Samsung QN75QN8 A Series User manual

75″
85″
* : 0~9, A~Z
QN75QN8**B 65.7 inches
(1668.3 mm)
37.6 inches
(955.6 mm)
0.7 inches
(17.2 mm)
40.3 inches
(1023.7 mm)
12.5 inches
(318.3 mm) 74.5 inches 71.0 lbs
(32.2 kg)
92.8 lbs
(42.1 kg)
QN85QN8**B 74.5 inches
(1893.4 mm)
42.6 inches
(1083.0 mm)
0.7 inches
(17.4 mm)
45.3 inches
(1151.5 mm)
13.4 inches
(341.4 mm) 84.5 inches 97.7 lbs
(44.3 kg)
121.9 lbs
(55.3 kg)
QN75QN9**B 65.1 inches
(1654.8 mm)
37.2 inches
(945.6 mm)
0.6 inches
(15.4 mm)
40.0 inches
(1017.4 mm)
12.5 inches
(318.3 mm) 74.5 inches 69.9 lbs
(31.7 kg)
92.2 lbs
(41.8 kg)
QN85QN9**B 73.9 inches
(1876.6 mm)
42.2 inches
(1071.5 mm)
0.6 inches
(15.4 mm)
45.1 inches
(1146.1 mm)
13.4 inches
(341.4 mm) 84.5 inches 96.6 lbs
(43.8 kg)
120.8 lbs
(54.8 kg)
* : 0~9, A~Z : Wall-Mount Bracket
QN75QN8**B QN85QN8**B QN75QN9**B QN85QN9**B
VESA x (mm) 400 x 400 600 x 400 400 x 400 600 x 400
(mm) 5-6
+
x 4 M8
(mm) 1.25
(inches) 8.5 8.5 8.3 8.3
(inches) 25.0 25.5 24.7 25.1
(inches) 13.1 18.2 13.0 18.0
15 cm
6 inches
* When installing the TV as wallmount, You can place the One Connect Box as shown below.
* To install using a wall mount, be sure to use the supplied HOLDER-WALL RING. HOLDER-BOLT x 3 HOLDER-WALL RING x 4
[When installing the TV as stand, Don’t place
the One Connect Box on back of the TV.
BN68-13876A-01
WScan this QR code
with your smart phone
to see helpful videos.
Quick Setup Guide
(Unpacking and Installation Guide)
9 10
85″

x 2
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
x 2
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
x 4
(M4 x L12)
Power Cable
One Connect Box
Samsung Smart Remote
One Connect Cable x 2
User Manual /
Regulatory Guide
1 2
3 4
5 6
7 8
