Santana Suenos User manual

SUENOS

3D SUPERNATURAL SOUND

WIRELESS EARBUDS

OVERVIEW OPERATION

Thank you for purchasing the Sueños Wireless Earbuds with 3D

SUPERNATURAL SOUND. Please read these instructions carefully

for proper operation and save for future reference.

Turning ON/OFF

Power on: Hold the MULTIFUNCTION (MF) button for

3 seconds until the white light illuminates.

Power off: Hold the MF button for 4 seconds until the

red light illuminates then turns off.

Connecting with Bluetooth

To play audio from a Bluetooth device,

you need to pair the device with your earbuds.

1. Hold the MF button for 3 seconds to power on the

earbuds, indicated by the voice prompt “Power on”,

then “Pairing”. The light blinks white, indicating

the earbuds are ready to connect with your

Bluetooth device.

2. Turn on Bluetooth mode on your device.

3. Select “Santana Suenos” to initiate pairing, and the

earbuds will automatically connect with your

Bluetooth device, indicated by a white light and

voice prompt “Connected”. Some devices ask you

to input the PIN “0000” as the password.

Note: Generally, there is a 10 minute maximum to pair

the earbuds with your Bluetooth device, otherwise

retry steps 1 to 3 to pair again.

MULTIFUNCTION (MF) Button

VOL(+) Button

VOL(–) Button

SUENOS

3D SUPERNATURAL SOUND

WIRELESS EARBUDS

OVERVIEW OPERATION

Thank you for purchasing the Sueños Wireless Earbuds with 3D

SUPERNATURAL SOUND. Please read these instructions carefully

for proper operation and save for future reference.

Turning ON/OFF

Power on: Hold the MULTIFUNCTION (MF) button for

3 seconds until the white light illuminates.

Power off: Hold the MF button for 4 seconds until the

red light illuminates then turns off.

Connecting with Bluetooth

To play audio from a Bluetooth device,

you need to pair the device with your earbuds.

1. Hold the MF button for 3 seconds to power on the

earbuds, indicated by the voice prompt “Power on”,

then “Pairing”. The light blinks white, indicating

the earbuds are ready to connect with your

Bluetooth device.

2. Turn on Bluetooth mode on your device.

3. Select “Santana Suenos” to initiate pairing, and the

earbuds will automatically connect with your

Bluetooth device, indicated by a white light and

voice prompt “Connected”. Some devices ask you

to input the PIN “0000” as the password.

Note: Generally, there is a 10 minute maximum to pair

the earbuds with your Bluetooth device, otherwise

retry steps 1 to 3 to pair again.

MULTIFUNCTION (MF) Button

VOL(+) Button

VOL(–) Button

SUENOS

3D SUPERNATURAL SOUND

WIRELESS EARBUDS

OVERVIEW OPERATION

Thank you for purchasing the Sueños Wireless Earbuds with 3D

SUPERNATURAL SOUND. Please read these instructions carefully

for proper operation and save for future reference.

Turning ON/OFF

Power on: Hold the MULTIFUNCTION (MF) button for

3 seconds until the white light illuminates.

Power off: Hold the MF button for 4 seconds until the

red light illuminates then turns off.

Connecting with Bluetooth

To play audio from a Bluetooth device,

you need to pair the device with your earbuds.

1. Hold the MF button for 3 seconds to power on the

earbuds, indicated by the voice prompt “Power on”,

then “Pairing”. The light blinks white, indicating

the earbuds are ready to connect with your

Bluetooth device.

2. Turn on Bluetooth mode on your device.

3. Select “Santana Suenos” to initiate pairing, and the

earbuds will automatically connect with your

Bluetooth device, indicated by a white light and

voice prompt “Connected”. Some devices ask you

to input the PIN “0000” as the password.

Note: Generally, there is a 10 minute maximum to pair

the earbuds with your Bluetooth device, otherwise

retry steps 1 to 3 to pair again.

MULTIFUNCTION (MF) Button

VOL(+) Button

VOL(–) Button

USING THE EARBUDS CHARGING THE SUENOS

Left and right are indicated by L/R on corresponding

earbuds.

Answering a Call

When a call is incoming, you will hear a ring tone.

Press the MF button once to accept the call, or

answer the call via your mobile phone.

Rejecting a Call

Double press the MF button to reject the incoming call.

Ending a Call

Press the MF button once to end the call, or hang up

via your mobile phone.

Music Play / Pause

Press the MF button once to play/pause music.

Volume Adjustment / Skip Track

Short press the Vol(+) or Vol(-) to adjust volume.

Long press the Vol(+) toselect next track.

Long press the Vol(-) toselect previous track.

3D Function

Double press the MF button to turn on/off the 3D

function.

Voice Assistant

Hold the MF button for 2 seconds to activate voice assistant.

IMPORTANT:

Activate your warranty at SantanaSounds.com

1. Before charging, make sure the earbuds have

been switched off.

2. Plug the USB cable into the charging port of

earbuds; plug the other side of the USB cable into

a USB charger or other charging device. Charging

will start, and the red light remains illuminated on

the earbuds.

3. A full charge takes approximately 2 hours, and

then the red light will turn white when fully charged.

Warning: You must use the original cable to charge

the Bluetooth earbuds, otherwise it may damage the

earbuds. Proper charger voltage must be 5V with a

current rated at 115mA.

These earbuds use a non-detachable built-in

rechargeable battery. In order to prevent damage to

the earbuds, please do not remove the battery.

Note: The voice prompt “Battery Low” will notify you

when the earbuds need to be recharged.

Product Name: Sueños Charging Time: 2 hours

Product Type: Earbuds Sensitivity(SPL): 96±3dB

Wireless Range: 33ft Impedance: 16Ω

Standby Time: 180 hours Rated Input Power: 10mW

Playtime: 9 hours Distortion: ≤5%

SPECIFICATIONS

ATTENTION

1. Try to avoid prolonged and continuous uses at high volume which can damage your hearing.

2. Do not wear the earbuds while driving or cycling.

3. Avoid placing the earbuds in prolonged sun exposure, high temperature or dusty and humid

environments, which may affect the normal use.

4. Clean your earbuds with a soft cloth, moistened only with mild soap and water. Stronger cleaning

agents can damage the surface of the unit.

WARRANTY

What is covered: Any defect in materials and workmanship.

Forhow long:1 year from date of purchase.

What wewill do:lf your product is defective and returned within 30 days after the date it was purchased,

we will replace it at no charge toyou. lf returned after 30 days but within 1 year of the date of purchase

we will repair it or, at our option, replace it at no charge toyou. If we repair your product, we may use new

or reconditioned replacement parts. lf we choose to replace your product we may replace it with a new or

reconditioned one of the same or similar design. The repair or replacement will be warrantied under our

standard one year warranty.

Limitations: purpose and merchantability (an

e limited to1year from the date of purchase. We

will not pay for loss of time, inconvenience, loss of use of your product or property damage caused by your

product or its failure to work, or any other incidental or consequential damages including personal injury. Some

states do not allow limitations on how long an implied warranty lasts or the exclusion of limitation of incidental

or consequential damages, sothe above exclusions or limitations may not apply to you.

What we ask you to do: To get warranty service for your product you must provide proof of the date of

purchase. Within 30 days of the date it was purchased, return your product toyour place of purchase for

immediate replacement. After 30 days, but before the end of the 1 year warranty period, you may contact us

at SantanaSounds.com to issue a return authorization. We suggest that you retain your original packaging

material in the event you need toship your product. When sending your product include your name, address,

phone number, proof of date of purchase, and a description of the operating problem. After repairing or

replacing your product we will ship it to your home within four weeks.

What thiswarranty does not cover:Among other things this warranty does not cover defects resulting

protection is not covered by our warranty, contact us at SantanaSounds.com to determine whether we will

repair your product and other repair information, including charges. We, at our option, may replace rather than

repair your product with a new or reconditioned one of the same or similar design, the repair or replacement

will be warrantied for one year. This limited warranty is the only one we give on your product, and it sets forth

all our responsibilities regarding your product. There are no warranties that extend beyond the description set

forth above.

State law rights:

vary from state tostate.

FCC/BLUETOOTH STATEMENT

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any

use of such marks by Santana Sounds, LLC is under license. Other trademarks and trade names are

those of their respective owners.

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device

may not cause harmful interference, and (2) this device must accept any interference received, including interference that

may cause undesired operation.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

V1.0
