Santos 26 Operating instructions

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 1 / 10 www.santos.fr
USER AND MAINTENANCE MANUAL
IMPORTANT: documents included in this manual to be kept:
•"CE" COMPLIANCE DECLARATION
•WARRANTY CERTIFICATE
TRANSLATION OF THE ORIGINAL VERSION
Model No 26
Coffee grinders - Fruit juicers - Mixers - Blenders - Drinks dispensers - Planetary mixers
Cheese graters - Ice crushers - Mincers - Vegetable slicers – Dough mixer
Moulins à café - Presse-fruits - Mixers - Blenders - Distributeurs de boissons - Batteurs
mélangeurs - Pétrin - Râpes à fromage - Broyeurs à glaçons - Hache-viande - Coupe-légumes
MODELES DEPOSES FRANCE ET INTERNATIONAL
INTERNATIONALLY PATENTED MODELS
SANTOS SAS
140-150 AVENUE ROGER SALENGRO
69120 VAULX-EN-VELIN (LYON) - FRANCE
PHONE: [phone] - FAX [phone]
E-Mail: [e-mail] www.santos.fr
GROUND COFFEE DISPENSER No 26
!

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 2 / 10 www.santos.fr
CONTENTS
“CE/EU” COMPLIANCE DECLARATION .................................................................................3
IMPORTANT SAFEGUARDS ........................................................................................................4
IMPROPER USE: ............................................................................................................................4
USING FOR THE 1st TIME ............................................................................................................4
RECYCLING THE PRODUCT AT THE END OF ITS SERVICE LIFE..........................................4
GROUND COFFEE DISPENSER No 26 ........................................................................................5
USING THE APPLIANCE ...............................................................................................................5
STARTING UP:................................................................................................................................5
USING: ............................................................................................................................................5
ADJUSTING THE MEASURED DOSE OF GROUND COFFEE: .................................................5
CLEANING ......................................................................................................................................6
MAINTENANCE ..............................................................................................................................6
Spare parts: ..................................................................................................................................6
FAULT FINDING..............................................................................................................................7
The ground coffee measure is not consistent...............................................................................7
The ground coffee jams in the outlet conduit ..............................................................................7
The adjustment of the ground coffee measure is not instant .......................................................7
There is too much ground coffee in the measure.........................................................................7
There is not enough ground coffee in the measure ......................................................................7
Dispensing a half measure ...........................................................................................................7
APPLIANCE TECHNICAL SPECIFICATIONS..........................................................................7
Figures .............................................................................................................................................9
WARRANTY CERTIFICATE .....................................................................................................10
APPLIANCE IDENTIFICATION PLATE ................................................................................10

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 3 / 10 www.santos.fr
“CE/EU” COMPLIANCE DECLARATION
THE MANUFACTURER:
SANTOS SAS - 140-150, Av. Roger SALENGRO 69120 VAULX-EN-VELIN (LYON) FRANCE
declares that the appliance intended for the professional market
described below:
Description: GROUND COFFEE DISPENSER
Type number: 26
complies with:
•the statutory provisions defined in appendix 1 of the European “machinery” directive
No. 2006/42/EC and the national legislation transposing it.
•the statutory provisions of the following European directives and regulations:
oNo 1935/2004/EC (Regulation) on materials and articles intended to come into
contact with food
oNo 10/2011/EU (regulation) on plastic materials and articles intended to come into
contact with food
Harmonised European standards used to give presumption of conformity with the essential
requirements of the above-mentioned directives:
•NF EN ISO 12100: 2010, Safety of machinery - General principles for design
•NF EN 1672-2+A1: 2009, Food processing machinery – Basic concepts - Hygiene
requirements.
Drawn up in VAULX-EN-VELIN on: 01/12/2020
Signatory’s position: CHIEF EXECUTIVE OFFICER
Signatory’s name: Aurélien FOUQUET
Signature:

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 4 / 10 www.santos.fr
IMPORTANT SAFEGUARDS
When using, maintaining or disposing of the appliance, always follow these basic
instructions.
Read all instructions
Keep this user manual
IMPROPER USE:
1. This appliance is not a coffee grinder, it is not intended to grind roasted
coffee beans.
2. Never use this appliance to dispense anything other than ground roasted
coffee.
3. Cleaning in a jet of water or a high pressure spray is prohibited.
4. The use of spare parts other than certified original SANTOS parts is
prohibited.
5. Never place the appliance close to or on a source of heat.
6. This appliance is not designed for use by people (including children) whose
physical, sensorial or mental capacities are impaired or by people with no
experience or knowledge, unless they have been supervised or given training
in the use of the appliance beforehand by a person responsible for their
safety.
Supervise children to ensure they do not play with the appliance.
USING FOR THE 1st TIME
Thoroughly clean all parts in contact with the coffee.
•Take off the dose measurer lid (1), the ground coffee collector (7) and wash them
with a standard dish washing product.
RECYCLING THE PRODUCT AT THE END OF ITS SERVICE LIFE
The packaging material should be disposed of or recycled in accordance with regulations
in force.
Note: You will find it easier to understand the next few paragraphs if you refer to
the diagrams at the end of this manual
!

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 5 / 10 www.santos.fr
GROUND COFFEE DISPENSER No 26
•The ground coffee dispenser No. 26 is designed for bars, cafés, hotels and
restaurants. It is suitable for all types of espresso coffee machines.
•The appliance consists of an aluminium base, a manual dose measurer and a dose
counter.
•The appliance can be used to measure doses of roasted coffee and dispense it via
an adjustable dose measurer.
Adjustment of the ground coffee measure (from approximately 5.5g to 9.5g).
USING THE APPLIANCE
STARTING UP:
Assembly and preparation:
1. Unpack the appliance and place it on a worktop.
2. Place the ground coffee collector (7) on the base (8).
3. Pour the ground coffee into the dose measurer (2)
4. Put the dose measurer lid (1) in place.
USING:
1. Place the filter-holder of your coffee machine under the dose measurer outlet (4)
using the filter-holder support (6) to help.
2. Pull the dose measurer handle (9) once or twice to dispense one or 2 measure(s) of
ground coffee.
3. Remove the filter-holder and tamp down the coffee with the tamper (3) fixed to the
dose measurer.
Note: A 5-figure counter on the side of the dose measurer counts each measure.
ADJUSTING THE MEASURED DOSE OF GROUND COFFEE:
The dose measurer should be cleaned regularly to prevent conglomerated blocks of
coffee on the cross bars from affecting the dose measurer setting.
The appliance is factory-set for a measure of approximately 7g.
1. Pour 250g of ground coffee into the dose measurer (2)
2. Place a container under the coffee outlet of the dose measurer (4) to collect the
ground coffee after each test
3. Pull the dose measurer handle (9) 6 times to fully rotate the dose cross bars
(replace the ground coffee of these first measures in the dose measurer
cylinder)
4. Draw a measure and measure the mass (weight) dispensed.

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 6 / 10 www.santos.fr
5. Tighten the thumb-wheel (5) by turning in a clockwise direction (right-handed
thread) to reduce the quantity of ground coffee per measure (the thumb-wheel
is adjusted in half-turns).
6. Loosen the thumb-wheel (5) by turning in an anti-clockwise direction to
increase the quantity of ground coffee per measure.
7. Draw off more than 6 measures for the adjustment to be taken into account.
IMPORTANT: It is important to keep a sufficient quantity of ground coffee in the dose
measurer to ensure a good measure consistency. Too little ground coffee will reduce
the weight of the measure dispensed.
CLEANING
•Cleaning in a jet of water or a high pressure spray is prohibited.
Clean the dose measurer (2) regularly using a brush.
Make sure that the walls of the coffee dispensing conduit (4) and the 6 branches of the
cross bars are always clean.
MAINTENANCE
Spare parts:
This machine requires no particular maintenance.
If servicing is necessary to replace parts subject to wear, please refer to the list of
components (see the exploded view at the end of this manual).
IMPORTANT: The use of spare parts other than certified original SANTOS
parts is prohibited.
Whenever ordering spare parts (see references in the exploded view at the end of this
manual), please quote the following:
the type
the appliance serial No
given under the appliance.
!

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 7 / 10 www.santos.fr
FAULT FINDING
Carefully determine the reason for the failure.
The ground coffee measure is not consistent
•Check there is ground coffee in the dose measurer (2)
•Clean the coffee dose measurer (2) + (4)
The ground coffee jams in the outlet conduit
•Clean the coffee outlet (4) regularly. Be careful not to damage the metal coffee
ejector tab.
The adjustment of the ground coffee measure is not instant
•Approximately 3 to 6 doses should be dispensed to see the effects of the change in
adjustment.
There is too much ground coffee in the measure
•Always use the same source of ground coffee
•Adjust the dose measurer
There is not enough ground coffee in the measure
•Check that the amount of ground coffee in the dose measurer is at least one third of
the capacity of the dose measurer
•Always use the same source of ground coffee
•Adjust the dose measurer
Dispensing a half measure
•Pull the handle to the front most stop. Half measures cannot be dispensed. Anything
that has not been dispensed will be dispensed on the next pull of the handle.
APPLIANCE TECHNICAL SPECIFICATIONS
Dose measurer capacity
(g)
350
Measure adjustment
(g)
From 5.5 to 9.5
Dimensions: Height
(mm)
352
Width
(mm)
200
Depth
(mm)
293
Weight: Net weight
(kg)
4.3
Weight
(kg)
5

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 8 / 10 www.santos.fr
Component cross-reference table
ITEM
Description
1
Dose measurer lid
2
Dose measurer
3
Ground coffee tamper
4
Ground coffee outlet conduit
5
Coffee measure adjustment thumb-wheel
6
Filter-holder support
7
Ground coffee collector
8
Base
9
Dose measurer handle

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 9 / 10 www.santos.fr
Figures
1
2
3
6
7
8
9
5
4
"+"
"-"
5

SANTOS: User and maintenance manual
98126 EN 1.0 - 12 2020 10 / 10 www.santos.fr
WARRANTY CERTIFICATE
WARRANTY
Since the 01.01.95, all our appliances comply with CE and possess the CE label. Our guarantee is
of 24 months from the manufacturing date mentioned on the descriptive plate, except concerning
the asynchronous motors (consisting of a rotor and a stator) which are warranted for 5 years from
their manufacturing date. Warranty is strictly limited to the free replacement of any part of origin
recognized by us as defective due to a defect or building default and identified as belonging to the
concerned appliance. Warranty does not apply to damages resulting from installation or use non-
complying with our appliance data sheet (user’s manual) or in case of an evident lack of
maintenance or disrespect of elementary security electric rules. It does not apply in case of regular
wear and tear. Any replacement of parts under warranty will be realized after return of the
defective part in our workshops, postage paid, supported by a copy of a conformity statement on
which appears the serial number of the appliance. Every appliance is equipped with a descriptive
plate conforming to the EC recommendations and of which a duplicate exists in the conformity
statement (serial number, manufacturing date, electrical characteristics …). In case of serious
damage judged repairable only in our workshops, and after prior consent from our departments,
any appliance under guarantee is sent by the Distributor, carriage paid. In case of repairs or
reconditioning of appliances not under guarantee, the round trip transport is payable by the
distributor. The parts and workforce are invoiced at the current rate. A preliminary estimate can be
supplied.
Coffee grinder not using SANTOS original burrs are not taken under guarantee. The warranty
conditions, repairs, reconditioning, of the espresso coffee grinder are the object of a specific note.
Our guarantee does not extend to the payment of penalties, the repair of direct or indirect
damages and notably to any loss of income resulting from the nonconformity or the defectiveness
of products, SANTOS's global responsibility being limited to the sale price of the delivered product
and to the possible repair of the defective products.
In case of revelation of an imperfection during the warranty period, the Distributor has to, unless a
different written agreement of SANTOS, indicate to his customer to stop any use of the defective
product. Such a use would release SANTOS of any responsibility.
APPLIANCE IDENTIFICATION PLATE
SPECIMEN
For all documents not supplied with
the appliance.
Printed, Faxed and Downloaded
