Sandstrom SMK1011 User manual

Quick Start Guide
Wireless Multimedia Keyboard
and Optical Mouse
GB
NO
SE
FI
DK
Quick Start Guide
Wireless Multimedia Keyboard
and Optical Mouse
SMK1011
CZ
SK
Hurtigstartguide
Trådløst multimediatastatur og
trådløs optisk mus
Snabbstartguide
Trådlös multimediatangentbord
och optisk mus
Pikaopas
Langaton multimedianäppäimistö
ja optinen hiiri
Startvejledning
Trådløst multimedietastatur og
optisk mus
Stručná příručka
Bezdrátová multimediální
klávesnice a optická myš
Stručný návod na
používanie
Bezdrôtová multimediálna
klávesnica a optická myš
SMK1011_IB_7L_RC_final120625.indb 1 25/06/2012 2:27 PM

SMK1011_IB_7L_RC_final120625.indb 2 25/06/2012 2:27 PM

Contents GB
Unpacking................................................. 5
Product Overview..................................... 6
Keyboard..............................................................6
Mouse ...................................................................6
System Requirements .............................. 6
Install the Battery..................................... 7
Connections .............................................. 8
Activation.................................................. 9
Function Keys.......................................... 10
Hints and Tips.......................................... 11
Safety Warnings...................................... 54
Innhold NO
Pakke opp................................................ 12
Produktoversikt...................................... 13
Tastatur...............................................................13
Mus.......................................................................13
Systemkrav.............................................. 13
Installere batterier.................................. 14
Tilkoblinger............................................. 15
Aktivering ............................................... 16
Funksjonstaster ...................................... 17
Feilsøking................................................ 18
Sikkerhetsadvarsler ............................... 55
Innehållsförteckning SE
Packa upp................................................ 19
Produktöversikt...................................... 20
Tangentbord.....................................................20
Mus.......................................................................20
Systemkrav.............................................. 20
Sätta i batteriet....................................... 21
Anslutningar ........................................... 22
Aktivering ............................................... 23
Funktionsknappar.................................. 24
Felsökning............................................... 25
Säkerhetsvarningar................................ 56
Sisältö FI
Pakkauksesta purkaminen .................... 26
Tuotteen yleiskatsaus ............................ 27
Näppäimistö .....................................................27
Hiiri.......................................................................27
Järjestelmävaatimukset......................... 27
Pariston asentaminen ............................ 28
Liitännät .................................................. 29
Aktivointi................................................. 30
Toimintonäppäimet................................ 31
Vianetsintä.............................................. 32
Turvallisuusvaroitukset ......................... 57
Indholdsfortegnelse DK
Udpakning .............................................. 33
Produktoversigt...................................... 34
Tastatur...............................................................34
Mus.......................................................................34
Systemkrav.............................................. 34
Batteriisætning....................................... 35
Tilslutninger............................................ 36
Aktivering ............................................... 37
Funktionstaster ...................................... 38
Fejlnding............................................... 39
Sikkerhedsadvarsler............................... 58
Obsah CZ
Vybalení .................................................. 40
Přehled výrobku..................................... 41
Klávesnice..........................................................41
Myš.......................................................................41
Systémové požadavky ........................... 41
Instalace baterie ..................................... 42
Připojení.................................................. 43
Aktivace................................................... 44
Klávesy funkcí......................................... 45
Řešení potíží............................................ 46
Bezpečnostní upozornění...................... 59
SMK1011_IB_7L_RC_final120625.indb 3 25/06/2012 2:27 PM

Obsah SK
Vybalenie ................................................ 47
Prehľad výrobku..................................... 48
Klávesnica..........................................................48
Myš.......................................................................48
Požiadavky na systém............................ 48
Vkladanie batérie ................................... 49
Pripájanie zariadení ............................... 50
Aktivácia.................................................. 51
Funkčné klávesy ..................................... 52
Odstraňovanie problémov..................... 53
Bezpečnostné výstrahy.......................... 60
SMK1011_IB_7L_RC_final120625.indb 4 25/06/2012 2:27 PM

GB
5
Unpacking
Remove all packaging from the unit. Retain the packaging. If you
dispose of it please do so according to local regulations.
The following items are included:
Thank youfor purchasing your new Sandstrøm
Wireless Multimedia Keyboard and Optical Mouse.
Before commencing the installation and set up, please
check that you have all the items and familarise yourself
with this Quick Start Guide.
Quick Start Guide
(PN.: SMK1011-002)
Keyboard Mouse
Nano Receiver
(P.N.: MRN)
AAA Size Batteries x 4
(PN.: SMK1011-AAA)
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
1 2
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
SMK1011_IB_7L_RC_final120625.indb 5 25/06/2012 2:27 PM

GB
6
System Requirements
Operating Systems:
Microsoft® Windows®2000/ XP/ Vista™ & Windows®7
Hardware:
1 available USB port
Product Overview
Keyboard
Mouse
Left Button Right Button
Scroll Wheel
Function Keys
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
12
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
SMK1011_IB_7L_RC_final120625.indb 6 25/06/2012 2:27 PM

GB
7
Install the Battery
1. Press and lift the battery cover.
2. Insert batteries.
3. Close the battery cover.
Please ensure the batteries’polarities (+ / -) match the battery
compartment’s polarities.
OPEN
ON OFF
C
O
N
N
E
C
T
Battery Cover
Battery Cover
ON/ OFF
Button
Connect
Button
SMK1011_IB_7L_RC_final120625.indb 7 25/06/2012 2:27 PM

GB
8
Connections
Step 1
Remove the Nano Receiver from the battery compartment cover as
shown in the diagram below.
Step 2
Plug the Nano Receiver directly into your computer’s USB port.
Step 3
Adjust the angle of the keyboard by lifting the feet.
OPEN
ON OFF
C
O
N
N
E
C
T
USB
SMK1011_IB_7L_RC_final120625.indb 8 25/06/2012 2:27 PM

GB
9
Activation
1. Switch the ON/OFF button on the bottom of the mouse to the ON
position.
2. If the mouse and keyboard does not respond after the Nano
receiver is plugged into the USB port, press the Connect button
on the mouse to activate the connection between the mouse,
keyboard and the RF receiver.
OPEN
ON OFF
C
O
N
N
E
C
T
ON OFF
C
O
N
N
E
C
T
Connect
Button
ON/OFF Button
For energy saving, switch the ON/OFF button on the bottom of
the mouse to the OFF position to disconnect between the mouse
and the RF receiver.
SMK1011_IB_7L_RC_final120625.indb 9 25/06/2012 2:27 PM

GB
10
Function Keys
1. MUTE
To mute and restore your
DVD sound output.
2. STOP
To stop the playback.
3. PLAY /PAUSE
To play the DVD disc and to
pause the playback.
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
12
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
1 2 3 4 5
4. VOLUME +/–
To increase and decrease the
volume.
5. BATTERY INDICATOR
When the indicator is
ashing, replace the batteries.
SMK1011_IB_7L_RC_final120625.indb 10 25/06/2012 2:27 PM

GB
11
Hints and Tips
Mouse or Keyboard Not Working:
1. Ensure that the power switch is in the ON position
2. Have the batteries been inserted incorrectly or are they spent?
Check the polarity (+/-) and exchange them for new ones as
necessary.
3. Make sure the Nano Receiver is plugged into a USB and the
computer is on.
4. Remove metallic objects between the mouse and the Nano
receiver.
5. If the Nano receiver is plugged into a USB hub, try plugging it
directly into the computer.
6. Move the keyboard closer to the receiver.
7. If mouse performance is slow or intermittent, unplug the Nano
Receiver from the USB port and then reinsert it. Switch the ON/
OFF button again on the bottom of the mouse to reactivate it.
8. If the mouse is moving erratically change the working surface
within the mouse id operating on.
9. Restart the computer.
SMK1011_IB_7L_RC_final120625.indb 11 25/06/2012 2:27 PM

NO
12
Pakke opp
Fjern all emballasje fra enheten. Ta vare på emballasjen. Ta hensyn til
lokale forskrifter om avfallshåndtering hvis du må kaste emballasjen.
Følgende elementer er vedlagt:
Takk for at du kjøpte nytt trådløst multimediatastatur og
trådløs optisk mus fra Sandstrøm.
Før du begynner installasjonen og oppsettet, se etter
at du har alle delene og gjør deg kjent med denne
hurtigstartguiden.
Hurtigstartguide
(Delnr.: SMK1011-002)
Tastatur Mus
Nanomottaker
(Delnr.: MRN)
Batterier størrelse AAA x 4
(Delnr.: SMK1011-AAA)
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
1 2
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
SMK1011_IB_7L_RC_final120625.indb 12 25/06/2012 2:27 PM

NO
13
Systemkrav
Operativsystemer:
Microsoft® Windows® 2000/XP/Vista™ & Windows® 7
Maskinvare:
1 tilgjengelig USB-kontakt
Produktoversikt
Tastatur
Mus
Venstre knapp Høyre knapp
Rullehjul
Funksjonstaster
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
12
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
SMK1011_IB_7L_RC_final120625.indb 13 25/06/2012 2:27 PM

NO
14
Installere batterier
1. Trykk og løft batteridekslet.
2. Sett inn batteriet/batteriene.
3. Lukk batteridekslet.
Påse at batterienes polaritet (+/-) samsvarer med merkingen i
batterirommet.
OPEN
ON OFF
C
O
N
N
E
C
T
Batterideksel
Batterideksel
På/av-
knapp
Koble til-
knapp
SMK1011_IB_7L_RC_final120625.indb 14 25/06/2012 2:27 PM

NO
15
Tilkoblinger
Trinn 1
Fjern nanomottakeren fra batteriromdekslet som vist i guren
nedenfor.
Trinn 2
Sett nanomottakeren direkte inn i datamaskinens USB-kontakt.
Nanomottaker
USB-kontakt
Trinn 3
Juster tastaturvinkelen ved å vippe ut føttene.
OPEN
ON OFF
C
O
N
N
E
C
T
SMK1011_IB_7L_RC_final120625.indb 15 25/06/2012 2:27 PM

NO
16
Aktivering
1. Sett På/av-knappen under musen i på-posisjonen.
2. Hvis musen og tastaturet ikke reagerer etter at nanomottakeren er
satt inn i USB-kontakten, trykk på Koble til-knappen på musen for
å aktivere den trådløse forbindelsen mellom musen, tastaturet og
RF-mottakeren.
OPEN
ON OFF
C
O
N
N
E
C
T
ON OFF
C
O
N
N
E
C
T
Koble
til-knapp
På/av-knapp
Spar strøm ved å sette På/av-knappen under musen i av-
posisjonen for å bryte forbindelsen mellom musen og
nanomottakeren.
SMK1011_IB_7L_RC_final120625.indb 16 25/06/2012 2:27 PM

NO
17
Funksjonstaster
1. DEMP
For å slå av lyden fra DVD-
spilleren og gjenopprette
den igjen.
2. STOPP
For å stoppe avspillingen.
3. SPILL /PAUSE
For å spille av en DVD-plate
og pause avspillingen.
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
12
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
1 2 3 4 5
4. VOLUM +/–
For å øke og minske
lydstyrken.
5. BATTERILAMPE
Når batterilampen blinker, må
batteriene skiftes.
SMK1011_IB_7L_RC_final120625.indb 17 25/06/2012 2:27 PM

NO
18
Feilsøking
Musen eller tastaturet fungerer ikke:
1. Kontroller at strømbryteren er satt i på-posisjonen
2. Er batteriene blitt satt feil inn eller uttømt? Kontroller polariteten
(+/–) og skift dem ut med nye om nødvendig.
3. Sørg for at nanomottakeren sitter i en USB-kontakt og at
datamaskinen er på.
4. Fjern metallgjenstander mellom musen og nanomottakeren.
5. Hvis nanomottakeren er tilkoblet et USB-nav, kan du prøve å sette
den direkte inn i datamaskinen.
6. Flytt tastaturet nærmere nanomottakeren.
7. Dersom musen virker treg eller faller ut, ta nanomottakeren ut av
USB-kontakten og sett den inn igjen. Sett På/av-knappen under
musen på for å aktivere den igjen.
8. Dersom musen beveger seg ujevnt, prøv å bruke den på en annen
overate.
9. Start datamaskinen på nytt.
SMK1011_IB_7L_RC_final120625.indb 18 25/06/2012 2:27 PM

SE
19
Packa upp
Ta bort allt förpackningsmaterial från produkten. Behåll
förpackningsmaterialet. Om förpackningen kastas ska du följa
gällande lokala föreskrifter.
Följande delar medföljer:
Tack för att du köpt nya Sandstrøms Trådlösa
multimediatangentbord och optiska mus.
Innan installationen och inställning genomförs kontrollera
att du har alla delar och bekanta dig med denna
snabbstartguide.
Snabbstartguide
(Art.nr.: SMK1011-002)
Tangentbord Mus
Nanomottagare
(Art.nr.: MRN)
AAA-batterier x 4
(Art.nr.: SMK1011-AAA)
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
1 2
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
SMK1011_IB_7L_RC_final120625.indb 19 25/06/2012 2:27 PM

SE
20
Systemkrav
Operativsystem:
Microsoft® Windows®2000/ XP/ Vista™ och Windows®7
Hårdvara:
1 tillgänglig USB-port
Produktöversikt
Tangentbord
Mus
Vänster knapp Höger knapp
Rullhjul
Funktionsknappar
Esc F1 F2 F3 F4 F5 F6 F7 F8 F11 F12 F9 F10 Print
SysRq
Scroll
Lock
Pause
Break Delete
Page
Up
Page
Down
End
Backspace Home
}
]
{
[
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
Caps Lock
Ctrl Alt Alt Ctrl Insert
Tab
<
,
>
.
?
/
:
;
@ ~
#
Shift
|
\
!
12
£
3
%
5
^
6
&
7
(
9
)
0
_
-
+
=
~
#
7
Home
4
1
End
5
8 9
PgUp
6
3
PgDn
0
Ins
.
Del
Enter
+
-
*
/
Num
Lock
2
*
8
$
4 C
SMK1011_IB_7L_RC_final120625.indb 20 25/06/2012 2:27 PM
