Sanyo T1443 - ECD Radio / CD User manual

Mobile Audio System
• PLL Synthesizer Stereo Radio
• Digital Compact Disc Player
• Automatic Memory Storing
• Fold Down Full Detachable Panel
• Preset Equalization
• Full Function IR Remote Control
• AV / Auxiliary Input
• Plays MP3 CD-R/RW discs
ECD-T1443
OWNER'S
MANUAL

2
Installation .....................................................................................................3
DIN Front-Mount (Method A) ..................................................................................3
Installing the unit ...............................................................................................3
Removing the unit .............................................................................................4
DIN Rear-Mount (Method B) ...................................................................................4
Using the Detachable Front Panel..........................................................................5
Wiring Connection ........................................................................................6
4 x 40W System......................................................................................................6
Operation .......................................................................................................7
General Operation ..................................................................................................7
Radio Operation......................................................................................................8
CD Operation..........................................................................................................9
MP3 Operation .....................................................................................................10
Remote Control Handset .....................................................................................12
Specification................................................................................................13
Trouble Shooting.........................................................................................14
CONTENTS

3
Notes:
• Choose the mounting location where
the unit will not interfere with the
normal activity of the driver.
• Before finally installing the unit,
connect the wiring temporarily and
make sure it is all connected up
properly. Test to see if the system is
working properly.
• Use only the parts included with the
unit to ensure proper installation.
The use of unauthorized parts can
cause malfunctions.
• Consult with your nearest dealer if
installation requires the drilling of holes
or other modifications of the vehicle.
• Install the unit where it does not get in
the driver’s way and cannot injure the
passenger if there is a sudden stop.
• If installation angle exceeds 30˚ from
horizontal, the unit might not give its
optimum performance.
• Avoid installing the unit where it would
be subject to high temperature, such
as direct sunlight, hot air from the
heater, or where it would be subject to
dust, dirt, or excessive vibration.
DIN FRONT/REAR-MOUNT
This unit can be properly installed either
from “Front” (conventional DIN Front-
mount) or “Rear” (DIN Rear-mount
installation, utilizing threaded screw holes
at the sides of the unit chassis).
For details, refer to the following
illustrated installation methods.
DIN FRONT-MOUNT (Method A)
Installing the unit
1. Dashboard
2. Holder
After inserting the holder into the
dashboard, select the appropriate tab
according to the thickness of the
dashboard material and bend them
inwards to secure the holder in place.
3. Screw
1. Dashboard
2. Nut (5mm)
3. Spring washer
4. Screw (5 x 25mm)
5. Screw
6. Strap
Be sure to use the strap to secure the
back of the unit in place. The strap
can be bent by hand to the desired
angle.
7. Plain washer
30˚
(Fig. 1)
1
3
2
182
53
(Fig. 2)
1
2
6
5
4
3
7
INSTALLATION

4
INSTALLATION
Removing the unit
1. Frame
2. Insert fingers into the groove in the
front of frame and pull out to remove
the frame. (When reattaching the
frame, point the side with a groove
downwards and attach it.)
3. Lever
Insert the levers supplied with the unit
into the grooves at both sides of the
unit as shown in figure until they click.
Pulling the levers makes it possible to
remove the unit from the dashboard.
DIN REAR-MOUNT (Method B)
Installation using the screw holes on the
sides of the unit.
1
3
2
1
3
4
2
5
5
2
Fastening the unit to the factory radio
mounting bracket.
1. Select a position where the screw
holes of the bracket and the screw
holes of the main unit become aligned
(are fitted), and tighten the screws at
2 places on each side.
Use either truss screws (5 x 5mm) or
flush surface screw (4 x 5mm),
depending on the shape of the screw
holes in the bracket.
2. Screw
3. Factory radio mounting bracket
4. Dashboard or Console
5. Hook (Remove this part)
Note: The mounting box, outer trim ring,
and half-sleeve are not used for method
B installation.

5
USING THE DETACHABLE FRONT PANEL
To Detach the Front Panel
1. Press the open button (OPEN), to
make the front panel fold down.
2. Remove the front panel by pulling its
middle outward.
3. For safekeeping, store the front panel
in the supplied protective case
immediately after being removed.
4. Push the front metal plate into the
main body. A ‘click’ sound should be
heard.
Protective Case
Front Panel
Front Panel
Open
To Reinstall the Front Panel
1. Push the front panel into the main
body. A ‘click’ sound should be
heard.
2. Note that if the front panel fails to lock
in position properly, the control
buttons may not function and display
may be missing some segments. In
this case, press the OPEN button and
then reinstall the front panel.
Precautions when Handling
1. Do not drop the front panel.
2. Do not put pressure on the display or
control buttons when detaching or
reinstalling the front panel.
3. Do not touch the contacts on the front
panel or on the main unit body. It may
result in poor electrical contact.
4. If any dirt or foreign substances
adhered on the contacts, they can be
removed with a clean and dry cloth.
5. Do not expose the front panel to high
temperatures or direct sunlight in
anywhere.
6. Keep away any volatile agents (e.g.
benzene, thinner, or insecticides) from
touching the surface of the front panel.
7. Do not attempt to disassemble the
front panel.

6
4 x 40W System
GREEN
GREEN/BLACK
GREY
GREY/BLACK
VIOLET
VIOLET/BLACK
MAIN UNIT
WHITE
WHITE/BLACK
FRONT Lch
SPEAKER
REAR Lch
SPEAKER
FRONT Rch
SPEAKER
REAR Rch
SPEAKER
Rch RED
Lch WHITE
(GREY)
REAR RCA CABLE
ANTENNA CONNECTOR
RED
YELLOW
BLACK
BLUE
POWER
ANTENNA
GROUND (B–)
MEMORY
BACK-UP
IGNITION
SWITCH (B+)
WIRING CONNECTION

7
GENERAL OPERATION
• ON/OFF/ILLUMINATE
Switch on the unit by pressing any
button (except OPEN button (7) and
EJECT button (4)). When system is
on, press PWR/ILL button (9) shortly
to control the brightness of VFD.
Press it for several seconds to turn off
the unit.
• FACEPLATE RELEASE
Press OPEN button (7) to detach the
removable faceplate.
OPERATION
• SOUND ADJUSTMENT
Press SEL button (10) shortly to select
the desired adjustment mode.
The adjustment mode will change in
the following order:
By pressing AUDIO CONTROL
button (11) or AUDIO CONTROL
button (12), it is possible to adjust the
desired sound quality.
VOL BAS TRE BAL FAD
(Volume) (Bass) (Treble) (Balance) (Fader)
23
14212019 22 96 24 1216171318
78 1 3 2 15 25 10 11
26 275 4

• RESET
Reset button (27) can be activated
with either a ball point pen or thin metal
object. The reset button is to be
activated for the following reasons:
- Initial installation of the unit when all
wiring is completed.
-
All the function buttons do not operate.
- Error symbol on the display.
RADIO OPERATION
• BAND SELECTION
At tuner mode, press BND/LOUD
button (13) to select the desired band.
The reception band will change in the
following order:
• STATION SELECTION
Press MANU/SKIP button (16) or
MANU/SKIP button (17) shortly to
activate automatic seek function.
Press for several seconds until
“MANUAL” appears on the display, to
select the manual tuning mode. If both
buttons are not pressed for several
seconds, they will return to seek tuning
mode and “AUTO” appears on the
display.
• LOCAL/DISTANCE
Press LOC button (2) to select
between local and distant stations.
Local setting for reception of strong
station, and a distant setting for
reception of weaker stations.
This function is in effect during AUTO
SEEK operation.
• SEEK Function
Press SEEK button (1) scan and hear
all tunable stations for a few seconds.
Press SEEK again to stop at current
station.
• LOUDNESS
Press BND/LOUD
button (13) to increase
bass output and display will show “LOUD”.
Press it again to release this function.
• SET THE CLOCK
Press and hold DSP/0 button (15), then
press the MANU/SKIP button
(17) to change minutes or MANU/SKIP
button (16) to change hours.
• SELECT MODE
Press MODE button (6) to choose
desired listening mode.
(e.g. radio mode to CD (MP3) mode to
CDC mode or AUX IN mode)
• MUTE
Press MUTE button (3) to silence the
receiver. Press it again to release the mode.
• VACUUM FLUORESCENT DISPLAY
Displays current frequency and
activated functions (23).
• EQUALIZATION
Press EQ button (8) to turn on
equalization function and to select
desired audio mode. There are five
kinds of modes as below:
• REMOTE SENSOR
Point the remote control handset to
the remote sensor RX (25).
Press the function keys on the handset
to control the system.
• AV / AUXILIARY INPUT
The unit can be connected to a
portable audio player through the AUX
IN jack (24).
• FLASHING LED
If the front panel is not installed in the
main unit, the LED (26) will be flashing.
8
OPERATION
FLAT CLASSICS POP M JAZZ DSP OFF
FM1 FM2 FM3 AM

9
• AUTOMATIC MEMORY
STORING & PROGRAM SCANNING
- Automatic Memory Storing
Press AS/PS button (18) for several
seconds, the radio searches from
the current frequency and checks
the signal strength until one cycle
search is finished. The six strongest
stations are stored into the
corresponding preset number button.
- Program Scanning
Press AS/PS button (18) shortly to
scan preset station.
• STATION STORING
Press any one of the preset buttons
(14) (M1 to M6) to select a station
which had been stored in the memory.
Press this button for several seconds,
current station is stored into the
number button.
CD OPERATION
• SELECT TRACKS
During CD operation, press
MANU/SKIP button (17) or
MANU/SKIP button (16) to move
to the previous track or the following
track. Track number shows on display.
During CD operation, hold
MANU/SKIP button (17) or
MANU/SKIP button (16) to fast
reverse or fast forward. CD play starts
from when you release the button.
• PAUSE PLAYING
Press PAU button (19) to pause CD
player. Press it again to resume play.
• REPEAT THE SAME TRACK
During CD operation, press RPT
button (21) to continuously repeat the
same track. Press again to stop repeat.
• PREVIEW ALL TRACKS
During CD operation, press SCN
button
(20) to play first several seconds of
each track on the current disc. Press
again to stop intro and listen to track.
• PLAY ALL TRACKS IN RANDOM
During CD operation, press SHF
button (22) to play all tracks on CD in
random order. Press again to cancel
the function.
• EJECT
Press EJECT button (4) to stop CD
playing and eject the disc from the disc
slot (5).
OPERATION

10
MP3 OPERATION
During MP3 operation, the buttons
mentioned below serve the following
functions:
1.“Search track directly” in Digital
Audio CD.
2.“Search File Name” in Digital Audio
CD.
3.“Search File or directory” by file
directory structure in Digital Audio CD.
AS/PS
button is assigned as Digital
Audio
Mode selection button. When
pressed, it is activated as selecting
each mode of Digital Audio.
“Search track directly” –>
“Search File Name” –>
“Searching
File or directory”
• Press AS/PS(MP3) button once. It
enters into “Search track directly” in
Digital Audio CD. The unit searches
the track selected by following buttons:
M1-M6, MODE(7), MANU/SKIP DOWN(8),
MANU/SKIP UP(9), DSP(0).
• Press AS/PS(MP3) button twice. It
enters into “Search File Name” in
Digital Audio CD. The unit searches
files and directories which have the same
character entered by the user.
The unit shows these sorted files and
directories by all the buttons listed on
the Table 1 below.
The selected file can be played by
pushing BND/LOUD(ENTER) button.
• Press AS/PS(MP3) button three times.
It enters into “Search File or directory”
by file directory structure in Digital
Audio CD.
The unit searches files or directory in
file directory structure by using
MANU/SKIP UP/DOWN buttons.
The selected file can be played by
pushing BND/LOUD(ENTER) button.
• Press DSP/0 button, ID3 TAG is
displayed, if available, when this key is
pressed. The Songname, Artist,
Album, Year, Comments are
supported by this unit.
OPERATION
If the ID3 tag is not available, one of
these words will be displayed. Unknown
Songname, Unknown Artist, No Album
Title, Unknown Year, No Comments,
NO ID3 TAG.
KEY Assignments IN Search mode (Table 1)
M5 and M6 is assigned as the “+10”
number during Normal play and when
Searching File or directory.
AS/PS Mode Select
BND/LOUD ENTER
M1 A, B, C, 1
M2 D, E, F, 2
M3 G, H, I, 3
M4 J, K, L, 4
M5 M, N, O, 5/10
TRACK DOWN
M6 P, Q, R, 6/10
TRACK UP
MODE S, T, U, 7
MANU/SKIP DOWN V, W, X, 8
MANU/SKIP UP Y, Z, SPACE, 9
SEL CHARACTER
SHIFT RIGHT
DSP/0 _, –, +, 0
AUDIO CONTROL CHARACTER SELECT
UP/DOWN (A, B......8, 9, 0)
