Sanyo FXD-780GD User manual

FXD-780GD
FM /AM CD RECEIVER FXD-780GD 50W x 4
123456
AUDIO
MUTE
VOL
RPTSHF
REL
LOUD
LO/DX
BAS-X
ATP
TUNTUN
TRKTRK
POWER
Full Panel Detachable
High Power FM/AM Stereo Receiver
Compact Disc Player
ISO Mounting with Removable Trim Ring
OPERATING INSTRUCTIONS ................. 1-18
FXD-780GD_Cover 03/04/2002, 04:46 pm1

1
CONTENTS
COMPACT DISC CARE ........................................................................................................................... 2
DIGITAL DISPLAY .................................................................................................................................... 3
DETACHABLE FRONT PANEL ................................................................................................................ 4
GENERAL OPERATION .......................................................................................................................... 5
RADIO OPERATION ................................................................................................................................ 8
CD OPERATION ..................................................................................................................................... 10
ERROR SIGNS ...................................................................................................................................... 12
HINTS FOR PROPER AND SAFE OPERATION ................................................................................... 13
TROUBLESHOOTING ........................................................................................................................... 14
ACCESSORIES AND HARDWARE ....................................................................................................... 15
INSTALLATION ....................................................................................................................................... 15
UNIT REMOVAL ..................................................................................................................................... 16
ELECTRICAL CONNECTIONS .............................................................................................................. 17
LINE OUT CONNECTIONS ................................................................................................................... 18
CAUTION
• This unit is designed to operate on 12 volts DC, NEGATIVE ground electrical systems only.
• When fuse replacement is necessary, use only a 10 amp fuse. Do not replace with a higher rated fuse. If
the fuse blows often, carefully check all electrical connections for any short circuits and have your car’s
voltage regulator checked also.
• Do not install the unit where it will be exposed to direct sunlight or hot air discharged from the car heater.
• Do not expose the unit to water or moisture.
• To avoid damaging the unit, never insert anything other than a compact disc into the disc slot.
• This unit should not be adjusted or repaired by anyone except qualified service personnel.
If servicing is required, return the unit to an authorized SANYO mobile audio dealer.
• Use the Controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
• Changes or modifications not expressly approved by Sanyo may void the user’s authority to operate this
equipment.
FXD-780GD_Ebody 03/04/2002, 04:44 pm1

2
•To prevent warping the disc, do not expose
it to direct sunlight, high humidity or high
temperatures for extended periods of time.
•Fingerprints and dust should be carefully
wiped off the signal surface of the disc
(glossy side) with a soft cloth.
Wipe in a straight motion from the inside to
the outside of the disc. Unlike conventional
records, the compact disc has no grooves to
collect dust and debris. Small dust particles
will have no effect on reproduction quality.
•Do not insert a disc which is cracked into
the unit.
•Do not apply paper or write anything on the
surface of the disc.
•Do not use non-conventional discs such as
heart- shaped, octagonal discs, etc.
The player could be damaged.
Benzene Thinner Cleaning spray
•Never use chemicals such as record clean-
ing sprays, antistatic sprays or fluids, ben-
zene or thinner to clean compact discs.
These chemicals will permanently damage
the plastic surface of the disc.
• When not using the disc player for extended
periods of time, remove the compact disc and
return it to the plastic storage case. This will pro-
tect the disc from dust and exposure to the sun.
•This unit has been designed to play com-
pact discs bearing the identification logo
shown on the left. No other discs can be
played.
COMPACT DISC CARE
Dirt, dust, scratches and warpage can cause a deterioration in the sound or intermittent skipping some
tracks during play.
Recommended CD-R Media
Data may not be properly written to CD-R media depending on the quality of the media. If
this happenes, the data may not be reproduced correctly. We recommend the following
manufacturers to insure proper quality of the media:
CD-R Media
TDK USA Corp., Taiyo Yuden (U.S.A.), Inc., Ricoh Corporation, Eastman Kodak Company,
Maxell Corporation of America, Mitsubishi Chemical Corporation, Fuji Photo Film U.S.A.,
Inc., Mitsui Chemicals, Inc., Sony Corporation of America, Philips Electronics North America
Corporation, Imation Corp.
Additionally, CD-R media compatible with various speeds such as 2X and 1X-4X are available.
Please refer to the instruction manuals of the drive and the recording software you are using to
insure selection of the correct media.
FXD-780GD_Ebody 03/04/2002, 04:44 pm2

3
DIGITAL DISPLAY
Radio Frequency, Time,
CD Track Number, Audio
Control Selected Mode
Audio Position
Shuffle Play
Repeat Play
Scan
AM Bands
FM Bands
Loudness
CD Mode
(Disc IN)
Preset No.
Track No.
Mute
Volume/Audio
Control Level
Indicator
FM Stereo
Local/DX
BASS
TREBLE
BAS-X
Disc IN
indicator
Radio Preset Chan-
nel Number,
Track Number Manual Tuning
FXD-780GD_Ebody 03/04/2002, 04:44 pm3

4
DETACHABLE FRONT PANEL
The front panel is designed to be removable for antitheft purposes.
It is recommended that you remove and carry the front panel with you when you leave your car.
HOW TO ATTACH THE FRONT PANEL
Align the right side of the panel with the stopper, and then push the
left side of the panel into the unit until it clicks.
HOW TO DETACH THE FRONT PANEL
Press the release button (REL) to release the front panel.
Pull the entire panel to remove it from the unit.
RETURNING TO THE INITIAL SETTINGS
When the eject button is pressed for more than 10 seconds, the mi-
crocomputer of the unit returns to the initial settings. If the display
window is not properly shown or the unit malfunctions, press the eject
button for more than 10 seconds.
Note
The unit will not operate if it is installed incorrectly.
CAUTION
•Do not attempt to remove the panel in a manner other than that described
above.
•When installing the panel, do not force it into the unit.
•Do not touch the connection terminals of the panel or the unit. It may
cause poor contact.
•Use a clean, dry cloth when cleaning the terminals.
•Keep the panel out of direct sunlight and high temperatures.
•Prevent the panel from coming into contact with benzene, thinner, or in-
secticides.
•Do not drop the panel.
123456
RPTSHF
FXD-780GD_Ebody 03/04/2002, 04:44 pm4

5
GENERAL OPERATION
FM /AM CD RECEIVER FXD-780GD 50W x 4
123456
AUDIO
MUTE
VOL
RPTSHF
REL
LOUD
LO/DX
BAS-X
ATP
TUNTUN
TRKTRK
POWER
TURNING THE POWER ON......................................1
Install the front panel and press the POWER MUTE button 1 when ACC is on.
TURNING THE POWER OFF ............................................................. 1
Press the POWER MUTE button for more than 2 seconds. Display will revert to clock indication.
VOLUME LEVEL CONTROL.......................................2
Rotate the VOL dial 2 to adjust the volume level.
MUTING THE SOUND .......................................................................... 1
Press the POWER MUTE button 1 while the receiver is on. While muting the sound, the MUTE indicator
on the display is blinking. To restore the previous volume level, press POWER MUTE button 1
again.
SETTING THE CLOCK..............................................3
The clock uses a 24-hour display system.
1. Press the DISP button 3 for more than 2 seconds.
2. Press the following buttons to set the clock.
VOL dial 2 : Adjust the hour and minutes.
: To activate Hour blink.
: To activate Minute blink.
BAND ATP 8 : Adjust the minutes to zero.
(Example) 12:29 →12:00
12:30 →13:00
3. Press the DISP button 3 to activate the clock.
32
14657
8
FXD-780GD_Ebody 03/04/2002, 04:44 pm5

6
ADJUSTING THE SOUND
CHARACTERISTICS ..............................................4,2
1. Each time you press the AUDIO button 4 until the desired mode is displayed.
2. Rotate the VOL dial 2 to adjust the selected item. Make the adjustment within 5 seconds after selecting.
After 5 seconds, the display window will revert to display priority.
•El LE(medidor de nivel) puede seleccionarse entre Hi (alta sensibilidad), Lo (sensibilidad normal), y OFF
(sin indicación).
•MUTE LEVEL controla el nivel de volumen aplicado cuando se silencia el sonido. Podráajustar el nivel
en el que se reduce el volumen desde el nivel de volumen anterior.
Adjustment Range
BASS BASS –5 BASS +5
TREBLE TREB –5 TREB +5
BAL L9 (Full left) R9 (Full right)
FAD F9 (Full front) R9 (Full rear)
LE(Level Meter) Hi Lo OFF
MUTE LEVEL –0 –20 –80
LOUDNESS EFFECT ......................................................................... 5
When listening to music at low volume levels, this feature will boost the extremes of the bass and treble
ranges to compensate for the negative characteristics of human hearing.
Press the LOUD LO/DX button 5. The “LOUD”indicator appears in the display window.
Pressing the button again will cancel this feature.
LOCAL/DISTANT (LO/DX) SELECTION ........................................... 5
This feature is used to select the strength of the signals at which the radio will stop during Automatic
Tuning. Press the LOUD LO/DX button 5 for more than 2 seconds to select the Local (LO) setting and only
the strongest (local) stations will be received. The “LOC”indicator appears in the display window.
Pressing again for 2 seconds will select the Distant setting and the radio will stop at a wider range of
signals, including weaker more distant stations. The “LOC”indicator will go out on the display window.
ENHANCING THE BASS SOUND (BAS-X)....................................... 7
Press the BAS-X button 7 to display the BAS-X INDICATOR ( ) on the display window.
Each time you press the BAS-X button 7, current mode appears on the display window and the mode
change as follows.
Note
Settings for BASS, TREBLE, LOUDNESS and BAS-X can be made to each of
the following modes independently: FM, AM, and CD.
BAS-X 0 (No BASS enhanced)
BAS-X 1 (Enhanced BASS level : LOW)
BAS-X 2 (Enhanced BASS level : Middle)
BAS-X 3 (Enhanced BASS level : High)
(No display)
BAS-X 4 (Enhanced BASS level : Very high)
FXD-780GD_Ebody 03/04/2002, 04:44 pm6

7
ADJUSTING THE SOUND STAGE .............................6
You can adjust the position of sound stage to best serve a particular seat.
TO MEMORY THE SOUND STAGE ................................................... 6
1. Adjust the BALANCE or FADER.
2. Press the appropriate Preset buttons 6 for more than 2 seconds. The Audio position indicator blinks
and adjusted sound stage is stored.
TO CALL THE SOUND STAGE ......................................................... 6
Press the appropriate Preset buttons 6 to call the desired sound stage during the BALANCE or FADER
adjustment mode. The Preset buttons are factory-set to the following conditions.
BALANCE FADER
P 1 1: For the left seat ( L0R2 ) ( R4F0 )
P 2
2
: For the front seat ( L0R0 ) ( R4F0 )
P 3
3
: For the right seat ( L2R0 ) ( R4F0 )
P 4
4/SHF
: For the rear seat ( L0R0 ) ( R0F4 )
P 5
5/RPT
: For all the seat ( L0R0 ) ( R0F0 )
Each time you press the preset buttons in the BALANCE or FADER adjustment mode, the audio position
indicator changes as follows ;
12 3 4/SHF 5/RPT
SWITCHING THE DISPLAY ........................................3
Each time you press the DISP button 3, the display window will change as shown below ;
• Radio mode
Frequency and Clock
• CD mode
Elapsed track time and Clock
IGNITION-OFF CLOCK RECALL .............................3
Press the DISP button 3 while the ignition switch is in the “OFF”position.
The display will illuminate showing the time and then automatically shut off after 5 seconds.
FXD-780GD_Ebody 03/04/2002, 04:45 pm7

8
RADIO OPERATION
FM /AM CD RECEIVER FXD-780GD 50W x 4
123456
AUDIO
MUTE
VOL
RPTSHF
REL
LOUD
LO/DX
BAS-X
ATP
TUNTUN
TRKTRK
POWER
SELECTING RADIO MODE
Press the BAND ATP button 1 to switch from CD mode to the radio mode.
Each time the BAND ATP button 1 is pressed, the selected band changes as shown below.
FM I ➔ FM II ➔ FM III ➔ AM I ➔ AM II
RADIO TUNING .................................................................................. 2
•Automatic tuning ............. Press the TUN/TRK or Button 2.
When the button is pressed, the system will start automatic tuning and stop at
the next receivable station.
•Manual tuning ................. To select higher frequency station, press the button for more than 0.5 sec-
onds. The “MANU”indicator appears in the display window. To select lower
frequency stations, press the button for more than 0.5 seconds. To quickly
scan up or down in frequency, press and hold the TUN/TRK or button.
Release the button when the display approaches the desired frequency, then
press and release the button repeatedly until the desired frequency is dis-
played. After 4 seconds of completing Manual Tuning, the tuning control will
revert to the Automatic Tuning mode.
STORING PRESET STATIONS .......................................................... 3
The preset buttons 3 can be used to store 6 stations in each band (FM I, FM II, FM III and AM I, AM II) for
convenient access to your favorite stations.
•Programming stations ..... 1. Select the desired band, then tune in the station you want to store in memory.
2. Press and hold one of the preset buttons for more than 2 seconds until the
frequency indicator flashes twice. Repeat steps 1. and 2. to program addi-
tional stations.
•Quick tuning .................... Select the desired band, then press one of the six preset buttons.
14
32
FXD-780GD_Ebody 03/04/2002, 04:45 pm8

9
ATP (AUTO TRAVEL PRESET) OPERATION ................................... 1
The Auto Travel Preset function searches for and memorizes the 6 strong stations in one of the two bands
(FM III, AM II).
This feature is useful when you are driving in an unfamiliar location and want to memorize local stations
without changing the standard preset stations.
A total of 12 stations (6 FM and 6 AM) can be programmed.
•To set the stations .................... Select the desired band. Press and hold the BAND ATP button 1 for
more than 2 seconds.
•Quick tuning of ATP stations ..... Select the desired band, then press one of the six preset buttons.
Note
This function is available for FM III and AM II.
SCAN OPERATION ............................................................................ 4
1. Press the BAND ATP button 1 to select the desired band.
2. Press the SCAN button 4. The system will select and receive each station for 10 seconds.
3. To stop scanning and retain the station currently selected, press the SCAN button 4 again.
PRESET SCAN OPERATION .............................................................. 4
This function scans each of the preset stations stored in the selected band (both manual preset and auto
travel presets).
1. Press the BAND ATP button 1 to select the desired band.
2. Press the SCAN button 4 for more than two seconds. The system will select and receive each preset
station for 10 seconds.
3. To stop scanning and retain the station currently selected, press the SCAN button 4 again.
FXD-780GD_Ebody 03/04/2002, 04:45 pm9

10
CD OPERATION
You can play CD-Rs (recordable CDs) designed for audio use on this unit.
You cannot play 3-inch CDs.
FM /AM CD RECEIVER FXD-780GD 50W x 4
123456
AUDIO
MUTE
VOL
RPTSHF
REL
LOUD
LO/DX
BAS-X
ATP
TUNTUN
TRKTRK
POWER
LOADING AND EJECTING THE CD
Insert a disc into the CD slot 1 and the CD player will start.
The system remains in CD mode and “”appears in the display.
Press the eject button 2 to eject a disc.
SWITCHING TO CD MODE ................................................................ 3
Press the CD button 3 with the power on to switch from radio mode to CD mode.
When the CD mode is switched on while a disc is loaded, play resumes from the point at which play was
stopped.
When the entire disc has played, the unit returns to the first track and play resumes.
The CD player continues playing the disc until the BAND ATP button is pressed, or the disc is ejected.
SKIPPING TRACKS ........................................................................... 4
Press the TUN/TRK button 4 to skip to the beginning of the next track.
Press the TUN/TRK button 4 to skip to the beginning of the track currently playing.
Press the TUN/TRK button 4 twice to skip to the beginning of the previous track.
Press and hold the TUN/TRK or button 4 for more than 0.5 seconds to search quickly (with sound) in
the forward or reverse direction.
When the button is released, the CD resumes normal play.
Notes
• Some CD-Rs (depending on the equipment used for its recording or the con-
dition of the disc) may not play on this unit.
• You cannot play CD-R that is not finalized.(A finalize process necessary for a
recorded CD-R disc to be played on the audio CD player.)
• You cannot play CD-RWs (rewritable CDs) on this unit.
12
4
5
6
7
8
3
FXD-780GD_Ebody 03/04/2002, 04:45 pm10

11
PLACING THE CD IN PAUSE MODE ................................................ 5
While playing a CD, press the Preset 6 button 5.
To resume playing, press the Preset 6 button again.
Note
The unit will turn-on automatically when a CD is inserted if the ignition switch is
“ON”.
REPEAT MODE .................................................................................. 6
Press the Preset 5 (RPT) button 6 to play the current track repeatedly.
The “RPT”indicator appears in the display window.
To cancel this mode, press the Preset 5 (RPT) button 6 again.
SHUFFLE MODE ................................................................................ 7
This function plays the tracks on a CD in random order.
Press the Preset 4 (SHF) button 7 to begin shuffle play.
The “SHF”indicator appears in the display window.
Press the button 7 to select another random track.
To cancel this mode, press the Preset 4 (SHF) button 7 again.
SCAN MODE (PLAYING THE BEGINNING
OF EACH TRACK) ............................................................................. 8
This function plays the first 10 seconds of each track sequentially.
Press the SCAN button 8 to begin the scan mode.
The “SCAN”indicator appears in the display window.
To cancel this mode, press the SCAN button 8 again.
FXD-780GD_Ebody 03/04/2002, 04:45 pm11

12
ERROR SIGNS
If a problem should occur while operating the CD player, one of the following error signs may be displayed.
Refer to the table below to identify the problem, then take the suggested corrective action. If the error
persists, contact your nearest dealer.
Message Cause Remedy
Dirty disc. Clean the disc.
Scratched disc. Replace the disc.
Up-side-down. Check the disc.
Focus error. Try ejecting and re-inserting
Up-side-down. under normal temperature
conditions.
Data and focus error, Under normal temperature
conditions, eject and insert
clean, undamaged disc
properly.
Mechanical problem. Eject and re-insert.
FXD-780GD_Ebody 03/04/2002, 04:45 pm12

13
HINTS FOR PROPER AND SAFE OPERATION
•Condensation
Moisture can condense on the optical lens of the CD player during humid or rainy days, or after the car
heater is turned on. If this occurs the disc player may not function properly. To remedy the situation,
remove the disc from the unit and wait approximately one hour. This should allow the moisture to evapo-
rate and restore normal operation.
•Temperature Consideration
The unit may not operate correctly in extremely hot or cold temperatures. Avoid exposing the unit to
extremely high or low temperatures.
•Interruptions in the sound (skipping)
When the car is driven on very rough surfaces, the sound from the CD player may skip and be inter-
rupted. This will not cause any damage to the disc or the player. If this occurs, wait for the road surface
to improve before using the CD player.
•Safety
For safer driving, keep the volume at a moderate level to enable you to hear outside sounds (such as
emergency vehicle sirens).
•Cleaning the unit
Clean the unit with a soft, dry cloth. Stains should be removed by wiping the surfaces with a soft cloth
immersed in lukewarm water and wrung dry. Never use strong chemicals or solvents. These will damage
the finish of the unit.
If the connectors of the unit and front panel are contaminated, malfunctions may occur. Detach the front
panel and clean the connectors with an alcohol dampened cotton swab.
•Disc care
When not using the disc player for extended periods, remove the compact disc and return it to the plastic
storage case. Do not leave a disc partially ejected from the player. If an ejected disc remains in the
loading slot for approximately 10 seconds, the player will reload the disc to prevent damage.
•Servicing
Should a problem develop, do not open the unit or try to repair it yourself. If servicing is required, bring
the unit to a Sanyo Authorized Service Center.
FXD-780GD_Ebody 03/04/2002, 04:45 pm13

14
TROUBLESHOOTING
Sometimes a simple operational error or a mistake in the wiring can appear to be a problem with the unit.
Before having the unit serviced, refer to the troubleshooting chart below.
The compact disc does not
play when inserted into the
unit.
No power.
The unit does not work prop-
erly (Eject, Load, Play)
The sound from the CD player
skips.
No radio reception.
The radio does not stop on
any stations when automatic
tuning is used.
The volume control is turned
down.
The power connections are
not wired correctly.
The vehicle ignition is
switched off.
The fuse is blown.
The microcomputer has been
affected by electrical noise.
The road surface is rough.
The unit is not mounted se-
curely.
The disc is defective.
The disc is dirty.
The antenna cable is not con-
nected.
The signal are weak.
Turn up the volume control.
Check the +12V and ground
connections.
Switch the ignition to the “ON”
or “ACC”position.
Replace the fuse with another
10A fuse.
Eject the disc, then insert it
again.
Wait for the road surface to im-
prove before playing a disc.
Install the unit securely. Be sure
to use the rear strap if the vehi-
cle does not provide support for
the rear of the unit. (See page
@)
Try another disc.
If it plays properly, the first disc
may be defective.
Clean the disc as explained on
page 2.
Insert the antenna cable firmly
into the antenna jack on the
unit.
Select a station using manual
tuning.
Symptom Cause Solution
FXD-780GD_Ebody 03/04/2002, 04:45 pm14

15
ACCESSORIES AND HARDWARE
INSTALLATION
Mounting Bracket Bushing & Screw Mounting Strap Locking Screw
(Half Sleeve)×1 × 1 and Screws × 1× 1
Removable Trim Ring Unlock Levers
×1 ×2
INSTALLATION
1. BEFORE INSTALLATION
When mounting the unit in a car, keep the unit as level as possible.
If the unit must be mounted at an angle, due to the design of the vehicle, make sure the unit does not tilt by
more than 30°.
max. 30°
FXD-780GD_Ebody 03/04/2002, 04:45 pm15

16
FIRE WALL
DASH BOARD
OR CONSOLE Mounting
Bracket
Removable
Trim Ring
Mounting Strap Screw
Bushing
2. INSTALLATION PROCEDURES
MOUNTING STRAP USE BUSHING USE
When mounting the unit into a DIN–standard cutout (182 ×53 mm) in the dashboard or console, attach the
provided Removable Trim Ring to the unit.
1. Insert the mounting bracket into the DIN-standard cutout (182 ×53 mm) in the dashboard or console.
2. Bend the mounting bracket stopper outward until the bracket fits snugly in the cutout.
Mounting Strap Use
3. Attaching the Mounting Strap to the underside of the dash board, using screw. Attach the back of the
unit to the Mounting Strap using support stem bolt and hardware.
Bushing Use
3. As shown in the figure above, securely fasten the screw, which has been inserted into the bush, to the
rear of the unit.
UNIT REMOVAL
1. Insert the unlock levers into the slots on each side of the unit until they click into place.
2. Pull the levers to remove the unit.
Notes
•Handle the unlock levers carefully to avoid injuring your fingers.
•Keep the unlock levers in a safe place for future use.
FXD-780GD_Ebody 03/04/2002, 04:45 pm16

17
ELECTRICAL CONNECTIONS
WIRING
(White)
(White/Black)
(Gray)
(Gray/Black)
(Green)
(Green/Black)
(Violet
(Violet/Black)
Left
Speaker
Right
Speaker
Do Not
Connect
Front Left
Speaker
Front Right
Speaker
Rear Left
Speaker
Rear Right
Speaker
(White)
(White/Black)
(Gray)
(Gray/Black)
(Green)
(Green/Black)
(Violet
(Violet/Black) Do Not
Connect
2-speaker System4-speaker System
+12V Constant Power Supply (Yellow)
+12V Accessory/Switched (Red)
Ground Wire (Black)
Power Antenna/Amplifier Turn On (Blue)
ANTENNA PLUG
ANTENNA SOCKET
In the case of a 2-speaker system,
tape the ends of unconnected
terminals to prevent short circuit
CAUTION
•DO NOT connect any speaker wires to the metal body or chassis of the vehicle.
•DO NOT connect the speaker common (–) wires to each other.
•Connect each speaker wire directly to each speaker terminal.
•All speaker common (–) wires must remain floating.
1Antenna socket
•Insert the plug from the antenna installed in your vehicle into this socket. (If your vehicle has a dual
antenna system, a dual antenna to single antenna cable adaptor may be required.)
2+ 12V Constant Power Supply (Yellow)
•Connect this wire to the +12V power terminal which receives power continuously.
3+12V Accessory/Switched (Red)
•Connect this wire to the terminal which receives power while the ignition switch is ON or in the ACCES-
SORY position.
•If the ignition switch does not have on ACC position, connect this wire to a +12V power terminal which
receives power continuously. (Same as item 2.)
4Ground wire (Black)
•Connect this wire to the vehicle chassis.
5Power Antenna/Amplifier Turn On (Blue)
•Connect this wire to the control terminal of a Power Antenna or an external amplifier.
•When not using a Power Antenna or an external amplifier, this wire is not connected.
FXD-780GD_Ebody 03/04/2002, 04:45 pm17

18
Notes
•When using a two-speaker installation, the Green, Green/Black, Violet, Vio-
let/Black wires, which are used for a four-speaker installation, are not used.
The ends of these wires must be covered with electrical tape to prevent them
from shorting to the unit or the vehicle chassis.
•When using a two-speaker installation, set the FADER control to the center
position.
REPLACING THE FUSE
When fuse replacement is necessary remove the blown fuse
by using pliers. Then install the new 10 amp. fuse.
LINE OUT CONNECTIONS
•The unit has a line out terminals. You can use a separate rear channel amplifier to upgrade your system.
External Amplifier
Rear Speaker
White (Left)
Red (Right)
RCA Line-out Jacks
RCA Line- out Jacks (For Rear Speakers)
•Connect a patch cable (not supplied) from the White (left rear channel) and Red (right rear channel) RCA
line output jacks to the line input terminals of the external amplifier.
FXD-780GD_Ebody 03/04/2002, 04:45 pm18

SANYO Electric Co., Ltd.
Printed in Singapore
Issue date 04-02
288F0530
FXD-780GD_Cover 03/04/2002, 04:46 pm2
