Samsung Ubigate iBG1000 User manual

COPYRIGHT
This manual is proprietary to SAMSUNG Electronics Co., Ltd. and is protected by copyright.
No information contained herein may be copied, translated, transcribed or duplicated for any
commercial purposes or disclosed to third parties in any form without the prior written consent of
SAMSUNG Electronics Co., Ltd.
TRADEMARKS
Ubigate iBG1000 is a registered trademark of SAMSNUG Electronics.
All other company and product names may be trademarks of the respective companies with which
they are associated.
This manual should be read before the installation and operation, and the operator should
correctly install and operate the product by using this manual.
This manual may be changed for the system improvement, standardization and other technical reasons
without prior notice.
If you have a question for the content of manual or want to obtain further information on the updated
manual, please contact the homepage below.
Homepage: http://www.samsungdocs.com
©2008 SAMSUNG Electronics Co., Ltd. All rights reserved.

Ubigate iBG1000 Installation Manual
© SAMSUNG Electronics Co., Ltd. I
GENERAL USER INFORMATION
RADIO FREQUENCY INTERFERENCE
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
FCC REQUIREMENTS
This equipment, the Ubigate iBG1000, complies with Part 68 of the FCC rules
and the requirements adopted by the ATCA. On the bottom of this equipment
is a label that contains, among other information, a product identifier in the
format US: A3LIS00BiBG1000. If requested, this number must be provided
to the telephone company.

GENERAL USER INFORMATION
II © SAMSUNG Electronics Co., Ltd.
UNAUTHORIZED MODIFICATIONS
Any changes or modifications performed on this equipment that are not
expressly approved in writing by SAMSUNG ELECTRONICS, CO., LTD.
could cause non-compliance with the FCC rules and void the user’s authority
to operate the equipment.
Allowing this equipment to be operated in such a manner as to not
provide for proper answer supervision is a violation of Part 68 of the
FCC’s rules.
TELEPHONE CONNECTION REQUIREMENT
A plug and jack used to connect this equipment to the premises wiring and
telephone network must comply with the applicable FCC Part 68 rules and
requirements adopted by the ATCA. A compliant telephone cord and modular
plug is provided with this product. It is designed to be connected to a
compatible modular jack that is also compliant. See installation instructions
for details.
FCC Part 68
This equipment complies with Part 68 of the FCC rules. The FCC Part 68
label is located on the bottom chassis panel. This label contains the FCC
Registration Number and Ringer Equivalence Number (REN) for this
equipment. If requested, this information must be provided to your telephone
company.
INCIDENCE OF HARM
If this equipment, the Ubigate iBG1000, causes harm to the telephone network,
the telephone company will notify you in advance that temporary
discontinuance of service may be required. But if advance notice isn’t practical,
the telephone company will notify the customer as soon as possible. Also, you
will be advised of your right to file a complaint with the FCC if you believe it is
necessary.

Ubigate iBG1000 Installation Manual/Ed.02
© SAMSUNG Electronics Co., Ltd. III
SERVICE CENTER
If trouble is experienced with the Ubigate iBG1000, please contact your local
office of SAMSUNG ELECTRONICS, CO., LTD. for repair or warranty
information. If the trouble is causing harm to the telephone network, the
telephone company may request that you remove the equipment from the
network until the problem is resolved.
FIELD REPAIRS
Only technicians certified on the Ubigate iBG1000, are authorized by
SAMSUNG ELECTRONICS, CO., LTD. to perform system repairs.
Certified technicians may replace modular parts of a system to repair or
diagnose trouble. Defective modular parts can be returned to SAMSUNG
ELECTRONICS, CO., LTD. for repair.
GENERAL
Connection to party line service is subject to state tariffs. Contact the state
public utility commission, public service commission or corporation
commission for information.
Electrical Safety Advisory
Parties responsible for equipment requiring AC power should consider
including an advisory notice in their customer information suggesting the
customer use a surge arrestor. Telephone companies report that electrical
surges, typically lightning transients, are very destructive to customer terminal
equipment connected to AC power sources. This has been identified as a
major nationwide problem.

GENERAL USER INFORMATION
IV © SAMSUNG Electronics Co., Ltd.
SAFETY WARNING
High touch current earth connection is essential before making
telecommunication network connection.
Energy Hazard-careful treatment is needed.
Every wire for communication should be larger than 26 AWG.
Double pole/neutral fusing.
UNDERWRITERS LABORATORIES
The Ubigate iBG1000 system has been tested to comply with safety standards
in the United States and Canada. This system is listed with Underwriters
Laboratories. The cUL Mark is separately shown on the label.
The following statement from Underwriters Labs applies to the Ubigate
iBG1000 System:
1. Separation of TNV and SELV - Pluggable A:
INSTRUCTION: The separate protective earthing terminal provided on
this product shall be permanently connected to earth.
2. Separation of TNV and SELV - Pluggable B:
INSTRUCTION: Disconnect TNV circuit connector(s) before
disconnecting power.

Ubigate iBG1000 Installation Manual/Ed.02
© SAMSUNG Electronics Co., Ltd. V
3. Warning to service personnel:
CAUTION: Double pole/neutral fusing
4. Telephone line cord:
CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger
(e.g., 24 AWG) UL Listed or CSA Certified Telecommunication Line
Cord
5. Leakage currents due to ringing voltage - Earthing installation
instructions: 1. A supplementary equipment earthing conductor is to be
installed between the product or system and earth, that is, in addition to
the equipment earthing conductor in the power supply cord.
2. The supplementary equipment earthing conductor may not be smaller
in size than the unearthed branch-circuit supply conductors.
The equipment earthing conductor is to be connected to the product at
the terminal provided, and connected to earth in a manner that will retain
the earth connection when the power supply cord is unplugged.
The connection to earth of the supplementary earthing conductor shall be
in compliance with the appropriate rules for terminating bonding
jumpers in Part K of Article 250 of the National Electrical Code,
ANSI/NFPA 70 and Article 10 of Part 1 of the Canadian Electrical Code,
Part 1, C22.1. Termination of the supplementary earthing conductor is
permitted to be made to building steel, to a metal electrical raceway
system, or to any earthed item that is permanently and reliably connected
to the electrical service equipment earthed.
3. Bare, covered, or insulated earthing conductors are acceptable.
A covered or insulated conductor must have a continuous outer finish
that is either green, or green with one or more yellow stripes.
6. Safety Instructions - Rack Mount ‘Rack Mount Instructions -
The following or similar rack-mount instructions are included with the
installation instructions:
A) Elevated Operating Ambient - If installed in a closed or multi-unit rack
assembly, the operating ambient temperature of the rack environment
may be greater than room ambient. Therefore, consideration should be
given to installing the equipment in an environment compatible with the
maximum ambient temperature (Tma) specified by the manufacturer.

GENERAL USER INFORMATION
VI © SAMSUNG Electronics Co., Ltd.
B) Reduced Air Flow - Installation of the equipment in a rack should
be such that the amount of air flow required for safe operation of
the equipment is not compromised.
C) Mechanical Loading - Mounting of the equipment in a rack should
be such that a hazardous condition is not achieved due to uneven
mechanical loading.
D) Circuit Overloading - Consideration should be given to the
connection of the equipment to the supply circuit and the effect that
overloading of the circuits might have on overcurrent protection
and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
E) Reliable Earthing - Reliable earthing of rack-mounted equipment
should be maintained. Particular attention should be given to supply
connections other than direct connections to the branch circuit (e.g., use
of power strips).’

Ubigate iBG1000 Installation Manual
© SAMSUNG Electronics Co., Ltd. VII
INTRODUCTION
Purpose
Ubigate iBG1000™ Installation Manual provides instructions on installing the
Ubigate iBG1000, including hardware descriptions, safety information,
chassis installation, module installation, interconnection, and troubleshooting
descriptions.
Document Content and Organization
This manual is composed of three Chapters and two Annexes.
CHAPTER 1. Ubigate iBG1000 Overview
Describes Ubigate iBG1000 characteristics.
CHAPTER 2. Pre-Installation Requirements
Describes the safety regulations and how to prepare for installation.
CHAPTER 3. Ubigate iBG1000 Installation
Describes how to install Ubigate iBG1000.
ANNEX A. Specifications
ANNEX B. Cable Specifications

INTRODUCTION
VIII © SAMSUNG Electronics Co., Ltd.
Conventions
The following types of paragraphs contain special information that must be
carefully read and thoroughly understood. Such information may or may not
be enclosed in a rectangular box, separating it from the main text, but is
always preceded by an icon and/or a bold title.
WARNING
Provides information or instructions that the reader should follow in
order to avoid personal injury or fatality.
CAUTION
Provides information or instructions that the reader should follow in
order to avoid a service failure or damage to the system.
NOTE
Indicates additional information as a reference.
Information for Product and Technical Support
For questions regarding the product and technical supports:
http://www.samsungnetwork.com
Revision History
EDITION DATE OF ISSUE REMARKS
00 05. 2008. First edition
01 06. 2008. Added caution for power adapter
02 10. 2008. Modified tabletop installation

Ubigate iBG1000 Installation Manual
© SAMSUNG Electronics Co., Ltd. IX
SAFETY CONCERNS
The purpose of the Safety Concerns section is to ensure the safety of users and prevent property
damage. Please read this document carefully for proper use.
Symbols
Caution
Indication of a general caution.
Restriction
Indication for prohibiting an action for a product.
Instruction
Indication for commanding a specifically required action.

SAFETY CONCERNS
X © SAMSUNG Electronics Co., Ltd.
Warning
Electric hazard exists. Verify the power is turned off. Do not work on
energized equipment. Working on energized equipment can result in
serious electrical shock.
To avoid electric shock, do not connect safety extra-low voltage
(SELV) circuits (as found in LAN ports) to telephone-network voltage
(TNV) circuits (as found in WAN ports).
Caution
This equipment must be installed and maintained by properly trained
service personnel. Make sure the proper electrical service is available
before plugging this unit in and turning it on. Disconnect the
telecommunications lines before unplugging the main power connector.
Do not place any items that weigh more than 10 pounds (4.5 kilograms)
on top of the chassis, and do not stack routers on a tabletop.
Use only the adapter provided with the Ubigate iBG1000. Using other
adapter can result in overheating or explosion and may cause
malfunction.
WARNING
CAUTION

Ubigate iBG1000 Installation Manual
© SAMSUNG Electronics Co., Ltd. XI
TABLE OF CONTENTS
GENERAL USER INFORMATION I
RADIO FREQUENCY INTERFERENCE..................................................................... I
FCC REQUIREMENTS.............................................................................................. I
SAFETY WARNING.................................................................................................IV
UNDERWRITERS LABORATORIES ........................................................................IV
INTRODUCTION VII
Purpose..................................................................................................................VII
Document Content and Organization.......................................................................VII
Conventions ..........................................................................................................VIII
Information for Product and Technical Support........................................................VIII
Revision History.....................................................................................................VIII
SAFETY CONCERNS IX
Symbols ..................................................................................................................IX
Warning....................................................................................................................X
Caution.....................................................................................................................X
CHAPTER 1. Ubigate iBG1000 Overview 1-1
Ubigate iBG1000 Chassis ........................................................................................... 1-1
Ubigate iBG1000 Top Side ..................................................................................... 1-2
Ubigate iBG1000 Rear Side ................................................................................... 1-3
Ubigate iBG1000 Hardware......................................................................................... 1-4
Memory ................................................................................................................. 1-4
Power Supply ........................................................................................................ 1-4
Ventilation.............................................................................................................. 1-5
Real-Time Clock .................................................................................................... 1-5

TABLE OF CONTENTS
XII © SAMSUNG Electronics Co., Ltd.
CHAPTER 2. Pre-Installation Requirements 2-1
Safety Recommendations...........................................................................................2-1
Cover Panels .........................................................................................................2-2
Best Practices-Safety.............................................................................................2-2
General Maintenance Guidelines............................................................................2-2
General Site Requirements ......................................................................................... 2-3
Site Preparation .....................................................................................................2-3
Environment .......................................................................................................... 2-3
Inspecting the Ubigate iBG1000.................................................................................. 2-4
Required Tools and Materials ..................................................................................... 2-5
Tools......................................................................................................................2-5
Cables................................................................................................................... 2-5
Materials................................................................................................................2-5
CHAPTER 3. Ubigate iBG1000 Installation 3-1
Installing the Ubigate iBG1000....................................................................................3-1
Installing on a tabletop............................................................................................3-1
Installing on a Wall ................................................................................................. 3-2
Port Numbering...........................................................................................................3-5
iBG1000 Port Numbering ....................................................................................... 3-6
Connecting the Ubigate iBG1000................................................................................ 3-7
LAN Interface.........................................................................................................3-7
T1/E1 Interface ......................................................................................................3-8
Console Interface................................................................................................... 3-9
Auxiliary Interface (for Remote Access)................................................................. 3-10
Powering Up the Ubigate iBG1000............................................................................ 3-12
Connecting Power................................................................................................ 3-12
Applying Power.................................................................................................... 3-13
ANNEX A. Specifications A-1
Ubigate iBG1000 Product Specifications................................................................... A-1
Interface...................................................................................................................... A-2
E1 WAN Interface ..................................................................................................A-2
T1 WAN Interface...................................................................................................A-2

Ubigate iBG1000 Installation Manual/Ed.02
© SAMSUNG Electronics Co., Ltd. XIII
Ethernet LAN Interface...........................................................................................A-3
ANNEX B. Cable Specifications B-1
Console Port Cable .....................................................................................................B-1
Auxiliary Port Cable ....................................................................................................B-2
Ethernet Cable ............................................................................................................B-3
T1/E1 Cable .................................................................................................................B-4

TABLE OF CONTENTS
XIV © SAMSUNG Electronics Co., Ltd.
LIST OF FIGURES
Figure 1.1 Ubigate iBG1000 Top View ..................................................................1-2
Figure 1.2 Ubigate iBG1000 Rear Connector........................................................ 1-3
Figure 1.3 Power Supply......................................................................................1-4
Figure 1.4 Ventilation...........................................................................................1-5
Figure 2.1 Air flow of the Ubigate iBG1000 ........................................................... 2-3
Figure 3.1 Making holes....................................................................................... 3-2
Figure 3.2 Insert plastic anchors........................................................................... 3-3
Figure 3.3 Tightening screws ...............................................................................3-3
Figure 3.4 Fixing on a wall ...................................................................................3-4
Figure 3.5 iBG1000 Port Numbering.....................................................................3-6
Figure 3.6 Connecting LAN Cables ......................................................................3-7
Figure 3.7 Connecting T1/E1 Cables .................................................................... 3-8
Figure 3.8 Connecting Console Cable ..................................................................3-9
Figure 3.9 Remotely Accessing an Ubigate iBG1000 .......................................... 3-10
Figure 3.10 Power Connection........................................................................... 3-12
Figure B.1 Console Port Cable.............................................................................B-1
Figure B.2 Auxiliary Port Cable ............................................................................B-2
Figure B.3 Ethernet LAN Interface Cable..............................................................B-3
Figure B.4 T1/E1 WAN Interface Cable ................................................................B-4

Ubigate iBG1000 Installation Manual
© SAMSUNG Electronics Co., Ltd. 1-1
CHAPTER 1. Ubigate iBG1000 Overview
Chapter 1 provides an overview of the Ubigate iBG1000.
This chapter provides an overview of Ubigate iBG1000 including information
about chassis components and hardware characteristics.
Ubigate iBG1000 Chassis
This section describes chassis components of the Ubigate iBG1000.
Additional information is also provided about external cables, wiring, and
connection points.

CHAPTER 1. Ubigate iBG1000 Overview
1-2 © SAMSUNG Electronics Co., Ltd.
Ubigate iBG1000 Top Side
The top side of Ubigate iBG1000 has LEDs in order to indicate the router’s
performance and operation status. Each LED’s description is shown as follows.
Figure 1.1 Ubigate iBG1000 Top View
LED Description
LED Indication & Color Description
Solid green System is operating normally.
Solid red System is not operating normally.
Amber System diagnostic mode.
SYS
Off Router is not receiving power.
Solid green T1/E1 port is operating normally.
Solid red T1/E1 port cable is not connected properly or
critical alarm detected.
Amber User alarm detected.
P0~P3
(T1/E1)
Off Router is not operating normally.
T1/E1
P0 P1 P2 P3 P0 P1 SYS
Ethernet

Ubigate iBG1000 Installation Manual/Ed.02
© SAMSUNG Electronics Co., Ltd. 1-3
(Continued)
LED Indication & Color Description
Solid green Ethernet port link is detected.
Blinking green Ethernet port activity is detected.
P0~P1
(Ethernet)
Off Ethernet port link is not detected.
Solid blue Power supply installed and operating normally.
Amber Power supply installed but power fault condition
detected.
(Power)
Off Power supply not present or power supply failure
Ubigate iBG1000 Rear Side
Ubigate iBG1000 rear side has four T1/E1 ports, two Fast Ethernet UTP ports,
one auxiliary port, and one console port.
Figure 1.2 Ubigate iBG1000 Rear Connector
Connector Description
T1/E1 Port T1/E1 WAN connection
Fast Ethernet UTP Port Fast Ethernet LAN connection
Console Port Serial port for local monitoring and configuring
Auxiliary Port Serial port for remote monitoring
Power Connector DC power connector
T1/E1 Ports Fast Ethernet
UTP Ports
Auxiliary Port Console Port
Power Connector

CHAPTER 1. Ubigate iBG1000 Overview
1-4 © SAMSUNG Electronics Co., Ltd.
Ubigate iBG1000 Hardware
Memory
The Ubigate iBG1000 supports the following types of memory:
 Double-Data-Rate II Synchronous Dynamic Random Access Memory
(DDR II SDRAM): This type of memory stores the running configuration
and routing tables. It also buffers packets at the network interfaces.
The base configuration shipped from the factory is 512 MB of main
memory. The Small Outline Dual In-line Memory Module (SODIMM) slot
can be used to upgrade the main memory to a maximum of 1 GB.
 SD memory card: The base configuration shipped from the factory is a
1 GB SD memory card, which can be upgraded to a maximum of 2 GB. SD
memory is used to store application code images.
 Internal Flash Memory: Ubigate iBG1000 includes 2 MB of internal flash
memory which is used to boot the router.
Power Supply
Ubigate iBG1000’s AC power adapter provides +12 VDC with an AC input
between 100 and 240 VAC.
Figure 1.3 Power Supply
