Sanyo U-D22S User manual

‑1‑

‑2‑
WiringDiagram

‑3‑
ExprodedView

‑4‑
Partslist Note : The parts marked with have special characteristics of safety.
If the mark parts need replacement, use only SANYO specified parts.
Ｕ－Ｄ２２Ｓ 120V 142480003
Key NO. Description Q'ty
ＡDA 02Z10502 UPPER LID COMP 1
1DA 02S15539 KNOB,(C) 1
2DA 02W20502 UPPER LID,SUS 1
3DA 02S15503 UPPER LID,(C) 1
4DA 02S70550 STEAM COVER 2
5DA 00B40001 SPRIN ,A 1
6DA 00B40002 SPRIN ,B 1
7DA 02S25509 FOOK 1
8DA 02S70549 STEAM PACKIN 1
9DA 00B50020 SHAFT 1
10 DA 02S10504 UPRER LID COVER 1
11 DA 02W20530 WATERPROOF VALVE 1
12 DA 02S10506 WATERPROOF CAP 1
13 DA 02W20501 INSIDE LID 1
14 DA 02S70543 PACKIN ,INSIDE LID 1
15 DA 02Y40514 OPERATION NAMER 1
16 DA 02S15512 FRAME COVER 1
18 DA 02D60533 PCB COMP,A 1
19 DA 02S70544 PACKIN ,MT PLATE 1
20 DA 02S10514 MT PLATE 1
21 DA 02D70519 LEAD WIRE,FLAT,22S 1
ＢDA 02Z10516 VALVE ASSY,FALL 1
23 DA 02W20513 FILTER 1
ＣDA 02Z10520 VESSEL COMP,22S 1
24 DA 02Z10530 VESSEL ASSY,22S 1
25 DA 02S70548 PACKIN ,PUMP 1
26 DA 02S70545 PACKIN ,VESSEL 1
29 DA 02Z20514 THERMISTOR ASSY 1
34 DA 02S70547 PACKIN ,UNDER 1
35 DA 02Z20522 PUMP ASSY 1
37 DA 02D60517 LEAD WIRE ASSY,A 1
38 DA 02D60530 PCB COMP,B 1
39 DA 02S10519 STAND,B 1
40 DA 02D60506 TERMINAL ASSY 1
41 DA 02Z20512 TEMP FUSE ASSY 1
42 DA 02S25516 KNOB,SHANK(C) 1
43 DA 02S15536 BODY,22S 1
44 DA 02Y40537 COVER LABEL,22S 1
45 DA 02S15532 HANDLE,(C) 1
47 DA 02S15529 ROLLIN PLATE 1
48 DA 02D70526 CORD ASSY 1
DA 02Y10528 INST MANUAL 1
DA 02Y30522 IND CORR CASE,22S 1
DA 02Y30525 OUTER CORR CASE,22S 1
