Samsung HL72A650C1F User manual

DLP TV
user manual
BP68-00670A-01
Contact SAMSUNG WORLD-WIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
Comment contacter Samsung dans le monde
Si vous avez des suggestions ou des questions concernant les produits Samsung, veuillez contacter le Service
Consommateurs Samsung.
Country Customer Care Center Web Site Address
CANADA 1-800-SAMSUNG (7267864) www.samsung.com/ca
Samsung Electronics Canada Inc., Customer Service 55
Standish Court Mississauga, Ontario L5R 4B2 Canada
Samsung Electronique Canada Inc., Service à la Clientèle
55 Standish Court Mississauga, Ontario L5R 4B2
Canada
U.S.A 1-800-SAMSUNG (7267864) www.samsung.com Samsung Electronics America, Inc. 105 Challenger Road
Ridgefield Park, NJ 07660-0511
Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/global/register
Model Serial No.
imagine the possibilities
BP68-00670A-01Eng.indb 1 2008-04-24 오후 3:03:58

English - 2
A Guide to Digital TV
● What is Digital Television?
Digital television (DTV) is a new way of transmitting high quality video and audio to your TV set. Using DTV, broadcasters can
transmit high definition TV (HDTV) images, Dolby digital surround audio, and new services such as multicasting (transmitting
more than one program on the same TV channel) and datacasting. Several of these services can be combined into a single digital
broadcast.
Digital Television Services
● Digital Picture Quality
DTV programs are transmitted in two different formats. The first is Standard Definition Television (SDTV) and the second is High
Definition Television (HDTV).
● SDTV program formats include 480-line interlaced (480i) and 480-line progressive (480p) video. 480i programs are essentially
a digital version of our current analog TV programs, while the 480p format offers improved image detail over 480i. Some 480p
programs are broadcast in widescreen and are comparable to progressive-scan DVD movies in image quality.
● HDTV program formats include 1080-line interlaced (1080i) and 720-line progressive (720p). Both HDTV formats are always
broadcast in widescreen, and offer much higher picture quality than SDTV.
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain third parties. In
particular, this product is licensed under the following US patents:
5,991,715, 5,740,317, 4,972,484, 5,214,678, 5,323,396, 5,539,829, 5,606,618, 5,530,655, 5,777,992, 6,289,308, 5,610,985,
5,481,643, 5,544,247, 5,960,037, 6,023,490, 5,878,080, and under US Published Patent Application No. 2001-44713-A1.
This license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are granted for
commercial use. The license does not cover any product unit other than this product unit and the license does not extend to any
unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or sold in combination with this
product unit. The license only covers the use of this product unit to encode and/or decode audio files conforming to the ISO/IEC
11172-3 or ISO/IEC 13818-3. No rights are granted under this license for product features or functions that do not conform to the
ISO/IEC 11172-3 or ISO/IEC 13818-3.
U.S.A Only
Other countries
The product unit accompanying this user manual is licensed under certain intellectual property rights of certain third parties. This
license is limited to private non-commercial use by end-user consumers for licensed contents. No rights are granted for commercial
use. The license does not cover any product unit other than this product unit and the license does not extend to any unlicensed
product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or sold in combination with this product unit. The
license only covers the use of this product unit to encode and/or decode audio files conforming to the ISO/IEC 11172-3 or ISO/IEC
13818-3. No rights are granted under this license for product features or functions that do not conform to the ISO/IEC 11172-3 or
ISO/IEC 13818-3.
➢See the warranty card for more information on warranty terms.
© 2008 Samsung Electronics Co., Ltd. All rights reserved.
SAMSUNG ELECTRONICS NORTH AMERICAN LIMITED WARRANTY STATEMENT
Subject to the requirements, conditions, exclusions and limitations of the original Limited Warranty supplied with Samsung
Electronics (SAMSUNG) products, and the requirements, conditions, exclusions and limitations contained herein, SAMSUNG will
additionally provide Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on
SAMSUNG products purchased in the United States, for the warranty period originally specified, and to the Original Purchaser only.
The above described warranty repairs must be performed by a SAMSUNG Authorized Service Center. Along with this Statement,
the Original Limited Warranty Statement and a dated Bill of Sale as Proof of Purchase must be presented to the Service Center.
Transportation to and from the Service Center is the responsibility of the purchaser.
Conditions covered are limited only to manufacturing defects in material or workmanship, and only those encountered in normal use
of the product.
Excluded, but not limited to, are any originally specified provisions for, in-home or on-site services, minimum or maximum repair
times, exchanges or replacements, accessories, options, upgrades, or consumables.
For the location of a SAMSUNG Authorized Service Center, please call toll-free:
In the United States : 1-800-SAMSUNG (1-800-726-7864) In Canada : 1-800-SAMSUNG
BP68-00670A-01Eng.indb 2 2008-04-24 오후 3:03:58

English - 3
Q&A
1. Is the antenna I use for existing TV reception good enough for DTV?
Over-the-air (OTA) digital TV broadcasting uses the same channels as analog TV and works well with many existing TV antennas.
However, DTV broadcast channel assignments are different than analog channels. You should find out whether your local DTV
broadcasts are on VHF (channels 2-13) or UHF (channels 14-69) to see if you need a different antenna.
If your DTV channels are on UHF and you already get good UHF reception, your present antenna may work fine. The same holds
true for VHF DTV reception. Note that in some markets, both VHF and UHF channels are used for DTV broadcasts.
You can find out the latest DTV channel assignments for your area by browsing selected Internet web sites such as www.titantv.
com, www.10000watts.com, and www.fcc.gov.
2. How difficult is it to receive DTV signals indoors?
This depends on whether your local DTV stations are running full power or not and how close your location is to the transmission
tower. DTV receivers do not require as much signal as analog TV receivers to produce high-quality images and sound.
Once the DTV signal level exceeds a certain threshold at the receiver, the digital video and audio data is decoded at the same
quality it was originally encoded for broadcast.
This is a big advantage for DTV over analog TV - there is no noise, ghosting, static, or scratchy audio.
3. How can I connect an antenna in my townhouse, co-operative apartment, condominium,
or apartment?
The Federal Communications Commission’s OTARD Rule (part of the Telecommunications Act of 1996) allows residents of
condominiums, townhouse, or members of neighborhood associations to put up outside antennas for reception of broadcast TV
signals as long as those antennas are not located in common areas and are no more than 12’ in height.
Residents of rental units (apartments, etc.) are not covered by the OTARD rules and will have to use indoor antennas to receive
DTV broadcasts. It is possible that the landlord of an apartment complex can provide broadcast DTV signals via a master TV
antenna system to each apartment.
4. Can I connect my DTV set-top receiver to my cable TV service?
Cable TV systems use a different method for transmitting digital TV programs that is currently incompatible with broadcast DTV set-
top receivers. So you will still need to use an outdoor or indoor antenna to receive OTA broadcast DTV programs.
The good news is that you won’t have to pay a monthly or per-program charge to watch OTA DTV and HDTV programs. They’re
free, unlike subscription satellite TV or premium cable TV. All you need is an antenna and a DTV set-top receiver to enjoy clear,
sharp widescreen images and high-quality audio.
BP68-00670A-01Eng.indb 3 2008-04-24 오후 3:03:58

English - 4
Contents
Contents
General Information
■  Viewing Position...................................................................... 5
■  List of Features ....................................................................... 5
■  Checking Parts........................................................................ 6
■  Viewing the Control Panel....................................................... 6
■  Viewing the Connection Panel................................................ 8
■  Remote Control....................................................................... 9
■  Installing Batteries in the Remote Control............................. 10
Connections
■  Connecting VHF and UHF Antennas .................................... 10
■  Connecting Cable TV.............................................................11
■  Connecting a DVD Player or Cable Box / Satellite receiver
(Set-Top Box) via HDMI ........................................................ 12
■  Connecting a DVD Player or Cable Box / Satellite receiver
(Set-Top Box) via DVI ........................................................... 12
■  Connecting a DVD Player or Cable Box / Satellite receiver
(Set-Top Box) via Component cables ................................... 13
■  Connecting a Camcorder...................................................... 13
■  Connecting a VCR ................................................................ 14
■  Connecting a Digital Audio System....................................... 15
■  Connecting an Amplier / DVD Home Theater ..................... 15
■  Connecting a PC................................................................... 16
Operation
■  Turning the TV On and Off.................................................... 16
■  Plug & Play Feature.............................................................. 17
■  Changing Channels .............................................................. 19
■  Adjusting the Volume ............................................................ 20
■  Viewing the Display............................................................... 20
■  Viewing the Menus................................................................ 20
■  Using the TOOLS Button ...................................................... 21
■  Memorizing the Channels ..................................................... 21
■  To Select the Source............................................................. 23
■  To Edit the Input Source Name ............................................. 23
Picture Control
■  Changing the Picture Standard............................................. 24
■  Customizing the Picture Settings.......................................... 24
■  Adjusting the Detailed Settings............................................. 25
■  Conguring Picture Options ................................................. 27
■  Using the 3D Function .......................................................... 32
■  Resetting the Picture Settings to the Factory Defaults ......... 33
Sound Control
■  Using Automatic Sound Settings........................................... 34
■  Customizing the Sound......................................................... 34
■  Setting the TruSurround XT .................................................. 35
■  Choosing Preferred Language.............................................. 36
■  Choosing a Multi-Channel Sound (MTS) Track - Analog ...... 36
■  Automatic Volume Control .................................................... 37
■  Setting the TV Speakers On/Off............................................ 37
■  Resetting the Sound Settings to the Factory Defaults .......... 38
Channel Control
■  Managing Channels .............................................................. 39
■  Clearing Scrambled Channels - Digital................................. 45
■  Fine Tuning Analog Channels............................................... 45
■  Checking the Digital-Signal Strength .................................... 46
PC Display
■  Using Your TV as a Computer (PC) Display ......................... 47
■  Display Modes ...................................................................... 47
■  Setting up the TV with your PC............................................. 48
Time Setting
■  Setting the Time.................................................................... 50
Function Description
■  Selecting a Menu Language ................................................. 54
■  Using the V-Chip ................................................................... 55
■  Viewing Closed Captions (On-Screen Text Messages) - Digital .... 63
■  Viewing Closed Captions (On-Screen Text Messages) - Analog ... 64
■  Adjusting the TV On/Off Melody Sound ................................ 65
■  Setting the Entertainment mode ........................................... 66
■  Upgrading the Software ........................................................ 67
WISELINK
■  Using the Photo List.............................................................. 70
■  Viewing a Photo or Slide Show............................................. 75
■  Using the Music List.............................................................. 79
■  Playing a Music File.............................................................. 83
■  Using the Setup Menu .......................................................... 85
About Anynet+
■  What is Anynet+?.................................................................. 86
■  Connecting Anynet+Devices................................................ 86
■  Setting Up Anynet+ ............................................................... 87
■  Scanning and Switching between Anynet+Devices ............. 87
■  Recording.............................................................................. 88
■  Listening through a Receiver (Home theater)....................... 89
■  Troubleshooting for Anynet+ ................................................. 89
Appendix
■  Troubleshooting .................................................................... 90
■  Replacing the Lamp.............................................................. 91
■  Cleaning and Maintaining Your TV........................................ 92
■  Using Your TV in Another Country ........................................ 92
■  Technical Specications........................................................ 93
Symbols
☛ ➢
Press Important Note One-Touch
Button
English
BP68-00670A-01Eng.indb 4 2008-04-24 오후 3:03:59

English - 5
General Information
Viewing Position
To optimize your viewing comfort, please follow the guidelines below for viewing distance.
If viewing for an extended period of time, sit as far back from the screen as possible.
List of Features
Your TV is designed and engineered using the latest technology. It is a full-featured, high-performance unit that exceeds
industry standards. In addition, it has these special features:
● Easy-to-operate remote control
● Dynamic menus and Navigating menus by using the menu map
● Easy-to-use on-screen menu system you can access from the side panel or remote control
● Automatic timer to turn the TV on and off at any time you choose
● Adjustable picture and sound settings and the ability to memorize your favorite settings
● Automatic channel tuning for up to 181 channels
● A special filter to reduce or eliminate reception problems
● Fine tuning control for the sharpest picture possible
● A built-in multi-channel sound decoder for stereo and bilingual listening
● Built-in, dual channel speakers
● A special sleep timer
● Widescreen TV with adjustable image size
● Life-like clear images provided by DNle technology
● Detailed settings mode to correspond with your color preference
● HDMI/DVI connection of your PC to this TV
● Digital Input jack
● Digital Audio Output (OPTICAL) jack
● Easy-to-use channel list menu.
● WISELINK enables you to view and play photo (JPEG) and audio files (MP3) through the TV’s WISELINK jack.
● AV network system (Anynet+) that enables you to easily control Samsung audio-video(AV) devices from this TV.
● 3D Effect Gaming Function
● Some users might observe small brightness variations in localized areas when very bright or dark signals are applied. These are
normal production variations and do not diminish the TVs viewing experience.
➢ When installing the product, make sure to keep it away
from the wall (more than 10cm / 4inches) for ventilation
purposes. Poor ventilation may cause an increase in
the internal temperature of the product, resulting in a
shortened component life and degraded performance.
< Top view> < Side view>
72˝ screen :
At least 8.4 feet
72˝ screen :
At least 8.4 feet
BP68-00670A-01Eng.indb 5 2008-04-24 오후 3:03:59

English - 6
Viewing the Control Panel
Buttons on the Lower-Right Part of the Panel
The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
Checking Parts
Owner’s Instructions Remote Control
(BN59-00673A)/
AAA Batteries
Warranty Card/
Safety Guide Manual/
Quick Guide Manual
(Not available in all locations)
Power Cord
(3903-000144)
Cloth-Clean
➢ The product color and shape may vary depending on the model.
Continued...
Sold Separately
S-Video Cable Video Cable Antenna Cable Component Cables
Replacement Lamp
(BP96-01600A)
To purchase a
replacement lamp, call
1-800-SAMSUNG.
• Use authorized lamps
only. We cannot
guarantee the quality
of the product if an
unauthorized lamp is
used.
D-Sub Cable PC Audio Cable HDMI/DVI Cable HDMI Cable
3.5 mm Stereo
mini-plug/ 2RCA Cable
Audio Cables Optical Cable
BP68-00670A-01Eng.indb 6 2008-04-24 오후 3:04:01

English - 7
1 SOURCE
Toggles between all the available input sources
(TV, AV1, AV2, S-Video, Component1, Component2,
PC, HDMI1, HDMI2, HDMI3/DVI or USB).
2 MENU
Press to see an on-screen menu of your TV’s features.
3 + VOL –
Press to increase or decrease the volume.
In the on-screen menu, use the + VOL – buttons as
you would use the ◄ and ► buttons on the remote
control.
4 CH
Press to change channels.
In the on-screen menu, use the CH buttons as
you would use the ▲ and ▼ buttons on the remote
control.
5 (ENTER)
Press to confirm a selection.
6 Indicator Lights
Blinks and turns off when the power is on and lights up
in stand-by mode.
7 POWER
Press to turn the TV on and off.
Remote Control Sensor
Aim the remote control towards this spot on the TV.
Indicator Light Key
( : On, : Blinking, : Off)
STAND BY/TEMP TIMER LAMP Indication
Standby state.
The picture will automatically appear in about 15 seconds.
Auto Timer ON/OFF has been set and the set will automatically be turned on in about 15 seconds.
A cooling fan inside the set is not operating normally.
Lamp cover on the side of the set is not properly shut.
Check if the ventilation hole on the side of the set is blocked, because if the inner temperature is too
high, the power will shut off.
Lamp may be defective. Please contact a certified technician.
➢ ● It takes about 30 seconds for the TV to warm up, so normal brightness may not appear immediately.
● The TV has a fan to keep the inside Lamp from overheating. You’ll occasionally hear it working.
➢ ● When using the on-screen menu, the volume adjustment and channel selection buttons have the same function as the
▲/▼/◄/► buttons on the remote control.
● If the remote control no longer works or you have lost it, you can use controls on the panel of the TV.
BP68-00670A-01Eng.indb 7 2008-04-24 오후 3:04:02

English - 8
Viewing the Connection Panel
Rear Panel Jacks
Use the side panel jacks to connect A/V components that will be connected continuously, such as VCR or DVD players.
For more information on connecting equipment, see pages 12~16.
1 ANT IN
75Ω Coaxial connector for Air/Cable Network.
2 HDMI IN 1, HDMI IN 2
Connect to the HDMI jack of a device with HDMI output.
3 HDMI3/DVI IN
Connect to the HDMI jack of a device with HDMI output.
This input can also be used as a DVI connection with
separate analog audio inputs. An optional HDMI/DVI cable
will be necessary to make this connection.
When using an optional HDMI/DVI adapter, the DVI analog
audio inputs on your TV allow you to receive left and right
audio from your DVI device.
4 DVI IN (AUDIO-L/R)
Connect to the DVI audio output jack of an external device.
5 DIGITAL AUDIO OUT (OPTICAL)
Connect to a Digital Audio component.
6 RS232C
Connector for service only
7 S-VIDEO
Video input for external devices with an
S-Video output, such as a Camcorder or VCR.
8 VIDEO/AUDIO-L/R (AV IN 1, 2)
Video input for external devices, such as a Camcorder or
VCR.
9 3D SYNC OUT
Connect to 3D IR Emitter.
0 AUDIO OUT-L/R
Audio outputs for external devices.
! COMPONENT IN 1, 2
Video (Y/PB/PR) and audio (L-AUDIO-R) component inputs.
@ POWER IN
Connect the supplied power cord.
# PC AUDIO IN
Connect to the audio output jack on your PC.
$ PC IN
Connect to the video output jack on your PC.
➢ The product color and shape may vary depending on the model.
➢ The product color and shape may vary depending on the model.
1 AV IN 2
Video and audio inputs for external devices.
2 WISELINK
Connect an USB mass storage device to view photo files (JPEG) and play audio files
(MP3).
Side Panel Jacks
Use the right side panel jacks to connect a component that is used only occasionally, such as a camcorder or video game.
BP68-00670A-01Eng.indb 8 2008-04-24 오후 3:04:03

English - 9
Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.
➢The performance of the remote control may be affected by bright light.
1POWER
Turns the TV on and off.
2TV
Selects the TV mode directly.
3NUMERIC BUTTONS
Press to change the channel.
4
Press to select additional channels
(digital and analog) being broadcast
by the same station. For example,
to select channel “54-3”, press “54”,
then press “ ” and “3”.
5MUTE
Press to temporarily cut off the
sound.
6
W.LINK
CH LIST
VOL
W.LINK
CH LIST
Press to increase or decrease the
volume.
7SOURCE
Press to display and select the
available video sources.
8CH LIST
Used to display Channel Lists on the
screen.
9TOOLS
Use to quickly select frequently used
functions.
0UP▲/DOWN▼/LEFT◄/
RIGHT►/ENTER
Use to select on-screen menu items
and change menu values.
!INFO
Press to display information on the
TV screen.
@COLOR BUTTONS
Use these button in the CH LIST and
W.LINK.
#CC
Controls the caption decoder.
$E.MODE
Press to select the preset display
and sound modes for sports, cinema
and games.
%Use these buttons in the DMA,
W.LINK and Anynet+ modes. (
: This remote can be used to control
recording on Samsung recorders
with the Anynet+ feature)
^ON/OFF
Press to backlight the buttons on the
remote.
This function is convenient for using
at night or when the room is dark.
(Using the remote control with the
light button set to On will reduce the
battery usage time.)
&PRE-CH
Tunes to the previous channel.
*
W.LINK
CH LIST
CH
W.LINK
CH LIST
Press to change channels.
(MENU
Displays the main on-screen menu.
)W.LINK (WISELINK)
This function enables you to view
and play photo and music files from
an external USB device. (Refer to
pages 70 (Photo) and 79 (Music))
aRETURN
Returns to the previous menu.
bEXIT
Press to exit the menu.
cMTS
Press to choose stereo, mono or
Separate Audio Program (SAP
broadcast).
dDMA (Digital Media Adapter)
Use this when connecting a
Samsung DMA device through an
HDMI interface and switching to
DMA mode.
For more information on the
operating procedures, refer to the
user manual of the DMA.
➢This button is available when
“Anynet+(HDMI-CEC)” is “On”.
(see page 86)
eP.SIZE
Picture size selection.
fFAV.CH
Press to switch to your favorite
channels.
BP68-00670A-01Eng.indb 9 2008-04-24 오후 3:04:04

English - 10
Installing Batteries in the Remote Control
1Lift the cover at the back of the remote control upward as shown in the figure.
2Install two AAA size batteries.
➢ ● Make sure to match the “+” and “–” ends of the batteries with the diagram inside the compartment.
 ● Do not mix battery types, i.e. alkaline and manganese.
3Close the cover as shown in the figure.
➢ Remove the batteries and store them in a cool and dry place if you won’t be using the remote
control for a long time. The remote control can be used up to about 23 feet from the TV. (Assuming
typical TV usage, the batteries last for about one year.)
➢ Using the remote control with the On/Off( ) light button set to On will reduce the battery usage
time.
➢ If the remote control doesn’t work! Check the following
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power cut, or is the power cord unplugged?
5. Is there a special fluorescent light or a neon sign nearby?
Connections
Connecting VHF and UHF Antennas
Ifyourantennahasasetofleadsthatlooklikethis,see“Antennaswith300ΩFlatTwin
Leads” below.
Ifyourantennahasoneleadthatlookslikethis,see“Antennaswith75ΩRoundLeads”.
If you have two antennas, see “Separate VHF and UHF Antennas”.
Antennaswith300ΩFlatTwinLeads
Ifyouareusinganoff-airantenna(suchasaroofantennaor“rabbitears”)thathas300Ωtwinflatleads,followthe
directions below.
1 Place the wires from the twin leads under the screws on a 300-75 Ω adapter (not supplied).
Use a screwdriver to tighten the screws.
2Plug the adaptor into the ANT IN terminal on the side of the TV.
Antennaswith75ΩRoundLeads
1Plug the antenna lead into the ANT IN terminal on the side of the TV.
Separate VHF and UHF Antennas
If you have two separate antennas for your TV (one VHF and one UHF), you must combine the two antenna signals before
connecting the antennas to the TV. This procedure requires an optional combiner-adaptor (available at most electronics
shops).
1Connect both antenna leads to the combiner.
2Plug the combiner into the ANT IN terminal on the bottom of the side panel.
BP68-00670A-01Eng.indb 10 2008-04-24 오후 3:04:06

English - 11
Connecting Cable TV
To connect to a cable TV system, follow the instructions below.
Cable without a Cable Box
1Plug the incoming cable into the ANT IN terminal on the side of the TV.
➢ Because this TV is cable-ready, you do not need a cable box to view unscrambled cable
channels.
Connecting to a Cable Box that Descrambles All Channels
1Find the cable that is connected to the ANT OUT terminal on your cable box.
➢ This terminal might be labeled “ANT OUT”, “VHF OUT” or simply, “OUT”.
2Connect the other end of this cable to the ANT IN terminal on the side of the TV.
Connecting to a Cable Box that Descrambles Some Channels
If your cable box descrambles only some channels (such as premium channels), follow the instructions below. You will need
a two-way splitter, an RF (A/B) switch, and four lengths of Antenna cable. (These items are available at most electronics
stores.)
1Find and disconnect the cable that is connected
to the ANT IN terminal on your cable box.
➢ This terminal might be labeled “ANT IN”,
“VHF IN” or simply, “IN”.
2Connect this cable to a two-way splitter.
3Connect an Antenna cable between an
OUTPUT terminal on the splitter and the IN
terminal on the cable box.
4Connect an Antenna cable between the ANT
OUT terminal on the cable box and the B–IN
terminal on the RF(A/B) switch.
5Connect another cable between the other OUT
terminal on the splitter and the A–IN terminal on
the RF (A/B) switch.
6 Connect the last Antenna cable between the
OUT terminal on the RF (A/B) switch and the
ANT IN terminal on the side of the TV.
After you have made this connection, set the A/B switch to the “A” position for normal viewing. Set the A/B switch to the “B” position to
view scrambled channels. (When you set the A/B switch to “B”, you will need to tune your TV to the cable box’s output channel, which
is usually channel 3 or 4.)
Splitter
Incoming
cable
Splitter
Cable Box
Incoming
cable
Splitter
Cable Box
RF (A/B)
Switch
Incoming
cable
Splitter
Cable Box
Incoming
cable
RF (A/B)
Switch
Incoming
cable Splitter
Cable Box RF (A/B)
Switch
ANT OUT
ANT IN
ANT IN
TV Side
BP68-00670A-01Eng.indb 11 2008-04-24 오후 3:04:07

English - 12
Connecting a DVD Player or Cable Box / Satellite receiver (Set-Top Box) via DVI
This connection can only be made if there is a DVI Output jack on the external device.
1 Connect a HDMI/DVI Cable
or DVI-HDMI Adapter
between the HDMI3/DVI IN
jack on the TV and the DVI
jack on the DVD Player or
Cable Box/Satellite receiver
(Set-Top Box).
2 Connect Audio Cables
between the HDMI3/DVI IN
[R-AUDIO-L] jack on the TV
and the DVD Player or Cable
Box / Satellite receiver (Set-
Top Box).
➢Each DVD Player or Cable Box / Satellite receiver (Set-Top Box) has a different
back panel configuration.
➢When connecting a DVD Player or Cable Box / Satellite receiver (Set-Top Box),
match the color of the connection terminal to the cable.
➢When using an HDMI / DVI cable connection, you must use the HDMI3/DVI IN
jack.
Connecting a DVD Player or Cable Box / Satellite receiver (Set-Top Box) via HDMI
This connection can only be made if there is an HDMI Output jack on the external device. This connection will
provide the highest quality picture.
1 Connect an HDMI Cable
between the HDMI IN (1, 2 or
3) on the TV and the HDMI
jack on the DVD Player or
Cable Box / Satellite receiver
(Set-Top Box).
What is HDMI?
• HDMI, or high-definition multimedia interface, is an interface that enables the
transmission of digital audio and video signals using a single cable.
• The difference between HDMI and DVI is that the HDMI device is smaller in size and
has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed.
➢Each DVD Player or Cable Box / Satellite receiver (Set-Top Box) has a different
back panel configuration.
➢The TV may not output sound and pictures may be displayed with abnormal color
when DVD Player or Cable Box / Satellite receivers supporting HDMI versions
older than 1.3 are connected. When connecting an older HDMI cable and there is
no sound, connect the HDMI cable to the HDMI3/DVI IN jack and the audio cables
to the HDMI3/DVI IN [R-AUDIO-L] jacks on the back of the TV. If this happens,
contact the company that provided the DVD Player or Cable Box / Satellite receiver
to confirm the HDMI version, then request an upgrade.
➢HDMI cables that do not support HDMI version 1.3 may cause annoying flicker or
no screen display.
HDMI Cable (Not supplied)1
DVD Player or Cable Box /
Satellite receiver (Set-Top Box)
TV Rear Panel
DVD Player or Cable Box /
Satellite receiver (Set-Top Box)
TV Rear Panel
Audio Cable (Not supplied)2
HDMI/DVI Cable (Not supplied)1
or or
BP68-00670A-01Eng.indb 12 2008-04-24 오후 3:04:10

English - 13
Connecting a Camcorder
The side panel jacks on your TV make it easy to connect a camcorder to your TV.
They allow you to view the camcorder tapes without using a VCR
1 Connect a Video Cable
(or S-Video Cable) between
the AV IN 2 [VIDEO] jack on
the TV and the VIDEO OUT
jack on the Camcorder.
2 Connect Audio Cables
between the AV IN 2
[L-AUDIO-R] jacks on the TV
and the AUDIO OUT jacks on
the Camcorder.
➢Each Camcorder has a different back panel configuration.
➢
When connecting a Camcorder, match the color of the connection terminal to the cable .
Camcorder
Video Cable (Not supplied)1
Audio Cable (Not supplied)2
Connecting a DVD Player or Cable Box / Satellite receiver (Set-Top Box) via
Component cables
The side panel jacks on your TV make it easy to connect a DVD Player/Cable Box/Satellite receiver (Set-Top Box)
to your TV.
1 Connect Component Cables
between the COMPONENT
IN (1 or 2) [Y, PB, PR]
jacks on the TV and the
COMPONENT [Y, PB, PR]
jacks on the DVD Player
or Cable Box / Satellite
receiver(Set-Top Box).
2 Connect Audio Cables
between the COMPONENT
IN (1 or 2) [R-AUDIO-L] jacks
on the TV and the AUDIO
OUT jacks on the DVD Player
or Cable Box / Satellite
receiver (Set-Top Box).
➢Component video separates the video into Y (Luminance (brightness)), PB (Blue)
and PR (Red) for enhanced video quality. Be sure to match the component video
and audio connections. For example, if connecting the Component video cable to
COMPONENT IN 1, connect the audio cable to COMPONENT IN 1 also.
➢Each DVD Player or Cable Box or Satellite receiver (Set-Top Box) has a different
back panel configuration.
➢When connecting a DVD Player or Cable Box or Satellite receiver (Set-Top Box),
match the color of the connection terminal to the cable.
DVD Player or Cable Box /
Satellite receiver (Set-Top Box)
TV Rear Panel
Audio Cable (Not supplied)2
Component Cable (Not supplied)
1
TV Side Panel
BP68-00670A-01Eng.indb 13 2008-04-24 오후 3:04:11

English - 14
Connecting a VCR
Video Connection
These instructions assume that you have already connected your TV to an antenna or a cable TV system (according
to the instructions on pages 10~11). Skip step 1 if you have not yet connected to an antenna or a cable system.
➢If you have a “mono” (non-stereo) VCR, use a Y-connector (not supplied) to hook
up to the right and left audio input jacks of the TV.
If your VCR is stereo, you must connect two cables.
➢Each VCR has a different back panel configuration.
➢When connecting a VCR, match the color of the connection terminal to the cable.
VCR Rear Panel
TV Rear Panel
2
Audio Cable(Not supplied)5
Video Cable(Not supplied)4
Antenna cable(Not supplied)3
S-Video Connection
Your Samsung TV can be connected to an S-Video jack on a VCR.
(This connection delivers a better picture as compared to a standard VCR.)
1 To begin, follow steps 1–3
in the previous section to
connect the antenna or cable
to your VCR and your TV.
2 Connect an S-Video Cable
between the S-VIDEO OUT
jack on the VCR and the AV
IN 1 [S-VIDEO] jack on the
TV.
3 Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the AV
IN 1 or 2 [R-AUDIO-L] jacks
on the TV.
An S-Video may be included with your VCR. (If not, check your local electronics store.)
➢Each VCR has a different back panel configuration.
➢When connecting a VCR, match the color of the connection terminal to the cable.
VCR Rear Panel
TV Rear Panel
Audio Cable (Not supplied)
3
S-Video Cable(Not supplied)2
Antenna cable(Not supplied)1
1 Unplug the cable or antenna
from the back of the TV.
2 Connect the cable or antenna
to the ANT IN terminal on the
back of the VCR.
3 Connect an Antenna Cable
between the ANT OUT
terminal on the VCR and the
ANT IN terminal on the TV.
4 Connect a Video Cable
between the VIDEO OUT
jack on the VCR and the AV
IN (1 or 2) [VIDEO] jack on
the TV.
5 Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the AV
IN (1 or 2) [VIDEO] jacks on
the TV.
BP68-00670A-01Eng.indb 14 2008-04-24 오후 3:04:14

English - 15
Connecting an Amplifier / DVD Home Theater
1 Connect Audio Cables
between the AUDIO OUT
[R-AUDIO-L] jacks on the TV
and AUDIO IN [L-AUDIO-R]
jacks on the Amplifier/DVD
Home Theater.
When an audio amplifier is
connected to the “AUDIO
OUT [R-AUDIO-L]” jacks
terminals: Decrease the
volume of the TV, and adjust
the volume level with the
Amplifier’s volume control.
➢Each Amplifier / DVD Home Theater has a different back panel configuration.
➢When connecting an Amplifier / DVD Home Theater, match the color of the
connection terminal to the cable.
Amplifier /
DVD Home Theater
TV Rear Panel
Audio Cable (Not supplied)
Connecting a Digital Audio System
The side panel jacks on your TV make it easy to connect a Digital Audio System to your TV.
1 Connect an Optical Cable
between the DIGITAL AUDIO
OUT (OPTICAL) jack on
the TV and the Digital Audio
Input (OPTICAL) jacks on the
Digital Audio System.
When a Digital Audio System
is connected to the “DIGITAL
AUDIO OUT (OPTICAL)”
jack:
Decrease the volume of the
TV, and adjust the volume
level with the system’s
volume control.
What is OPTICAL?
• An optical cable converts an electric signal into an optical light signal, and transmits
it through glass fibers. S/PDIF is a transmission system of digital audio in the form of
a light wave that uses a glass conductor.
➢Each Digital Audio System has a different back panel configuration.
➢When the receiver (home theater) is set to On, you can hear sound output from
the TV’s Optical jack. When the TV is displaying a DTV(air) signal, the TV will send
out 5.1 channel sound to the Home theater receiver. When the source is a digital
component such as a DVD and is connected to the TV via HDMI, only 2 channel
sound will be heard from the Home Theater receiver.
➢If you want to hear 5.1 channel audio, connect the DIGITAL AUDIO OUT
(OPTICAL) jack on the DVD player or Cable/Satellite Box directly to an Amplifier or
Home Theater, not the TV.
Digital Audio System
TV Rear Panel
Optical Cable (Not supplied)
BP68-00670A-01Eng.indb 15 2008-04-24 오후 3:04:17

English - 16
Operation
Turning the TV On and Off
Press the POWER button on the remote control.
You can also use the POWER button on the TV.
➢It may take a while before you see a full picture.
Using the D-Sub Cable
1 Connect a D-Sub Cable
between PC IN [PC] jack on
the TV and the PC output
jack on your computer.
2 Connect a PC Audio Cable
between the PC IN [AUDIO]
jack on the TV and the Audio
Out jack of the sound card on
your computer.
Using the HDMI/DVI Cable
1 Connect a HDMI/DVI cable
between the HDMI3/DVI IN
jack on the TV and the PC
output jack on your computer.
2 Connect a 3.5 mm Stereo
mini-plug/2RCA Cable
cable between the DVI IN
[R-AUDIO-L] jack on the TV
and the Audio Out jack of the
sound card on your computer.
➢Each PC has a different back panel configuration.
➢When connecting a PC, match the color of the connection terminal to the cable.
➢When using an HDMI/DVI cable connection, you must use the HDMI3/DVI IN
terminal.
Connecting a PC
PC
TV Rear Panel
PC Audio Cable (Not supplied)2
D-Sub Cable (Not supplied)1
Using the D-Sub Cable
Using the HDMI/DVI Cable
TV Rear Panel
PC
3.5 mm Stereo mini-plug/2RCA Cable (Not supplied)
2
HDMI/DVI Cable (Not supplied)
1
BP68-00670A-01Eng.indb 16 2008-04-24 오후 3:04:20

English - 17
Plug & Play Feature
The first time you turn on your new TV, choose your basic settings for language, input source and channels, and
time of day using the plug and play feature. The TV will store these settings in memory. Storing the channels in
memory will allow you to scan the stored channels rather than have to enter their digits each time you want to
change channels.
When the TV is initially powered on, basic settings proceed automatically:
1Press the POWER button on the remote control.
The message Menu Language, Store Demo, Channels and Time will be set.
is automatically displayed.
2Press the ENTER button to enter the language.
Press the ▲ or ▼ button to select language, then press the ENTER button.
The message Select 'Home Use' when installing this TV in your home. is
automatically displayed.
3 Press the ◄ or ► button to select Store Demo or Home Use, then press the
ENTER button.
 ➢ The default selection is Home Use.
 ➢ We recommend setting the TV to Home Use for the best picture in your
home environment.
 ➢ Store Demo mode is only intended for use in retail environments.
 ➢ If the unit is accidentally set to Store Demo mode and you want to return
to Home Use (Standard): Press the Volume button on the TV. When the
volume OSD is displayed, press and hold the MENU button on the TV for 5
seconds.
4 Press the ▲ or ▼ button to memorize the channels of the selected connection,
then press the ENTER button.
 ➢ Air: Air antenna signal.
Cable: Cable antenna signal.
Auto: Air and Cable antenna signals.
 ➢ In Cable mode, you can select the correct analog signal source among
STD, HRC, and IRC by pressing the ◄ or ► button, then press the ENTER
button. If you have Digital cable, select the signal source for both Analog
and Digital. Contact your local cable company to identify the type of cable
system that exists in your particular area.
Continued...
Plug & Play
Menu Language, Store Demo, Channels and Time will
be set.
Enter
OK
SkipEnter
Plug & Play
Select the Antenna source to memorize
Air
Cable
Auto
Start
Start
Move
Plug & Play
Select Language of the OSD.
Menu Language : English ►
Enter
Plug & Play
Select 'Home Use' when installing this TV in your home.
Home Use
Store Demo
EnterMove
Plug & Play
Select Language of the OSD.
Enter
Menu Language : English
Move
English
Español
Français
Start
SkipEnter
Plug & Play
Move
Selects the cable system.
Analog
Digital
STD HRC IRC
HRC IRCSTD
Start
BP68-00670A-01Eng.indb 17 2008-04-24 오후 3:04:21

English - 18
5The TV will begin memorizing all of the available channels.
After all the available channels are stored, the Auto program menu reappears.
Press the ENTER button when channel memorization is complete.
The Clock Mode menu is displayed.
 ➢ To stop the search before it has nished, press the ENTER button with
stop selected.
6Press the ENTER button.
Press the ▲ or ▼ button to select Manual for setting the current time
manually, then press the ENTER button. The message Set current date and
time. is displayed.
 ➢ If you select Auto, Set to daylight saving time. is displayed, then go to
step 9.
7 Press the ◄ or ► button to move to Month, Day, Year, Hour, Minute, or
am/pm.
Set the date and time you want by pressing the ▲ or ▼ button, then press the
ENTER button.
 ➢ You can set the month, day, year, hour, and minute directly by pressing the
number buttons on the remote control.
8The message Enjoy your watching. is displayed.
When you have nished, press the ENTER button.
 ➢ Even if the ENTER button is not pressed, the message will automatically
disappear after several seconds.
Setting the Clock Automatically
9Press the ENTER button.
Press the ▲ or ▼ button to select Off or On, then the ENTER button.
The message Select the time zone in which you live. is displayed.
10 Press the ▲ or ▼ button to highlight the time zone for your local area (and
to move the highlight to the appropriate time zone on the map of the United
States).
Press the ENTER button.
If clock is not automatically set, see pages 50~51 to set the clock.
11 The message Enjoy your watching. is displayed.
When you have nished, press the ENTER button.
 ➢ Even if the ENTER button is not pressed, the message will automatically
disappear after several seconds.
Continued...
Plug & Play
Auto Program is incomplete.
7 channels are memorized.
Air : 7 Cable : 0
OK
Enter Skip
Plug & Play
Set the Clock Mode.
Clock Mode : Auto
Auto
Manual
SkipEnterMove
Plug & Play
Auto Program in Progress.
Stop
Enter Skip
Air
3%
DTV Air : -- Air : --
DTV Cable : -- Cable : --Cable : --
OK
Plug & Play
Enjoy your watching.
SkipEnter
Plug & Play
Set to daylight saving time.
DST : Off
Off
On
Move
Plug & Play
Set current date and time
01
Month
01
Day
2008
Year
12
Hour
00
Minute
am
am/pm
SkipEnterAdjustMove
Plug & Play
Select the time zone in which you live.
Newfoundland
Atlantic
Eastern
Central
Mountain
Pacific
▼
SkipEnterMove
OK
Plug & Play
Enjoy your watching.
BP68-00670A-01Eng.indb 18 2008-04-24 오후 3:04:22

English - 19
If you want to reset this feature...
1 Press the MENU button to display the menu.
Press the ▲ or ▼ button to select Setup, then press the ENTER button.
2Press the ENTER button to select Plug & Play. For further details on setting
up options, refer to the pages 17~18.
 ➢ The Plug & Play feature is only available in the TV .
Changing Channels
Using the Channel Buttons
1 Press the CH
W.LINK
CH LIST
or CH
W.LINK
CH LIST
button to change channels.
➢When you press the CH
W.LINK
CH LIST
or CH
W.LINK
CH LIST
button, the TV changes channels
in sequence. You will see all the channels that the TV has memorized.
(The TV must have memorized at least three channels). You will not
see channels that were either erased or not memorized. See page 21 to
memorize channels.
Using the Number Buttons
1 Press the number buttons to go directly to a channel. For example, to select
channel 27, press 2, then 7.
The TV will change channels when you press the second number.
➢For quick channel change, press the number buttons, then press the ENTER
button.
➢You can press number buttons on Remote control for direct channel access,
press the same Number button again to switch between digital and analog
TV channels broadcast by the same station.
Using the “-” Button
The “ ” button is used to select stations that broadcast a digital signal.
1 For example, for Channel 7-1, press 7, then , then 1.
➢HD indicates the TV is receiving a Digital High Definition signal.
SD indicates the TV is receiving a Standard Definition signal.
➢For quick channel change, press the number buttons, then press the ENTER
button.
Using the PRE-CH Button to select the Previous Channel
Use the number buttons to quickly tune to any channel.
1 Press the PRE-CH button. The TV will switch to the last channel viewed.
➢To quickly switch between two channels that are far apart, tune to one
channel, then use the number button to select the second channel.
Then use the PRE-CH button to quickly alternate between them.
Plug & Play ►
Language : English
Time
V-Chip
Caption
Melody
Entertainment : Off
Setup
Plug & Play
Menu Language, Store Demo, Channels and Time will
be set.
Enter
OK
Return
BP68-00670A-01Eng.indb 19 2008-04-24 오후 3:04:23

English - 20
Viewing the Menus
1 With the power on, press the MENU button.
The main menu appears on the screen. The menu’s left side has icons:
Picture, Sound, Channel, Setup, Input, Application.
2 Press the ▲ or ▼ button to select one of the icons.
Then press the ENTER button to access the icon’s sub-menu.
3 Press the EXIT button to exit.
➢It takes about one minute until the on-screen menu disappears.
Mode :Standard
Contrast : 80
Brightness : 45
Sharpness : 50
Color : 50
Tint (G/R) : G50/R50
Detailed Settings
Picture Options
Adjusting the Volume
Using the Volume Buttons
1 Press the VOL
W.LINK
CH LIST
or VOL
W.LINK
CH LIST
button to increase or decrease the volume.
Using the Mute Button
At any time, you can cut off the sound using the MUTE button.
1 Press MUTE and the sound cuts off.
The is displayed on the screen.
2 To turn mute off, press the MUTE button again, or simply press the VOL
W.LINK
CH LIST
or
VOL
W.LINK
CH LIST
button.
Viewing the Display
The display identifies the current channel and the status of certain audio-video settings.
1 Press the INFO button on the remote control.
The TV will display the channel, the type of sound, and the status of certain
picture and sound settings.
Press the INFO button once more or wait approximately 10 seconds and it disappears
automatically.
TV #1 Wed, Jan 2 12:28am
M. Spillane’s Mike Hammer
Bonocrunch
DTV Air
13-1
Dolby Digital
480i 4:3 English
11:36 pm - 12:42 am
