
EXIT QUIT
CAMERA ID OFF
IRIS ALC...
SHUTTER OFF
AGC HIGH
WHITE BAL ATW2
FOCUS MODE AF
MOTION DET OFF
DAY/NIGHT DAY...
PRIVACY OFF
SPECIAL ...
PRESET ...
EXIT QUIT
SCC-C4333_Eng-EURO.indd 20 2007-11-12 오전 10:18:25
