Dimensions (unit : in)
Front/Rear Panel
SAMSUNG | GVI Security • Toll Free: 888-595-2288 • Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice • v2.6.09
Specications
SCC-B9371
1/3” High Resolution, Day/Night, Vari-Focal, Weather
Resistant, Bullet IR Camera
Camera Type Color/BW Bullet IR Camera
Image Device Super HAD Sony CCD
Size 1/3“
Pixels – Effective 768 (H) x 492 (V)-380K Pixels
Scanning System 525 lines, 2:1 Interlace
Min. Scene Illumination Color 0.4 Lux @ 15IRE (F1.2)
1.3 Lux @ 50IRE (F1.2)
B/W 0 Lux @ 15IRE (F1.2)
0 Lux @ 50IRE (F1.2)
Shutter speed 1/60 sec
Functions AGC Built In
IR 36
CDS Photocell Auto Switch
Lens Size 3.8~9.5mmVarifocal, DC Auto
Iris F1.2
Resolution Horizontal 540(Color) / 570(B/W) TVL
Video Output VBS 1.0Vp-p VBS 1.0Vp-p (75 Ohm Load)
S/N Ratio S/N Ratio Greater Than 48dB (AGC off)
Environmental Conditions Operating Temperature -10˚ ~ 50˚C (14˚ ~ 122˚F)
Power Power Requirement 12VDC/ AC24V
Power Consumption AC24V 2.5VA~7.2VA max./
IR LED On
12VDC 240mA~600mA max/
IR LED On
Physical Specification Dimensions (øxL) 2.87 x 4.80 in / 73 x 122 mm
Weight 3.2 Ib / 1.45 kg
3.36
2.87
4.8
1.43 3.22
3.74
Day/Night Function
The Day/Night function automatically switches to color mode during the day and to
black and white mode during the night depending on the level of illumination which
makes it ideally suitable for 24/7 surveillance.
Day Night
Weather Resistant (IP66)
The SCC-B9371 is suited for external installation, thanks to its special structure that
resists water and dust
Summary
The SCC-B9371 Vari-Focal bullet camera with infrared illuminators is the
perfect choice for installations where night lighting is very low or does not
exist at all. The 36 LEDs provide powerful illumination that have a range of
up to 75 feet to light up the night and maintain a clear sharp picture.
The camera comes equipped with a 3.8 ~ 9.5mm Vari-Focal DC auto iris
lens and a mounting bracket.
The externally adjustable variable focal length and focus functions of the
camera make the installation more fast and convenient. The camera is IP66
rated for weather resistance that allows it to be used for both indoor and
outdoor applications.
Features
• 1/3 Inch Super HAD CCD
• 540TV Lines (Color) / 570TV Lines (B/W) Resolution
• Minimum Scene Illumination: 0.4 Lux Color/ 0 Lux B/W @ 15IRE, (F1.2)
• 3.8~9.5mm Vari-Focal, DC Auto Iris Lens
• Color & B/W Auto Switchable By Photocell and Sensitivity
• Externally Adjustable Focal Length & Focus By Side Screws
• Externally Adjustable DC Iris Level
• 36 IR LED with CDS Photocell Auto Switch
• 55~75ft range effective IR illumination
• Weather Resistant (IP66)
• AC24V/DC12V
Recommended Accessories
GV-TRAN-24-40LED, 24VAC, 40VA, Class II plug in transformer
*See accessories page for more options
