Samsung HW-C451 User manual

Crystal Surround Air Track
(Active Speaker System)
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
HW-C450
HW-C451

2
features
Active Speaker System
This unit features an Active Speaker System that provides high sound quality in a single slim unit.
This unit does not require any satellite loudspeakers or speaker cabling, which are normally associated with
conventional surround sound systems.
Multi-function Remote Control
The supplied remote control can be used to control the TV connected to this unit.
The remote control has a TV hotkey that enables you to perform various operations with the simple press of a button.
You can adjust the volume, change the channel or customize the navigation menu of the TV using this Multi-function Remote
Control.
Special Sound Field mode
You can select from 7 different sound field modes (NEWS, DRAMA, SPORTS, GAME, CINEMA, MUSIC and PASS
(Original Sound)) depending on the type of content you want to enjoy.
Compatibility with various audio Technologies
This unit employs decoders compatible with Dolby Digital, DTS (Digital Theater Systems) and SFE (Sound Field Effect).
− Dolby Digital
This is the standard audio signal format used on DVDs and other purely digital media.
This surround technology delivers high-quality digital audio of up to 5.1 discrete channels to produce a
directional and more realistic effect.
− DTS (Digital Theater Systems)
DTS provides a discrete 5.1 CH digital audio signal for both music and movie contents and uses less
compression than Dolby Digital for richer sound.
− SFE (Sound Field Effect) Using 32bit Audio Digital Signal Processing
Provides more realistic surround sound with normal stereo audio sources.
Wireless Subwoofer
Samsung’s wireless module does away with cables running between the main unit and the subwoofer.
Instead, the subwoofer connects to a compact wireless module that communicates with the main unit.

3
ENG
WHAT’S INCLUDED
Check for the supplied accessories below.
Optical Cable Audio Cable User's Manual
Bracket-Wall Mount Remote Control
/ Batteries (AAA size)
The accessories may look slightly different than those pictured above.▪
POWER TV POWER
VOL/CONTROL TV CH
AV SYNC DRC
MUTE
S.VOL
O/A
INPUT S/W
LEVEL
AUTO
POWER
MENU
EXIT
TOOLS
INFO
SOUND
MODE
DIMMER

4
safety information
SAFETY WARNINGS
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK).
NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates “dangerous voltage”
inside the product that presents a risk of
electric shock or personal injury.
This symbol indicates important instructions
accompanying the product.
WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture.
CAUTION : TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
•
This apparatus shall always be connected to a AC outlet with a protective grounding connection.
•
To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains
plug shall be readily operable.
CAUTION
•
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be
placed on the apparatus.
• The Mains plug is used as a disconnect device and shall stay readily operable at any time.

5
ENG
PRECAUTIONS
Ensure that the AC power supply in your house complies with the identification sticker located on the back of your product. Install your
product horizontally, on a suitable base (furniture), with enough space around it for ventilation (3~4 inches). Make sure the ventilation slots
are not covered. Do not place the unit on amplifiers or other equipment which may become hot. This unit is designed for continuous use.
In order to disconnect the unit completely from the power supply, remove the main plug from the wall outlet, especially when left unused
for a long period of time.
During thunderstorms, disconnect the AC main plug from the
wall outlet. Voltage peaks due to lightning could damage the unit.
Protect the product from moisture (i.e. vases) , and excess heat
(e.g.fireplace) or equipment creating strong magnetic or electric fields
Disconnect the power cable from the AC supply if the unit malfunctions.
Your product is not intended for industrial use. Use of this product is for
personal use only.
Condensation may occur if your product or disc has been stored in
cold temperatures. If transporting the unit during the winter,
wait approxi mately 2 hours until the unit has reached room temperature
before using.
Do not expose the unit to direct sunlight or other heat sources.
This could lead to overheating and malfunction of the unit.
The batteries used with this product contain chemicals that are harmful to
the environment.
Do not dispose of batteries in the general household trash.
The batteries used with this product contain chemicals that are harmful to
Phones
3.9 inch 3.9 inch
2.7 inch
3.9 inch

6
contents
FEATURES
2
2 Features
3 What’s included
SAFETY INFORMATION
4
4 Safety warnings
5 Precautions
GETTING STARTED
7
7 Before reading the user’s manual
DESCRIPTIONS
8
8 Front panel
9 Rear panel
REMOTE CONTROL
10
10 Tour of the remote control
CONNECTIONS
11
11 Installing the wall mount
12 Connecting the wireless subwoofer
13 Connecting the Crystal Surround Air Track
TROUBLESHOOTING
17
17 Troubleshooting
APPENDIX
18
18 Specifications
FUNCTIONS
14
14 Basic functions
14 Advanced functions
16 Software upgrade

7
ENG
●GETTING STARTED
BEFORE READING THE USER’S MANUAL
Make sure to check the following terms before reading the user manual.
Icons that will be used in manual
Icon Term Definition
Caution
This involves a case where a function does not operate or settings may be
canceled.
Note
This involves tips or instructions on the page that help each function operate.
About the use of this user’s manual
Be sure to be familiar with Safety Instructions before using this product. ( See page 4 )
If a problem occurs, check the Troubleshooting. ( See page 17 )
Copyright
©2010 Samsung Electronics Co.,Ltd.
All rights reserved; no part or whole of this user’s manual may be reproduced or copied without the prior
written permission of Samsung Electronics Co.,Ltd.
1)
2)
getting started

8
descriptions
FRONT PANEL
DISPLAY Displays the current mode.
POWER BUTTON Turns the Crystal Surround Air Track on and off.
VOLUME +/- Controls the volume level.
SOUND FIELD
MODE
Selects the sound field mode.
(NEWS, DRAMA, SPORTS, GAME, CINEMA, MUSIC and
PASS(Original Sound))
INPUT MODE Selects the Optical or Audio input.
When you turn on the power of this unit, there will be a 4 to 5 second delay before it can
reproduce sound.
▪
2
3451

9
ENG ●DESCRIPTION
REAR PANEL
USB PORT You can update this unit through the USB port.
POWER SUPPLY
CABLE Plug the power supply cable into the AC wall outlet.
AUDIO IN JACK Connect to the analog output of an external device.
OPTICAL DIGITAL IN
1,2 Connect to the digital (optical) output of an external device.
When disconnecting the power cable from the wall outlet, hold the plug.
Do not pull the cable.
Do not connect this unit or other components to the main power until all connections
between components are complete.
▪
▪
ONLYFOR UPDATE
1
2
3
4

10
remote control
TOUR OF THE REMOTE CONTROL
The remote control can operate TVs made by SAMSUNG only.
Depending on the TV you are using, you may not be able to operate your TV with this
remote control. In this case, operate the TV using the TV's remote control.
▪
▪
Installing batteries in the Remote Control
1. Lift the cover at the back of
the remote control upward as
shown.
2. Install two AAA size batteries.
Make sure to match the “+” and “–” ends
of the batteries with the diagram inside the
compartment.
3. Replace the cover.
Assuming typical TV usage,
the batteries last for about
one year.
Operation Range of the Remote Control
The remote control can be used up to approximately 23 feet (7 meters) in a straight line. It can also be operated at a
horizontal angle of up to 30° from the remote control sensor.
POWER BUTTON
Turns the Crystal Surround
Air Track on and off.
ADJUST THE TV
NAVIGATION MENU
Adjusts and selects an item
of the navigation menu on
your Samsung TV.
VOL/CONTROL
Adjusts the volume level of
the unit.
O/A INPUT
Selects the Digital ( Optical)
or the Audio input.
SMART VOLUME
Regulate and stabilize the
volume level against a
drastic volume change.
TV POWER BUTTON
Turns your Samsung TV on
and off.
SOUND MODE
Selects the sound field mode.
(NEWS, DRAMA, SPORTS,
GAME, CINEMA, MUSIC and
PASS(Original Sound))
TV CHANNEL
Switches between the
available TV channels.
MUTE
Mutes the sound from the unit.
Press again to restore the
sound to the previous volume
level.
AUTO POWER LINK
Synchronizes to turn the
unit on with the optical
signal from the TV.
POWER TV POWER
VOL/CONTROL TV CH
AV SYNC DRC
MUTE
S.VOL
O/A
INPUT S/W
LEVEL
AUTO
POWER
MENU
EXIT
TOOLS
INFO
SOUND
MODE
DIMMER
S/W LEVEL
Adjusts the Subwoofer
level.
DRC/DIMMER
You can use this function to
enjoy Dolby Digital sound
when watching movies at
low volume at night
(Standard, MAX, MIN).
You can control the
brightness of the Display.
AV SYNC
Used to help sync video to
audio when connected to a
digital TV.
