Samsung SM-T580 User manual

Mobile Device
SM-T580
1. Safety Precautions
2. Specification
3. Product Function
4. Exploded View and Parts list
5. MAIN Electrical Parts List
6. Level 1 Repair
7. Level 2 Repair
8. Level 3 Repair
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti-
es of the product are subject to change without
notice. Samsung reserves the right to alter this doc-
ument or the product described herein at anytime,
without obligation to provide notification of such
changes.
Mobile Device CONTENTS

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1.Safety Precautions
1-1. Repair Precaution
Before attempting any repair or detailed tuning, shield the device from RF noise or static
electricity discharges.
Use only demagnetized tools that are specifically designed for small electronic repairs,
as most electronic parts are sensitive to electromagnetic forces.
Use only high quality screwdrivers when servicing products. Low quality screwdrivers can
easily damage the heads of screws.
Use only conductor wire of the properly gauge and insulation for low resistance, because of the low
margin of error of most testing equipment.
We recommend 22-gauge twisted copper wire.
Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily
damaged, even with relatively low heat. Never use a soldering iron with a power rating of
more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).
Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.
Always use the replacement parts that are registered in the SEC system. Third-party replacement parts
may not function properly.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
1.Safety Precautions
1-2. ESD(Electrostatically Sensitive Devices) Precaution
Many semiconductors and ESDs in electronic devices are particularly sensitive to static discharge and
can be easily damaged by it. We recommend protecting these components with conductive anti-static
bags when you store or transport them.
Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate
static electricity from your body before repairing ESDs.
Ensure that soldering irons have AC adapter with ground wires and that the ground wires are properly
connected.
Use only desoldering tools with plastic tips to prevent static discharge.
Properly shield the work environment from accidental electrostatic discharge before opening
packages containing ESDs.
The potential for static electricity discharge may be increased in low humidity environments,
such as air-conditioned rooms. Increase the airflow to the working area to decrease the
chance of accidental static electricity discharges.

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
2. Specification
N/A

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
3. Operation Instruction and Installation
Main Function
Item Description
OS Android V6.0 (Marshmallow)
RF 2G : 850/900/180/1900 3G : B1,2,5,8
LTE : Band B1/3/5/7/8/20/40
Battery 7,300mAh
Base Band Exynos 7870 Octa-Core 1.6GHz
Other RF USB 2.0, BT4.1, GPS, Glonass, WIFI 802.11 a/b/g/n /ac 2.4GHz+5GHz
Camera 8.0MP AF, 2.0MP FF
LCD 10,1” 1920x1200(WUXGA), TFT, LCD
RAM 2G LPDDR3+16G eMMC
Sensor Accelerometer, RGB Light,Hall Sensor
Accessory Charger: 5V/2A
Data cable: 3.0pi, 0.8m

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-1. Cellular phone Exploded View

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
4. Exploded View and Parts List
4-2. Cellular phone Parts list
Design LOC Description SEC CODE
QCR145 SCREW-MACHINE L2.5 6001-003193
QME01 FFC-HOME KEY (SM-T585) GH41-05105A
QBA01 INNER BATTERY PACK-EB-BT585ABE,7300,30 GH43-04627A
QJK01 MODULE-EAR JACK FPCB (SM-T280) GH59-14606A
QRF01 RUBBER-EARJACK GH67-03160A
QMP01 A/S ASSY-PBA MAIN(COMM),SM-T580;SVC GH82-12357A
QME03 A/S ASSY-HOME KEY PBA(IF SUB),SM-T580; GH82-12358A
QME04 A/S ASSY-SUB PBA(SUB ANT),SM-T580 GH82-12359A
QSP01 ASSY SPEAKER-SPK R(SM-T585) GH96-09957A
QCA02 ASSY CAMERA-2M 1/5"(SM-T536) GH96-09959A
QSP02 ASSY SPEAKER-SPK L(SM-T580) GH96-10007A
QCA01 ASSY CAMERA-8M AF_SM-T585 GH96-10043A
QFR01 SVC LCD ASSY-LCD,(E/BLK);SM-T585,DBT,BL GH97-19022A
QSU01 ASSY BRACKET-IF SUS GH98-39618A
QSU02 ASSY BRACKET-EARJACK SUS GH98-39860A
QRE01 ASSY CASE-REAR SVC(EUROPE) GH98-40212A
QSD01 COVER-SD GH63-12808A
QCK01 KEY-POWER GH64-05757A
QVO01 KEY-VOLUME GH64-05758A
SVC JIG-TEST_100MM GH81-09146A
SVC JIG-CABLE-C-TC11-110 GH81-10631A

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
Parts Code Design Loc Description
0403-002001 ZD4006 DIODE-ZENER
0404-001250 D4000 DIODE-SCHOTTKY
0404-001250 D4001 DIODE-SCHOTTKY
0404-001669 D6000 DIODE-SCHOTTKY
0406-001623 ZD4014 DIODE-TVS
0406-001645 ZD5001 DIODE-TVS
0406-001645 ZD5002 DIODE-TVS
0406-001682 D5000 DIODE-TVS
0406-001682 D5001 DIODE-TVS
0406-001682 D5002 DIODE-TVS
0406-001682 ZD5012 DIODE-TVS
0406-001690 ZD4010 DIODE-TVS
0406-001690 ZD4011 DIODE-TVS
0406-001690 ZD4012 DIODE-TVS
0406-001690 ZD4013 DIODE-TVS
0406-001690 ZD5007 DIODE-TVS
0406-001690 ZD5008 DIODE-TVS
0406-001690 ZD5009 DIODE-TVS
0406-001690 ZD5010 DIODE-TVS
0406-001690 ZD5011 DIODE-TVS
0406-001690 ZD7000 DIODE-TVS
0406-001690 ZD7001 DIODE-TVS
0406-001733 ZD4000 DIODE-TVS
0407-001055 ZD4007 DIODE-ARRAY
0505-002088 Q6000 FET-SILICON
0505-002341 TR4000 FET-SILICON
0505-003234 Q4000 FET-SILICON
0601-003526 LED4000 LED
1001-001968 U5004 IC-ANALOG MULTIPLEX
1009-001066 U7005 IC-HALL EFFECT S/W
1105-002710 UCP300UP IC-DDR3 SDRAM
1107-002454 UME3000 IC-EMMC
1201-003790 U2004 IC-GPS AMP
1203-004819 U7006 IC-POSI.FIXED REG.
1203-004819 U7016 IC-POSI.FIXED REG.
1203-006767 U6003 IC-MULTI REG.
1203-008518 U6000 IC-SWITCH REG.
1203-008644 U6002 IC-BACKLIGHT DRIVER
1203-008646 U4006 IC-POWER SUPERVISOR
1203-008766 U2005 IC-DC/DC CONVERTER
1203-008767 U4007 IC-POWER SUPERVISOR
1205-005097 U4009 IC-SWITCH

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
1205-005310 U2001 IC-GPS RECEIVER
1205-005367 U5005 IC-CODEC
1205-005564 U2010 IC-WIFI
1205-005565 UCP300 IC-MODEM
1205-005604 U6001 IC-TOUCH
1209-002275 U7001 IC-ACCELEROMETER SENSOR
1209-002331 U2006 IC-TOUCH SENSOR
1209-002351 U7008 IC-OPTICS SENSOR
1404-001471 TH4000 THERMISTOR-NTC
1404-001724 TH3000 THERMISTOR-NTC
1405-001375 VR2000 VARISTOR
1405-001375 VR5001 VARISTOR
1405-001404 VR7000 VARISTOR
1405-001404 VR7002 VARISTOR
2007-000138 R4024 R-CHIP
2007-000138 R4025 R-CHIP
2007-000138 R4026 R-CHIP
2007-000138 R5019 R-CHIP
2007-000138 R5026 R-CHIP
2007-000140 R2005 R-CHIP
2007-000140 R4028 R-CHIP
2007-000148 R6007 R-CHIP
2007-000162 R5017 R-CHIP
2007-000172 R5004 R-CHIP
2007-000172 R5006 R-CHIP
2007-007134 R6022 R-CHIP
2007-007142 R4035 R-CHIP
2007-007156 R4043 R-CHIP
2007-007538 R5018 R-CHIP
2007-007573 R5011 R-CHIP
2007-007798 R4014 R-CHIP
2007-007942 R3011 R-CHIP
2007-007942 R6018 R-CHIP
2007-007946 R3012 R-CHIP
2007-007946 R5010 R-CHIP
2007-008043 R4022 R-CHIP
2007-008045 R4034 R-CHIP
2007-008045 R6016 R-CHIP
2007-008055 R3018 R-CHIP
2007-008055 R3060 R-CHIP
2007-008055 R3061 R-CHIP
2007-008055 R3062 R-CHIP
2007-008055 R4029 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2007-008055 R4041 R-CHIP
2007-008055 R5000 R-CHIP
2007-008055 R5003 R-CHIP
2007-008055 R6014 R-CHIP
2007-008055 R6015 R-CHIP
2007-008055 R6019 R-CHIP
2007-008419 R4003 R-CHIP
2007-008420 R4050 R-CHIP
2007-008483 R4020 R-CHIP
2007-008483 R4021 R-CHIP
2007-008486 R4004 R-CHIP
2007-008486 R4006 R-CHIP
2007-008516 R2008 R-CHIP
2007-008516 R2016 R-CHIP
2007-008516 R2023 R-CHIP
2007-008516 R2024 R-CHIP
2007-008516 R3004 R-CHIP
2007-008516 R3046 R-CHIP
2007-008516 R3047 R-CHIP
2007-008516 R3054 R-CHIP
2007-008516 R3057 R-CHIP
2007-008516 R3058 R-CHIP
2007-008516 R3059 R-CHIP
2007-008516 R5005 R-CHIP
2007-008516 R5007 R-CHIP
2007-008516 R6010 R-CHIP
2007-008588 R2002 R-CHIP
2007-008588 R2003 R-CHIP
2007-008588 R2004 R-CHIP
2007-008588 R3021 R-CHIP
2007-008588 R3022 R-CHIP
2007-008588 R3023 R-CHIP
2007-008588 R3024 R-CHIP
2007-008588 R3028 R-CHIP
2007-008588 R3029 R-CHIP
2007-008588 R3030 R-CHIP
2007-008588 R3033 R-CHIP
2007-008588 R3034 R-CHIP
2007-008588 R3035 R-CHIP
2007-008588 R3037 R-CHIP
2007-008588 R3039 R-CHIP
2007-008588 R3041 R-CHIP
2007-008588 R3042 R-CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2007-008588 R3043 R-CHIP
2007-008588 R3044 R-CHIP
2007-008588 R3064 R-CHIP
2007-008588 R3065 R-CHIP
2007-008588 R3066 R-CHIP
2007-008588 R3067 R-CHIP
2007-008588 R3068 R-CHIP
2007-008588 R3069 R-CHIP
2007-008588 R3070 R-CHIP
2007-008588 R3071 R-CHIP
2007-008774 R3063 R-CHIP
2007-008774 R4036 R-CHIP
2007-008774 R4037 R-CHIP
2007-008800 R3006 R-CHIP
2007-008800 R3008 R-CHIP
2007-008800 R3036 R-CHIP
2007-008800 R3038 R-CHIP
2007-008811 R2007 R-CHIP
2007-009084 R2028 R-CHIP
2007-009084 R4033 R-CHIP
2007-009111 R3007 R-CHIP
2007-009157 R3027 R-CHIP
2007-009170 R4055 R-CHIP
2007-009171 R3005 R-CHIP
2007-009171 R4040 R-CHIP
2007-009182 R6021 R-CHIP
2007-009212 R4018 R-CHIP
2007-009212 R5014 R-CHIP
2007-009223 R5015 R-CHIP
2007-009233 R2027 R-CHIP
2007-009315 R4002 R-CHIP
2007-009793 R5016 R-CHIP
2007-009920 R3001 R-CHIP
2007-009920 R3002 R-CHIP
2007-009920 R3009 R-CHIP
2007-009969 R5020 R-CHIP
2007-010856 R4042 R-CHIP
2007-011043 R3010 R-CHIP
2007-011377 R6020 R-CHIP
2203-000233 C6013 C-CER,CHIP
2203-000233 C6025 C-CER,CHIP
2203-000233 C6026 C-CER,CHIP
2203-000330 C2002 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-000386 C5011 C-CER,CHIP
2203-000386 C5047 C-CER,CHIP
2203-000386 C5049 C-CER,CHIP
2203-000386 C5056 C-CER,CHIP
2203-000812 C5051 C-CER,CHIP
2203-000854 C6016 C-CER,CHIP
2203-001101 C6018 C-CER,CHIP
2203-001153 C5016 C-CER,CHIP
2203-001153 C5018 C-CER,CHIP
2203-001153 C5019 C-CER,CHIP
2203-001153 C5046 C-CER,CHIP
2203-001153 C5048 C-CER,CHIP
2203-001153 C5055 C-CER,CHIP
2203-001239 C4087 C-CER,CHIP
2203-002687 C4084 C-CER,CHIP
2203-005288 C6017 C-CER,CHIP
2203-005344 C4051 C-CER,CHIP
2203-005682 C2003 C-CER,CHIP
2203-005717 C4101 C-CER,CHIP
2203-005725 C2056 C-CER,CHIP
2203-005729 C7028 C-CER,CHIP
2203-005731 C2000 C-CER,CHIP
2203-005736 C2001 C-CER,CHIP
2203-005736 C2006 C-CER,CHIP
2203-005736 C2008 C-CER,CHIP
2203-005736 C2010 C-CER,CHIP
2203-005736 C2011 C-CER,CHIP
2203-005736 C2012 C-CER,CHIP
2203-005736 C2047 C-CER,CHIP
2203-005736 C2053 C-CER,CHIP
2203-005736 C2068 C-CER,CHIP
2203-005736 L2013 C-CER,CHIP
2203-005740 C2004 C-CER,CHIP
2203-005740 C7022 C-CER,CHIP
2203-005777 C2078 C-CER,CHIP
2203-006121 C5014 C-CER,CHIP
2203-006121 C5015 C-CER,CHIP
2203-006137 C6003 C-CER,CHIP
2203-006137 C6005 C-CER,CHIP
2203-006194 C2079 C-CER,CHIP
2203-006208 C2029 C-CER,CHIP
2203-006305 L2008 C-CER,CHIP
2203-006324 C4098 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-006348 C4046 C-CER,CHIP
2203-006399 C2061 C-CER,CHIP
2203-006399 C2072 C-CER,CHIP
2203-006399 C2073 C-CER,CHIP
2203-006399 C2075 C-CER,CHIP
2203-006399 C2076 C-CER,CHIP
2203-006399 C2077 C-CER,CHIP
2203-006399 C3005 C-CER,CHIP
2203-006399 C3017 C-CER,CHIP
2203-006399 C3022 C-CER,CHIP
2203-006399 C3028 C-CER,CHIP
2203-006399 C3032 C-CER,CHIP
2203-006399 C3047 C-CER,CHIP
2203-006399 C3075 C-CER,CHIP
2203-006399 C3077 C-CER,CHIP
2203-006399 C3079 C-CER,CHIP
2203-006399 C3081 C-CER,CHIP
2203-006399 C3088 C-CER,CHIP
2203-006399 C4008 C-CER,CHIP
2203-006399 C4011 C-CER,CHIP
2203-006399 C4012 C-CER,CHIP
2203-006399 C4033 C-CER,CHIP
2203-006399 C4034 C-CER,CHIP
2203-006399 C4038 C-CER,CHIP
2203-006399 C4091 C-CER,CHIP
2203-006399 C5001 C-CER,CHIP
2203-006399 C5020 C-CER,CHIP
2203-006399 C5021 C-CER,CHIP
2203-006399 C5038 C-CER,CHIP
2203-006399 C5053 C-CER,CHIP
2203-006399 C6022 C-CER,CHIP
2203-006399 C6024 C-CER,CHIP
2203-006399 C7003 C-CER,CHIP
2203-006399 C7014 C-CER,CHIP
2203-006399 C7031 C-CER,CHIP
2203-006400 C4067 C-CER,CHIP
2203-006410 C4097 C-CER,CHIP
2203-006423 C2032 C-CER,CHIP
2203-006423 C2034 C-CER,CHIP
2203-006423 C2035 C-CER,CHIP
2203-006423 C2036 C-CER,CHIP
2203-006423 C2037 C-CER,CHIP
2203-006423 C2038 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-006423 C2039 C-CER,CHIP
2203-006423 C2041 C-CER,CHIP
2203-006423 C2043 C-CER,CHIP
2203-006423 C2045 C-CER,CHIP
2203-006423 C2046 C-CER,CHIP
2203-006423 C2049 C-CER,CHIP
2203-006423 C2062 C-CER,CHIP
2203-006423 C3001 C-CER,CHIP
2203-006423 C3002 C-CER,CHIP
2203-006423 C3016 C-CER,CHIP
2203-006423 C3034 C-CER,CHIP
2203-006423 C3083 C-CER,CHIP
2203-006423 C3085 C-CER,CHIP
2203-006423 C4043 C-CER,CHIP
2203-006423 C4069 C-CER,CHIP
2203-006423 C4073 C-CER,CHIP
2203-006423 C4096 C-CER,CHIP
2203-006423 C5003 C-CER,CHIP
2203-006423 C5004 C-CER,CHIP
2203-006423 C5005 C-CER,CHIP
2203-006423 C5008 C-CER,CHIP
2203-006423 C5033 C-CER,CHIP
2203-006423 C5035 C-CER,CHIP
2203-006423 C7008 C-CER,CHIP
2203-006423 C7010 C-CER,CHIP
2203-006423 C7017 C-CER,CHIP
2203-006462 C2009 C-CER,CHIP
2203-006556 C2074 C-CER,CHIP
2203-006562 C6002 C-CER,CHIP
2203-006562 C6004 C-CER,CHIP
2203-006562 C6006 C-CER,CHIP
2203-006562 C6021 C-CER,CHIP
2203-006562 C7004 C-CER,CHIP
2203-006562 C7013 C-CER,CHIP
2203-006668 C3039 C-CER,CHIP
2203-006668 C4074 C-CER,CHIP
2203-006839 C5007 C-CER,CHIP
2203-006844 C6019 C-CER,CHIP
2203-006872 C2064 C-CER,CHIP
2203-006872 C4036 C-CER,CHIP
2203-006872 C4037 C-CER,CHIP
2203-006872 C5006 C-CER,CHIP
2203-006872 C5009 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-006872 C5013 C-CER,CHIP
2203-006872 C5017 C-CER,CHIP
2203-006872 C6001 C-CER,CHIP
2203-006872 C6010 C-CER,CHIP
2203-006872 C7024 C-CER,CHIP
2203-006872 C7027 C-CER,CHIP
2203-006890 R5021 C-CER,CHIP
2203-006890 R5022 C-CER,CHIP
2203-006978 C4083 C-CER,CHIP
2203-007240 C4052 C-CER,CHIP
2203-007240 C4055 C-CER,CHIP
2203-007240 C4057 C-CER,CHIP
2203-007240 C4058 C-CER,CHIP
2203-007270 C2063 C-CER,CHIP
2203-007270 C4028 C-CER,CHIP
2203-007270 C4054 C-CER,CHIP
2203-007270 C5000 C-CER,CHIP
2203-007270 C5002 C-CER,CHIP
2203-007270 C6014 C-CER,CHIP
2203-007271 C2048 C-CER,CHIP
2203-007271 C2071 C-CER,CHIP
2203-007271 C4080 C-CER,CHIP
2203-007271 C4086 C-CER,CHIP
2203-007279 C4023 C-CER,CHIP
2203-007279 C4024 C-CER,CHIP
2203-007279 C4025 C-CER,CHIP
2203-007279 C4026 C-CER,CHIP
2203-007279 C4027 C-CER,CHIP
2203-007279 C4048 C-CER,CHIP
2203-007279 C4082 C-CER,CHIP
2203-007317 C3000 C-CER,CHIP
2203-007317 C3003 C-CER,CHIP
2203-007317 C3020 C-CER,CHIP
2203-007317 C3024 C-CER,CHIP
2203-007317 C3027 C-CER,CHIP
2203-007317 C3037 C-CER,CHIP
2203-007317 C3046 C-CER,CHIP
2203-007317 C3067 C-CER,CHIP
2203-007317 C3068 C-CER,CHIP
2203-007317 C4001 C-CER,CHIP
2203-007317 C4004 C-CER,CHIP
2203-007317 C4005 C-CER,CHIP
2203-007317 C4006 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-007317 C4035 C-CER,CHIP
2203-007317 C5024 C-CER,CHIP
2203-007317 C5025 C-CER,CHIP
2203-007317 C5027 C-CER,CHIP
2203-007317 C5028 C-CER,CHIP
2203-007317 C5034 C-CER,CHIP
2203-007317 C5036 C-CER,CHIP
2203-007317 C5037 C-CER,CHIP
2203-007317 C5039 C-CER,CHIP
2203-007317 C7025 C-CER,CHIP
2203-007385 C3040 C-CER,CHIP
2203-007391 C2021 C-CER,CHIP
2203-007391 C2022 C-CER,CHIP
2203-007392 C4066 C-CER,CHIP
2203-007392 C4081 C-CER,CHIP
2203-007393 C2024 C-CER,CHIP
2203-007393 C4044 C-CER,CHIP
2203-007449 C2030 C-CER,CHIP
2203-007449 C2031 C-CER,CHIP
2203-007449 C2033 C-CER,CHIP
2203-007449 C2040 C-CER,CHIP
2203-007449 C2042 C-CER,CHIP
2203-007449 C2044 C-CER,CHIP
2203-007449 C2050 C-CER,CHIP
2203-007449 C2051 C-CER,CHIP
2203-007449 C2052 C-CER,CHIP
2203-007449 C3004 C-CER,CHIP
2203-007449 C3006 C-CER,CHIP
2203-007449 C3007 C-CER,CHIP
2203-007449 C3008 C-CER,CHIP
2203-007449 C3009 C-CER,CHIP
2203-007449 C3010 C-CER,CHIP
2203-007449 C3011 C-CER,CHIP
2203-007449 C3012 C-CER,CHIP
2203-007449 C3013 C-CER,CHIP
2203-007449 C3014 C-CER,CHIP
2203-007449 C3015 C-CER,CHIP
2203-007449 C3018 C-CER,CHIP
2203-007449 C3019 C-CER,CHIP
2203-007449 C3021 C-CER,CHIP
2203-007449 C3023 C-CER,CHIP
2203-007449 C3025 C-CER,CHIP
2203-007449 C3026 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-007449 C3029 C-CER,CHIP
2203-007449 C3030 C-CER,CHIP
2203-007449 C3031 C-CER,CHIP
2203-007449 C3033 C-CER,CHIP
2203-007449 C3035 C-CER,CHIP
2203-007449 C3036 C-CER,CHIP
2203-007449 C3038 C-CER,CHIP
2203-007449 C3041 C-CER,CHIP
2203-007449 C3043 C-CER,CHIP
2203-007449 C3044 C-CER,CHIP
2203-007449 C3045 C-CER,CHIP
2203-007449 C3048 C-CER,CHIP
2203-007449 C3049 C-CER,CHIP
2203-007449 C3051 C-CER,CHIP
2203-007449 C3052 C-CER,CHIP
2203-007449 C3053 C-CER,CHIP
2203-007449 C3054 C-CER,CHIP
2203-007449 C3055 C-CER,CHIP
2203-007449 C3056 C-CER,CHIP
2203-007449 C3057 C-CER,CHIP
2203-007449 C3058 C-CER,CHIP
2203-007449 C3059 C-CER,CHIP
2203-007449 C3060 C-CER,CHIP
2203-007449 C3061 C-CER,CHIP
2203-007449 C3062 C-CER,CHIP
2203-007449 C3063 C-CER,CHIP
2203-007449 C3064 C-CER,CHIP
2203-007449 C3065 C-CER,CHIP
2203-007449 C3066 C-CER,CHIP
2203-007449 C3069 C-CER,CHIP
2203-007449 C3070 C-CER,CHIP
2203-007449 C3073 C-CER,CHIP
2203-007449 C3074 C-CER,CHIP
2203-007449 C3076 C-CER,CHIP
2203-007449 C3078 C-CER,CHIP
2203-007449 C3080 C-CER,CHIP
2203-007449 C4002 C-CER,CHIP
2203-007449 C4003 C-CER,CHIP
2203-007449 C4007 C-CER,CHIP
2203-007449 C4009 C-CER,CHIP
2203-007449 C4010 C-CER,CHIP
2203-007449 C4014 C-CER,CHIP
2203-007449 C4015 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-007449 C4016 C-CER,CHIP
2203-007449 C4017 C-CER,CHIP
2203-007449 C4030 C-CER,CHIP
2203-007449 C4031 C-CER,CHIP
2203-007449 C4032 C-CER,CHIP
2203-007449 C4039 C-CER,CHIP
2203-007449 C4040 C-CER,CHIP
2203-007449 C4041 C-CER,CHIP
2203-007449 C4042 C-CER,CHIP
2203-007449 C4056 C-CER,CHIP
2203-007449 C4059 C-CER,CHIP
2203-007449 C4063 C-CER,CHIP
2203-007449 C4088 C-CER,CHIP
2203-007449 C4089 C-CER,CHIP
2203-007449 C4090 C-CER,CHIP
2203-007449 C4092 C-CER,CHIP
2203-007449 C5010 C-CER,CHIP
2203-007449 C5022 C-CER,CHIP
2203-007449 C5023 C-CER,CHIP
2203-007474 C3042 C-CER,CHIP
2203-007474 C7007 C-CER,CHIP
2203-007781 C4065 C-CER,CHIP
2203-007790 C4100 C-CER,CHIP
2203-007790 C6012 C-CER,CHIP
2203-007790 C6015 C-CER,CHIP
2203-007795 C2023 C-CER,CHIP
2203-007796 C4075 C-CER,CHIP
2203-008394 C2080 C-CER,CHIP
2203-008654 C4049 C-CER,CHIP
2203-008790 C2060 C-CER,CHIP
2203-008860 C4022 C-CER,CHIP
2203-008860 C4050 C-CER,CHIP
2203-008860 C4062 C-CER,CHIP
2203-008860 C4064 C-CER,CHIP
2203-009328 C4061 C-CER,CHIP
2203-009551 C4053 C-CER,CHIP
2203-009733 C4021 C-CER,CHIP
2203-009733 C4060 C-CER,CHIP
2203-009733 C4085 C-CER,CHIP
2203-009733 C6000 C-CER,CHIP
2203-009733 C6007 C-CER,CHIP
2203-009733 C6008 C-CER,CHIP
2203-009733 C6009 C-CER,CHIP

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
2203-009733 C6011 C-CER,CHIP
2703-002309 L5012 INDUCTOR-SMD
2703-002313 L2011 INDUCTOR-SMD
2703-002367 C2018 INDUCTOR-SMD
2703-002367 L2000 INDUCTOR-SMD
2703-002951 L2005 INDUCTOR-SMD
2703-002951 L2006 INDUCTOR-SMD
2703-002959 L3002 INDUCTOR-SMD
2703-002961 L2004 INDUCTOR-SMD
2703-002961 L2016 INDUCTOR-SMD
2703-004013 C2017 INDUCTOR-SMD
2703-004036 L4007 INDUCTOR-SMD
2703-004299 C2067 INDUCTOR-SMD
2703-004332 L6000 INDUCTOR-SMD
2703-004366 L2015 INDUCTOR-SMD
2703-004371 L2009 INDUCTOR-SMD
2703-004530 L6001 INDUCTOR-SMD
2703-005038 L2012 INDUCTOR-SMD
2703-005067 L2010 INDUCTOR-SMD
2703-005067 L4002 INDUCTOR-SMD
2703-005067 L4003 INDUCTOR-SMD
2703-005067 L4004 INDUCTOR-SMD
2703-005067 L4005 INDUCTOR-SMD
2703-005067 L4006 INDUCTOR-SMD
2703-005340 L4001 INDUCTOR-SMD
2801-005154 OSC2000 CRYSTAL-SMD
2801-005254 OSC4000 CRYSTAL-SMD
2805-001113 OSC2002 OSCILLATOR-TCXO
2805-001113 TCX4000 OSCILLATOR-TCXO
2904-002168 F2003 FILTER-SAW
2904-002169 F2002 FILTER-SAW
2904-002314 F2001 FILTER-SAW
3003-001233 AU5000 MIC MEMS
3301-001534 L7005 BEAD-SMD
3301-001876 L7007 BEAD-SMD
3301-001885 L5001 BEAD-SMD
3301-001885 L5003 BEAD-SMD
3301-001885 L5010 BEAD-SMD
3301-001885 L5013 BEAD-SMD
3301-001885 L5014 BEAD-SMD
3301-001885 L5016 BEAD-SMD
3301-002037 L6002 BEAD-SMD
3301-002078 L7006 BEAD-SMD

Confidential and proprietary-the contents in this service guide subject to change without prior notice
Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
5. MAIN Electrical Parts List
3301-002122 L5002 BEAD-SMD
3301-002122 L5004 BEAD-SMD
3301-002122 L5006 BEAD-SMD
3301-002122 L5007 BEAD-SMD
3301-002122 L5008 BEAD-SMD
3301-002122 L5009 BEAD-SMD
3301-002238 L2003 BEAD-SMD
3301-002254 L4000 BEAD-SMD
3301-002312 L3001 BEAD-SMD
3404-001540 TAC4000 SWITCH-TACT
3404-001540 TAC4001 SWITCH-TACT
3404-001540 TAC4002 SWITCH-TACT
3404-001542 SW7000 SWITCH-TACT
3708-002162 HEA7000 CONNECTOR-FPC/FFC/PIC
3708-003132 HEA5000 CONNECTOR-FPC/FFC/PIC
3708-003132 HEA7001 CONNECTOR-FPC/FFC/PIC
3708-003167 SCL6000 CONNECTOR-FPC/FFC/PIC
3708-003187 HEA6000 CONNECTOR-FPC/FFC/PIC
3708-003254 HDC7000 CONNECTOR-FPC/FFC/PIC
3708-003263 SLC4000 CONNECTOR-FPC/FFC/PIC
3709-001811 SD4000 CONNECTOR-CARD EDGE
3711-008347 HEA5001 HEADER-BOARD TO BOARD
3712-001604 ANT2000 CONNECTOR-TERMINAL
3712-001604 ANT2001 CONNECTOR-TERMINAL
3712-001634 CON2001 CONNECTOR-TERMINAL
3712-001634 CON2002 CONNECTOR-TERMINAL
3712-001634 CON2003 CONNECTOR-TERMINAL
3712-001634 CON2004 CONNECTOR-TERMINAL
3712-001634 CON2005 CONNECTOR-TERMINAL
3712-001694 CON7001 CONNECTOR-TERMINAL
3712-001694 CON7002 CONNECTOR-TERMINAL
3712-001694 CON7004 CONNECTOR-TERMINAL
3712-001694 CON7005 CONNECTOR-TERMINAL
3722-003700 IFC4000 JACK-MICRO USB
4709-002284 F2000 FREQ-DISTRIBUTER
GH62-00040A CN7002 PAD GAP-SMD GASKET (SM-G925F)
GH62-00044A CN7000 PAD GAP-SMD GASKET(SM-T555)
GH63-12801A SC2003 SHIELD-COVER A
GH63-12802A SC2000 SHIELD-FRAME B
GH61-11529A SUS2000 SHIELD-SD SUS
GH98-39624A SC2002 ASSY COVER-SHIELD CAN D
Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list.
