Samsung SCP-3371 User manual

NETWORK
ANAlOguE
CAmERA
DVRlENSPERIPHERAlmONITORCONTROllER
ACCESS CONTROl
SySTEm
123
• High resolution of 600TV lines (Color), 700TV lines (B/W)
• Min. illumination [email protected] (Color), 0.07Lux (B/W)
• Powerful 37x zoom (3.5 ~ 129.5mm), Digital 16x
• WDR, VPS, True Day & Night (ICR), Intelligent video analytics, MD, SSNRIII
• IP66 (SCP-3371H)
• Coax : Pelco-C (Coaxitron), RS-485/422, 24V AC
600TVL 37x
D&N ICR
SCP-3371H SCP-3371
SCP-3371HN/3371N SCP-3371HP/3371P
VIDEO
Imaging Device 1/4" Ex-view HAD CCD (Double scan)
Total Pixels 811(H) x 508(V) 795(H) x 596(V)
Effective Pixels 768(H) x 494(V) 752(H) x 582(V)
Scanning System 2 : 1 Interlace
Synchronization Internal / Line lock
Frequency H : 15.734KHz / V : 59.94Hz H : 15.625KHz / V : 50Hz
Horizontal Resolution Color : 600TV lines, B/W : 700TV lines
Min. Illumination Color : [email protected] (50IRE), 0.001Lux (Sens-up, 512x)
B/W : [email protected] (50IRE), 0.0001Lux (Sens-up, 512x)
S / N Ratio 52dB (AGC off, Weight on)
Video Output CVBS : 1.0 Vp-p / 75Ωcomposite
LENS
Focal Length (Zoom Ratio)
3.5 ~ 129.5mm (Optical 37x)
Max. Aperture Ratio 1 : 1.6(Wide) ~ 3.9(Tele)
Angular Field of View H : 55.5°(Wide) ~ 1.59°(Tele) / V : 42.5°(Wide) ~ 1.19°(Tele)
Min. Object Distance 1.8m (5.91ft)
Focus Control Auto / Manual / One shot
Zoom Movement Speed
2.8sec (Wide to tele)
PAN / TILT
Pan Range 360° Endless
Pan Speed
Preset : 500°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
Tilt Range -5° ~ 185°
Tilt Speed
Preset : 500°/sec, Manual : 0.024°/sec ~ 120°/sec (Proportional zoom ratio)
Preset 255
Preset Accuracy ±0.1°
OPERATIONAL
On Screen Display English, Japanese, Spanish, French,
Portuguese,Taiwanese, Korean
English, French, German, Spanish,
Italian, Chinese, Russian, Polish,
Czech,Turkish, Portuguese
Camera Title Off / On (Displayed 12 characters)
Day & Night Auto (ICR) / External / Color / B/W
Backlight Compensation
Off / BLC / HLC / WDR
Wide Dynamic Range Low / Medium / High
Contrast Enhancement SSDR (Off / On)
Digital Noise Reduction SSNR
III (Off / On)
Digital Image Stabilization
Off / On
Motion Detection Off / On
Privacy Masking Off / On (8 programmable zones)
Sens-up (Frame Integration)
2x ~ 512x
Gain Control Off / Low / Medium / High / Manual
White Balance ATW / Outdoor / Indoor / Manual / AWC
Electronic Shutter Speed
1/60 ~ 1/120,000sec 1/50 ~ 1/120,000sec
Digital Zoom Off / On (1x ~ 16x)
Digital Flip Off / On
VPS Off / On
Intelligent Video Analytics
Off / Detection / Tracking / Fixed_Moved
PIP Off / On
Schedule Day / Time
Alarm 8 In 3 Out
Communication Coaxial control (SPC-300 compatible), RS-485/422
Protocol Coax : Pelco-C (Coaxitron)
RS-485/422 : Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell,Vicon,AD, GE
ENVIRONMENTAL
Operating Temperature / Humidity
-50°C ~ +55°C (-58°F ~ +131°F) / Less than 90% RH : SCP-3371H
-10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH : SCP-3371
Ingress Protection IP66 grade (SCP-3371H only)
ELECTRICAL
Input Voltage / Current 24V AC ±10%
Power Consumption Max. 15W / 60W (Fan & heater on) : SCP-3371H, Max. 15W : SCP-3371
MECHANICAL
Color / Material Ivory / Aluminum, Plastic (Dome Cover : Clear) : SCP-3371H
Ivory / Plastic (Dome cover : Clear) : SCP-3371
Dimensions (WxH) Ø220.0 x 293.6mm (Ø8.66" x 11.56") : SCP-3371H
Ø152.0 x 218.0mm (Ø5.98" x 8.58") : SCP-3371
Weight 3.1Kg (6.83 lb) : SCP-3371H, 1.6Kg (3.53 lb) : SCP-3371
0.7Lux
SCP-3371H/3371
High Resolution 37x WDR PTZ Dome Camera
Technical Specifications
Key Features
Accessories (Optional)
Dimensions Unit : mm (inch)
SCP-3371H
SCP-3371
FIRST EDITION 03-2013
* The latest product information / specification can be found at www.samsungsecurity.com
20.0 (0.79")
293.6 (11.56")
Ø220.0 (8.66")
Ø220.0 (8.66")
Ø220.0 (8.66")
Ø220.0 (8.66")
293.6 (11.56")
20.0 (0.79")
WDR
SBP-300WMSBP-300WM1 SBP-300CM SBP-300LM SBP-300B
SBP-300PM
SBP-300KM
SBP-301HM3
SHP-3701H
(SCP-3371)
SHP-3701F
27.6 (1.09")
218.0 (8.58")
Ø133.2 (5.24")
Ø152.0 (5.98")
Ø133.2 (5.24")
Ø152.0 (5.98")
218.0 (8.58")
27.6 (1.09")
