Samsung QA75Q60AAUXZN Guide

E-MANUAL
Thank you for purchasing this Samsung product.
To receive more complete service, please register your
product at
www.samsung.com
Model Serial No.
To directly go to the page that provides instructions on
how to use the manual for visually impaired users, select
the Menu Learning Screen link below.
"Menu Learning Screen" Link
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Samsung Q60A 75"
(QA75Q60AAUXZN) o cerca il tuo prodotto tra le migliori offerte di Televisori

Contents
Guide
Connections
5Connection Guide
7 Connecting an Antenna (Aerial)
8Connecting to the Internet
12 Screen Sharing (Smart View) with your Mobile Device
15 Connecting to a Network via a Mobile Dongle (For India
Only)
16 Connection Cables for External Devices
18 ADB (Auto Data Backup) functions (For India Only)
19 Switching between external devices connected to the TV
21 Connection Notes
Remote Control and Peripherals
24 About the Samsung Smart Remote (QLED TV/AU9 Series or
higher/The Frame)
27 About the Samsung Smart Remote (AU8 Series)
30 Connecting the Samsung Smart Remote to the TV
31 Controlling External Devices with a Samsung Remote
Control - Using the Universal Remote
32 Using Anynet+ (HDMI-CEC)
33 Controlling the TV with a Keyboard, Mouse or Gamepad
35 Entering Text using the On-Screen Virtual Keyboard
Smart Features
37 Using Smart Hub
46 Using a Samsung account
48 Using Ambient Mode
53 Using Art Mode
61 Using PC on TV
67 Using the Apps Service
71 Using the e-Manual
73 Using the Internet
74 Using SmartThings
77 Playing pictures/video/music
84 Using Multi View
86 Using Bixby
91 Using the Game Bar
TV Viewing
94 Using the Guide
96 Recording Programmes
98 Setting Up Schedule Viewing
100 Using Timeshift
100 Buttons and functions available while recording a
programme or Timeshift
102 Using the Channel List
103 Editing channels
104 Using a Personal Favourites List
105 TV-Viewing Support Functions
Picture and Sound
112 Using Intelligent Mode
114 Adjusting the Picture Quality
116 Setting the Viewing Environment for External Devices
119 Picture Support Functions
120 Conguring a Sound Mode and Expert Settings
122 Using the Sound Support Functions
System and Support
124 Using the Time Functions and the Timers
126 Using the Power and Energy Saving Functions
127 Updating the TV's Software
128 Audio and Video Functions for the Visually or Hearing
Impaired
133 Using Voice Assistants on the TV
134 Using Other Functions
136 HbbTV
137 Using a TV Viewing Card (“CI or CI+ Card”) (For India Only)
140 Teletext Feature

Precautions and Notes
144 Before Using the Recording and Timeshift Functions
146 Supported broadcasting audio options
147 Read Before Using Apps
148 Read Before Using the Internet Function
150 Read Before Playing Photo, Video or Music Files
160 Read After Installing the TV
161 Supported Resolutions for UHD Input Signals
162 Resolutions for Input Signals supported by 8K models
(QN7**A series or higher)
163 Supported Resolutions for FreeSync (VRR)
164 Supported Resolutions for Wide Screen
165 Read Before Connecting a Computer (Supported
Resolutions)
168 Supported Resolutions for Video Signals
170 Read Before Using Bluetooth Devices
171 Sufx : Parental Rating - Thailand only
172 Licences
Troubleshooting
Picture Issues
173 Testing the picture
Sound and Noise Issues
179 Testing the sound
Channel and Broadcast Issues
External Device Connectivity Issues
Network Issues
Anynet+ (HDMI-CEC) Issues
Remote Control Issues
Recording Issues
Apps
Media Files
Voice Assistant Issues
Other issues
Diagnosing TV operational issues
Getting Support
195 Getting support through Remote Management
195 Finding the contact information for service
195 Requesting service

FAQ
The TV Screen does not Display Properly
196 When the TV screen does not display properly
The TV does not Turn On
201 When your TV does not turn on
The Picture is Distorted, or No Sound Comes Out of the
Sound Bar
207 When the TV does not connect with an external device
properly
Internet Access is not Available
211 When the TV can't connect to the Internet
There is No Sound or the Speakers are Making an Odd Sound
216 When no sound comes out of the TV, or the sound is
breaking up
The Remote Control does not Work
222 When the remote control does not work
Updating the Software
226 Updating to the latest TV's software
Accessibility Guidance
Menu Learning Screen
232 Using the Remote control
234 Using the accessibility menu
238 Using the TV with Voice Guide on
240 Using the guide
243 Using Schedule Viewing
244 Using the Channel List
246 Recording
249 Using Smart Hub
253 Launching the e-Manual
254 Using Bixby

Guide
Learn how to use various features.
Connections
You can watch live broadcasts by connecting an antenna cable to your TV and can get access to the Internet by
using a LAN cable or wireless access point. Using various connectors, you can also connect external devices.
Connection Guide
You can view detailed information about external devices that can be connected to the TV.
Source Connection Guide Try Now
It shows you how to connect various external devices such as video devices, game consoles and PCs using pictures.
If you select the connection method and an external device, the connection details appear.
•Audio Device: HDMI (eARC), Optical, Bluetooth, Wi-Fi, Wi-Fi Speaker Surround Setup
•Video Device: HDMI, AV
•Smartphone: Screen Sharing (Smart View), SmartThings, Apple AirPlay, NFC on TV, Tap View
•PC: HDMI, Screen Sharing (Wireless), Apple AirPlay
•Input Device: Remote Control, Keyboard, Mouse, USB Gamepad, USB Camera, Bluetooth Device
•Game Console: HDMI, AV
- 5 -

•External Storage: USB Flash Drive, Hard Disk Drive (HDD)
Using HDMI Troubleshooting, you can check the connection to HDMI cable and external devices (takes approximately 2
minutes).
Some functions may not be supported depending on the model or geographical area.
The connection method and available external devices may differ depending on the model.
Connection Guide
Audio Device
Video Device
Smartphone
PC
Input Device
Game Console
External Storage
HDMI (eARC)
Optical
Bluetooth
Wi-Fi
Wi-Fi Speaker Surround Setup
HDMI Troubleshooting
Connect audio devices, such as speakers, sound bars,
headphones, or home theatres, to your TV.
The image on your TV may differ from the image above depending on the model and geographical area.
- 6 -

Connecting an Antenna (Aerial)
You can connect an antenna cable to your TV.
An antenna connection is not necessary if you connect a cable box or satellite box.
The port on your TV may differ from the following gure depending on the product model and region.
A connection method may differ depending on the model or geographical area.
- 7 -

Connecting to the Internet
You can get access to the Internet through your TV.
Settings General Network Open Network Settings Try Now
Congure network settings to connect to an available network.
Establishing a wired Internet connection
Settings General Network Open Network Settings Wired
If you connect a LAN cable, the TV automatically accesses the Internet.
If the TV does not automatically connect to the network, refer to "Network Issues" in "Troubleshooting".
To connect a LAN cable, use a CAT 7 (*STP type) cable for the connection. (100/10 Mbps)
* Shielded Twisted Pair
The TV will not be able to connect to the Internet if your network speed is below 10 Mbps.
This function may not be supported depending on the model.
- 8 -

Establishing a wireless Internet connection
Settings General Network Open Network Settings Wireless
Make sure that you have the wireless access point's name (SSID) and password settings before attempting to
connect. The network name (SSID) and security key are available on the wireless access point's conguration
screen. See the wireless access point's user manual for more information.
- 9 -

Wireless Connection
Select your wireless network.
Refresh
Manage Saved Networks
The image on your TV may differ from the image above depending on the model and geographical area.
If no wireless access point is found, select Add Network at the bottom of the list and enter the network name (SSID).
If your wireless access point has a WPS or PBC button, select Use WPS at the bottom of the list, and then push the WPS or
PBC button on your access point within 2 minutes. The TV will connect automatically.
To view or delete previously connected network names (SSIDs), move the focus to Manage Saved Networks, and then press
the Select button.
To disconnect Wi-Fi, select Disconnect in Settings General Network Network Status.
Checking the Internet connection status
Settings General Network Network Status Try Now
View the current network and Internet status.
Resetting Your Network
Settings General Network Reset Network Try Now
Restore the network settings to the factory default.
- 10 -

Turning on the TV with a mobile device
Settings General Network Expert Settings Power On with Mobile
You can turn on the TV using a mobile device connected to the same network as the TV.
This function is available with a mobile device connected to the TV through the SmartThings app or the Apple AirPlay
function.
Apple AirPlay may not be supported depending on the model or geographical area.
Connecting an IP control device to the TV
Settings General Network Expert Settings IP Remote
You can connect an IP control device to the TV remotely to manage your IP device.
To use this function, Power On with Mobile must be turned on.
Turning this feature on may allow other IP control devices to control your TV. We recommend turning this feature on only
if an authorised third-party custom controller is installed and congured specically for a Samsung TV and if your Wi-Fi
network is password protected.
This function may not be supported depending on the model or geographical area.
Allowing to connect a wireless network
Settings General Network Expert Settings Wi-Fi
You can enable the connection to Wi-Fi.
To connect a wireless network, the function must be active.
Changing the name of the TV
Settings General System Manager Device Name Try Now
You can change the name of the TV on the network. Select User Input at the bottom of the list and change the
name.
- 11 -

Screen Sharing (Smart View) with your Mobile Device
You can watch the screen of your mobile device on the TV screen through Smart View, Tap View or Multi View.
For information on how to share the screen with your mobile device, refer to Source Connection Guide
Smartphone Screen Sharing (Smart View).
• To turn off Screen Sharing (Smart View), disconnect the mobile device or press the button on the remote
control.
• Using the Smart View menu on your mobile device, you can change the settings such as aspect ratio.
• Use AirPlay if you are an iPhone or iPad user. For more information, refer to Source Connection Guide
Smartphone Apple AirPlay.
This function may not be supported depending on the model or geographical area.
• The screen sharing function (Smart View / Apple AirPlay) on your mobile device appears on Multi View of the TV
(or the screen on your mobile device).
This function may not be supported depending on the model or geographical area.
- 12 -

Using Tap View
Tap your mobile device on the TV, you can watch the Multi View or mobile device's screen through the TV screen.
When you tap a mobile device on your TV while running a music app on your mobile device, the TV screen switches
to the Music Wall screen.
This function may not be supported depending on the model.
This function is available in Samsung mobile devices with Android 8.1 or higher.
Music Wall screen is a function that allows you to enjoy music along with visual video effects that change according to the
genre and beat of the music.
1. Enable Tap View on your mobile device.
For more information about conguration, refer to 'Enabling Tap View'.
2. Turn on the screen of your mobile device.
3. Tap your mobile device on the TV. The TV screen switches to Multi View, Music Wall or mobile device's screen.
When you perform Tap View while in Ambient Mode or Art Mode, only the mobile device's screen appears on the TV.
4. Watch the Multi View, Music Wall or mobile device's screen on the TV screen.
The displayed TV screen may differ depending on the model.
This function enables Screen/Sound Mirroring by detecting vibrations generated when you tap the mobile device on the TV.
Be sure to tap away from the TV screen and bezel corners. It may be scratched or broken to the TV or mobile device screen.
We recommend using your mobile device with the cover in place and lightly tap it on any external edge of the TV.
- 13 -

Enabling Tap View
Enable Tap View in the SmartThings app.
This function may not be supported depending on the model.
Depending on the SmartThings app version, you may need to register the TV with your mobile device.
1. Launch the SmartThings app on your mobile device.
2. Select Settings ( ) in SmartThings app on your mobile device.
3. Set Tap View to on.
Upon connection for the rst time, select Allow on a pop-up window of the TV.
Mobile Screen Viewing in Multi View
When you start screen sharing with a mobile device (Smart View / Apple AirPlay / Tap View), the TV screen switches
to the Multi View or mobile device's screen. Watch multiple contents at the same time with the Multi View screen.
This function may not be supported depending on the model.
For more information, refer to "Using Multi View".
- 14 -

Connecting to a Network via a Mobile Dongle (For India Only)
Make network connection by connecting a mobile dongle to the TV.
You can make the TV to connect to a network via a mobile device by connecting a mobile dongle to the TV. Connect
the mobile dongle to the USB port that are marked as Dongle in the TV.
This function is not available on certain models in specic geographical areas.
When you use a large mobile dongle(Data Card), USB devices may not work properly due to interferences among the USB
ports, or the wireless network may not work properly due to interferences from the peripherals and surroundings. In this
case, use a USB extension cable to connect a large mobile dongle to a USB port.
When using the optical cable or 3G dongle, interference may occur due to the large size of the dongle.
Channel-Bound Apps is not available when you set up mobile network.
If you have any problems using online services, please contact your Internet service provider.
The mobile service providers and their devices that support this function are as follows:
• Airtel (Model No: E3276s LTE, E1731, E303C, E303U, E3131B, E3121B, E8221, E8231, E3276 LTE)
• Idea, Vodafone
- 15 -

Connection Cables for External Devices
You can view detailed information about the connection cables for external devices that can be connected to the TV.
Cable name Image Description
HDMI
to
HDMI
Each cable simultaneously transmits digital video and audio signals
from an external device to the HDMI port on the TV.
Cables are divided into various types according to the types of input/
output ports on external devices.
HDMI
to
MINI HDMI
HDMI
to
Micro HDMI
HDMI
to
USB Type-C
HDMI
to
DisplayPort
Mini DisplayPort
to
HDMI
- 16 -

Cable name Image Description
DVI
to
HDMI
DVI to HDMI cables can transmit only digital video signals and not
audio signals. We recommend that you use HDMI to HDMI cables.
Optical
Optical cables are used to transmit audio signals to external
speakers with low signal loss.
Optical cables can't transmit video signals.
Component
Component cables transmit analogue signals.
The video signal is separated and transmitted to the red, green and
blue terminals to provide HD (1080i) pictures. The audio signal is
transmitted to the red and white terminals.
Composite
Composite cables transmit analogue signals.
The video signal is transmitted to the yellow terminal and the audio
signal is transmitted to the red and white terminals.
Available connection cables may differ depending on the model or geographical area.
- 17 -

ADB (Auto Data Backup) functions (For India Only)
This function may not be supported depending on the model or geographical area.
Your mobile device comes close to the TV, the ADB (Auto Data Backup) feature backs up your mobile data such
as images and videos into a pre-congured specic folder on a USB storage device or an external hard disk drive
connected to the TV. You can also transfer les from the ADB (Auto Data Backup) folder to a Samsung mobile
device over Wi-Fi Direct.
• Transferring data from a mobile device to the TV
Your mobile device comes close to the TV, images and videos are copied from your mobile device to a USB
storage device or an external hard disk drive connected to the TV.
• Transferring data from the TV to a mobile device
You can select and transfer files from the ADB (Auto Data Backup) folder on the TV to a Samsung mobile device.
How to Use ADB (Auto Data Backup)
1.ADB (Auto Data Backup) Registration
First, register the TV using the USB Backup app, and then select a USB storage device or an external hard disk drive
connected to the TV. The ADB (Auto Data Backup) folder is automatically created on the selected storage device.
Then, select folders from your mobile device's gallery, set the password to open the ADB (Auto Data Backup) folder
on the selected storage device connected to the TV.
2.Auto File Copy
When your mobile device comes close to the TV, data are automatically copied from the selected folders on your
mobile device to the selected storage device connected to the TV.
3.Share les back from the ADB folder to a mobile device
You can also share le back from ADB folder to Samsung Mobile, by rst connecting Samsung Mobile with TV over
Wi-Fi direct & then select the les to be transferred from TV, and press "Share" option to send les to connected
Mobile device.
- 18 -

Switching between external devices connected to the TV
You can switch between TV programmes and the content of external devices.
Source
When you select a connected external device on the Source screen, the output of the selected device is displayed on
the TV's screen.
On the Standard Remote Control, press the SOURCE button.
To control a device (Blu-ray player, game console, etc.) that supports universal remote control with the TV's remote control,
connect the device to an HDMI port on the TV, and then turn on the device. The output displayed on the TV is automatically
switched to the output of the device or you can congure universal remote control for the device automatically. For more
information, refer to "Controlling External Devices with a Samsung Remote Control - Using the Universal Remote".
When a USB device is connected to the USB port, a pop-up message appears that lets you switch easily to the media
content listed on the device.
This function may not be supported depending on the device and geographical area.
Editing the name and icon of an external device
Source
You can change the port name for a connected external device or add it to the Home Screen.
Sources
Universal Remote
Edit
Information
Add to Home
Source
The image on your TV may differ from the image above depending on the model and geographical area.
1. Move the focus to a connected external device.
2. Press the up directional button. The following functions become available.
Available functions may differ depending on the port type.
- 19 -

1.Universal Remote
You can control external devices connected to the TV using a Samsung remote control. To control external devices,
register them by following the instructions on the screen.
This function may not be supported depending on the model or geographical area.
For more information, refer to "Controlling External Devices with a Samsung Remote Control - Using the Universal
Remote".
2.Edit
You can rename the input ports and change the device icons.
3.Information
You can view detailed information about an external device.
4.Add to Home
You can add the port of an external device to the Home Screen for quick switching.
Using additional functions
You can use the following features on the Source screen.
•PC on TV
Use the TV to access your PC via remote PC or Screen Sharing (Wireless).
For more information, refer to "Using PC on TV".
•Connection Guide
Displays device connection instructions.
For more information about the Connection Guide, refer to "Connection Guide".
•Remote Key Guide
You can view how to use the remote control.
This function may not be supported depending on the model or geographical area.
•Universal Remote
Lets you register external devices to your Samsung remote control and control them using the Remote.
This function may not be supported depending on the model or geographical area.
For more information, refer to "Controlling External Devices with a Samsung Remote Control - Using the Universal
Remote".
- 20 -
