Samsung SCD-3080 Series User manual

High Resolution Varifocal Dome Camera SCD-3080 User Guide
ENGLISH
Before installing and operating this product,
please read this manual thoroughly.
High Resolution WDR Dome Camera SCD-3080 User Guide
Before installing and operating this product,
please read this manual thoroughly.
ENGLISH

I
fo
d
e
u
a
c
O
in
o
W
W


Before operating the camera, confirm the camera model and correct input power
voltage. To help you understand this manual thoroughly, we'll introduce our model
description.
 SCD-3080 SERIES
• NTSC MODELS • PAL MODELS
SCD-3080N
SCD-3080P
 MODEL DESCRIPTION
• SCD-3080X
_
• SIGNAL SYSTEM
N ĄNTSC MODEL
P ĄPAL MODEL
SIGNAL SYSTEM

This installation should be made by a qualified service person and
should conform to all local codes.
The lightning flash with an arrowhead symbol, within an equilateral triangle
is intended to alert the user to the presence of uninsulated “dangerous
voltage” within the product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the
equipment.
WARNING - To prevent electric shock and risk of fire hazards:
 Do NOT use power sources other than that specified.
 Do NOT expose this appliance to rain or moisture.
r
el

COLOR DOME CAMERA SCD-3080
4
Contents
Contents
• Features  ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
•
Precautions ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
•
Components and Accessories ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
•
Overview  ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
• Installation  ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 

■Installation
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ

■Adjust the panning and tilting, rotating while watching the monitor
ÄÄÄ 

■Connecting to Monitor
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 

■Connecting to Power
 ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 

■Using Coaxial Communications
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
• Operating Your Camera ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 

■Menu Configuration
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 

■Menu Setup
 ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
LENS ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
EXPOSURE ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
WHITE BAL ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
BACKLIGHT ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
SSNR3  ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
DAY/NIGHT ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
PROFILE ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
SPECIAL ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
 Â
EXIT ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
• Troubleshooting ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
•
Specifications  ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 
•Dimension ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ 

COLOR DOME CAMERA SCD-3080
5
Features
Day&Night (ICR)
This camera has a function that automatically selects the
mode that is appropriate for daytime or night-time
conditions.
The COLOR mode operates in daytime conditions to
provide optimum colors, and B/W mode operates in night-
time conditions to enhance the definition of the image.
SSNR3 (Samsung Super Noise
Reduction) Function
The high-performance SV-V DSP chip effectively
removes low-light gain noise and afterimage to
provide clear images even in dark environments.
Ultra High Resolution
By adopting a double-speed 410,000 pixel Sony CCD,
the camera produces clear picture quality with a
horizontal resolution of 600 TV lines for color, and 700
TV lines for B/W.
SSDR
(Samsung Super Dynamic Range)
For images with high contrast between bright and
dark areas from difficult lighting conditions such as
backlighting, this camera selectively illuminates
darker areas while retaining the same light level for
brighter areas to even out the overall brightness.
Intelligence
Without assistance from an external sensor, this
camera independently detects and traces objects
while examining stillness and movement to activate
the alarm.
Excellent Sensitivity
The built-in high sensitivity COLOR CCD produces a
clear image.
- Color : 0.3 Lux (50IRE, @F1.2),
0.0006LUX (SENS-UP, x512)
- B/W : 0.01 Lux (50IRE, @F1.2),
0.00002 LUX (SENS-UP, x512)
VPS(Virtual Progressive Scan)
Adopting Samsung’s unique development, the VPS
(Virtual Progressive Scan) enhances the sharpness of
moving subject’s outline. The VPS enables elective
output in progressive mode using the existing
interlaced input and effectively enhances the
sharpness of captured pictures from video and still
images. The function effectively removes blurred
outline problems resulting in excellent road
monitoring and improved license plate recognition.
WDR
By adopting a proprietary SV-V DSP chip, the camera
delivers clear, high quality pictures even when the
scene is backlight, by increasing exposure in dark
areas while decreasing it in bright areas; a corrected
image with clear details results.
PIP
PROFILE
You can set a mode according to the camera
installation conditions.
- BASIC, DAY/NIGHT, BACKLIGHT, ITS, INDOOR, USER
Displays a full-size image along with the thumbnail.

COLOR DOME CAMERA SCD-3080
6
T
o
OSD
The camera’s OSD is complimented by 19 languages.
- NTSC : English, Korean, Japanese, Spanish,
French, Portuguese, Taiwanese
- PAL : English, Chinese, German, Italian, French,
Spanish, Russian, Czech, Polish, Romanian,
Serbian, Swedish, Danish, Turkish,
Portuguese, Thai
DIS (Digital Image Stabilizer)
The DIS function compensates for any camera
movement, to produce more stable pictures.
Miscellaneous Functions
HLC(High Light Compensation), SENS-UP, REVERSE ,
D-ZOOM, SHARPNESS and PRIVACY functions are
provided.
Communication
Coaxial communication methods are supported.
- Protocol : Pelco Coaxitron
Contents
Features

COLOR DOME CAMERA SCD-3080
7
Samsung Techwin cares for the environment at all product manufacturing
stages to preserve the environment, and is taking a number of steps to provide
customers with more environment-friendly products. The Eco mark represents
Samsung Techwin's will to create environment-friendly products, and
indicates that the product satisfies the EU RoHS Directive.
This information is provided to ensure your safety and to prevent any losses, financial or
otherwise. Please read it carefully and use the product accordingly.
* For product inquiries, please contact the retail shop where you bought the camera. The use of equipment such as
an aerial ladder while providing after-sales service shall be at your expense.
* Separate the power plug during a thunder storm.
* This product is support equipment for surveillance system. Therefore, we can't compensate for material loss and/or
personal injuries by robbery, fire, natural disaster or other such events.
Ignoring this information may
result in material loss and/or
serious personal injuries including
death.
Indicates "Never Allowed."
Ignoring this information may
result in material loss and/or a
slight injuries.
Indicates "No Disassembling."
Warning/Attention/Special Mark Messages
s.
Warnings & Cautions

COLOR DOME CAMERA SCD-3080
8
Do not install under extreme
temperature conditions.
Do not install in high humidity
environment.
The lens is the most important component of
the camera. Be careful not to smear it with
fingerprints.
Severe lighting changes or flickering may hinder
normal camera operation.
May lower image quality.Use only under temperature conditions between
-10ºC and +50ºC. Provide good ventilation
when using in high temperature conditions.
Avoid touching the camera lens.
Do not drop the camera or subject it
to physical shock.
May damage the CCD.May cause a product malfunction.
Never keep the camera face to strong
light directly.
Do not install under unstable lighting
conditions.
Precautions
If
❶
➍

COLOR DOME CAMERA SCD-3080
9
• Exposure to a spotlight or an object emitting strong light may cause smear or blooming.
• Ensure that the power source complies with normal specifications before supplying it to
the camera.
Notes
Do not expose the camera to
radioactivity.
Do not expose the camera to rain or
other types of liquids.
If exposed to radioactivity, the CCD will fail. May cause a product malfunction.Wipe dry any
liquids. Liquids may contain minerals that are
corrosive to electronic components.
❶ High Resolution WDR Dome Camera SCD-3080
➋ Instruction Manual
➌ M4 Tapping Screw 3EA
➍
Installation Video Output Cable
❶
➍
➋➌
Components and Accessories
Before installing and operating this product,
please read this manual thoroughly.
High Resolution WDR Dome Camera SCD-3080 User Guide
Before installing and operating this product,
please read this manual thoroughly.
ENGLISH

COLOR DOME CAMERA SCD-3080
10
❶Pan Base : Control panning angle of camera.
➋Rotate Base : Control rotating angle of camera.
➌x3.9 Vari-focal Lens Module 2.8 ~ 11mm (F1.2)
➍Video Output Terminal to Monitor
➎
Function Setup switch : Display the menu on the screen and move the cursor to four
directions to confirm status or changing a selected item.
➏Video Output Jack ➐Power Input Terminal
➑MD Output Terminal : Motion detection signals are output through this terminal.
➒D & N Input Terminal : You can switch to Day & Night Mode by connecting an external
signal to this terminal.
❿Ground Terminal ⓫Dome Cover ⓬Shield Case
Overview
1
2
RED(MD_OUT
WHITE(EXT_DN)
BLACK(GND)
➑
➏
➐
➌
⓬❶
➍➎ ➋
⓫
➒
❿
• Be sure to connect the Day & Night input terminal to GND when using an external input.
Notes

COLOR DOME CAMERA SCD-3080
11
Installation
Installation
1) Separate the dome cover by turning anti-clockwise.
2) Separate the shield case by pulling from the camera body.
* To install the dome cover on the camera
body, turn the latches in locking direction
as shown in the figure-1.
Latch
Locking direction
[Figure-1]
Locking direction
(Clockwise)
Main Body
(Camera)
Shield Case
Dome cover
Unlocking direction
(Anti-clockwise)
• The installation should be done by qualified
service personnel or system installers.
• If the ceiling material is not strong enough to
hold the installation screws, the camera
may fall off. Reinforce the ceiling as needed.
• To change the position of the cable, take
away the Hole Cover and pass the cable
through.
Notes
Original position of
the cable
Hole Cover

COLOR DOME CAMERA SCD-3080
12
An arrow for installing
directions
When using the Ceiling bracket
[Figure-2]
M4 tapping
screw
Pan Base
fixation
screw
Unlocking
direction
M4 tapping
screw (provided)
Dome cover
CAMERA
Locking
direction
Ceiling bracket
1) Hold the ceiling bracket (located where the arrow
points to) and separate it from the main body of the
camera by rotating it anti-clockwise.
(refer to the picture in 'Notes' on page 11)
2) Place the separated ceiling bracket so that the
“Front” side faces the area to be monitored and
install it with the M4 tapping screws.
3) To combine the main body with the ceiling bracket,
make sure that the pan base fixation screw face the
opposite side of the “Front” side of the ceiling
bracket and rotate it clockwise.
4) Adjust the camera lens to face the area to be
monitored and fix the main body and the dome cover
by aligning the grooves and rotating the body
clockwise.
• If you want to install the camera with the ceiling bracket combined, fix it using two M4
tapping
screws at the side of the main body (refer to the [Figure-2] on page 12).
Notes
1
2








Installation

COLOR DOME CAMERA SCD-3080
13
Base
on
w
e
er
1) You can adjust the camera to any direction by using Pan, Tilt, Rotate mechanism.
• Pan Base moves by 176˚ to each side direction and 352˚ on the whole.
• Tilt Base covers total 73˚ angle(0˚ ~ 73˚).
• Rotate Base moves by 174° to each side direction and 348° on the whole.
2) Methods of adjustment
• Mounting on a wall
➊After mounting the camera on a wall, adjusting the panning angle so that the camera can face the direction
to monitor when tilted.
➋Adjust the tilting angle by rotating the tilt base.
➌Loosen the rotate base hold screw and adjust rotate base for the best view.
➍Tighten the rotate base hold screw.
• Mounting on a ceiling
➊After mounting the camera on a ceiling, adjusting the panning angle to the correct viewing position by rotating
the pan base.
➋Adjust the tilting angle by rotating the tilt base.
➌Loosen the rotate base hold screw and adjust rotate base for the best view.
➍Tighten the rotate base hold screw.
Adjust the panning and tilting, rotating while watching the monitor
73˚
174˚
176˚
Pan Base
Tilt Base
Rotate Base
174˚
176˚

COLOR DOME CAMERA SCD-3080
14
Connect the Video Output jack to the VIDEO-IN jack of monitor.
CCTV Camera Monitor
• As the connecting method varies with the instruments, refer to the manual supplied with the instrument.
• If necessary, you can connect the monitor to the REMOTE jack on the back of your camera.
• Only connect the cable when the power is turned off.
Connect the adaptor to the power input terminal as shown in the figure below.
The recommended adaptor specification for SCD-3080N/SCD-3080P is DC 12V / 500mA or AC
24V / 500mA.
Connecting to Monitor
Connecting to Power
---- Power Input
Terminal
• As shown in the table above, voltage decreases as the wire gets longer. Therefore use of
an excessively long adaptor output line for connection to the camera may affect the
performance of the camera.
* Standard voltage for camera operation : DC 12V ± 10%, AC 24V ±10%
* There may be some deviation in voltage drop depending on the type of wire and the manufacturer.
When the resistance value of copper wire is at [20˚C(68˚F)]
Copper wire size (AWG) #24(0.22mm2) #22(0.33mm2) #20(0.52mm2) #18(0.83mm2)
Resistance (Ω/m)
0.078 0.050 0.030 0.018
Voltage Drop (V/m)
0.028 0.018 0.011 0.006
Connection
•
•
•
For AC / DC power
• Since the power specification supports both AC
and DC, connect AC 24V, 500mA Adaptor or DC
12V, 500mA Adaptor.

COLOR DOME CAMERA SCD-3080
15
• Be sure to connect power only after all the installation is complete.
• Note that AC / DC adaptor is not supplied with camera.
• Ground should be connected to the GND terminal.
Notes
• Coaxial Communications System
• OSD Control method
Using Coaxial Communications
Distance Recommended Cable Specification
300m 3C2V(RG-59/U)
450m 5C2V(RG-6/U)
600m 7C2V(RG-11/U)
• Video Cable
The camera's video output port is connected to the monitor with a BNC coaxial
cable, shown below : If the distance between the camera and the monitor exceeds
the recommended maximum, please use an auxiliary video amp.
• It is recommended that pure copper coax cable is used and not copper coated
steel, as this will cause issues with the communication over the coaxial cable.
Notes
CAMERA DVR CONTROLLER
SET MENU/ENTER OSD KEY
UP UP KEY JOYSTICK UP
DOWN DOWN KEY JOYSTICK DOWN
LEFT LEFT KEY JOYSTICK LEFT
RIGHT RIGHT KEY JOYSTICK RIGHT
DVD
DVR
• : BNC
• ---- : RS-485

COLOR DOME CAMERA SCD-3080
16
Menu Configuration
MAIN SETUP
LENS úDC

EXPOSURE úBRIGHTNESS
 úSHUTTER  úAGC 
úSENS-UP úRETURN
WHITE BAL úATW
 úOUTDOOR  úINDOOR 
úMANUAL  úAWC→SET
BACKLIGHT úOFF
 úUSER BLC  úHLC
úSSDR  úWDR 
SSNR3 úON
 úOFF
DAY/NIGHT úAUTO
 úEXTERN  úCOLOR
úB/W
PROFILE
úBASIC  úDAY/NIGHT  úBACKLIGHT
úITS  úINDOOR  úUSER
SPECIAL
úIMAGE ADJ  úCAM TITLE  úSYNC
úINTELLIGENCE  úPRIVACY  úDIS 
úLANGUAGE  úRETURN
EXIT úSAVE
 úNOT SAVE  úRESET
U
1
Se
th
2
3
4
Operating Your Camera

COLOR DOME CAMERA SCD-3080
17
T
Use the Function Setup switch within the camera.
Menu Setup
1. Press the Function Setup switch.
• Main SETUP menu is displayed on the monitor screen.
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR3 ON
6.DAY/NIGHT AUTO
7.PROFILE BASIC
8.SPECIAL
9.EXIT SAVE
Select the function using
the Function Setup switch.
Change the status using
the Function Setup switch.
2. Select a desired function using the Function Setup switch.
• Place the cursor over a desired item.
3. Set up a selected item by using the Function Setup switch.
4. To finish the setting, select ‘EXIT’ and press the Function Setup switch .
Function Setup switch

COLOR DOME CAMERA SCD-3080
18
• An item with the  icon also has sub menus. To select a sub menu, select an item
with the icon and press the Function Setup switch.
•
An item with the --- icon is unavailable due to function settings.
Notes
MAIN SETUP
1.LENS DC
2.EXPOSURE
Using this function, you can control the screen brightness.
1. When the SETUP menu screen is displayed, select ‘LENS’ by using the Function Setup
switch so that the arrow indicates ‘LENS’.
2.
The Lens mode has sub menu site as listed below.
- BRIGHTNESS : Adjusts the video brightness.
- FOCUS ADJ : To adjust the lens focus correctly, you must activate the Focus Settings mode.
To activate the Focus Settings mode, adjust the lens focus, and then deactivate the settings mode.
You can adjust the shutter value of ESC shutter mode.
LENS
• Set the shutter mode to --- if color rolling occurs.
Notes
MAIN SETUP
1.LENS DC
2.EXPOSURE
EXPOSURE
1. When the SETUP menu screen is displayed, select ‘EXPOSURE’ by using the Function
Setup switch so that the arrow indicates ‘EXPOSURE’.
2. Select a desired mode using the Function Setup switch.
Operating Your Camera

COLOR DOME CAMERA SCD-3080
19
.
EXPOSURE SETUP
1.BRIGHTNESS 25
2.SHUTTER ---
3.AGC HIGH
4.SENS-UP OFF
5.RETURN
BRIGHTNESS : Adjusts the video brightness.
SHUTTER : You can select the shutter.
- --- : Shutter speed is fixed at 1/60 sec (1/50 sec).
- ESC : Select this to control the shutter speed automatically. If ESC is selected,
the shutter speed is automatically controlled depending on the ambient
illumination of the subject.
- MANUAL : You can control shutter speed manually.
(NTSC MODEL - 1/60sec~1/120,000sec, PAL MODEL - 1/50sec~1/120,000sec)
- A.FLK : Select this when you experience picture flicker, this happen when there
is a clash with the installed lighting frequency.
• Set the shutter mode to --- if color rolling occurs.
• When the SHUTTER is set to ESC after selecting the Internal Synchronization Type, the
picture may become unstable if the camera faces a bright fluorescent light. Therefore,
take care when choosing the installation position.
• When the SHUTTER is set to MANUAL or A.FLK mode, SENS-UP will be disabled.
Notes
AGC(AUTO GAIN CONTROL) : The higher the gain level, the brighter the screen - but
the greater the noise.
- OFF : Deactivates the AGC function.
- LOW : Allows automatic gain control from 5.3dB to 32dB.
- HIGH : Allows automatic gain control from 5.3dB to 37dB.
SENS-UP : When it is night or dark, the camera automatically detects the light level
and maintains a clear picture if this mode is activated.
- OFF : Deactivates the SENS-UP function.
- AUTO : Activates the SENS-UP function.

COLOR DOME CAMERA SCD-3080
20
Operating Your Camera
• If you set the Function Setup switch to ‘AUTO’ mode, You can adjust the brightness by
increasing or decreasing the shutter speed. (x2 ~ x512)
• Note that the higher the zoom level, the brighter the screen, but the more likely it is that
an after-image will appear.
• Although Noise, Spots and Whitish symptoms may occur in SENS-UP operation when
the zoom level is increased, this is normal.
Notes
RETURN : Select this to save the changes in the EXPOSURE menu and return to the
SETUP menu.
Use the White Balance function to adjust the screen color.
1. When the SETUP menu screen is displayed, select ‘WHITE BAL’ by using the Function
Setup switch so that the arrow indicates ‘WHITE BAL’.
2. Select a desired mode using the Function Setup switch.
WHITE BAL (White Balance)
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
öSelect one of the following 5 modes, as appropriate for your purpose.
ATW : Select this when the color temperature is between 1,700˚K and
11,000˚K.
OUTDOOR : Select this when the color temperature is between 1,700˚K and
11,000˚K. (sodium light inclusion)
INDOOR :
Select this when the color temperature is between 4,500˚K and 8,500˚K.
MANUAL : Select this to fine-tune White Balance manually. Set White Balance first by
using the ATW or AWC mode. After that switch to MANUAL mode, fine-
tune the White Balance and the Function Setup switch.
T
s
S
1
2
