Samsung SCC-C7433(P) User manual

User’s Guide
SCC-C7433(P)/C7435(P)
SmartDome Camera (Outdoor type)
ENG RUS POL
SCC-C7435-EEU.indb 1 2008-09-12 오전 10:44:52

1
2
This symbol indicates that dangerous
voltage consisting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying this unit.
WARNING
• To reduce the risk of re or electric shock, do
not expose this appliance to rain or moisture.
WARNING
1. Be sure to use only the standard adapter
that is specied in the specication sheet.
Using any other adapter could cause re,
electrical shock, or damage to the product.
2. Incorrectly connecting the power supply or
replacing battery may cause explosion, re,
electric shock, or damage to the product.
3. Do not connect multiple cameras to a single
adapter. Exceeding the capacity may cause
abnormal heat generation or re.
4. Securely plug the power cord into the
power receptacle. Insecure connection
may cause re.
5. When installing the camera, fasten it
securely and rmly. A falling camera may
cause personal injury.
6.
Do not place conductive objects (e.g.
screwdrivers, coins, metal things, etc.) or
containers lled with water on top of the
camera. Doing so may cause personal injury
due to re, electric shock, or falling objects.
7. Do not install the unit in humid, dusty, or
sooty locations. Doing so may cause re
or electric shock.
8. If any unusual smells or smoke come
from the unit, stop using the product. In
such case, immediately disconnect the
power source and contact the service
centre. Continued use
in such a condition may cause re or
electric shock.
Safety Precautions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
SCC-C7435-EEU.indb 1 2008-09-12 오전 10:44:52

1
ENG
2
9. If this product fails to operate normally,
contact the nearest service centre. Never
disassemble or modify this product
in any way. (SAMSUNG is not liable
for problems caused by unauthorized
modications or attempted repair.)
10. When cleaning, do not spray water
directly onto parts of the product. Doing
so may cause re or electric shock.
CAUTION
1. Do not drop objects on the product or
apply strong shock to it. Keep away from
a location subject to excessive vibration
or magnetic interference.
2. Do not install in a location subject to
high temperature (over 60°C), low
temperature (below -45°C), or high
humidity. Doing so may cause re or
electric shock.
3. If you want to relocate the already
installed product, be sure to turn off the
power and then move or reinstall it.
4. Remove the power plug from the outlet
when then there is a lightning.
Neglecting to do so may cause re or
damage to the product.
5. Keep out of direct sunlight and heat
radiation sources. It may cause re.
6. Install it in a place with good ventilation.
7. Avoid aiming the camera directly towards
extremely bright objects such as sun,
as this may damage the CCD image
sensor.
8. Apparatus shall not be exposed to
dripping or splashing and no objects
lled with liquids, such as vases, shall be
placed on the apparatus.
9.
The Mains plug is used as a disconnect device
and shall stay readily operable at any time.
SCC-C7435-EEU.indb 2 2008-09-12 오전 10:44:52

3
4
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources
such as radiators, heat registers, or
other apparatus (including ampliers)
that produce heat.
9. Do not defeat the safety purpose of
the polarized or grounding-type plug.
A polarized plug has two blades with
one wider than the other. A grounding
type plug has two blades and a third
grounding prong. The wide blade or the
third prong is provided for your safety.
If the provided plug does not t into
your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories
specied by the manufacturer.
12. Use only with cart, stand, tripod, bracket,
or table specied by the manufacturer, or
sold with the apparatus.
13. Unplug this apparatus. When a cart is
used, use caution when moving the
cart/apparatus combination to avoid
injury from tip-over.
14. Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or been dropped.
SCC-C7435-EEU.indb 3 2008-09-12 오전 10:44:52

3
ENG
4
Overview ........................................................................................... 7
About this guide ............................................................................7
Product overview...........................................................................7
Main features .................................................................................7
Components...................................................................................7
CHECKING COMPONENTS IN THE PACKAGE.......................7
NAMES OF EACH PART ...........................................................8
Installation ....................................................................................... 9
Before installation .........................................................................9
THINGS TO KEEP IN MIND DURING INSTALLATION AND USE .......9
Initial setting ................................................................................10
CAMERA ADDRESS SETUP...................................................10
SETTING COMMUNICATION PROTOCOL.............................10
BAUD RATE SETTING ............................................................ 11
SETTING RS-422A/RS-485 TERMINATION ...........................12
Preparing the cable to connect to the SMARTDOME.............. 14
Note: Connector arrangement of the camera adaptor board ....... 16
Cable connection.........................................................................17
Separately sold products for installation..................................20
Installation precautions ..............................................................23
Installation....................................................................................23
Camera Setup................................................................................ 30
Camera set ...................................................................................34
CAMERA ID .............................................................................34
V-SYNC....................................................................................34
DAY/NIGHT..............................................................................35
MOTION DET...........................................................................38
ZOOM SPEED .........................................................................41
Contents
SCC-C7435-EEU.indb 4 2008-09-12 오전 10:44:52

5
6
DIGITAL ZOOM........................................................................41
DISPLAY ZOOM.......................................................................42
DISPLAY P/T............................................................................43
EXIT .........................................................................................43
Video set ......................................................................................44
IRIS ..........................................................................................44
ALC ..........................................................................................44
SHUTTER ................................................................................47
AGC..........................................................................................48
MOTION...................................................................................49
WHITE BAL..............................................................................50
FOCUS MODE.........................................................................51
SPECIAL ..................................................................................52
EXIT .........................................................................................54
Preset ...........................................................................................55
Zone set........................................................................................57
PRIVACY ZONE.......................................................................57
ZONE DIR SET ........................................................................58
ZONE AREA SET.....................................................................59
Auto set ........................................................................................62
AUTO PAN ...............................................................................62
PATTERN .................................................................................64
SCAN .......................................................................................65
AUTO PLAY..............................................................................66
Alarm set ......................................................................................67
ALARM PRIORITY SET...........................................................68
ALARM IN SET ........................................................................ 68
ALARM OUT SET .................................................................... 68
SCC-C7435-EEU.indb 5 2008-09-12 오전 10:44:52

5
ENG
6
AUTO SET ...............................................................................68
AUX OUT CONTROL...............................................................68
Other set ......................................................................................69
PROPORTIONAL P/T ..............................................................69
TURBO P/T ..............................................................................69
AUTO CAL ...............................................................................69
D-FLIP......................................................................................70
CAM RESET ............................................................................ 70
LANGUAGE .............................................................................70
PASSWORD.............................................................................71
RS-485 .....................................................................................72
Clock set ......................................................................................72
System info ..................................................................................73
Shortcut keys...............................................................................74
Product Specications............................................................... 77
SCC-C7435-EEU.indb 6 2008-09-12 오전 10:44:53

7
8
Overview
❚About this guide
This user guide includes basic instructions for
the product. It is recommended that all users
read this guide before use.
This guide is divided as follows:

“Overview” introduces the user guide and product
related information.

“Installation” explains how to set and install the
product.
 “Camera Setup” presents the structure of the
Setup menu for the SCC-C7433(P)/C7435(P)
including a detailed explanation of the functions
performed in each submenu.
 “Product Speci cations” provides the
specications of the product.
❚Product overview
This camera is a zoom lens built in smart
dome camera which provides you with the
best monitoring function in connection with
CCTV at banks or companies. This camera is
a high quality surveillance camera using x32
zoom lens and digital zoom IC, it can catch
clear images up to 510 times.
This camera uses an Alarm function for alert
situations and moving camera in the direction
you want, ZOOM-IN and ZOOM-OUT
functions can be remote controlled.
Note
SCC-C7433(P) does not support for WDR function.
❚Main features

Power: AC24V, 3A

Special functions

WDR to cover the full screen irregardless of its
brightness

DAY/NIGHT to improve the sensitivity by
automatic conversion into the black and white
mode at night or in the environment with low
illumination

White Balance to control the brightness to the
illumination

Backlight Compensation under spotlight or
utmost bright illumination

Auto Focus to automatically adjust the focus
to the subject movement

Privacy zone to hide a specic area for
personal privacy

PAN/TILT for precise control at high speed
❚Components
CHECKING COMPONENTS IN THE PACKAGE
Please check your camera and accessories
are included in the package. Those
components are as shown below:
SCC-C7433(P)/C7435(P) Holder Housing
User’s Guide Screws
Rod Coupling Cover Rear
Cover Front
SCC-C7435-EEU.indb 7 2008-09-12 오전 10:44:53

7
ENG
8
NAMES OF EACH PART
Your camera has the following components:
1. Cover Front
2. Cover Rear
3. Camera Body
4. Cover-dome
5. Alarm Output: N/O, COM, N/C, AO-2, AO-1, GND
6. Alarm Input (1~8): AI-8, AI-7, AI-6, AI-5,GND, AI-4, AI-3, AI-2, AI-1, GND
7. RS-485: TXD+, TXD-, RXD+, RXD-
8. Power Input: 24V, EARTH, 24V
9. Video Output
SCC-C7435-EEU.indb 8 2008-09-12 오전 10:44:54

9
10
❚Before installation
THINGS TO KEEP IN MIND DURING INSTALLATION AND USE
• Do not disassemble the camera on your own.
• Always be careful when handling the camera. Do not strike the camera by your sts or shake
it. Please be careful not to be careless when storing and operating it.
• Do not place or operate the camera in any wet environment such as rain or wet surfaces.
•
Do not clean the camera with rough sandpaper. Please always use a dry cloth when cleaning it.
• Put the camera in a cool area free from direct sunlight. Otherwise, the camera may be damaged.
• Power adaptor: 24V AC, 3.0A
• If the camera is installed or rebooted after a power failure under 0 ºC temperature condition, frost
may appear on the DOME cover. Also, PTZ initial error and bad image quality may be displayed
under -10 ºC.
• After the problems, the recovery will be performed as following:
(Conditions: No wind and under -45 ºC temperature which is guaranteed the normal operation)
1 It is possible to defrost the DOME cover within 3 hours after the power on.
2 For PTZ initial error, reboot will be executed every 10 minutes and the camera will work normally
within 3 hours after the power on.
※If PTZ error occurs after the initial boot, the message shown below will be displayed.
"WARMING UP NOW...", "PLEASE WAIT 10 MINUTES."
3 For bad image quality, the camera will work normally within 3 hours after the power on.
❚Initial setting
Setting up the Address of Smartdome
For the Address Setup of Smartdome, use “SW902”, “SW903”, and “SW904”.
You can set the address from 0 to 255. Set up the address digit for 100 with “SW902”, for 10
with “SW903”, for 1 with “SW904”.
For example, if the camera address is “1”, you can setup as follows.
Installation
SW902 SW903 SW904
SCC-C7435-EEU.indb 9 2008-09-12 오전 10:44:54

9
ENG
10
SETTING COMMUNICATION PROTOCOL
Use number 1~4 PIN of SW901 to set communication Protocol.
A : SAMSUNG HALF
B : SAMSUNG FULL
PIN
Comp PIN1 PIN2 PIN3 PIN4
A OFF OFF OFF OFF
BON OFF OFF OFF
COFF ON OFF OFF
DON ON OFF OFF
EOFF OFF ON OFF
F ON OFF ON OFF
G OFF ON ON OFF
H ON ON ON OFF
IOFF OFF OFF ON
JON OFF OFF ON
K OFF ON OFF ON
L ON ON OFF ON
M OFF OFF ON ON
N ON OFF ON ON
O OFF ON ON ON
P ON ON ON ON
1 2 3 4 5 6 7 8
ON
1 2
ON
(x1)
SW903
(x100)
SW901 TERMINATION
SW905
SW904
SW902
(x10)
SEE INSTRUCTION
MANUAL
0
9
8
7
6
5
4
3
2
1
0
9
8
7
6
5
4
3
2
1
0
9
8
7
6
5
4
3
2
1
<Top side of the Housing>
SCC-C7435-EEU.indb 10 2008-09-12 오전 10:44:54

11
12
BAUD RATE SETTING
Use PIN 5 and 6 of SW901.
The factory default setting is set to 9600BPS.
BAUD RATE PIN 5 PIN 6
4800 BPS ON ON
9600 BPS OFF ON
19200 BPS ON OFF
38400 BPS OFF OFF
SCC-C7435-EEU.indb 11 2008-09-12 오전 10:44:54

11
ENG
12
SETTING RS-422A/RS-485 TERMINATION
As it is shown in the structure map, when Controller and RS-422A/RS-485 is connected,
it should be terminated according to the Cable feature of impedance on the each end of the
transmitting line to transfer the signals in long distance by controlling the reection of the signals
to the lowest.
Note
Termination: using numbers 1 and 2 PIN, turn to ON and it will be terminated.
<RS-485 Half Duplex Organization>
Controller
Division n < 32 Termination
SW1-ON
CAM n CAM n-1 CAM 2CAM 1
TX+(DATA+)
TX-(DATA-)
RX- RX+RX+ RX- RX+ RX- RX+ RX-
SCC-C7435-EEU.indb 12 2008-09-12 오전 10:44:54

13
14
Note
A communication error may occur if you connect multiple cameras that are assigned the same address
in the network.
Controller
CAM 1
<RS-422A/RS-485 Full Duplex Organization>
CAM 2
CAM n-1 CAM n
Division
n < 32 Division
SW1-ON
SW2-ON
SCC-C7435-EEU.indb 13 2008-09-12 오전 10:44:55

13
ENG
14
Preparing the cable to connect to the SMARTDOME
See the wiring diagram of the Holder Housing and prepare cables for the SMARTDOME.
(Power adaptor: 24V AC, 3.0A)
<Wiring Diagram of the Holder Housing>
SCC-C7435-EEU.indb 14 2008-09-12 오전 10:44:55

15
16
<Holder Housing>
HOLDER HOUSING
SCC-C7435-EEU.indb 15 2008-09-12 오전 10:44:55

15
ENG
16
❚Note: Connector arrangement of the camera adaptor board
1
3
4
5
14
13
12
11
9
8
7
6
5
4
3
2
1
4
3
2
1
6
SCC-C7435(P) Adapter Board
SCC-C7435-EEU.indb 16 2008-09-12 오전 10:44:55

17
18
❚Cable connection
1. First, connect one end of the BNC video cable connector to the Video Output Terminal
(VIDEO OUT).
2. Then, connect the other end of the connector to the Video Input Terminal of the monitor.
IN
OUT
Video terminal on the
rear of monitor
BNC Cable
SCC-C7435-EEU.indb 17 2008-09-12 오전 10:44:56

17
ENG
18
3. Connect the Power Adapter to the Power Cable of the camera.
4. Adjust the switch on the Power Adapter to the proper voltage. Then, connect the Power
Adapter's plug to the Power Connector. (Power adaptor: 24V AC, 3.0A)
7


)
5
3
"
&
7


7
&"35)
7
Power Selection Switch
under the Power Adaptor
Power Selection Switch
under the Power Adaptor
SCC-C7435-EEU.indb 18 2008-09-12 오전 10:44:56

19
20
5. Connect the Remote Control Terminal of the camera and the external Controller.
59%
59%
39%
39%
Adapter Cable
Controller
SCC-C7435-EEU.indb 19 2008-09-12 오전 10:44:56
