Samsung LNT series Technical manual

Samsung Electronics
Samsung TV
F/W Update Guide
Model : 2007 models
LCD TV : LNT series
PDP TV : HPT series
DLP TV : HLT series

2. Connect the USB Memory Drive
to the USB port of your PC.
Copy the file onto the USB Memory Drive.
3. Go to the USB Memory Drive and then double click the file.
1. Save the firmware file from Samsung.com onto your computer.
4. Press the “Unzip” button. 5. Unzipping is in progress.
6. After completing, please press the
“OK” and “Close” buttons. 7. A folder containing the firmware files has been added to the USB memory drive.
* DO NOT CHANGE or MODIFY
THE FOLDER NAME
8. Safely disconnect the USB memory drive
by right clicking the green check mark
on the taskbar and then left click
“Safely Remove”.
OK
1. Prepare the USB Memory Drive

2. Firmware Upgrade with the USB Memory Drive
1. Turn the TV on, and then insert the
USB Memory Drive into the USB port
on the rear or side AV panel of the TV.
2. Press the Menu button on the
remote control.
3. Select Setup, and then press Enter or
the arrow button (▶) on the remote control.
4. On the Setup Menu, select SW Upgrade,
and then press Enter or the arrow
button (▶) on the remote control.
5. The TV displays USB. Press Enter or
the arrow button (▶) on the remote control.

9. After completing the firmware update,
the TV will turn off in 3 seconds and
turn back on.
6. The TV scans the USB Memory Drive.
Note: This may take up to 30 seconds.
7. A message will appear asking
if you want to perform the firmware
update.
Select “Yes” and then press the
“Enter” button on the remote control.
8. The firmware update will start.
This should take 30 sec. to 1 min.
-. Do not disconnect
the USB drive during this step.
-. Do not unplug the power cable
or turn the TV off.
2. Firmware Upgrade with the USB Memory Drive
10. It is safe to remove the USB Memory Drive after the TV turns on.

3. How to check Firmware Version
1. Press the Menu button
on the remote control 2. Go to Setup. On the Setup Menu,
select Function Help.
3. Highlight the On option as
shown above, and then
press the Info button on
the remote control.
The firmware version
appears at the bottom
of the screen.
TV F/W Version : 1024

Firmware Upgrade Error Messages
1. If the USB Memory Drive was not inserted into USB port.
2. If there are no files on USB Memory Drive.
3. While update is in progress, please do not pull the USB
Memory Drive out or do not unplug the power cable.
