SARGENT AND GREENLEAF® (S&G®)
MANUAL LOCK
Model 6730
•Left-Right-Left Dialing Sequence; One Handed Operation
•Key Locking Day-Lock Option Allowing Dial Lock Position Open or Closed
•Time Tested Mechanical Security
•Internal Relocker to Protect Against Dial and Spindle Punching Attacks
•All Metal Combination Wheels
•Dual Locking Arm Design Prevents Combination Drift Over Time
•One Million Possible Combinations
OPERATING INSTRUCTIONS
Opening Safe for the First Time
S&G® Manual Lock combination is set leaving the
factory with the dial locked in place by the
Day-Lock. The safe will open by simply rotating the
hub or hand wheel clockwise and pulling the safe door
open. If the hub seems stiff, try inserting a solid
round wooden stick into one of the handle holes and
turning the hub clockwise to open.
1. There is an envelope inside the safe with a set of
keys. Unlock the Day-Lock by inserting the key into
the Day-Lock keyhole and turning the key
clockwise until it stops.
2. Remove the key. Now the dial is operational.
Verifying the Combination
The unique combination of the manual lock can be found on the envelope that
contained the Owner’s Manual and Day-Lock keys. With the safe door open,
extend the locking bolts by turning the handle or hand wheel counter-clockwise.
Verify the combination multiple times (by following the directions below) before
using the safe.
Operating the Dial on the Manual Lock
The manual lock requires accurate alignment of each two-digit number with the
Index Mark (each two-digit number of the combination is separated by dashes).
Avoid rotating past any number, even slightly, as the entire combination must be
re-dialed if there are any errors.
Index Mark
Day-Lock Keyhole

4X
3X
2X
Turn the handle of the safe clockwise and pull the safe door open.
5
Turn the dial slowly
clockwise until it
stops, at about 87.
There may be some
resistance at around
95 (which is normal).
Turn the dial
counter-clockwise
passing the third
number of the
combination. Stop
at exactly the third
number of the
second revolution.
Turn the dial
clockwise, passing
the second number
of the combination
twice. Stop at
exactly on the
second number of
third revolution.
Rotate the dial
counter-clockwise
at least four full
revolutions. Stop
exactly on the first
number of the
combination.
4
3
2
1
Day-Lock Instructions
For maximum security, it is recommended using the Day-Lock in addition to the
combination to the manual lock. This feature is also helpful to prevent the dial from
rotating and accidentally locking when moving items into or out of the safe.
Suggested Day-Lock Operation
1. Shut the safe door and turn the handle or hand wheel counter-clockwise to
extend the locking bolts into the locked position.
2. Rotate the dial counter-clockwise at least four times to clear the
combination completely.
3. Stop at about “87” on the Index Mark.
4. Insert the Day-Lock key into the keyway and turn counter-clockwise until it stops.
Remove the key.
To Open After the Day-Lock is Locked
1. Insert the Day-Lock key into the keyway and turn clockwise until it stops. Remove
the key.
2. Follow the “Operating the Dial on the Manual Lock” instructions.
Changing Combination on Manual Locks
The lock portion of the Warranty will be void if anyone other than a certified locksmith
changes the combination on a manual lock. Contact Rhino Metals Tech Support to
locate a certified locksmith.
Lost Combination and Keys for Manual Locks
Most safes have their original combination stored by serial number at Rhino Metals.
If the combination is lost, a $25.00 research fee will be assessed for restoring the
combination to the original owner. If keys are lost, a $25.00 fee will be assessed for
each set of duplicated keys requested. Both requests require completing and
The Day-Lock does not lock the safe. It is intended to prevent the dial from
rotating.

providing proper documentation of ownership of the safe.
Rhino Metals cannot guarantee the recovery of a combination or responsibility for
keeping the information. Please keep the code in a secure place outside the safe.
CARE AND MAINTENANCE
Cleaning the Safe Body
Use a clean and soft cloth (such as a microfiber cleaning cloth) that is slightly
damp with water to clean the exterior of the safe. Take care around the edges
of any logos or pin striping as any pressure could cause damage to them.
Cleaning Safe Locks and Handles
Locks and handles are coated to protect from rust or tarnish. Do not use any
kind of metal polish or harsh cleaning products. Simply wipe off with a soft,
damp cloth. Minor scratches may be touched up with a paint touch up kit
available from Rhino Metals.
Manual Lock Maintenance
To keep a manual lock as reliable as possible, it is recommended to have a
certified lock technician service annually. Avoid applying any lubricants to the
lock as it could result in lock failure and may void the lock portion of the
Warranty.
IMPORTANT FOR MANUAL LOCKS
♦ DO NOT CLOSE THE SAFE DOOR IF THE COMBINATION DOES NOT WORK. Refer to
the Troubleshooting Guide or call Rhino Metals Tech Support for further
assistance. Do not wait until the safe is locked out.
♦ Store the safe’s model, serial number, Owner’s Manual, and combination in a
secure location outside the safe.
♦ Rotate dial slowly as rapidly spinning the dial in alternate directions will damage
the lock and cause a lockout.
♦ Be sure to have good visibility and stand directly in front of the dial when
operating the lock.
♦ Consider purchasing an Extended Lock Warranty for extended services.

TROUBLESHOOTING
WARRANTY CLAIMS AND REPAIRS
Please carefully read the Limited Lifetime Warranty. It details the length of
coverage and limitations for services and repairs. All Warranty services must be
pre-authorized by Rhino Metals and require completing and providing proper
documentation of ownership of the safe. Any Warranty questions, contact a local
authorized dealer or Rhino Metals Tech Support. It is the sole responsibility of the
safe owner for payment of any services or repairs done without pre-authorization
from Rhino Metals.
INSURANCE COVERAGE
Rhino Metals highly recommends the purchase of additional insurance coverage to
the total value of the contents inside the safe. The Limited Lifetime Warranty does
not insure any of the contents inside the safe. Most homeowner insurers require
purchasing endorsements or riders for valuables exceeding the standard coverage
policy for personal items. Be sure to check with the residential insurance provider for
more details.
Common Issues Possible Solutions
Manual Lock Not
Working Properly
If dialing the combination according to the instructions, it could be
that the numbers in the combination are slightly off by a number
to the left or right. Try the combination again but try dialing up or
down one number of each number of the combination. If
successful, be sure to update the combination records and contact
Rhino Metals to update the master combination on file.
Lost Combination
See Lost Combination instructions, depending on lock type. Rhino
Metals cannot give combinations over the phone as there is no
method to verify ownership of the safe.

LIMITED LIFETIME WARRANTY
Rhino Metals offers to the original Purchaser a Limited Lifetime Warranty covering defects
in workmanship, material, damage by unlawful attempted or actual break-in, and fire.
Warranty applies only to safes located in the United States and Canada, purchased at an
authorized Rhino Metals safe dealer, and that have been used solely in residential
applications. Commercial or industrial use applications carry a one-year Warranty against
defects in workmanship and materials.
To receive Warranty support, Purchaser must provide Rhino Metals with (1) proof of
purchase, (2) serial number on safe, (3) a written statement, (4) photographs of the
damaged safe, and (5) a police or fire department report.
Rhino Metals will make the decision to repair the safe in-home, at the factory, or replace
the safe altogether. If possible, the safe will be repaired locally. If the safe is to be
repaired at the factory or replaced, Rhino Metals will, at its expense, have the safe
opened, if required, and will pay for the freight back to the factory. Purchaser must
package and palletize the safe and make the safe available for a curbside pickup at
Purchaser’s expense. The Warranty does not cover any costs for removal or installation
of the safe or its contents. Personal property in the safe is not covered by this Warranty.
The obligation of Rhino Metals under the Warranty is contingent upon proper use,
installation, and maintenance of the safe and shall not apply to safes or safe parts which
have been neglected, misused, or exposed to extreme or unusual environments. Failure
to anchor the safe using factory pre-drilled holes will void the Warranty. Any modifying or
tampering with the safe which alters or affects the safe’s use or operation will void the
Warranty.
Without limit, the Warranty specifically excludes any liability for defects or damage
caused or increased use of unauthorized parts. Upon purchase, the Purchaser must
promptly notify Rhino Metals of any defects. The Purchaser’s remedies are solely limited
to replacing parts or repair and are at the discretion of Rhino Metals. Warranty gives the
Purchaser specific legal rights, and Purchaser may also have other rights which vary from
state to state.
Locks and electronic keypads carry a five-year Warranty for labor and parts. The
Warranty does not cover forgotten or lost combinations, lost keys, dead or weak
batteries, or improper opening procedures. Lights and electrical components carry a one-
year Warranty. Paint or powder coat finish and interior carry a one-year Warranty based
on proper care and environment.
Warranty is given in place of all other Warranties and assurances, whether expressed or
implied, including but not limited to matters of merchantability, quality, or fitness for
purpose. Rhino Metals accepts no liability under any circumstances whatsoever for any
incidental or consequential damage or loss suffered by anyone because of using or being
unable to use the safe.

EXTENDED LOCK WARRANTY (SOLD SEPARATELY)
Rhino Metals offers to the original Purchaser an Extended Lock Warranty covering
defects in workmanship and material on either electric or manual locks. Locks and
electronic keypads carry a five-year Warranty for labor and parts. The Warranty does not
cover forgotten or lost combinations, dead or weak batteries, or improper opening
procedures. Warranty applies only to safes located in the United States and Canada,
purchased at an authorized Rhino Metals safe dealer, and that have been used solely in
residential applications. Commercial or industrial use applications carry a one-year
Warranty against defects in workmanship and materials.
Extended Lock Warranty coverage extends the existing Lock Warranty for an additional
two-years at $30.00 or four-years at $60.00. To receive Warranty support, Purchaser
must provide Rhino Metals with (1) proof of purchase, (2) serial number on safe, and (3)
payment. For payment, Rhino Metals accepts Visa, Discover, Mastercard, Amex and
money orders made payable to Rhino Metals.
Rhino Metals will make the decision to repair the lock in-home, at the factory, or replace
the lock altogether. If possible, the lock will be repaired locally. If the lock is to be
repaired at the factory or replaced, Rhino Metals will, at its expense, have the safe
opened, if required, and will pay for the freight back to the factory. The Purchaser must
package the safe and make the safe available for a curbside pickup at their expense. The
Warranty does not cover any costs for removal or installation of the safe or its contents.
Personal property in the safe is not covered by the Warranty.
The obligation of Rhino Metals under the Warranty is contingent upon proper use,
installation, and maintenance of the safe or lock. The Warranty shall not apply to safes,
locks or safe parts which have been neglected, misused, or exposed to extreme or
unusual environments. Any modifying or tampering with the safe or lock which alters or
affects the safe or lock’s use or operation will void the Warranty.
Without limit, the Warranty specifically excludes any liability for defects or damage
caused or increased use of unauthorized parts. Upon purchase, the Purchaser must
promptly notify Rhino Metals of any defects. The Purchaser’s remedies are solely limited
to replacing parts or repair and are at the discretion of Rhino Metals. Warranty gives
Purchaser specific legal rights, and Purchase may also have other rights which vary from
state to state.
The Warranty is given in place of all other Warranties and assurances, whether expressed
or implied, including but not limited to matters of merchantability, quality, or fitness for
purpose. Rhino Metals accepts no liability under any circumstances whatsoever for any
incidental or consequential damage or loss suffered by anyone because of using or being
unable to use the safe or lock.
To purchase the Extended Lock Warranty, go to www.rhinosafe.com (or complete and
return the purchase form located below) within 30 days to Rhino Metals.
Warranty must be purchased within 30 days of safe purchase to become valid.
