Samsung POWERbot SR1 M70 Series User manual

POWERbot
User manual
SR1M70, SR2M70 Series
• Before operating this unit, please read the instructions carefully.
• For indoor use only.
1_VR7000_EN_DJ68-00763G-03_SB.indd 1 2017-03-03 오후 3:38:53

ENGLISH-02
Contents 03 Safety information
08 Installation
Accessories / Installation note
10 Charging
Automatic charging / Recharging / Low
battery (Lo)
12 Using POWERbot
Turning the power on/off / Selecting
cleaning modes/ Using special cleaning
functions
15 Installing the Virtual guard
Part name of the Virtual guard /
Inserting batteries
17 Using the remote control
20 Name of each part
Top / Bottom / Display panel
22 Setting time/schedule
Setting the time / Setting the schedule
25 Cleaning and maintaining
Cleaning the dustbin / Cleaning the sensors and
the camera / Cleaning the brush and Auto shutter
tool / Cleaning the Driving wheel
27 Samsung Smart Home App
Preparing the network / Using the Samsung
Smart Home app
31 Notes and cautions
Charging / Using / Cleaning and maintenance /
About the battery / About the IrDA sensor
33 Information codes
35 Troubleshooting
37 Warnings about battery
38 Open Source Announcement
39 Specications
1_VR7000_EN_DJ68-00763G-03_SB.indd 2 2017-03-03 오후 3:38:53

ENGLISH-03
Safety information
SAFETY INFORMATION
WARNING
• Before operating the appliance, please read this manual thoroughly and
retain it for your reference.
WARNING
• Because these following operating instructions cover various models, the
characteristics of your vacuum cleaner may differ slightly from those
described in this manual.
CAUTION/WARNING SYMBOLS USED
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
NOTE
Indicates that a risk of personal injury or material damage exists.
This Smart Robot vacuum supports from Samsung Smart Home.
More detailed information, please visit Samsung.com/Smarthome.
• For information on Samsung’s environmental commitments and product
specic regulatory obligations e.g. REACH visit: samsung.com/uk/
aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.htm
1_VR7000_EN_DJ68-00763G-03_SB.indd 3 2017-03-03 오후 3:38:53

ENGLISH-04
Safety information
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be observed, including
the following:
READ ALL INSTRUCTIONS BEFORE USING YOUR POWERbot.
Unplug from outlet when not in use and before conducting maintenance.
WARNING: to reduce the risk of re, electric shock, or injury:
GENERAL
• Use only as described in this manual.
• Do not operate POWERbot or the battery charger / docking station if it has
been damaged in any way.
• If the vacuum cleaner is not working as it should, has been dropped, damaged,
left outdoors, or dropped in water, return it to a customer care center.
• Do not handle the battery charger / docking station or POWERbot with wet
hands.
• Use only on dry, indoor surfaces.
• This appliance can be used by children aged from 8years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualied person in order to avoid a hazard.
Battery charger / Docking station
• Do not modify the polarized plug to t a non-polarized outlet or extension
cord.
• Do not use outdoors or on wet surfaces.
• Unplug the battery charger / docking station from the outlet when not in use
and before servicing.
• Use only the battery charger / docking station supplied by the manufacturer to
recharge.
• Do not use with a damaged cord or plug or a loose power outlet.
• Do not pull or carry by the cord, use the cord as a handle, close the door on the
cord, or pull the cord around sharp edges or corners. Keep the cord away from
heated surfaces.
1_VR7000_EN_DJ68-00763G-03_SB.indd 4 2017-03-03 오후 3:38:53

ENGLISH-05
• Do not use extension cords or outlets with inadequate current carrying
capacity.
• Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord.
• Do not mutilate or incinerate batteries as they will explode at high
temperatures.
• Do not attempt to open the battery charger / docking station. Repairs should
only be carried out by a qualied customer care center.
• Do not expose the battery charger / docking station to high temperatures or
allow moisture or humidity of any kind to come into contact with the battery
charger / docking station.
• Do not charge the non-rechargeable batteries with charger.
POWERbot
• Do not pick up hard or sharp objects such as glass, nails, screws, coins, and etc.
• Do not use without a lter in place. When servicing the unit, never put ngers
or other objects into the fan chamber in case the unit accidentally turns on.
• Do not put any objects into openings. Do not use with any openings blocked;
keep openings free of dust, lint, hair, and anything that may reduce air ow.
• Do not pick up toxic materials (chlorine bleach, ammonia, drain cleaner, etc.).
• Do not pick up anything that is burning or smoke, such as cigarettes, matches,
or hot ashes.
• Do not use to pick up ammable or combustible liquids such as gasoline, nor
use on areas where they may be present.
• Locations with candles or desk lamps on the oor.
• Locations with unattended res (re or embers).
• Locations with distilled alcohol, thinner, ashtrays with burning cigarettes, etc.
• Do not use POWERbot in an enclosed space lled with vapours given off by oil
based paint, paint thinner, moth proong substances, ammable dust, or other
explosive or toxic vapours.
• Leaks from battery cells can occur under extreme usage or temperature
conditions. If the liquid gets on skin, wash quickly with water. If the liquid
gets into the eyes, ush them immediately with clean water for a minimum of
10minutes. Seek medical attention.
1_VR7000_EN_DJ68-00763G-03_SB.indd 5 2017-03-03 오후 3:38:53

ENGLISH-06
WARNING Power related
fPlease prevent any risk of electric shock
or re.
– Do not damage the power cord.
– Do not pull the power cord too hard or
touch the power plug with wet hands.
– Do not use a power source other than 100-
240V~ and also do not use a multi outlet
to supply power to number of devices
at the same time. (Do not leave the cord
carelessly on the oor.)
– Do not use a damaged power plug, power
cord or loose power outlet.
fClean dust or any foreign matters on the
pin and contact part of the power plug.
– There is a risk of electric shock or
malfunction.
WARNING Before use
fDo not use POWERbot near combustible
materials.
– Place near candle, desktop lamps, replace
or near combustible materials such as
gasoline, alcohol, thinners etc.
fThe POWERbot is intended for household
use therefore do not use it in an attic,
basement, storage, industrial building,
out of indoor space, places with moisture
(such as bathroom, laundry), on the table
or shelves.
– The POWERbot can be damaged or
malfunction.
fBe sure POWERbot does not pass through
or touch any kind of liquids.
– The POWERbot can be severely damaged
and it may contaminate other areas if the
wheels pass through liquid.
fDo not spill any liquids on the docking
station.
– There is a risk of re or electric shock.
fDo not use the docking station for
anything other than its intended purpose.
– There is a risk of re or severe damage to
the docking station.
fAlways keep the cliff sensor clean for
your safety.
WARNING In use
fIf any abnormal sounds, smells or smoke
come from POWERbot, immediately shut
off the emergency switch at the bottom
of POWERbot and contact a service
center.
WARNING Cleaning and
maintenance
fWhen power cord is damaged, contact
a service center to get it replaced by a
certied repairman.
– There is a risk of re or electric shock.
fPlease check with a Samsung Electronics
service center when exchanging
batteries.
– Using batteries from other products can
cause malfunction.
Safety information
1_VR7000_EN_DJ68-00763G-03_SB.indd 6 2017-03-03 오후 3:38:53

ENGLISH-07
CAUTION Before use
fInsert the dustbin before using
POWERbot.
fBe careful with the followings for proper
automatic recharging.
– Always turn on the power of the docking
station.
– Install the docking station where
POWERbot can easily nd.
– Do not leave any object in front of the
docking station.
fWhen installing the docking station, do
not leave the cord carelessly on the oor
since POWERbot may get tangled by it.
fDo not use POWERbot on black colored
oors.
– The POWERbot may not be able to operate
normally.
fDo not place any objects within 0.5m
to both sides and 1m to the front of the
docking station.
fMake sure the docking station's charging
contact is not damaged or have any
foreign matters on it.
fDo not install the docking station in an
area with a dark oor.
– If the oor around the docking station is
dark, recharging is hindered.
fMove any obstacles that may disturb
POWERbot's movement (such as
children's indoor swing or slides) before
cleaning.
fDo not use the POWERbot in a place
which is narrower than the turning
radius (0.5 m or less) of the POWERbot.
CAUTION In use
fUsing POWERbot on thick carpet may
damage both POWERbot and the carpet.
– The POWERbot cannot pass over carpet
that is thicker than 1 cm.
fDo not use POWERbot on tables or other
high surfaces.
– There is a risk of damage if it falls.
fThe POWERbot may bump into chair,
desk legs therefore move them away for
faster and efcient cleaning.
fWhen POWERbot is operating, do not lift
it up or carry it to another area.
fDo not hold by driving wheels of
POWERbot when carrying it to another
area.
fDo not put any objects on top of
POWERbot and camera since it may
cause malfunction.
fRemove any large papers or plastic bags
immediately when using POWERbot since
they may block the intake.
fDo not aim the red pointer directly at
people or animals.
fDo not lie down around the POWERBOT
that is running.
– Your hair may be caught in the brush,
resulting in physical injury.
CAUTION Cleaning and
maintenance
fPrevent any damage to POWERbot by
complying with the following
– Do not clean POWERbot by spraying water
directly onto it or use benzene, thinner,
acetone or alcohol to clean it.
fDo not disassemble or repair POWERbot.
This should only be done by a certied
repairman.
fAlways keep the obstacle sensor, cliff
sensor and camera clean.
– If foreign matter accumulates, sensors may
malfunction.
1_VR7000_EN_DJ68-00763G-03_SB.indd 7 2017-03-03 오후 3:38:53

ENGLISH-08
1Connect the
battery charger
jack to the
docking station
2Connect the
power cord
to the battery
charger
When using the battery
charger, the side with the
sticker attached must face
down.
3Connect the
power plug to
the outlet
Installation
The docking station must be plugged in and turned on at all times.
DC-IN
About 1m
About
0.5m
About
0.5m
Install the docking station in
a place without obstacles and
danger of falling.
1_VR7000_EN_DJ68-00763G-03_SB.indd 8 2017-03-03 오후 3:38:53

ENGLISH-09
Accessories
or
Remote control
(Not included with
SR1M701 Series)
Batteries (AAA type) User manual Spare lter
(Option)
Docking station Power cord Battery charger Virtual guard
(option)
 Battery Spec
SR1M70 series : Lithium-ion, 21.6V, 1800mAh, 6cell
SR2M70 series : Lithium-ion, 21.6V, 3600mAh, 6cell
Installation note
Note
fInstall the docking station in a place where the oor and wall are level.
fIt is best to install the docking station along the grain of wooden oors.
fIf the emergency switch is off, the POWERbot will not charge even if it is docked on the
docking station.
fAlways turn on the power of the docking station.
– If power is not supplied to the docking station, the POWERbot cannot nd it and cannot
automatically recharge.
– If the POWERbot is left detached from the docking station, the battery will drain naturally.
fIf the POWERbot is in sleep mode, power will not come on even if the emergency switch
is turned off and then on. Press and hold the [Start/Stop] button on the POWERbot to turn
the sleep mode off.
1_VR7000_EN_DJ68-00763G-03_SB.indd 9 2017-03-03 오후 3:38:54

ENGLISH-10
After completely charging the POWERbot for the rst time (after purchase), it can be used for 60
min. in Nomal ( ) mode. (Refer to the page 39 for the charging time.)
Smart Charging
If POWERbot runs out of charge in Auto clean mode, it will automatically return to the docking
station to be charged and will recommence the cleaning to complete the cleaning area after two-
third of battery charging is done. (Max. 2 times).
Charging
1Turn on the
emergency switch
on the bottom
You must turn on the
emergency switch to turn on
the POWERbot.
Press and release the
button.
2
Manually charge
the POWERbot by
placing it on the
docking station
Make sure the charging
pins on the POWERbot
and the docking station
are aligned.
3Check the
charging status
For SR1M701 Series,
The battery indicator blinks at 1 sec.
intervals during charging and the indicator
will remain in ON status when fully charged.
For SR1M702 / SR1M703 /
SR2M70 Series,
" " will turn on according to charging
progress and "FULL" will turn on when
charging is complete.
WARNING
• Rated input voltage of
this product is 100-
240V~.
<SR1M702 / SR1M703 /
SR2M70 Series>
<SR1M701 Series>
1_VR7000_EN_DJ68-00763G-03_SB.indd 10 2017-03-03 오후 3:38:54

ENGLISH-11
1. SR1M701 Series
If the battery indicator blinks at 0.4 sec. intervals,
the POWERbot will automatically return to the
docking station to be charged.
2. SR1M70 / SR2M70 Series
When the battery indicator blinks during cleaning,
the POWERbot will return to the docking station to
charge itself automatically.
Automatic charging
You can command the POWERbot to
recharge at the docking station while it is
in cleaning.
Recharging
Manually charge the POWERbot by placing
it on the docking station.
Low battery (Lo)
Steps to take if recharging not occuring:
Check the installation status of the
docking station when:
fthe docking station is located in a place where
the POWERbot cannot easily access it.
fthe distance between the docking station and
POWERbot is over 5m.
– It may take a long time for POWERbot to
return to the docking station for recharging
Manually charge the POWERbot when:
fthe docking station is located in a corner
fthe battery is fully exhausted
fthe POWERbot is immobilized by an obstacle
(furniture etc.)
fthe POWERbot can't climb a threshold near
the docking station (The maximum height of
a threshold the POWERbot can climb is about
1.5 cm.)
fwhen the battery indicator blinks and "Lo" is
displayed
fwhen the battery indicator blinks (Applicable
to SR1M701 Series)
fwhen the POWERbot is set to the Spot clean or
Manual clean mode
1_VR7000_EN_DJ68-00763G-03_SB.indd 11 2017-03-03 오후 3:38:54

ENGLISH-12
Using POWERbot
You must turn on the emergency switch on the bottom of the unit before using POWERbot.
Turning the power on/off
Press the button for more than 3seconds
Starting Auto clean mode
Press and release this button. The POWERbot
moves and automatically cleans the set areas only
once.
 Stop cleaning: Press and release the button
Recharging
You can command POWERbot to recharge at the
docking station automatically while it is cleaning
by pressing this button.
Using Spot clean mode
The POWERbot cleans a localized area intensely.
WARNING
• When POWERbot is not used for 30 min.;
SR1M70U/ SR2M70Useries: Turns to energy-saving mode.
SR1M70W/ SR2M70Wseries: Automatically returns to the docking
station to be charged.
1_VR7000_EN_DJ68-00763G-03_SB.indd 12 2017-03-03 오후 3:38:55

ENGLISH-13
Selecting cleaning modes
Cleaning mode How to select
Displayed icon
SR1M702
SR1M703
SR2M70
SR1M701
Auto clean
Spot clean
Repeat clean
 Press the [A,B type ],
[C,D type ] on the remote
controller rst and then press
the [Start/Stop ].
-
Manual clean
 Manual clean mode can be
selected by the direction control
buttons of the remote control. -
 If POWERbot fails to return to the docking station, it will turn to energy-saving mode and display
panel will be turned off.
 To exit the energy-saving mode, press the [Start/Stop ] or [Power ] button of main body or
remote controller.
 If cleaning in Auto clean mode is completed within 15 minutes, POWERbot cleans 1 more time.
1_VR7000_EN_DJ68-00763G-03_SB.indd 13 2017-03-03 오후 3:38:55

ENGLISH-14
Cleaning method for each modes
About 1.5 m
About 1.5 m
Auto clean
Automatically cleans the
set areas only once.
 SR1M701
series: Cleans
repeatedly until the
battery is depleted.
Spot clean
Cleans a localized area
intensely. It can be used
to clean bread or cookie
crumbs.
Manual clean
You can move
POWERbot with the
remote control to clean
the desired spot.
 This function is
not applicable to
SR1M701
series.
Repeat clean
Cleans repeatedly until
the battery is depleted.
 This function is
not applicable to
SR1M701
series.
Note
fIf Auto clean or Repeat clean is commenced, POWERbot cleans the area near the docking station
rst.
Using special cleaning functions
Cleaning
function Operation
Displayed icon
SR1M702
SR1M703
SR2M70
SR1M701
Intelligent
power control
 When the POWERbot detects a
carpet in normal mode, it will
automatically operate with
stronger suction power.
Edge Clean
Master
 When the POWERbot detects an
edge or corner in Auto clean or
Spot clean, the auto shutter tool
operates and approaches the
edge or corner section to clean.
fStraight edge (One time cleaning)
fCorner (Two times cleaning)
Using POWERbot
1_VR7000_EN_DJ68-00763G-03_SB.indd 14 2017-03-03 오후 3:38:56

ENGLISH-15
Installing the Virtual guard
Infrared ray from the Virtual guard will restrict POWERbot from approaching
certain area.
 (Included with SR2M707 series only. For SR2M704/ SR2M705/
SR2M706 series, additional purchase is required.)
Virtual guard
1Press the Power button
to turn it on
Power lamp (Red) will blink.
2Install the Virtual guard
where you want to restrict
POWERbot's entrance
Make sure that distance sensor is facing
at the desired direction you want to
create a invisible barrier (which will
restrict POWERbot's approach).
The distance of virtual wall is 2.5m at minimum and may differ
depending on surroundings and movement status of POWERbot.
Minimum 2.5 m
1_VR7000_EN_DJ68-00763G-03_SB.indd 15 2017-03-03 오후 3:38:56

ENGLISH-16
Installing the Virtual guard
Part name of the Virtual guard
Power button
Distance detection sensor
(Infrared ray sensor)
Power lamp
Power on: Red lamp blinks
Power off: Lamp is off
POWERbot detection sensor
Battery cover
Inserting batteries
Batteries for Virtual guard must be purchased separately.
1Open the battery cover
of the Virtual guard by
pressing the locking
tab and lift it up.
2Insert the alkaline
batteries (D type)
as shown in the
illustration (check the
+, - polarity).
3Insert the tip of the
cover into the slot and
push the other end
to close the battery
cover.
 Specication: type D (LR20) batteries
1_VR7000_EN_DJ68-00763G-03_SB.indd 16 2017-03-03 오후 3:38:56

ENGLISH-17
Using the remote control
[C Type] [D Type]
1 1
3 3
55
22
Refer to
page 23 Refer to
page 23
44
44
66
[A Type] [B Type]
11
1, 2 1, 2
1, 2 1, 2
33
55
Refer to
page 22
Refer to
page 22
22
44
1_VR7000_EN_DJ68-00763G-03_SB.indd 17 2017-03-03 오후 3:38:56

ENGLISH-18
[A Type] / [B Type] / [C Type] / [D Type]
1 Power / Recharging / Start/Stop
Power Turn POWERbot's power on/off
Recharging Select to recharge POWERbot at the docking
station automatically
Start/Stop Select to start or stop cleaning process
2 Cleaning modes
Auto clean Select to clean all set areas only once and
then automatically return to the docking
station.
Spot clean Select to clean a localized area intensely
Repeat clean Select to clean repeatedly until the battery
becomes very low with indicator blinking
3 Suction power
Max mode Select to clean with the strongest suction
power
Normal mode Select to clean with moderate suction power
Quiet mode Select to clean with lower operation noise
4 Additional function
Sound Each time you press this button, Sound
Effects Mute is selected in this sequence
Remote control Select to turn Wi-Fi function on or off
 The previously selected setting will not change even if the emergency switch is turned off and then
on.
Using the remote control
1_VR7000_EN_DJ68-00763G-03_SB.indd 18 2017-03-03 오후 3:38:58

ENGLISH-19
5 Manual clean mode & Direction control
Move forward Select to move forward
Turn left Select to turn left
Turn right Select to turn right
 Moving backward is not available.
6 Point cleaning
Available only with C, D type remote controllers.
You can use the remote control to point and clean the desired spot while the
POWERbot is in cleaning process.
Point the red light on the oor within 0.5m around POWERbot's location.
Press and hold the Point cleaning button to move the red light to the desired spot. The POWERbot
will follow the light while cleaning.
0.5 m
Operating distance of the remote control
Height of the
remote control
Operating distance
Height of the
remote control 0.5m 1m 1.5 m
Operating
distance About 1.5m About 2m About 3m
Inserting batteries
Open the battery cover by lifting it
up while pressing the locking tab and
insert the batteries as shown in the
illustration. Then, close the cover until
it clicks into place.
1_VR7000_EN_DJ68-00763G-03_SB.indd 19 2017-03-03 오후 3:38:59

ENGLISH-20
Name of each part
1
4
2
2
6
5
3
7
8
Top
1. Display panel
2. Remote control signal receiver
3. Obstacle sensor
4. Dustbin
5. Camera
6. Dustbin button
7. Bumper sensor
8. Auto shutter tool
5
5
4
2
3
4
10
7
4
8
9
6
1
Bottom
1. Charge pins
2. Brush
3. Brush cover
4. Cliff sensor
5. Roller
6. Battery cover
7. Brush cover button
8. Driving wheel
9. Emergency switch
10. Auto shutter tool
6
3
5
2
1
4
Display panel
<SR1M701 series>
1. Daily schedule
2. Normal/Turbo mode
3. Battery indicator
4. Spot cleaning button, daily
schedule(3sec)
5. Start/Stop button, max mode(3sec)
6. Recharging button
1_VR7000_EN_DJ68-00763G-03_SB.indd 20 2017-03-03 오후 3:38:59
