Santana Suenos User manual

SUENOS
3D SUPERNATURAL SOUND
WIRELESS EARBUDS
OVERVIEW OPERATION
Thank you for purchasing the Sueños Wireless Earbuds with 3D
SUPERNATURAL SOUND. Please read these instructions carefully
for proper operation and save for future reference.
Turning ON/OFF
Power on: Hold the MULTIFUNCTION (MF) button for
3 seconds until the white light illuminates.
Power off: Hold the MF button for 4 seconds until the
red light illuminates then turns off.
Connecting with Bluetooth
To play audio from a Bluetooth device,
you need to pair the device with your earbuds.
1. Hold the MF button for 3 seconds to power on the
earbuds, indicated by the voice prompt “Power on”,
then “Pairing”. The light blinks white, indicating
the earbuds are ready to connect with your
Bluetooth device.
2. Turn on Bluetooth mode on your device.
3. Select “Santana Suenos” to initiate pairing, and the
earbuds will automatically connect with your
Bluetooth device, indicated by a white light and
voice prompt “Connected”. Some devices ask you
to input the PIN “0000” as the password.
Note: Generally, there is a 10 minute maximum to pair
the earbuds with your Bluetooth device, otherwise
retry steps 1 to 3 to pair again.
MULTIFUNCTION (MF) Button
VOL(+) Button
VOL(–) Button

USING THE EARBUDS CHARGING THE SUENOS
Left and right are indicated by L/R on corresponding
earbuds.
Answering a Call
When a call is incoming, you will hear a ring tone.
Press the MF button once to accept the call, or
answer the call via your mobile phone.
Rejecting a Call
Double press the MF button to reject the incoming call.
Ending a Call
Press the MF button once to end the call, or hang up
via your mobile phone.
Music Play / Pause
Press the MF button once to play/pause music.
Volume Adjustment / Skip Track
Short press the Vol(+) or Vol(-) to adjust volume.
Long press the Vol(+) toselect next track.
Long press the Vol(-) toselect previous track.
3D Function
Double press the MF button to turn on/off the 3D
function.
Voice Assistant
Hold the MF button for 2 seconds to activate voice assistant.
IMPORTANT:
Activate your warranty at SantanaSounds.com
1. Before charging, make sure the earbuds have
been switched off.
2. Plug the USB cable into the charging port of
earbuds; plug the other side of the USB cable into
a USB charger or other charging device. Charging
will start, and the red light remains illuminated on
the earbuds.
3. A full charge takes approximately 2 hours, and
then the red light will turn white when fully charged.
Warning: You must use the original cable to charge
the Bluetooth earbuds, otherwise it may damage the
earbuds. Proper charger voltage must be 5V with a
current rated at 115mA.
These earbuds use a non-detachable built-in
rechargeable battery. In order to prevent damage to
the earbuds, please do not remove the battery.
Note: The voice prompt “Battery Low” will notify you
when the earbuds need to be recharged.
Product Name: Sueños Charging Time: 2 hours
Product Type: Earbuds Sensitivity(SPL): 96±3dB
Wireless Range: 33ft Impedance: 16Ω
Standby Time: 180 hours Rated Input Power: 10mW
Playtime: 9 hours Distortion: ≤5%
SPECIFICATIONS
ATTENTION
1. Try to avoid prolonged and continuous uses at high volume which can damage your hearing.
2. Do not wear the earbuds while driving or cycling.
3. Avoid placing the earbuds in prolonged sun exposure, high temperature or dusty and humid
environments, which may affect the normal use.
4. Clean your earbuds with a soft cloth, moistened only with mild soap and water. Stronger cleaning
agents can damage the surface of the unit.
WARRANTY
What is covered: Any defect in materials and workmanship.
Forhow long:1 year from date of purchase.
What wewill do:lf your product is defective and returned within 30 days after the date it was purchased,
we will replace it at no charge toyou. lf returned after 30 days but within 1 year of the date of purchase
we will repair it or, at our option, replace it at no charge toyou. If we repair your product, we may use new
or reconditioned replacement parts. lf we choose to replace your product we may replace it with a new or
reconditioned one of the same or similar design. The repair or replacement will be warrantied under our
standard one year warranty.
Limitations: purpose and merchantability (an
e limited to1year from the date of purchase. We
will not pay for loss of time, inconvenience, loss of use of your product or property damage caused by your
product or its failure to work, or any other incidental or consequential damages including personal injury. Some
states do not allow limitations on how long an implied warranty lasts or the exclusion of limitation of incidental
or consequential damages, sothe above exclusions or limitations may not apply to you.
What we ask you to do: To get warranty service for your product you must provide proof of the date of
purchase. Within 30 days of the date it was purchased, return your product toyour place of purchase for
immediate replacement. After 30 days, but before the end of the 1 year warranty period, you may contact us
at SantanaSounds.com to issue a return authorization. We suggest that you retain your original packaging
material in the event you need toship your product. When sending your product include your name, address,
phone number, proof of date of purchase, and a description of the operating problem. After repairing or
replacing your product we will ship it to your home within four weeks.
What thiswarranty does not cover:Among other things this warranty does not cover defects resulting
protection is not covered by our warranty, contact us at SantanaSounds.com to determine whether we will
repair your product and other repair information, including charges. We, at our option, may replace rather than
repair your product with a new or reconditioned one of the same or similar design, the repair or replacement
will be warrantied for one year. This limited warranty is the only one we give on your product, and it sets forth
all our responsibilities regarding your product. There are no warranties that extend beyond the description set
forth above.
State law rights:
vary from state tostate.
FCC/BLUETOOTH STATEMENT
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Santana Sounds, LLC is under license. Other trademarks and trade names are
those of their respective owners.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
V1.0
