SYO S/M830032 ( )
______________ 1111
______________ 1111
______________ 1111
______________ 1111
FILE NO.
SERVICE MANUAL
85464849152001 REFERENCE NO. SM830052
1
4
OUTDOOR MODEL No. PRODUCT CODE No. APPLICABLE INDOOR MODEL No. V / ø / Hz
SPW-C483GYH8 85401274 SPW - K · AS · S· F· FM· U 93GH56 OUTDOOR
SPW-C703GYH8 85401128 SPW - X · K · U · AS · S · F · FM 123GH56 380 - 415 / 3 ø / 50
SPW-C903GYH8 85401129 SPW - X · K · T · S · U · F · FM 183GH56
SPW-C483GY8 85401275 SPW - X · T · S · U · D · F · FM 253GH56 INDOOR
SPW-C703GY8 85401163 SPW - X · T · U · D 363GH56 220 - 240 / 1 ø / 50
SPW-C903GY8 85401164 SPW - X · T · U · D 483GH56
0409_C_S
3
2

i
Please Read Before Starting
This air conditioning system meets strict safety and
operating standards. As the installer or service person, it
is an important part of your job to install or service the
system so it operates safely and efficiently.
For safe installation and trouble-free operation, you
must :
ⓦCarefully read this instruction booklet before beginning.
ⓦFollow each installation or repair step exactly as shown.
ⓦObserve all local, state, and national electrical codes.
ⓦPay close attention to all warning and caution notices
given in this manual.
This symbol refers to a
hazard or unsafe practice
which can result in severe
personal injury or death.
This symbol refers to a
hazard or unsafe practice
which can result in personal
injury or product or property
damage.
If Necessary, Get Help
These instructions are all you need for most installation
sites and maintenance conditions. If you require help for a
special problem, contact our sales/service outlet or your
certified dealer for additional instructions.
In Case of Improper Installation
The manufacturer shall in no way be responsible for
improper installation or maintenance service, including
failure to follow the instructions in this document.
SPECIAL PRECAUTIONS
When Wiring
……………………………………………………………………
ELECTRICAL SHOCK CAN CAUSE
SEVERE PERSONAL INJURY OR DEATH.
ONLY A QUALIFIED, EXPERIENCED
ELECTRICIAN SHOULD ATTEMPT TO
WIRE THIS SYSTEM.
• Do not supply power to the unit until all wiring and
tubing are completed or reconnected and checked.
• Highly dangerous electrical voltages are used in this
system. Carefully refer to the wiring diagram and these
instructions when wiring. Improper connections and
inadequate grounding can cause accidentaly injury or
death.
•Ground the unit following local electrical codes.
• Connect all wiring tightly. Loose wiring may cause
overheating at connection points and a possible fire
hazard.
When Transporting
……………………………………………………………………
Be careful when picking up and moving the indoor and
outdoor units. Get a partner to help, and bend your knees
when lifting to reduce strain on your back. Sharp edges or
thin aluminum fins on the air conditioner can cut your
fingers.
Important
CAUTION
When Installing
……………………………………………………………………
…In a Room
Properly insulate any tubing run inside a room to prevent
“sweating” that can cause dripping and water damage to
walls and floors.
…In Moist or Uneven Locations
Use a raised concrete pad or concrete blocks to provide a
solid, level foundation for the outdoor unit. This prevents
water damage and abnormal vibration.
…In an area with High Winds
Securely anchor the outdoor unit down with bolts and a
metal frame. Provide a suitable air baffle.
…In a Snowy Area (for Heat Pump-type Sys-
tems)
Install the outdoor unit on a raised platform that is higher
than drifting snow. Provide snow vents.
When Connecting Refrigerant Tubing
……………………………………………………………………
• Ventilate the room well, in the event that refrigerant gas
leaks during the installation. Be careful not to allow
contact of the refrigerant gas with a flame as this will
cause the generation of poisonous gas.
• Keep all tubing runs as short as possible.
• Use the flare method for connecting tubing.
• Apply refrigerant lubricant to the matching surfaces of
the flare and union tubes before connecting them, then
tighten the nut with a torque wrench for a leak-free
connection.
• Check carefully for leaks before starting the test run.
NOTE
Depending on the system type, liquid and gas lines may
be either narrow or wide. Therefore, to avoid confusion the
refrigerant tubing for your particular model is specified as
either “narrow” or “wide” rather than as “liquid” or “gas”.
When Servicing
……………………………………………………………………
• Turn the power OFF at the main power box (mains)
before opening the unit to check or repair electrical
parts and wiring.
• Keep your fingers and clothing away from any moving
parts.
• Clean up the site when installation is finished. Check
that no metal scraps or bits of wiring have been left
inside the unit.
CAUTION
• Ventilate any enclosed areas when installing or testing
the refrigeration system. Contact of refrigerant gas with
fire or heat can produce poisonous gas.
• Confirm after installation that no refrigerant gas is
leaking. If the gas comes in contact with a burning
stove, gas water heater, electric room heater or other
heat source, it can cause the generation of poisonous
gas.

ii
0001_M_I
ImportantCheck of Density Limit
The room in which the air conditioner is to be
installed requires a design that in the event of
refrigerant gas leaking out, its density will not
exceed a set limit.
The refrigerant R-22 which is used in the air conditioner
is safe, without the toxicity or combustibility of ammonia,
and is not restricted by laws to be imposed which protect
the ozone layer. However, since it contains more than air,
it poses the risk of suffocation if its density should rise
excessively. Suffocation from leakage of R-22 is almost
non-existent. With the recent increase in the number of
high density buildings, however, the installation of multi
air conditioner systems is on the increase because of the
need for effective use of floor space, individual control,
energy conservation by curtailing heat and carrying
power etc.
Most importantly, the multi air conditioner system is able
to replenish a large amount of refrigerant compared with
conventional individual air conditioners. If a single unit of
the multi air conditioner system is to be installed in a
small room, select a suitable model and installation
procedure so that if the refrigerant accidentally leaks out,
its density does not reach the limit (and in the event of an
emergency, measures can be made before injury can
occur).
In a room where the density may exceed the limit, create
an opening with adjacent rooms, or install mechanical
ventilation combined with a gas leak detection device.
The density is as given below.
Total amount of refrigerant (kg)
Min. volume of the indoor unit installed room (m3)
Density limit (kg/m3)
The density limit of R-22 which is used in multi air
conditioners is 0.15 kg/m3.
2: The standards for minimum room
volume are as follows.
(1) No partition (shaded portion)
(2) When there is an effective opening with the
adjacent room for ventilation of leaking refrigerant
gas (opening without a door, or an opening 0.15%
or larger than the respective floor spaces at the top
or bottom of the door).
(3) If an indoor unit is installed in each partitioned room
and the refrigerant tubing is interconnected, the
smallest room of course becomes the object. But
when a mechanical ventilation is installed
interlocked with a gas leakage detector in the
smallest room where the density limit is exceeded,
the volume of the next smallest room becomes the
object.
NOTE
1: If there are 2 or more refrigerating
systems in a single refrigerating
device, the amounts of refrigerant
should be as charged in each
independent device.
NOTE
0803_M_I
e.g., charged
amount (10 kg)
Outdoor unit
Indoor unit
Room A Room B Room C Room D Room E Room F
e.g.,
charged amount (15 kg)
For the amount of charge in this example:
The possible amount of leaked refrigerant gas in
rooms A, B and C is 10 kg.
The possible amount of leaked refrigerant gas in
rooms D, E and F is 15 kg.
>
Outdoor unit
0002_M_I
Refrigerant tubing
Indoor unit
3 : The minimum indoor floor space com-
pared with the amount of refrigerant is
roughly as follows.
(When the ceiling is 2.7 m high)
NOTE
5
13.5
27.0
40.5
54.0
67.5
81.0
94.5
108
121.5
135
5
10
15
20
25
30
35
40
45
50 m3
m2
Total amount of refrigerant 0766_M_I
Min. indoor floor area (when the ceiling is 2.7 m high)
Min. indoor volume
10 15 20 kg
Range below the
density limit of
0.15 kg/m3
(Countermeasures
not needed)
Range above the
density limit of
0.15 kg/m3
(Countermeasures
needed)
Refrigerant tubing
Outdoor unit
Very
small
room Indoor unit
Small
room Medium room Large room
Mechanical ventilation device - Gas leak detector
0003_M_
I

iii
Contents
Page
Please Read Before Starting Important ....................................................... i
Check of Limit Density Important ................................................................ii
Line Up .........................................................................................................iv
Section 1 : ECO MULTI SYSTEM Unit Specifications........................ I - 1
1. Outdoor Unit .......................................................................................................I - 3
2. 4-way Air Discharge Semi-concealed Type ........................................................I - 19
3. 2-way Air Discharge Semi-concealed Type ........................................................I - 34
4. 1-way Air Discharge Semi-concealed Type ........................................................I - 48
5. Wall Mounted Type .............................................................................................I - 56
6. Ceiling Mounted Type .........................................................................................I - 66
7. Concealed Duct Type .........................................................................................I - 78
8. Concealed Duct High Static Pressure Type........................................................I - 97
9. Floor-Standing Type (F Type) .............................................................................I - 107
10. Concealed Floor-Standing Type (FM Type)........................................................I - 119
Section 2 : Processes and Functions ................................................ II - 1
1. Compressor Control............................................................................................II - 2
2. Reverse Cycle Defrosting ...................................................................................II - 5
3. Reverse Cycle Starting Control...........................................................................II - 6
4. Outdoor Fan Control ...........................................................................................II - 6
5. 4-way Valve Switching Control............................................................................II - 6
6. Save Valve Control .............................................................................................II - 6
7. Room Temperature Control ................................................................................II - 7
8. Automatic Cooling Control ..................................................................................II - 8
9. Dehumidifying Control.........................................................................................II - 8
10. Heating Preparations ..........................................................................................II - 9
11. Automatic Fan Speed Control .............................................................................II - 10
12. Auto-flap Control .................................................................................................II - 11
13. Drain Pump Control ............................................................................................II - 12
14. Indoor Electronic Control Valve...........................................................................II - 12
Section 3 : Service Procedures......................................................... III - 1
1. Troubleshooting ..................................................................................................III - 2
2. Sensor and Solenoid Layout Diagram ................................................................III - 37
3. Thermistor Characteristic Curve .........................................................................III - 44
4. Test Run ............................................................................................................. III - 45
5. PCBs and Their Location ....................................................................................III - 48
6. Compressor Defects ...........................................................................................III - 51
7. Operation Procedure for Replacing the Compressor ......................................... III - 52
Section 4 : Electrical Data..................................................................IV - 1
1. Outdoor Unit .......................................................................................................IV - 2
2. Indoor Unit ..........................................................................................................IV -10

ECO MULTI SYSTEM
SM830052
Line Up
iv SM830052
Indoor Units
Capacity: kW (BTU/h)
Cooling
/
Heating
566_8132 566_8132 566_8132
729_8132
729_8132
563_8132
563_8132 563_8132
563_8132
564_8132
564_8132 564_8132
730_8132
730_8132 730_8132
565_8132
584_8132 584_8132
565_8132
565_8132
565_8132
567_8132 567_8132
568_8132 569_8132 569_8132
567_8132
0855_V_I
0856_V_I
0857_V_I
0858_V_I
0855_V_I
0857_V_I
0856_V_I
0858_V_I
* K183GH: Cooling / Heating capacity is 5.0 (17,000) / 6.0 (20,000) : KW (BTU / h)
** F253GH, FM253GH: Cooling / Heating capacity is 7.1 (24,000) / 8.0 (27,000) : KW (BTU / h)
570_8132
570_8132
0859_C_S
Outdoor units Type 48 70 90
Capacity: kW (BTU/h) 14 (47,800) 22.4 (76,400) 28.0 (95,500)
Cooling / Heating / 16 (54,600) / 25.0 (85,300) / 31.5 (107,500)
Outdoor Unit
Heat pump C483GYH8 C703GYH C903GYH
Cooling Only C483GY8 C703GY C903GY
Indoor / Outdoor Unit Capacity Ratio
Indoor Unit Total Capacity ×100
Max. 130 % (Cooling)
Outdoor Unit Capacity
Operating Range Cooling –5 °C ~ 43 °C DB / Heating –15 °C ~ 15.5 °C WB
Outdoor Air Intake Temperature
40 m (When outdoor unit installed higher) 50 m (When outdoor unit installed higher)
Limit of Elevation Difference
30 m (When outdoor unit installed lower) 30 m (When outdoor unit installed lower)
Limit of Tubing Length 50 m 100 m
Allowable No. of 6 units 10 units 13 units
Indoor Unit Connected
X123GH X183GH X253GH X363GH X483GH
S93GH S123GH S183GH S253GH
K93GH K123GH
*
K183GH D253GH D363GH D483GH
AS93GH AS123GH T183GH T253GH T363GH T483GH
U93GH U123GH U183GH U253GH U363GH U483GH
Floor Standing Type (F type)
F93GH F123GH F183GH
**
F253GH
Concealed
Floor Standing Type
(FM type)
FM93GH FM123GH FM183GH
**
FM253GH
4-Way Air Discharge
Semi-Concealed Type
2-Way Air Discharge
Semi-Concealed Type
Wall-Mounted Type &
Concealed-Duct
High Static Pressure
Type
1-Way Air Discharge
Semi-Concealed Type &
Ceiling-Mounted Type
Concealed-Duct Type
Type 9 12 18 25 36 48
2.8 (9,600) 3.6 (12,000) 5.6 (19,000) 7.3 (25,000) 10.6 (36,000) 14.0 (47,800)
//// //
3.2 (11,000) 4.2 (14,000) 6.3 (21,000) 8.0 (27,000) 11.4 (39,000) 16.0 (54,600)

ECO MULTI SYSTEM Unit Specifications
SM830052
I-1
1
Contents
1. ECO MULTI SYSTEM Unit Specifications
1. Outdoor Unit .....................................................................................I - 3
1-1. Specifications ...................................................................................................................................................I - 3
1-2. Major component specifications .......................................................................................................................I - 9
1-3. Control specifications .......................................................................................................................................I - 12
1-4. Other component specifications .......................................................................................................................I - 13
1-5. Dimensional data..............................................................................................................................................I - 15
1-6. Refrigerant flow diagram ..................................................................................................................................I - 16
1-7. Noise criterion curves.......................................................................................................................................I - 18
2. 4-way Air Discharge Semi-concealedType ................................... I - 19
2-1. Specifications ..................................................................................................................................................I - 19
2-2. Major component specifications ......................................................................................................................I - 24
2-3. Other component specifications ......................................................................................................................I - 29
2-4. Dimensional data.............................................................................................................................................I - 30
2-5. Noise criterion curves......................................................................................................................................I - 32
2-6. Air throw distance chart...................................................................................................................................I - 33
3. 2-way Air Discharge Semi-concealedType ................................... I - 34
3-1. Specifications ..................................................................................................................................................I - 34
3-2. Major component specifications ......................................................................................................................I - 38
3-3. Other component specifications ......................................................................................................................I - 42
3-4. Dimensional data.............................................................................................................................................I - 43
3-5. Noise criterion curves......................................................................................................................................I - 45
3-6. Air throw distance chart...................................................................................................................................I - 47
4. 1-way Air Discharge Semi-concealedType ................................... I - 48
4-1. Specifications ..................................................................................................................................................I - 48
4-2. Major component specifications ......................................................................................................................I - 50
4-3. Other component specifications ......................................................................................................................I - 52
4-4. Dimensional data.............................................................................................................................................I - 53
4-5. Noise criterion curves......................................................................................................................................I - 54
4-6. Air throw distance chart...................................................................................................................................I - 55
5. Wall MountedType ...........................................................................I - 56
5-1. Specifications ..................................................................................................................................................I - 56
5-2. Major component specifications ......................................................................................................................I - 59
5-3. Other component specifications ......................................................................................................................I - 62
5-4. Dimensional data.............................................................................................................................................I - 63
5-5. Noise criterion curves......................................................................................................................................I - 64
5-6. Air throw distance chart...................................................................................................................................I - 65
6. Ceiling MountedType.......................................................................I - 66
6-1. Specifications ..................................................................................................................................................I - 66
6-2. Major component specifications ......................................................................................................................I - 70
6-3. Other component specifications ...................................................................................................................... I - 74
6-4. Dimensional data.............................................................................................................................................I - 75
6-5. Noise criterion curves......................................................................................................................................I - 76
6-6. Air throw distance chart...................................................................................................................................I - 77
7. Concealed DuctType........................................................................I - 78
7-1. Specifications ..................................................................................................................................................I - 78
7-2. Major component specifications ......................................................................................................................I - 84
7-3. Other component specifications ...................................................................................................................... I - 90
7-4. Dimensional data............................................................................................................................................. I - 91
7-5. Noise criterion curves......................................................................................................................................I - 94
7-6. Increasing the fan speed .................................................................................................................................I - 96
8. Concealed Duct High Static PressureType .................................. I - 97
8-1. Specifications ..................................................................................................................................................I - 97
8-2. Major component specifications ......................................................................................................................I - 100
8-3. Other component specifications ......................................................................................................................I - 103
8-4. Dimensional data.............................................................................................................................................I - 104
8-5. Noise criterion curves......................................................................................................................................I - 105
8-6. Indoor fan performance ...................................................................................................................................I - 106

ECO MULTI SYSTEM Unit Spesifications
SM830052
I-2
1
Contents
9. Floor StandingType .......................................................................I - 107
9-1. Specifications ..................................................................................................................................................I - 107
9-2. Major component specifications......................................................................................................................I - 111
9-3. Other component specifications......................................................................................................................I - 115
9-4. Dimensional data.............................................................................................................................................I - 116
9-5. Noise criterion curves......................................................................................................................................I - 117
9-6. Air throw distance chart...................................................................................................................................I - 118
10. Concealed Floor StandingType ....................................................I - 119
10-1. Specifications ................................................................................................................................................I - 119
10-2. Major component specifications ....................................................................................................................I - 123
10-3. Other component specifications....................................................................................................................I - 127
10-4. Dimensional data...........................................................................................................................................I - 128
10-5. Noise criterion curves....................................................................................................................................I - 129
10-6. Air throw distance chart.................................................................................................................................I - 130
10-7. Indoor fan performonce.................................................................................................................................I - 131

ECO MULTI SYSTEM Unit Specifications
SM830052
I-3
1
1-1. Specifications
Unit specifications (A)
Rated conditions
Cooling: Indoor air temperature 27 °C DB / 19.0 °C WB , Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °C DB / 6 °C WB
* Full load conditions at Indoor / outdoor capacity ratio 100 %
Cooling: Indoor air temperature 32 °C DB / 22.5 °C WB , Outdoor air temperature 43 °C DB / 25.5 °C WB
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
MODEL No. Outdoor Unit SPW – C483GYH8
POWER SOURCE 380 - 400 - 415 V / 3 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 14 16
BTU / h 47,800 54,600
Air circulation (Hi) m3/min(cu. ft/min) 84 (2,970)
ELECTRICAL RATINGS
Voltage rating V 380 - 400 - 415
Available voltage range V 342 - 456
Running amperes A 8.5 - 8.5 - 8.8 8.9 - 8.8 - 9.0
Max. running amperes* A 10.0 - 9.9 - 10.0 —
Power input kW 4.87 - 4.92 - 4.97 5.18 - 5.17 - 5.18
Max. power input* kW 5.90 - 5.91 - 5.95 —
Power factor % 87 - 84 - 79 88 - 85 - 80
C.O.P W/W 2.87 - 2.85 - 2.82 3.09 - 3.09 - 3.09
Compressor locked rotor amperes A 62 - 65 - 67
FEATURES
Controls Microprocessor
Defrost control Reverse cycle, microprocessor control
Service function Sensor temp. recall function
Past service warnings recall function
Refrigerant amount at shipment kg R22 - 3.0
Refrigerant control Electronic Refrigerant Control Valve
Operation sound (Hi) dB-A 55
REFRIGERANT TUBING
Limit of tubing length m(ft.) 50 (164)
Limit of elevation difference m(ft.) Outdoor unit is higher than indoor unit : 40 (131)
between the two units Outdoor unit is lower than indoor unit : 30 (98)
Refrigerant tube Narrow tube mm (in) 9.52 (3 / 8)
outer diameter Wide tube mm (in) 19.05 (3 / 4)
Refrigerant tubing kit / joint kit Optional
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Unit dimensions Height mm(in) 1,235 (48 - 20 / 32) 1,326 (52 - 7 / 32)
Width mm(in) 940 (37 ) 1,016 (40 )
Depth mm(in) 340 (13 - 12 / 32) 416 (16 - 12 / 32)
Net weight kg(lb) 109 ( 240 )
Shipping weight kg(lb) 116 ( 251 )
Shipping volume m3(Cu. ft.) 0.56 ( 19.8 )
1. Outdoor Unit

ECO MULTI SYSTEM Unit Spesifications
SM830052
I-4
1
1. Outdoor Unit
MODEL No. Outdoor Unit SPW – C483GY8
POWER SOURCE 380 - 400 - 415 V / 3 phase / 50Hz
PERFORMANCE Cooling
Capacity kW 14
BTU / h 47,800
Air circulation (Hi) m3/min(cu. ft/min) 84 (2,970)
ELECTRICAL RATINGS
Voltage rating V 380 - 400 - 415
Available voltage range V 342 - 456
Running amperes A 8.5 - 8.5 - 8.8
Max. running amperes* A 10.0 - 9.9 - 10.0
Power input kW 4.87 - 4.92 - 4.97
Max. power input* kW 5.90 - 5.91 - 5.96
Power factor % 87 - 84 - 79
C.O.P W/W 2.87 - 2.85 - 2.82
Compressor locked rotor amperes A 62 - 65 - 67
FEATURES
Controls Microprocessor
Defrost control Reverse cycle, microprocessor control
Service function Sensor temp. recall function
Past service warnings recall function
Refrigerant amount at shipment kg R22 - 3.0
Refrigerant control Electronic Refrigerant Control Valve
Operation sound (Hi) dB-A 55
REFRIGERANT TUBING
Limit of tubing length m(ft.) 50 (164)
Limit of elevation difference m(ft.) Outdoor unit is higher than indoor unit : 40 (131)
between the two units Outdoor unit is lower than indoor unit : 30 (98)
Refrigerant tube Narrow tube mm (in) 9.52 ( 3 / 8 )
outer diameter Wide tube mm (in) 19.05 ( 3 / 4 )
Refrigerant tubing kit / joint kit Optional
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Unit dimensions Height mm(in) 1,235 (48 - 20/32) 1,326 (52 - 7/32)
Width mm(in) 940 (37 ) 1,016 (40 )
Depth mm(in) 340 (13 - 12/32) 416 (16 - 12/32)
Net weight kg(lb) 107 ( 236 )
Shipping weight kg(lb) 114 ( 251 )
Shipping volume m3(Cu. ft.) 0.56 ( 19.8 )
Unit specifications (B)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °C DB / 19.0 °C WB , Outdoor air temperature 35 °C DB
* Full load conditions at Indoor / outdoor capacity ratio 100 %
Cooling: Indoor air temperature 32 °C DB / 22.5 °C WB , Outdoor air temperature 43 °C DB / 25.5 °C WB

ECO MULTI SYSTEM Unit Specifications
SM830052
I-5
1
1. Outdoor Unit
Unit specifications (C)
Rated conditions
Cooling: Indoor air temperature 27 °C DB / 19.0 °C WB , Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °C DB / 6 °C WB
* Full load conditions at Indoor / outdoor capacity ratio 130 %
Cooling: Indoor air temperature 32 °C DB / 22.5 °C WB , Outdoor air temperature 43 °C DB / 25.5 °C WB
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
MODEL No. Outdoor Unit SPW – C703GYH8
POWER SOURCE 380 - 400 - 415 V / 3 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 22.4 25.0
BTU / h 76,400 85,300
Air circulation (Hi) m3/min(cu. ft/min) 155 (5,470)
ELECTRICAL RATINGS
Voltage rating V 380 - 400 - 415
Available voltage range V 342 - 456
Running amperes A 15.0 - 14.4 - 14.1 13.2 - 12.7 - 12.5
Max. running amperes* A 20.6 - 19.6 - 19.2 —
Power input kW 9.23 - 9.28 - 9.34 8.15 - 8.20 - 8.25
Max. power input* kW 12.6 - 12.6 - 12.7 —
Power factor % 93 - 93 - 92 94 - 93 - 92
C.O.P W/W 2.43 - 2.41 - 2.40 3.07 - 3.05 - 3.03
Compressor locked rotor amperes A 51 - 53 - 55
FEATURES
Controls Microprocessor
Defrost control Reverse cycle, microprocessor control
Service function Sensor temp. recall function
Past service warnings recall function
Refrigerant amount at shipment kg R22 - 9.5
Refrigerant control Electronic Refrigerant Control Valve
Operation sound (Hi) dB-A 58
REFRIGERANT TUBING
Limit of tubing length m(ft.) 100 (328)
Limit of elevation difference m(ft.) Outdoor unit is higher than indoor unit : 50 (165)
between the two units Outdoor unit is lower than indoor unit : 30 (100)
Refrigerant tube Narrow tube mm (in) 12.7 ( 1 / 2 )
outer diameter Wide tube mm (in) 25.4 ( 1 )
Refrigerant tubing kit / joint kit Optional
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Unit dimensions Height mm(in) 1,218 (48 -) 1,351 (53 - 1 / 4)
Width mm(in) 883 (34 - 3 / 4) 1,047 (41 - 1 / 4)
Depth mm(in) 883 (34 - 3 / 4) 1,005 (39 - 5 / 8)
Net weight kg(lb) 219 ( 483 )
Shipping weight kg(lb) 234 ( 516 )
Shipping volume m3(Cu. ft.) 1.42 ( 50.1 )

ECO MULTI SYSTEM Unit Spesifications
SM830052
I-6
1
1. Outdoor Unit
Unit specifications (D)
MODEL No. Outdoor Unit SPW – C903GYH8
POWER SOURCE 380 - 400 - 415 V / 3 phase / 50Hz
PERFORMANCE Cooling Heating
Capacity kW 28.0 31.5
BTU / h 95,500 107,500
Air circulation (Hi) m3/min(cu. ft/min) 150 (5,300)
ELECTRICAL RATINGS
Voltage rating V 380 - 400 - 415
Available voltage range V 342 – 456
Running amperes A 17.6 - 17.1 - 16.8 15.2 - 14.8 - 14.7
Max. running amperes* A 24.2 - 23.6 - 23.1 —
Power input kW 10.9 - 11.0 - 11.1 9.38 - 9.54 - 9.70
Max. power input* kW 15.0 - 15.2 - 15.3 —
Power factor % 94 - 93 - 92 94 - 93 - 92
C.O.P. W/W 2.57 - 2.55 - 2.52 3.36 - 3.30 - 3.25
Compressor locked rotor amperes A 62 - 65 - 67
FEATURES
Controls Microprocessor
Defrost control Reverse cycle, microprocessor control
Service function Sensor temp. recall function
Past service warnings recall function
Refrigerant amount at shipment kg R22 - 11.0
Refrigerant control Electronic Refrigerant Control Valve
Operation sound (Hi) dB-A 58
REFRIGERANT TUBING
Limit of tubing length m(ft.) 100 (328)
Limit of elevation difference m(ft.) Outdoor unit is higher than indoor unit : 50 (165)
between the two units Outdoor unit is lower than indoor unit : 30 (100)
Refrigerant tube Narrow tube mm (in) 12.7 ( 1 / 2 )
outer diameter Wide tube mm (in) 28.58 (1-1 / 8 )
Refrigerant tubing kit / joint kit Optional
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Unit dimensions Height mm(in) 1,218 (48 -) 1,351 (53 - 1 / 4)
Width mm(in) 883 (34 - 3 / 4) 1,047 (41 - 1 / 4)
Depth mm(in) 883 (34 - 3 / 4) 1,005 (39 - 5 / 8)
Net weight kg(lb) 227 ( 500 )
Shipping weight kg(lb) 242 ( 534 )
Shipping volume m3(cu. ft.) 1.42 ( 50.1 )
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °C DB / 19.0 °C WB , Outdoor air temperature 35 °C DB
Heating: Indoor air temperature 20 °C DB , Outdoor air temperature 7 °C DB / 6 °C WB
* Full load conditions at Indoor / outdoor capacity ratio 130 %
Cooling: Indoor air temperature 32 °C DB / 22.5 °C WB , Outdoor air temperature 43 °C DB / 25.5 °C WB

ECO MULTI SYSTEM Unit Specifications
SM830052
I-7
1
1. Outdoor Unit
Unit specifications (E)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °C DB / 19.0 °C WB , Outdoor air temperature 35 °C DB
* Full load conditions at Indoor / outdoor capacity ratio 130 %
Cooling: Indoor air temperature 32 °C DB / 22.5 °C WB , Outdoor air temperature 43 °C DB / 25.5 °C WB
MODEL No. Outdoor Unit SPW – C703GY8
POWER SOURCE 380 - 400 - 415 V / 3 phase / 50Hz
PERFORMANCE Cooling
Capacity kW 22.4
BTU / h 76,400
Air circulation (Hi) m3/min(cu. ft/min) 155 (5,470)
ELECTRICAL RATINGS
Voltage rating V 380 - 400 - 415
Available voltage range V 342 - 456
Running amperes A 15.0 - 14.4 - 14.1
Max. running amperes* A 20.6 - 19.6 - 19.2
Power input kW 9.23 - 9.28 - 9.34
Max. power input* kW 12.6 - 12.6 - 12.7
Power factor % 93 - 93 - 92
C.O.P W/W 2.43 - 2.41 - 2.40
Compressor locked rotor amperes A 51 - 53 - 55
FEATURES
Controls Microprocessor
Defrost control Reverse cycle, microprocessor control
Service function Sensor temp. recall function
Past service warnings recall function
Refrigerant amount at shipment kg R22 - 9.5
Refrigerant control Electronic Refrigerant Control Valve
Operation sound (Hi) dB-A 58
REFRIGERANT TUBING
Limit of tubing length m(ft.) 100 (328)
Limit of elevation difference m(ft.) Outdoor unit is higher than indoor unit : 50 (165)
between the two units Outdoor unit is lower than indoor unit : 30 (100)
Refrigerant tube Narrow tube mm (in) 12.7 ( 1/ 2 )
outer diameter Wide tube mm (in) 25.4 ( 1 )
Refrigerant tubing kit / joint kit Optional
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Unit dimensions Height mm(in) 1,218 (48 ) 1,351 (53 - 1 / 4)
Width mm(in) 883 (34 - 3 / 4) 1,047 (41 - 1 / 4)
Depth mm(in) 883 (34 - 3 / 4) 1,005 (39 - 5 / 8)
Net weight kg(lb) 214 ( 472 )
Shipping weight kg(lb) 229 ( 505 )
Shipping volume m3(Cu. ft.) 1.42 ( 50.1 )

ECO MULTI SYSTEM Unit Spesifications
SM830052
I-8
1
1. Outdoor Unit
Unit specifications (F)
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
Rated conditions
Cooling: Indoor air temperature 27 °C DB / 19.0 °C WB , Outdoor air temperature 35 °C DB
* Full load conditions at Indoor / outdoor capacity ratio 130 %
Cooling: Indoor air temperature 32 °C DB / 22.5 °C WB , Outdoor air temperature 43 °C DB / 25.5 °C WB
MODEL No. Outdoor Unit SPW – C903GY8
POWER SOURCE 380 - 400 - 415 V / 3 phase / 50Hz
PERFORMANCE Cooling
Capacity kW 28.0
BTU / h 95,500
Air circulation (Hi) m3/min(cu. ft/min) 150 (5,300)
ELECTRICAL RATINGS
Voltage rating V 380 - 400 - 415
Available voltage range V 342 – 456
Running amperes A 17.6 - 17.1 - 16.8
Max. running amperes* A 24.2 - 23.6 - 23.1
Power input kW 10.9 - 11.0 - 11.1
Max. power input* kW 15.0 - 15.2 - 15.3
Power factor % 94 - 93 - 92
C.O.P. W/W 2 .57 - 2.55 - 2.52
Compressor locked rotor amperes A 62 - 65 - 67
FEATURES
Controls Microprocessor
Defrost control Reverse cycle, microprocessor control
Service function Sensor temp. recall function
Past service warnings recall function
Refrigerant amount at shipment kg R22 - 11.0
Refrigerant control Electronic Refrigerant Control Valve
Operation sound (Hi) dB-A 58
REFRIGERANT TUBING
Limit of tubing length m(ft.) 100 (328)
Limit of elevation difference m(ft.) Outdoor unit is higher than indoor unit : 50 (165)
between the two units Outdoor unit is lower than indoor unit : 30 (100)
Refrigerant tube Narrow tube mm (in) 12.7 ( 1 / 2 )
outer diameter Wide tube mm (in) 28.58 (1-1 / 8 )
Refrigerant tubing kit / joint kit Optional
DIMENSIONS & WEIGHT Unit dimensions Package dimensions
Unit dimensions Height mm(in) 1,218 (48 -) 1,351 (53 - 1 / 4)
Width mm(in) 883 (34 - 3 / 4) 1,047 (41 - 1 / 4)
Depth mm(in) 883 (34 - 3 / 4) 1,005 (39 - 5 / 8)
Net weight kg(lb) 222 ( 489 )
Shipping weight kg(lb) 237 ( 522 )
Shipping volume m3(cu. ft.) 1.42 ( 50.1 )

ECO MULTI SYSTEM Unit Specifications
SM830052
I-9
1
1-2. Major component specifications
1. Outdoor Unit
MODEL No. SPW – C483GYH8 / SPW – C483GY8
Source 380 - 400 - 415 V / 3 phase / 50Hz
Controller P.C.B. Ass’y CR - C483GYH / CR - C483GY
Control circuit fuse 250 V , 3.15 A
Compressor Rotary (Hermetic)
PC (Power Control)
Model … Code No. C-5R433H8U ... 80843688
Nominal output kW 4.3
Compressor oil (SUNISO 4GSD-T) cc 2,000
Coil resistance ΩV - U: 2.76 , U - W: 2.59
(Ambient temperature 25°C) W - V: 2.71
Safety devices
Thermal protector ON / OFF °C 120 ±5 / 98 ±11
Microprocessor safety devices Compressor current detection circuit
Compressor discharge gas temperature control
Defective and negative phase detection circuit
Voltage drop detection circuit
Crank case heater V, W 240, 32
High pressure switch ACB - 1TB07
Set pressure ON / OFF kg/cm224 ±2.0 / 30 + 2.0
Fan (Number … diameter(mm)) Propeller (2 … ø 460)
Fan motor
Model … Nominal output W KFC6T - 91C5P ×2 … 70W ×2
No. of pole … r.p.m. (230 V, High) 6 … 772 r.p.m.
Coil resistance ΩBRN - WHT : 127.3
WHT - VLT : 56.7
VLT - YEL : 15.0
(Ambient temperature 20 °C) YEL - PNK : 7.2
Safety device
Thermal protector ON / OFF °C 130 ±8 / 79 ±15
Run capacitor VAC , µF 440 V , 6 µF ×2
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … fin pitch mm 2 … 2.0
Face area m21.08
Outdoor Unit (A)
+ 0.5

ECO MULTI SYSTEM Unit Spesifications
SM830052
I-10
1
1. Outdoor Unit
1-2. Major component specifications
Outdoor Unit (B)
MODEL No. SPW – C703GYH8 / SPW – C703GY8
Source 380 - 400 - 415 V / 3 phase / 50Hz
Controller P.C.B. Ass’y CR - C703GYH / CR - C703GY
Control circuit fuse 250 V , 3.15 A
Compressor Rotary (Hermetic)
PC (Power Control) AC (Standard)
Model … Code No. C-5R373H8U ... 80837688 C-5R373H8C ... 80837588
Nominal output kW 3.75 3.75
Compressor oil (SUNISO 4GSD-T) cc 2,000 2,000
Coil resistance ΩV - U: 2.83 , U - W: 2.65 V - U: 2.83 , U - W: 2.65
(Ambient temperature 25°C) W - V: 2.78 W - V: 2.78
Safety devices
Thermal protector ON / OFF °C 120 ±5 / 98 ±11 120 ±5 / 98 ±11
Microprocessor safety devices Compressor current detection circuit
Compressor discharge gas temperature control
Defective and negative phase detection circuit
Voltage drop detection circuit
Crank case heater V, W 240 , 32 240 , 32
Fusible plug (Operating temp.) °C 73 ±2
High pressure switch ACB - 1TB04W (TUV Approved)
Set pressure ON / OFF kg/cm224 ±2.0 / 30 + 0
Fan (Number … diameter(mm)) Propeller (1 … ø 750)
Fan motor
Model … Nominal output W KFS8T - 201C3P … 200 W
No. of pole … r.p.m. (230 V, High) 8 … 567 r.p.m.
Coil resistance ΩBRN - WHT : 9.42
WHT - VLT : 4.59
VLT - YEL : 5.85
(Ambient temperature 20 °C) YEL - PNK : 3.33
Safety device
Thermal protector ON / OFF °C 125 – 15 / 130 ±5
Run capacitor VAC , µF 440 V , 15.0 µF
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … fin pitch mm 2 … 1.7
Face area m22.40
– 1. 5

ECO MULTI SYSTEM Unit Specifications
SM830052
I-11
1
1. Outdoor Unit
Outdoor Unit (C)
– 1. 5
MODEL No. SPW – C903GYH8 / SPW – C903GY8
Source 380 - 400 - 415 V / 3 phase / 50Hz
Controller P.C.B. Ass’y CR - C703GYH / CR - C703GY
Control circuit fuse 250 V , 3.15 A
Compressor Rotary (Hermetic)
PC (Power Control) AC (Standard)
Model … Code No. C-5R433H8U ... 80843688 C-5R433H8A ... 80843588
Nominal output kW 4.3 4.3
Compressor oil (SUNISO 4GSD-T) cc 2,000 2,000
Coil resistance ΩV - U: 2.76 , U - W: 2.59 V - U: 2.76 , U - W: 2.59
(Ambient temperature 25°C) W - V: 2.71 W - V: 2.71
Safety devices
Thermal protector ON / OFF °C 120 ±5 / 98 ±11 120 ±5 / 98 ±11
Microprocessor safety devices Compressor current detection circuit
Compressor discharge gas temperature control
Defective and negative phase detection circuit
Voltage drop detection circuit
Crank case heater V, W 240 , 32 240 , 32
Fusible plug (Operating temp.) °C 73 ±2
High pressure switch ACB - 1TB04W (TUV Approved)
Set pressure ON / OFF kg/cm224 ±2.0 / 30 + 0
Fan (Number … diameter(mm)) Propeller (1 … ø 750)
Fan motor
Model … Nominal output W KFS8T - 201C3P … 200W
No. of pole … r.p.m. (230 V, High) 8 … 567 r.p.m.
Coil resistance ΩBRN - WHT : 9.42
WHT - VLT : 4.59
VLT - YEL : 5.85
(Ambient temperature 20 °C) YEL - PNK : 3.33
Safety device
Thermal protector ON / OFF °C 125 – 15 / 130 ±5
Run capacitor VAC , µF 440 V , 15.0 µF
Heat exchanger
Coil Aluminum plate fin / Copper tube
Rows … fin pitch mm 2 … 1.7
Face area m22.40

ECO MULTI SYSTEM Unit Spesifications
SM830052
I-12
1
1. Outdoor Unit
1-3. Control specifications
*: Only for heat pump type.
SPW – C483GYH8 / SPW – C483GY8
MODEL No. Outdoor Unit SPW – C703GYH8 / SPW – C703GY8
SPW – C903GYH8 / SPW – C903GY8
Available Cooling 18 – 30 °C
Thermostat Setting temp. Dry 18 – 30 °C
Heating 16 – 26 °C
Operation mode HEAT* • DRY • COOL • FAN
Mode setting Fan speed Auto • Hi • Med • Lo
Timer ON • OFF • (Max. 72 hour)
Auto. flap Fan Aim / Sweep
Serial communication E1 – E 7
Improper address setting & others E8 – E18
Alarm message Activation of protective device P1 – P17
Thermistor failure F1 – F 9
Fault with comp. & its circuit H1 – H12
Compressor contactor (Mg SW) abnormal H9 & H19
* Cold draft prevention
Timer –
Indoor unit coil temp. E2 < 27 °C
Defrosting control* Reverse cycle, microprocessor control
Service function Sensor temp. recall function
Past service warnings recall function (Max. 4 alarms)
System control Multiple remote control Max. 2 controllers (Main : 1, Sub: 1)
Group control Simultaneous operation Max. 8 units
Automatic restart after power interruption
Test run function (built in 60 min. timer)

ECO MULTI SYSTEM Unit Specifications
SM830052
I-13
1
1-4. Other component specifications
1. Outdoor Unit
MODEL No. Outdoor Unit SPW – C483GYH8 / SPW – C483GY8
Power Transformer ATR-195, CL-4
Thermostat Available Cooling 18 – 30 °C
(Option) setting temp. Dry 18 – 30 °C
Heating 16 – 26 °C
Thermistor (Coil sensor) PBC-41E-S36
Coil resistance KΩ–10 ˚C : 23.7 ±5 % , 20 ˚C : 6.5 ±5 %
–5 ˚C : 18.8 ±5 % , 30 ˚C : 4.4 ±5 %
0 ˚C : 15.0 ±5 % , 40 ˚C : 3.1 ±5 %
5 ˚C : 12.1 ±5 % , 45 ˚C : 2.6 ±5 %
10 ˚C : 9.7 ±5 %
Thermistor (Discharge gas sensor PTC-51H
or coil sensor)
Coil resistance KΩ60 ˚C : 13.8 ±5 % , 90 ˚C : 5.1 ±5 %
70 ˚C : 9.7 ±5 % , 100 ˚C : 3.8 ±5 %
75 ˚C : 8.2 ±5 % , 110 ˚C : 2.8 ±5 %
80 ˚C : 7.0 ±5 % , 120 ˚C : 2.2 ±5 %
85 ˚C : 5.9 ±5 % , 130 ˚C : 1.7 ±5 %
Relay FMCA-1SZ607
Coil rated V AC 220 V - 240 V
Contact rating V.A AC 440 V, 13 A
Coil Resistance (at 25 ˚C) kΩ—
Solenoid control valve or coil
Solenoid control valve NEV603DXFa19 / NEV202DXFa19
Solenoid coil NEV-MOAJ50B0
Reversing valve or coil (only heat pump type)
Reversing valve CHV-0401
Solenoid coil CHV-01AJ504D1

ECO MULTI SYSTEM Unit Spesifications
SM830052
I-14
1
Other component specifications
1. Outdoor Unit
MODEL No. Outdoor Unit SPW – C703GYH8 / SPW – C703GY8
SPW – C903GYH8 / SPW – C903GY8
Power Transformer ATR-II45, CT CL-3
Thermostat Available Cooling 18 – 30 °C
(Option) setting temp. Dry 18 – 30 °C
Heating 16 – 26 °C
Thermistor (Coil sensor) PBC-41E-S36
Coil resistance KΩ–10 ˚C : 23.7 ±5 % , 20 ˚C : 6.5 ±5 %
–5 ˚C : 18.8 ±5 % , 30 ˚C : 4.4 ±5 %
0 ˚C : 15.0 ±5 % , 40 ˚C : 3.1 ±5 %
5 ˚C : 12.1 ±5 % , 45 ˚C : 2.6 ±5 %
10 ˚C : 9.7 ±5 %
Thermistor (Discharge gas sensor PTC-51H
or coil sensor)
Coil resistance KΩ60 ˚C : 13.8 ±5 % , 90 ˚C : 5.1 ±5 %
70 ˚C : 9.7 ±5 % , 100 ˚C : 3.8 ±5 %
75 ˚C : 8.2 ±5 % , 110 ˚C : 2.8 ±5 %
80 ˚C : 7.0 ±5 % , 120 ˚C : 2.2 ±5 %
85 ˚C : 5.9 ±5 % , 130 ˚C : 1.7 ±5 %
Relay HH62S / 085
Coil rated V AC 220 V - 240 V
Contact rating V.A AC 250 V, 5 A
Coil Resistance (at 25 ˚C) kΩ17.2 ±10 %
Solenoid control valve or coil
Solenoid control valve NEV603DXFa19 / NEV202DXFa19
Solenoid coil NEV-MOAJ504B0
Reversing valve or coil (only heat pump type)
Reversing valve VH 60100
Solenoid coil LB 60012
