Samsung SCC-C7478 User manual

SCC/SNC-C7478 Installation Guide
SAMSUNG | GVI Security, Inc .
Phone: [phone] • Toll Free: 888-595-2288 • Fax: [phone]
www.samsung-security.com
v.11.19.08
SCC/SNC-C7478
Installation Guide
36x PTZ Dome Camera

Connection for power
RJ-45 Connection
7. Pull retractable safety cable
from bottom of camera and
insert into hook, inside upper
housing. (figure 7a)
1. Remove junction box cover with supplied hex tool to view inner connection block. (figure 1a)
Inner connection block exposes connections for power, video, alarm input/output as well
as dip switches for selecting camera ID, protocol, baud rate and termination. (figure 1b) See
manual for proper settings.
2. Attach wall mount to wall with supplied anchor bolts and make connections.
Inner Box connections
*Note for RS-485 Connection:
GVI uses solid colored wire to represent posi-
tive (+) and striped wire for negative(-) polar-
ity. Regardless of the wire color you choose
make sure polarity matches on oth ends of
the connection
Cable connection for dome. Connect
cable from mount into upper housing
Inside view of upper housing
3. Remove camera mechanism from upper housing. (figure 3a)
4. Use Teflon tape (included) to wrap around pipe fitting. (figure 4a)
5. Attach safety cable to neck of mount. (figure 5a)
6. Attach other end of safety cable to housing (figure 6a) and now screw in upper
housing to mount pole, bring in cable from pole mount and attach. (figure 6b)
afety cable to mount
Teflon tape for tight connection
afety cable to housing
1a
1b
2a
2b
4a
5a
6a
3a
Retractable safety cable
6b
7a
SCC/SNC-C7478 Installation Guide
SAMSUNG | GVI Security, Inc .
Phone: [phone] • Toll Free: 888-595-2288 • Fax: [phone]
www.samsung-security.com
v.11.19.08

9. Attach fan and heater cables inside upper housing and attach dome cover safety
cable. (figure 9a)
10. Return PTZ camera mechanism into upper housing by pressing the
two black handles until camera mechanism snaps into
place. (figure 10a)
11. Close the dome cover by matching the arrow markers. Be sure internal
cabling does not obstruct camera’s movement.
12. Orientation of housing my be adjusted by rotating the ring on which the
safety cable is attached.
(figure 12a)
Completed mounted camera
Fan/heater cable
afety Cable
9a
10a
12a
Remove plastic covering carefully and power dome with 24 VAC 2.5 amps
SCC/SNC-C7478 Installation Guide
SAMSUNG | GVI Security, Inc .
Phone: [phone] • Toll Free: 888-595-2288 • Fax: [phone]
www.samsung-security.com
v.11.19.08

SNC-C7478 Setup Guide
SAMSUNG | GVI Security, Inc .
Phone: [phone] • Toll Free: 888-595-2288 • Fax: [phone]
www.samsung-security.com
v.11.19.08
IP Setup Guide
36x PTZ IP Dome Camera
SNC-C7478
1. Plug the included cross-over cable into the RJ-45 jack located inside the
inner connection block. (figure 1a)
2. Plug the other end of the cross-over cable into the RJ-45 jack on back of
your computer. (figure 2a)
3. From included CD, run the application titled IPInstaller. This will open a
window and scan your computer to locate the default IP address and subnet
mask assigned to the IP dome. (figure 3a)
4. Once camera has been identified within the window, you may view the default IP settings by first selecting
(clicking) the camera entry in the window, then choosing Manual Set in the lower right of the IPInstaller
window. Make note of the camera IP Address and the Subnet
Mask. You will refer to these in future steps. (figure 4a) After
these values have been viewed and written down, you may can-
cel from the Manual Setting window and you may exit the
IPInstaller.
5. Next you will need to set your computer with a static IP address
as well as set your Subnet Mask to the same value as the IP PTZ
Dome Camera. (Subnet Mask value from previous step)
6. From your computer’s Control Panel go to Network and Internet Connections. Enter Network Connections
so that you are able to view all available Network Connections. Your screen should look similar to the
figure below. (figure 6a)
1a
2a
3a
4a
6a

SNC-C7478 Setup Guide
SAMSUNG | GVI Security, Inc .
Phone: [phone] • Toll Free: 888-595-2288 • Fax: [phone]
www.samsung-security.com
v.11.19.08
7. Double click on Local Area Connection to bring up the Local Area Connection Status
box. (figure 7a) Click Properties in the lower left corner to display Local Area Connection
Properties.
8. From the Local Area Connection Properties window, double click
Internet Protocol (TCP/IP) to display Internet Protocol (TCP/IP)
Properties. (figure 8a)
9. Choose the option for Use the Following IP Address and type an
IP address that begins with 192.168.1. but use a number other
than the ending number assigned to the camera. (number must fall
between 1 and 255) (figure 9a)
10. Type the subnet mask, this number must be the same as the
camera’s subnet mask, then choose OK at the bottom of the Inter-
net Protocol (TCP/IP) Properties box.
11. You may now close out of the Network Connections window.
12. After the above steps have been completed you may now use Microsoft’s Internet Explorer to enter the
camera’s setup menu.
13. Open an Internet Explorer window. In the address bar at the top of the window type HTTP:// followed by
the IP address assigned to your camera. (This value was obtained in step 4) (figure 13a)
14. See users manual for full explanation of menus and
settings.
15. Once you have finished with camera setup and have
exited from browser, be sure to go back into your
network settings and return all of your settings to
normal.
Accessing the Camera Menu from Internet Explorer
7a
8a
9a
13a
