Sanyo N-1000SCR Cadnica User manual

Typical Characteristics
Specifications
Cell Type N-1000SCR
Dimensions
of
Bare Cell
H33.0 ±0.3 mm
1.299 ±0.012 inch
D22.0 ±0.3 mm
0.866 ±0.012 inch
d10.0 mm
0.394 inch
D
d
H
Nominal Capacity 1000mAh
Nominal Voltage 1.2V
Charging Current
Standard 100mA
Quick 300mA
Fast 1500mA
Charging Time
Standard 14 to 16Hrs.
Quick 4 to 6Hrs.
Fast about 1Hr.
Ambient
Temperature
Charge
Standard 0°C to +45°C [+32°F to 113°F]
Quick 10°C to +45°C [+50°F to 113°F]
Fast 5°C to +40°C [+41°F to 104°F]
Discharge -20°C to +60°C [ -4°F to 140°F]
Storage -30°C to +50°C [ -22°F to 122°F]
Internal Impedance (Av.)
(at. 50% discharge)
4.5mΩ
(at 1000Hz)
Weight 41g/1.45oz
Dimensions(D)×(H)
(with tube)
Charge (5 cells pack)
7.0
7.5
8.0
0
0
20
40
60
10 20 30 40 50 60 70 80
Charge : 1.5A to 45˚C/113˚F
Battery Voltage (V)
Battery Temperature (˚C)
Charge Time (Mins)
Cell Capacity (at various discharge rate)
100
80
60
40
90
70
50
012345678
Charge : 1.5A to 45˚C/113˚F
Discharge : End Volt 1.0V
at 20˚C/68˚F
Available Capacity (%)
Discharge Rate (It)
Discharge (at low rate)
1.4
1.2
1.0
0.8
0246810121416
at 20˚C/68˚F
(0.1 It)(0.2 It)(0.5 It)
Cell Voltage (V)
Discharge Time (Hrs.)
Charge : 1.5A to 45˚C/113˚F
Discharge (at high rate)
1.4
1.2
1.0
0.8
0 1020304050607080
at 20˚C/68˚F
(2 It) (1 It)
Cell Voltage (V)
Discharge Time (Mins)
Charge : 1.5A to 45˚C/113˚F
Discharge (at high rate)
1.4
1.2
1.0
0.8
0246810121416
at 20˚C/68˚F
(4 It)(8 It)
Cell Voltage (V)
Discharge Time (Mins)
Charge : 1.5A to 45˚C/113˚F
Temperature (Charge & Discharge)
100
80
60
40
-20-100 102030405060˚C
-4 14 32 50 68 86 104 122 140˚F
Available Capacity (%)
Operating Temperature
90
70
50
Charge Characteristics
Discharge Characteristics
Condition Charge : 1.5A to 45˚C/113˚F
Discharge : 200mA
(End Volt 1.0V)
22.9 0× 34.0 0mm
-1 -1.2
0.90 0× 1.34 0inch
-0.04 -0.05
CD010830
