Samsung Galaxy Tab S SM-T805 User manual

N
GSM TELEPHONE
SM-T805
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1Repair
7. Level 2Repair
8. Level 3Repair
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti
-es of the product are subject to change without
notice. Samsung reserves the right to alter this doc
-ument or the product described herein at anytime,
without obligation to provide notification of such
changes.
GSM TELEPHONE CONTENTS

1. Safety Precautions
1-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of
the low margin of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use asoldering iron with apower rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replac
ement parts may not function properly.

Safety Precautions
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
1-2
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discha
rge and can be easily damaged by it. We recommend protecting these components with cond
uctive anti-static bags when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are
properly connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

2. Specification
2-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2-1. GSM General Specification
GSM850 EGSM 900 DCS1800 PCS1900 WCDMA
2100 WCDMA 900 WCMDA 850 WCDMA 1900
Freq.
Band[MHz]
Uplink/
Downlink
824~849
869~894 880~915 925~960 1710~1785 1805~1880 1850~1910 1930~1990 1922~1977 2112~2167 880~915 925~960 824~849 869~894 1852~1907 1932~1987
ARFCN
range 128~251 0~124 &
975~1023 512~885 512~810 UL:
9612~9888
DL:
10562~10838
UL:
2712~2863
DL:
2937~3088
UL:
4132~4233
DL:
4357~4458
UL:
9612~9888
DL:
10562~10838
Tx/Rx
spacing 45MHz 45MHz 95MHz 80MHz 190MHz 45MHz 45MHz 80MHz
Mod. Bit
rate/
Bit Period
270.833kbps
3.692us 270.833kbps 3.692us 270.833kbps 3.692us 270.833kbps 3.692us 3.84Mcps 3.84Mcps 3.84Mcps 3.84Mcps
Time Slot
Period/
Frame
Period
576.9us
4.615ms 576.9us 4.615ms 576.9us 4.615ms 576.9us 4.615ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
FrameLength:
10ms
Slotlength:
0.667ms
Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSKHQPSK QPSKHQPSK QPSKHQPSK QPSKHQPSK
MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm 24dBm~
-50dBm 24dBm~ -50dBm 24dBm~ -50dBm 24dBm~ -50dBm
Power Class 5pcl ~ 19pcl 5pcl ~19
pcl 0pcl ~15
pcl 0pcl ~15 pcl 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)
Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -103.7dBm -104.7dBm -104.7dBm
TDMAMux8888----
Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km 2Km 2Km

Specification
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
2-2
2-2. GSM Tx Power Class
TX Power
control
level
GSM850
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
EGSM900
533±2
dBm
631±2
dBm
729±2
dBm
827±2
dBm
925±2
dBm
10 23±2 dBm
11 21±2 dBm
12 19±2 dBm
13 17±2 dBm
14 15±2 dBm
15 13±2 dBm
16 11±3 dBm
17 9±3dBm
18 7±3 dBm
19 5±3 dBm
TX Power
control
level
DCS1800
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm
TX Power
control
level
PCS1900
030±3
dBm
128±3
dBm
226±3
dBm
324±3
dBm
422±3
dBm
520±3
dBm
618±3
dBm
716±3
dBm
814±3
dBm
912±4
dBm
10 10±4 dBm
11 8±4 dBm
12 6±4 dBm
13 4±4 dBm
14 2±5 dBm
15 0±5 dBm

Specification
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
2-3
2-3. LTE General Specification
LTE Band1 LTE Band3 LTE Band5 LTE Band7 LTE Band8 LTE Band20
Freq.
Band[MHz]
Uplink/
Downlink
1920~1980
2110~2170 1710~1785 1805~1880 824~849 869~894 2500~2570 1805~1880 880~914.9 925~959.9 832~862 791~821
ARFCN
range
UL:
18000~18599
DL:
0~599
UL:
19200~19950
DL:
1805~1880
UL:
20400~20649
DL:
2400~2649
UL:
2500~2570
DL:
2620~2690
UL:
21450-21799
DL:
3450-3799
UL:
24150~24450
DL:
6150~6450
Tx/Rx
spacing 190MHz 95MHz 45MHz 120MHz 45MHZ 41MHz
Channel
Bandwidth 5/10/15/20 MHz 1.4/3/5/10/15/20 MHz 1.4/3/5/10 MHz 5/10/15/20 MHz 1.4/3/5/10MHz 5/10/15/20 MHz
Modulation QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM QPSK,16/64QAM
MS Power
(MPR) -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm -35~25.7 dBm
Sensitivit
(QPSK)
(BW 10MHz) -94 dBm -92 dBm -92 dBm -95dBm -95dBm -94dBm
Cell Radius >5Km >5Km >5Km >5Km >5Km >5Km

3. Operation Instruction and Installation
3-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Main Function
•Android OS: KitKat (4.4)
• 10.5" WQXGA On-Cell Touch AMOLED (OCTA)
•A-GPS /GLONASS /BT v4.0 +EDR with LE /USB v2.0 /Wi-Fi (802.11 a/b/g/n/ac VHT80) /MHL 2.1 / OTG
•Main 8.0 MP, Sub 2.0 MP
•Recording definition: 1080p
•Sensors: Accelerometer, Gyro, Geomagnetic, Light Sensor, Fingerprint
•Additional :
-Octa core AP (1.9 GHz Quad Core /1.3
GHz Quad Core)
-CP (LTE baseband controller)

4. Exploded View and Parts List
4-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4-1. Cellular phone Exploded View

5. MAIN Electrical Parts List
5-1
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
SEC CODE Design Location Description
0403-001688 ZD500 DIODE-ZENER
0403-001688 ZD700 DIODE-ZENER
0404-001250 D501 DIODE-SCHOTTKY
0404-001782 D500 DIODE-SCHOTTKY
0404-001782 D502 DIODE-SCHOTTKY
0406-001223 ZD711 DIODE-TVS
0406-001223 ZD712 DIODE-TVS
0406-001375 ZD501 DIODE-TVS
0406-001375 ZD502 DIODE-TVS
0406-001413 ZD702 DIODE-TVS
0406-001413 ZD703 DIODE-TVS
0406-001413 ZD709 DIODE-TVS
0406-001413 ZD710 DIODE-TVS
0406-001413 ZD716 DIODE-TVS
0406-001413 ZD717 DIODE-TVS
0406-001413 ZD718 DIODE-TVS
0406-001459 ZD701 DIODE-TVS
0406-001494 ZD606 DIODE-TVS
0406-001494 ZD607 DIODE-TVS
0406-001494 ZD608 DIODE-TVS
0406-001494 ZD611 DIODE-TVS
0406-001494 ZD613 DIODE-TVS
0406-001494 ZD614 DIODE-TVS
0406-001494 ZD615 DIODE-TVS
0406-001494 ZD616 DIODE-TVS
0406-001494 ZD707 DIODE-TVS
0406-001494 ZD800 DIODE-TVS
0406-001494 ZD801 DIODE-TVS
0406-001494 ZD802 DIODE-TVS
0406-001494 ZD803 DIODE-TVS
0406-001494 ZD804 DIODE-TVS
0406-001494 ZD807 DIODE-TVS
0406-001505 ZD600 DIODE-TVS
0406-001505 ZD601 DIODE-TVS
0406-001505 ZD602 DIODE-TVS
0406-001505 ZD603 DIODE-TVS
0406-001505 ZD604 DIODE-TVS
0406-001505 ZD605 DIODE-TVS
0406-001505 ZD708 DIODE-TVS
0406-001505 ZD713 DIODE-TVS
0406-001505 ZD714 DIODE-TVS
0406-001505 ZD715 DIODE-TVS

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-2
0406-001506 ZD720 DIODE-TVS
0406-001506 ZD721 DIODE-TVS
0406-001549 ZD704 DIODE-TVS
0406-001549 ZD705 DIODE-TVS
0505-002088 TR500 FET-SILICON
0505-002088 TR501 FET-SILICON
0505-002341 TR503 FET-SILICON
0505-002341 TR701 FET-SILICON
0505-002384 TR900 FET-SILICON
0505-002720 U700 FET-SILICON
0505-003070 TR700 FET-SILICON
0505-003234 TR600 FET-SILICON
0505-003234 TR601 FET-SILICON
0601-003398 LED500 LED
0801-003228 U508 IC-CMOS LOGIC
0801-003228 U509 IC-CMOS LOGIC
0801-003228 U510 IC-CMOS LOGIC
0801-003437 U1010 IC-CMOS LOGIC
0902-003074 UCP4001 IC-MICROPROCESSOR
1001-001394 U506 IC-ANALOG SWITCH
1107-002297 UME4000 IC-EMMC
1201-003642 PAM1002 IC-POWER AMP
1201-003645 PAM1001 IC-POWER AMP
1201-003729 U201 IC-GPS AMP
1202-001120 U600 IC-VOLTAGE COMP.
1203-002250 U504 IC-VOL. DETECTOR
1203-004776 U505 IC-POSI.FIXED REG.
1203-006182 U702 IC-VOL. DETECTOR
1203-006766 U203 IC-VOL. DETECTOR
1203-006766 U302 IC-VOL. DETECTOR
1203-006767 U903 IC-MULTI REG.
1203-007766 U1003 IC-DC/DC CONVERTER
1203-007791 U800 IC-POSI.FIXED REG.
1203-007791 U801 IC-POSI.FIXED REG.
1203-007823 U802 IC-DC/DC CONVERTER
1203-008004 U701 IC-VOL. DETECTOR
1203-008158 U502 IC-POWER SUPERVISOR
1203-008172 U500 IC-SWITCH REG.
1203-008193 U512 IC-POWER SUPERVISOR
1203-008217 U805 IC-DC/DC CONVERTER
1205-004753 U804 IC-TRANSMITTER
1205-004772 U602 IC-CODEC
1205-004863 UCP301 IC-MODEM

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-3
1205-004884 U1007 IC-TRANSMITTER
1205-004916 U904 IC-SWITCH
1205-005012 U206 IC-WIFI
1205-005016 U202 IC-GPS RECEIVER
1209-002245 U902 IC-SENSOR
1209-002246 U901 IC-SENSOR
1209-002252 U1009 IC-SENSOR
1301-002167 U900 IC-FPGA
1404-001694 TH4000 THERMISTOR-NTC
1404-001694 TH4001 THERMISTOR-NTC
1404-001694 TH4002 THERMISTOR-NTC
1404-001728 TH301 THERMISTOR-NTC
1405-001375 V1001 VARISTOR
2007-000148 R617 R-CHIP
2007-000148 R618 R-CHIP
2007-000148 R619 R-CHIP
2007-000169 R1005 R-CHIP
2007-000174 R904 R-CHIP
2007-000174 R905 R-CHIP
2007-000174 R906 R-CHIP
2007-000174 R907 R-CHIP
2007-000174 R908 R-CHIP
2007-000174 R909 R-CHIP
2007-000174 R910 R-CHIP
2007-000174 R911 R-CHIP
2007-000174 R912 R-CHIP
2007-000174 R913 R-CHIP
2007-001308 R4082 R-CHIP
2007-001308 R4109 R-CHIP
2007-001325 R613 R-CHIP
2007-001325 R614 R-CHIP
2007-003015 R502 R-CHIP
2007-007107 R314 R-CHIP
2007-007136 R4087 R-CHIP
2007-007136 R4088 R-CHIP
2007-007139 R807 R-CHIP
2007-007142 R514 R-CHIP
2007-007312 R4051 R-CHIP
2007-007312 R4054 R-CHIP
2007-007312 R4067 R-CHIP
2007-007312 R4071 R-CHIP
2007-007312 R4098 R-CHIP
2007-007312 R4099 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-4
2007-007312 R4100 R-CHIP
2007-007312 R4102 R-CHIP
2007-007318 R1025 R-CHIP
2007-007517 R4072 R-CHIP
2007-007517 R4073 R-CHIP
2007-007517 R4080 R-CHIP
2007-007517 R4081 R-CHIP
2007-007517 R4096 R-CHIP
2007-007517 R4097 R-CHIP
2007-007585 R202 R-CHIP
2007-007627 R919 R-CHIP
2007-007741 R4085 R-CHIP
2007-007741 R805 R-CHIP
2007-007942 R4008 R-CHIP
2007-007942 R4200 R-CHIP
2007-007946 R4201 R-CHIP
2007-008045 R511 R-CHIP
2007-008045 R525 R-CHIP
2007-008045 R707 R-CHIP
2007-008049 R710 R-CHIP
2007-008049 R719 R-CHIP
2007-008051 R705 R-CHIP
2007-008052 R4049 R-CHIP
2007-008052 R4050 R-CHIP
2007-008052 R4068 R-CHIP
2007-008052 R515 R-CHIP
2007-008052 R523 R-CHIP
2007-008052 R803 R-CHIP
2007-008052 R804 R-CHIP
2007-008052 R806 R-CHIP
2007-008052 R902 R-CHIP
2007-008052 R903 R-CHIP
2007-008055 R315 R-CHIP
2007-008055 R4031 R-CHIP
2007-008055 R4032 R-CHIP
2007-008055 R4034 R-CHIP
2007-008055 R4035 R-CHIP
2007-008055 R4036 R-CHIP
2007-008055 R4038 R-CHIP
2007-008055 R4084 R-CHIP
2007-008055 R700 R-CHIP
2007-008055 R711 R-CHIP
2007-008055 R724 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-5
2007-008057 R1002 R-CHIP
2007-008057 R1003 R-CHIP
2007-008403 R521 R-CHIP
2007-008419 R319 R-CHIP
2007-008419 R321 R-CHIP
2007-008419 R500 R-CHIP
2007-008419 R501 R-CHIP
2007-008420 R510 R-CHIP
2007-008420 R516 R-CHIP
2007-008420 R517 R-CHIP
2007-008420 R518 R-CHIP
2007-008420 R601 R-CHIP
2007-008420 R723 R-CHIP
2007-008478 R4015 R-CHIP
2007-008478 R4016 R-CHIP
2007-008483 R209 R-CHIP
2007-008483 R210 R-CHIP
2007-008483 R211 R-CHIP
2007-008483 R212 R-CHIP
2007-008483 R213 R-CHIP
2007-008483 R716 R-CHIP
2007-008483 R717 R-CHIP
2007-008483 R721 R-CHIP
2007-008483 R722 R-CHIP
2007-008486 R503 R-CHIP
2007-008486 R512 R-CHIP
2007-008486 R520 R-CHIP
2007-008516 R4001 R-CHIP
2007-008516 R4002 R-CHIP
2007-008516 R4003 R-CHIP
2007-008516 R4004 R-CHIP
2007-008516 R4022 R-CHIP
2007-008516 R4026 R-CHIP
2007-008516 R4027 R-CHIP
2007-008516 R4063 R-CHIP
2007-008516 R4086 R-CHIP
2007-008516 R4103 R-CHIP
2007-008516 R4104 R-CHIP
2007-008516 R4105 R-CHIP
2007-008516 R4106 R-CHIP
2007-008516 R4107 R-CHIP
2007-008516 R4108 R-CHIP
2007-008516 R4115 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-6
2007-008516 R513 R-CHIP
2007-008516 R701 R-CHIP
2007-008516 R704 R-CHIP
2007-008516 R706 R-CHIP
2007-008516 R720 R-CHIP
2007-008516 R900 R-CHIP
2007-008516 R901 R-CHIP
2007-008516 R915 R-CHIP
2007-008516 R916 R-CHIP
2007-008531 R4064 R-CHIP
2007-008531 R4079 R-CHIP
2007-008579 R205 R-CHIP
2007-008588 R1019 R-CHIP
2007-008588 R1020 R-CHIP
2007-008588 R1021 R-CHIP
2007-008588 R1022 R-CHIP
2007-008588 R1023 R-CHIP
2007-008588 R307 R-CHIP
2007-008588 R308 R-CHIP
2007-008588 R309 R-CHIP
2007-008774 R702 R-CHIP
2007-008774 R708 R-CHIP
2007-008774 R709 R-CHIP
2007-008798 R508 R-CHIP
2007-008806 R1006 R-CHIP
2007-008806 R1024 R-CHIP
2007-008808 R201 R-CHIP
2007-009084 R504 R-CHIP
2007-009084 R522 R-CHIP
2007-009084 R603 R-CHIP
2007-009084 R616 R-CHIP
2007-009084 R703 R-CHIP
2007-009084 R715 R-CHIP
2007-009111 R4069 R-CHIP
2007-009155 R316 R-CHIP
2007-009155 R726 R-CHIP
2007-009157 R4074 R-CHIP
2007-009157 R4075 R-CHIP
2007-009157 R4076 R-CHIP
2007-009157 R4077 R-CHIP
2007-009157 R4078 R-CHIP
2007-009157 R4089 R-CHIP
2007-009157 R4090 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-7
2007-009157 R4091 R-CHIP
2007-009157 R4092 R-CHIP
2007-009157 R4093 R-CHIP
2007-009157 R4094 R-CHIP
2007-009157 R4095 R-CHIP
2007-009157 R918 R-CHIP
2007-009171 R4053 R-CHIP
2007-009171 R4055 R-CHIP
2007-009171 R4056 R-CHIP
2007-009171 R4057 R-CHIP
2007-009171 R4058 R-CHIP
2007-009171 R4059 R-CHIP
2007-009171 R4060 R-CHIP
2007-009171 R4061 R-CHIP
2007-009171 R4062 R-CHIP
2007-009171 R4112 R-CHIP
2007-009171 R4113 R-CHIP
2007-009199 R1001 R-CHIP
2007-009199 R313 R-CHIP
2007-009212 R604 R-CHIP
2007-009223 R602 R-CHIP
2007-009233 R324 R-CHIP
2007-009361 R1004 R-CHIP
2007-009408 R4009 R-CHIP
2007-009408 R4010 R-CHIP
2007-009408 R4011 R-CHIP
2007-009408 R4012 R-CHIP
2007-009408 R4013 R-CHIP
2007-009408 R4014 R-CHIP
2007-009408 R4019 R-CHIP
2007-009408 R4020 R-CHIP
2007-009408 R4039 R-CHIP
2007-009408 R4040 R-CHIP
2007-009408 R4041 R-CHIP
2007-009408 R4042 R-CHIP
2007-009408 R4043 R-CHIP
2007-009408 R4044 R-CHIP
2007-009408 R4118 R-CHIP
2007-009408 R4119 R-CHIP
2007-009801 R1017 R-CHIP
2007-009801 R1018 R-CHIP
2007-009805 R1013 R-CHIP
2007-009920 R312 R-CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-8
2007-009969 R605 R-CHIP
2007-010233 R320 R-CHIP
2007-011511 R524 R-CHIP
2203-000233 C1014 C-CER,CHIP
2203-000233 C1015 C-CER,CHIP
2203-000233 C1119 C-CER,CHIP
2203-000233 C1123 C-CER,CHIP
2203-000386 C710 C-CER,CHIP
2203-000425 C1122 C-CER,CHIP
2203-000425 C633 C-CER,CHIP
2203-000438 C214 C-CER,CHIP
2203-000438 C707 C-CER,CHIP
2203-000489 C4099 C-CER,CHIP
2203-000489 C4100 C-CER,CHIP
2203-000725 C248 C-CER,CHIP
2203-000725 C597 C-CER,CHIP
2203-000812 C653 C-CER,CHIP
2203-000812 C654 C-CER,CHIP
2203-000812 C656 C-CER,CHIP
2203-000812 C813 C-CER,CHIP
2203-000995 C577 C-CER,CHIP
2203-000995 C580 C-CER,CHIP
2203-000995 C581 C-CER,CHIP
2203-001072 C711 C-CER,CHIP
2203-001101 C708 C-CER,CHIP
2203-001239 C632 C-CER,CHIP
2203-001383 C1016 C-CER,CHIP
2203-002677 C1093 C-CER,CHIP
2203-002687 C576 C-CER,CHIP
2203-002687 C578 C-CER,CHIP
2203-002687 C579 C-CER,CHIP
2203-005056 C1013 C-CER,CHIP
2203-005482 C563 C-CER,CHIP
2203-005682 C1003 C-CER,CHIP
2203-005682 C1092 C-CER,CHIP
2203-005682 C1107 C-CER,CHIP
2203-005682 C1108 C-CER,CHIP
2203-005682 C212 C-CER,CHIP
2203-005682 C712 C-CER,CHIP
2203-005682 C713 C-CER,CHIP
2203-005717 C1037 C-CER,CHIP
2203-005719 C1004 C-CER,CHIP
2203-005725 C201 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-9
2203-005725 C4102 C-CER,CHIP
2203-005725 C528 C-CER,CHIP
2203-005725 C551 C-CER,CHIP
2203-005725 C715 C-CER,CHIP
2203-005725 C716 C-CER,CHIP
2203-005725 C717 C-CER,CHIP
2203-005725 C839 C-CER,CHIP
2203-005726 C275 C-CER,CHIP
2203-005727 C272 C-CER,CHIP
2203-005727 C596 C-CER,CHIP
2203-005731 C4000 C-CER,CHIP
2203-005731 C4001 C-CER,CHIP
2203-005731 C649 C-CER,CHIP
2203-005731 C651 C-CER,CHIP
2203-005734 C648 C-CER,CHIP
2203-005734 C650 C-CER,CHIP
2203-005734 C702 C-CER,CHIP
2203-005736 C1002 C-CER,CHIP
2203-005736 C1020 C-CER,CHIP
2203-005736 C1025 C-CER,CHIP
2203-005736 C1035 C-CER,CHIP
2203-005736 C1038 C-CER,CHIP
2203-005736 C1056 C-CER,CHIP
2203-005736 C1077 C-CER,CHIP
2203-005736 C1104 C-CER,CHIP
2203-005736 C1106 C-CER,CHIP
2203-005736 C1110 C-CER,CHIP
2203-005736 C1112 C-CER,CHIP
2203-005736 C211 C-CER,CHIP
2203-005736 C213 C-CER,CHIP
2203-005736 C223 C-CER,CHIP
2203-005777 C1009 C-CER,CHIP
2203-005777 C1031 C-CER,CHIP
2203-005777 C221 C-CER,CHIP
2203-005777 C228 C-CER,CHIP
2203-005777 C276 C-CER,CHIP
2203-005777 C292 C-CER,CHIP
2203-005789 C1006 C-CER,CHIP
2203-005789 C1039 C-CER,CHIP
2203-005789 C258 C-CER,CHIP
2203-005792 C1008 C-CER,CHIP
2203-005792 C1010 C-CER,CHIP
2203-005792 C1034 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-10
2203-005792 C1109 C-CER,CHIP
2203-005792 C218 C-CER,CHIP
2203-006048 C4094 C-CER,CHIP
2203-006048 C4098 C-CER,CHIP
2203-006048 C833 C-CER,CHIP
2203-006194 C1096 C-CER,CHIP
2203-006194 C227 C-CER,CHIP
2203-006194 C291 C-CER,CHIP
2203-006194 C574 C-CER,CHIP
2203-006305 C208 C-CER,CHIP
2203-006305 C216 C-CER,CHIP
2203-006305 C225 C-CER,CHIP
2203-006305 C254 C-CER,CHIP
2203-006305 C271 C-CER,CHIP
2203-006305 C273 C-CER,CHIP
2203-006305 C277 C-CER,CHIP
2203-006305 C278 C-CER,CHIP
2203-006305 C279 C-CER,CHIP
2203-006305 C280 C-CER,CHIP
2203-006305 C281 C-CER,CHIP
2203-006305 C282 C-CER,CHIP
2203-006305 C283 C-CER,CHIP
2203-006305 C284 C-CER,CHIP
2203-006305 C285 C-CER,CHIP
2203-006305 C286 C-CER,CHIP
2203-006305 C287 C-CER,CHIP
2203-006305 C288 C-CER,CHIP
2203-006305 C289 C-CER,CHIP
2203-006305 C293 C-CER,CHIP
2203-006305 C295 C-CER,CHIP
2203-006305 C296 C-CER,CHIP
2203-006305 C719 C-CER,CHIP
2203-006399 C1021 C-CER,CHIP
2203-006399 C1022 C-CER,CHIP
2203-006399 C522 C-CER,CHIP
2203-006399 C718 C-CER,CHIP
2203-006399 C720 C-CER,CHIP
2203-006399 C721 C-CER,CHIP
2203-006399 C722 C-CER,CHIP
2203-006400 C1023 C-CER,CHIP
2203-006400 C1036 C-CER,CHIP
2203-006400 C1046 C-CER,CHIP
2203-006400 C1072 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-11
2203-006400 C1079 C-CER,CHIP
2203-006400 C1088 C-CER,CHIP
2203-006400 C1103 C-CER,CHIP
2203-006400 C1105 C-CER,CHIP
2203-006410 C1007 C-CER,CHIP
2203-006423 C1045 C-CER,CHIP
2203-006423 C1047 C-CER,CHIP
2203-006423 C1048 C-CER,CHIP
2203-006423 C1051 C-CER,CHIP
2203-006423 C1052 C-CER,CHIP
2203-006423 C1053 C-CER,CHIP
2203-006423 C1055 C-CER,CHIP
2203-006423 C1057 C-CER,CHIP
2203-006423 C1058 C-CER,CHIP
2203-006423 C1061 C-CER,CHIP
2203-006423 C1065 C-CER,CHIP
2203-006423 C1066 C-CER,CHIP
2203-006423 C1067 C-CER,CHIP
2203-006423 C1068 C-CER,CHIP
2203-006423 C1069 C-CER,CHIP
2203-006423 C1070 C-CER,CHIP
2203-006423 C1071 C-CER,CHIP
2203-006423 C1118 C-CER,CHIP
2203-006423 C206 C-CER,CHIP
2203-006423 C238 C-CER,CHIP
2203-006423 C240 C-CER,CHIP
2203-006423 C241 C-CER,CHIP
2203-006423 C305 C-CER,CHIP
2203-006423 C306 C-CER,CHIP
2203-006423 C307 C-CER,CHIP
2203-006423 C309 C-CER,CHIP
2203-006423 C310 C-CER,CHIP
2203-006423 C312 C-CER,CHIP
2203-006423 C316 C-CER,CHIP
2203-006423 C317 C-CER,CHIP
2203-006423 C318 C-CER,CHIP
2203-006423 C319 C-CER,CHIP
2203-006423 C320 C-CER,CHIP
2203-006423 C321 C-CER,CHIP
2203-006423 C322 C-CER,CHIP
2203-006423 C323 C-CER,CHIP
2203-006423 C324 C-CER,CHIP
2203-006423 C325 C-CER,CHIP

Main Electrical Parts List
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
Confidential and proprietary-the contents in this service guide subject to change without prior notice.
5-12
2203-006423 C326 C-CER,CHIP
2203-006423 C327 C-CER,CHIP
2203-006423 C328 C-CER,CHIP
2203-006423 C331 C-CER,CHIP
2203-006423 C332 C-CER,CHIP
2203-006423 C333 C-CER,CHIP
2203-006423 C334 C-CER,CHIP
2203-006423 C335 C-CER,CHIP
2203-006423 C338 C-CER,CHIP
2203-006423 C343 C-CER,CHIP
2203-006423 C348 C-CER,CHIP
2203-006423 C349 C-CER,CHIP
2203-006423 C351 C-CER,CHIP
2203-006423 C352 C-CER,CHIP
2203-006423 C354 C-CER,CHIP
2203-006423 C4003 C-CER,CHIP
2203-006423 C4004 C-CER,CHIP
2203-006423 C4007 C-CER,CHIP
2203-006423 C4011 C-CER,CHIP
2203-006423 C4013 C-CER,CHIP
2203-006423 C4015 C-CER,CHIP
2203-006423 C4017 C-CER,CHIP
2203-006423 C4030 C-CER,CHIP
2203-006423 C4032 C-CER,CHIP
2203-006423 C4043 C-CER,CHIP
2203-006423 C4048 C-CER,CHIP
2203-006423 C4051 C-CER,CHIP
2203-006423 C4053 C-CER,CHIP
2203-006423 C4060 C-CER,CHIP
2203-006423 C4064 C-CER,CHIP
2203-006423 C4066 C-CER,CHIP
2203-006423 C4068 C-CER,CHIP
2203-006423 C4070 C-CER,CHIP
2203-006423 C4072 C-CER,CHIP
2203-006423 C4074 C-CER,CHIP
2203-006423 C4076 C-CER,CHIP
2203-006423 C4088 C-CER,CHIP
2203-006423 C517 C-CER,CHIP
2203-006423 C518 C-CER,CHIP
2203-006423 C526 C-CER,CHIP
2203-006423 C573 C-CER,CHIP
2203-006423 C590 C-CER,CHIP
2203-006423 C609 C-CER,CHIP
