The following projector manual has not been modified or altered in any way.

Multimedia Projector
MODEL LC-XBL20
LC-XBL25
Owner’s Manual
Network Supported
□ WiredLAN
   100-Base-TX/10-Base-T
RefertotheOwner'sManualsbelowfor
detailsaboutnetworkfunction.
□  NetworkSet-upandOperation
□  PJNetworkManager

2
Features and Design
ThisMultimediaProjectorisdesignedwiththemostadvancedtechnologyforportability,durability,andeaseofuse.
Thisprojectorutilizesbuilt-inmultimediafeatures,apaletteof16.77millioncolors,andmatrixliquidcrystaldisplay
(LCD)technology.
♦Compact Design
 Thisprojectorisdesignedcompactinsizeandweight.
Itis easy tocarry and installedanywhere you wishto
use.
♦Simple Computer System Setting
 TheprojectorhastheMulti-scansystemtoconformto
almostallcomputeroutputsignalsquickly(p.28).Upto
UXGAresolutioncanbeaccepted.
♦Useful Functions for Presentations
 -Thedigitalzoomfunction allowsyouto focus onthe
crucialinformationduringapresentation(p.35).
 -Blackboards*canbeusedasaprojectionscreen.
*TheboardcolorislimitedtoGreen(pp.32,39).
♦Lamp Control
 Brightnessoftheprojectionlampcanbeselected
(pp.25,52).
♦Quick Termination
 TheACpowercordcanbeunplugged immediately
after turning off the projector without waiting for the
terminationofthecoolingfanrotation(p.20).
♦Logo Function
 TheLogofunctionallowsyoutocustomizethescreen
logo(pp.46-48).Youcancapture animageforthe
screen logo and use it for thestarting-up display or
betweenpresentations.
♦Multilanguage Menu Display
 Operationmenuisavailablein18languages;English,
German,French,Italian,Spanish,Portuguese,Dutch,
Swedish,Finnish,Polish,Hungarian,Romanian,
Russian,Chinese,Korean,Japanese,Thaiand
Turkish.(p.43)
Note:
 •TheOn-ScreenMenuandfiguresinthismanualmaydifferslightlyfromtheproduct.
 •Thecontentsofthismanualaresubjecttochangewithoutnotice.
♦Security Function
 TheSecurityfunctionhelpsyoutoensuresecurity
of the projector. With the Key lock function, you can
locktheoperationonthetopcontrolorremotecontrol
(p.53). PIN code lock function prevents unauthorized
useoftheprojector(pp.19,53–54).
♦ Helpful Maintenance Functions
 Lampandfiltermaintenancefunctionsprovidefor
betterandpropermaintenanceoftheprojector.
♦LAN Network Function
 This projector is loadedwith the Wired LAN network
function.You can operate and manage the projector
vianetwork.Fordetails,refertotheowner’smanualof
“NetworkSet-upandOperation.”
♦Auto Setup Function
 ThisfunctionenablesInputsearch,AutoKeystone
correctionandAutoPCadjustmentbysimplepressing
theAUTOSETUPbuttononthetopcontrol(p.44).
♦Colorboard Function
 Atthetimeofsimpleprojectiononthecoloredwall,
youcangettheclosecolorimagetothecolorimage
projectedonawhitescreenbyselectingthesimilar
colortothewallcolorfromthepresetfourcolors.
♦Switchable Interface Terminal
Theprojectorprovidesaswitchableinterfaceterminal.
Youcanusetheterminalascomputerinputormonitor
outputconveniently.(p.49)
♦ Power Management
 ThePowermanagementfunctionreducespower
consumptionandmaintainsthelamplife(p.50).
♦Closed Caption
 ClosedCaptionisafunctionthatdisplaystheaudio
portionofaTVprogramastextonthescreen.The
closedcaptioningserviceisavailablemainlyinthe
U.S.(p.51)

3
Table of Contents
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
Features and Design ...................2
Table of Contents ......................3
To the Owner..........................4
Safety Instructions.....................5
AirCirculation 6
InstallingtheProjectorinProperPosition 6
MovingtheProjector 6
Compliance...........................7
Part Names and Functions ..............8
Front 8
Back 8
Bottom 8
RearTerminal 9
TopControl 10
RemoteControl 11
RemoteControlBatteryInstallation 12
RemoteControlOperatingRange 12
RemoteControlCode 12
Installation...........................13
PositioningtheProjector 13
AdjustableFoot13
ConnectingtoaComputer 14
ConnectingtoVideoEquipment 15
ConnectingtoComponentVideoandRGB
(Scart)Equipment 16
ConnectingtheACPowerCord 17
Basic Operation ......................18
TurningOntheProjector 18
TurningOfftheProjector 20
HowtoOperatetheOn-ScreenMenu 21
MenuBar 22
ZoomandFocusAdjustment 23
AutoSetupFunction 23
KeystoneCorrection 23
SoundAdjustment 24
RemoteControlOperation 25
Computer Input .....................27
InputSourceSelection
(RGB:Computer1/Computer2) 27
ComputerSystemSelection 28
AutoPCAdjustment 29
ManualPCAdjustment 30
ImageModeSelection 32
ImageAdjustment 33
ScreenSizeAdjustment 34
Video Input ..........................36
InputSourceSelection(Video,S-video) 36
InputSourceSelection
(Component,RGBScart21-pin) 37
VideoSystemSelection 38
ImageModeSelection 39
ImageAdjustment 40
ScreenSizeAdjustment 42
Setting ..............................43
Setting 43
Information ......................... 57
InputSourceInformationDisplay 57
Maintenance and Cleaning .............58
WARNINGindicator 58
CleaningtheFilters 59
ResettingtheFilterCounter 59
AttachingtheLensCap 60
CleaningtheProjectionLens 60
CleaningtheProjectorCabinet 60
LampReplacement 61
Appendix............................63
Troubleshooting 63
MenuTree 67
IndicatorsandProjectorCondition 69
CompatibleComputerSpecifications 70
TechnicalSpecifications 71
OptionalParts 72
PJLinkNotice 73
ConfigurationsofTerminals 74
PINCodeNumberMemo 75
Dimensions 76

4
To the Owner
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS
INSIDE EXCEPT LAMP REPLACEMENT.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THISSYMBOLINDICATESTHATDANGEROUS
VOLTAGECONSTITUTINGARISKOFELECTRIC
SHOCKISPRESENTWITHINTHISUNIT.
THISSYMBOLINDICATESTHATTHEREARE
IMPORTANTOPERATINGANDMAINTENANCE
INSTRUCTIONSINTHEOWNER'SMANUAL
WITHTHISUNIT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Beforeinstallingandoperatingthisprojector,readthis
manualthoroughly.
Thisprojectorprovidesmanyconvenientfeaturesand
functions.Operatingtheprojectorproperlyenables
youtomanagethosefeaturesandmaintainsitingood
conditionformanyyearstocome.
Improperoperationmayresultinnotonlyshorteningthe
product-life,butalsomalfunctions,firehazard,orother
accidents.
Ifyourprojectorseemstooperateimproperly,readthis
manualagain,checkoperationsandcableconnections
andtrythesolutionsinthe“Troubleshooting”sectionon
pages63-65ofthisbooklet.Iftheproblemstillpersists,
contactthedealerwhereyoupurchasedtheprojectoror
theservicecenter.
Safety Precaution
CAUTION
DO NOT SET THE PROJECTOR IN GREASY, WET, OR
SMOKY CONDITIONS SUCH AS IN A KITCHEN TO PREVENT
A BREAKDOWN OR A DISASTER. IF THE PROJECTOR
COMES IN CONTACT WITH OIL OR CHEMICALS, IT MAY
BECOME DETERIORATED.
READ AND KEEP THIS OWNER'S MANUAL FOR
LATER USE.
WARNING: ●THIS APPARATUS MUST BE EARTHED.
●TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
–Thisprojectorproducesintenselightfromtheprojection
lens.Donotstaredirectlyintothelens,otherwiseeye
damagecouldresult.Beespeciallycarefulthatchildren
donotstaredirectlyintothebeam.
–Installtheprojectorinaproperposition.Otherwiseitmay
resultinfirehazard.
–Allowingtheproperamountofspaceonthetop,sides,
andrearoftheprojectorcabinetiscriticalforproper
aircirculationandcoolingoftheunit.Thedimension
shownhereindicatetheminimumspacerequired.
Iftheprojectoristobebuiltintoacompartmentor
similarlyenclosed,theseminimumdistancesmustbe
maintained.
–Donotcovertheventilationslotontheprojector.Heat
build-upcanreducetheservicelifeofyourprojector,and
canalsobedangerous.
–Iftheprojectorisunusedforanextendedtime,unplug
theprojectorfromthepoweroutlet.
–Donotprojectthesameimageforalongtime.The
afterimagemayremainontheLCDpanelsbythe
characteristicofpanel.
SIDEandTOP REAR
CAUTION
NotforuseinacomputerroomasdefinedintheStandard
fortheProtectionofElectronicComputer/DataProcessing
Equipment,ANSI/NFPA75.
Nepeutêtreutilisédansunesalled’ordinateurstelle
quedéfiniedanslanormeANSI/NFPA75Standard
forProtectionofElectronicComputer/DataProcessing
Equipment.
0.7’(20cm)
1.5’(50cm) 3’(1m) 3’(1m)
20cm
50cm 1m 1m
Thesymbol markandrecycling systemsdescribedbelow
applytoEUcountriesanddonotapplytocountriesinother
areasoftheworld.
Yourproductisdesignedandmanufacturedwithhighquality
materialsandcomponentswhichcanberecycledand/or
reused.
Thesymbolmarkmeansthatelectricalandelectronic
equipment,batteriesandaccumulators,attheirend-oflife,
shouldbedisposedofseparatelyfromyourhousehold
waste.
Note:
If a chemical symbol is printed beneath the symbol mark,
thischemicalsymbolmeansthatthebatteryoraccumulator
contains a heavy metal at a certain concentration. This will
beindicatedasfollows:Hg:mercury,Cd:cadmium,Pb:lead
IntheEuropeanUnionthereareseparatecollectionsystems
forusedelectricalandelectronicequipment,
batteriesandaccumulators.
Please,disposeofthemcorrectlyatyourlocal
communitywastecollection/recyclingcentre.
Please,helpustoconservetheenvironment
welivein!

5
Safety Instructions
All the safety and operating instructions should be read
beforetheproductisoperated.
Read all of the instructions given here and retain them
forlateruse.UnplugthisprojectorfromACpowersupply
beforecleaning.Donotuseliquidoraerosolcleaners.
Useadampclothforcleaning.
Followallwarningsandinstructionsmarkedonthe
projector.
For added protection to the projector during a lightning
storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will
preventdamageduetolightningandpowerlinesurges.
Do not expose this unit to rain or use near water... for
example,inawetbasement,nearaswimmingpool,etc...
Donotuseattachmentsnotrecommendedbythe
manufacturerastheymaycausehazards.
Donotplacethisprojectoronanunstablecart,stand,
or table. The projector may fall, causing serious injury
to a child or adult, and serious damage to the projector.
Useonlywithacartorstandrecommended bythe
manufacturer,orsoldwiththeprojector.Wallorshelf
mounting should follow the manufacturer’sinstructions,
andshoulduseamountingkitapprovedbythe
manufacturers.
Anappliance andcartcombination
shouldbemovedwithcare.Quick
stops,excessiveforce,anduneven
surfacesmaycausetheappliance
andcartcombinationtooverturn.
Slotsandopeningsinthebackandbottomofthecabinet
areprovidedforventilation,toensurereliableoperationof
theequipmentandtoprotectitfromoverheating.
Theopeningsshouldneverbecoveredwithclothorother
materials,andthebottomopeningshouldnotbeblocked
byplacingtheprojectorona bed,sofa,rug,orother
similarsurface.Thisprojectorshouldneverbeplaced
nearoroveraradiatororheatregister.
Thisprojectorshouldnotbeplacedinabuilt-ininstallation
suchasabookcaseunlessproperventilationisprovided.
Neverpushobjectsofanykindintothisprojectorthrough
cabinetslotsastheymaytouchdangerousvoltagepoints
orshort out partsthat couldresultin afire orelectric
shock.Neverspillliquidofanykindontheprojector.
Do not install the projector near the ventilation duct of
air-conditioningequipment.
Thisprojectorshouldbeoperatedonlyfromthetype
of power source indicated on the marking label. If you
arenotsureofthetypeofpowersupplied,consultyour
authorizeddealerorlocalpowercompany.
Donotoverloadwalloutletsandextensioncordsasthis
canresultinfireorelectricshock.Donotallowanything
to rest on the power cord. Do not locate this projector
wherethecordmaybedamagedbypersonswalkingon
it.
Donotattempttoservicethis projectoryourselfas
openingorremoving Coversmayexposeyouto
dangerousvoltageorotherhazards.Referallservicing
toqualifiedservicepersonnel.
Unplugthisprojectorfromwalloutletandreferservicing
toqualifiedservicepersonnelunderthefollowing
conditions:
a.Whenthepowercordorplugisdamagedorfrayed.
b.Ifliquidhasbeenspilledintotheprojector.
c.Iftheprojectorhasbeenexposedtorainorwater.
d.Iftheprojectordoesnotoperatenormallybyfollowing
the operating instructions.Adjust only those controls
that are covered by the operating instructions as
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualifiedtechniciantorestoretheprojectortonormal
operation.
e.If the projector has beendroppedorthecabinethas
beendamaged.
f.Whentheprojectorexhibitsadistinctchangein
performance-thisindicatesaneedforservice.
Whenreplacementpartsarerequired,besure the
servicetechnicianhasusedreplacementpartsspecified
bythemanufacturerthathavethesamecharacteristics
asthe original part.Unauthorized substitutionsmay
resultinfire,electricshock,orinjurytopersons.
Uponcompletionofanyserviceorrepairsto this
projector, ask the service technician to perform routine
safety checks to determine that the projector is in safe
operatingcondition.
NOTE FOR CUSTOMERS IN THE US
HgLAMP(S)INSIDETHISPRODUCTCONTAIN
MERCURYANDMUSTBERECYCLEDORDISPOSED
OFACCORDINGTOLOCAL,STATEORFEDERAL
LAWS.

6
Safety Instructions
Openingsinthe cabinetareprovidedfor ventilation.To
ensurereliableoperationoftheproductandtoprotectit
from overheating, these openings must not be blocked
orcovered.
CAUTION
Hotairisexhaustedfromtheexhaustvent.Whenusing
or installing the projector, the following precautions
shouldbetaken.
–Donotputanyflammableobjectorspraycannearthe
projector,hotairisexhaustedfromtheairvents.
–Keeptheexhaustventatleast3’(1m)awayfromany
objects.
–Do not touch a peripheral part of the exhaust vent,
especiallyscrewsandmetallicparts.Theseareaswill
becomehotwhiletheprojectorisbeingused.
–Donotputanythingonthecabinet.Objectsputonthe
cabinetwillnotonlygetdamagedbutalsomaycause
firehazardbyheat.
Cooling fans are provided to cool down the projector.
The fans’ running speed is changed according to the
temperatureinsidetheprojector.
Moving the Projector
Whenmovingtheprojector,replacethelenscapand
retractadjustablefoottopreventdamagetothelensand
cabinet.
Whentheprojectorisnotinuseforanextendedperiod,
putitintoasuitablecase.
Air Circulation
AirIntakeVent
ExhaustVent
(Hotairexhaust)
AirIntakeVent
Donottilttheprojectormorethan30
degreesfromaboveandbelow.
Donotpointtheprojectoruptoprojectan
image.
Donotpointtheprojectordowntoproject
animage.
Donotputtheprojectoroneithersideto
projectanimage.
Install the projector properly. Improper Installation may
reducethelamplifeandcauseafirehazard.
Installing the Projector in Proper Position
Donottilttheprojectormorethan20
degreesfromsidetoside.
20°
20°
30°
30°

CAUTION IN CARRYING OR TRANSPORTING
THE PROJECTOR
–Donotdroporbumptheprojector,otherwisedamages
ormalfunctionsmayresult.
–Whencarryingtheprojector,useasuitablecarryingcase.
–Donottransporttheprojectorbycourieroranyother
transportserviceinanunsuitabletransportcase.This
maycausedamagetotheprojector.Forinformation
abouttransportingtheprojectorbycourieroranyother
transportservice,consultyourdealer.
–Donotputtheprojectorinacasebeforetheprojectoris
cooledenough.

7
Safety Instructions Compliance
Federal Communications Commission Notice
Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause harmful interference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determinedbyturningtheequipment offandon,theuseris encouragedtotrytocorrecttheinterferenceby
oneormoreofthefollowingmeasures:
 –Reorientorrelocatethereceivingantenna.
 –Increasetheseparationbetweentheequipmentandreceiver.
 –Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
 –Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
UseofshieldedcableisrequiredtocomplywithclassBlimitsinSubpartBofPart15ofFCCRules.
Donotmakeanychangesormodificationstotheequipmentunlessotherwisespecifiedintheinstructions.If
suchchangesormodificationsshouldbemade,youcouldberequiredtostopoperationoftheequipment.
ModelNumber :LC-XBL20,LC-XBL25
TradeName :EIKI
Responsibleparty :EIKIInternational,Inc.
Address :30251EsperanzaRanchoSantaMargaritaCA92688-2132
TelephoneNo. :800-242-3454(949-457-0200)
TheACPowerCordsuppliedwiththisprojectormeetstherequirementforuseinthecountryyoupurchasedit.
AC Power Cord for the United States and Canada:
ACPowerCordusedintheUnitedStatesandCanadaislistedbytheUnderwriters
Laboratories(UL)andcertifiedbytheCanadianStandardAssociation(CSA).
ACPowerCordhasagrounding-typeAClineplug.Thisisasafetyfeaturetobesurethatthe
plugwillfitintothepoweroutlet.Donottrytodefeatthissafetyfeature.Shouldyoubeunable
toinserttheplugintotheoutlet,contactyourelectrician.
GROUND
AC Power Cord Requirement
AC Power Cord for the United Kingdom:
Thiscordisalreadyfittedwithamouldedplugincorporatingafuse,thevalueofwhichisindicatedonthepin
faceoftheplug.Shouldthefuseneedtobereplaced,anASTAapprovedBS1362fusemustbeusedofthe
samerating,markedthus
A S A
.Ifthefusecoverisdetachable,neverusetheplugwiththecoveromitted.Ifa
replacementfusecoverisrequired,ensureitisofthesamecolourasthatvisibleonthepinfaceoftheplug
(i.e.redororange).FusecoversareavailablefromthePartsDepartmentindicatedinyourUserInstructions.
Iftheplugsuppliedisnotsuitableforyoursocketoutlet,itshouldbecutoffanddestroyed.
Theendoftheflexiblecordshouldbesuitablypreparedandthecorrectplugfitted.
WARNING : A PLUG WITH BARED FLEXIBLE CORD IS HAZARDOUS IF ENGAGED IN A LIVE SOCKET
OUTLET.
TheWiresinthismainsleadarecolouredinaccordancewiththefollowingcode:
 Green-and-yellow .. Earth
 Blue ...........Neutral
 Brown.........Live
Asthecoloursofthewiresinthemainsleadofthisapparatusmaynotcorrespondwiththecolouredmarkings
identifyingtheterminalsinyourplugproceedasfollows:
Thewirewhichiscolouredgreen-and-yellowmustbeconnectedtotheterminalintheplugwhichismarkedby
theletterEorbythesafetyearthsymbol orcolouredgreenorgreen-and-yellow.
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or
colouredblack.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or
colouredred.
WARNING: THIS APPARATUS MUST BE EARTHED.
THE SOCKET-OUTLET SHOULD BE INSTALLED NEAR THE EQUIPMENT AND EASILY ACCESSIBLE.

8
Part Names and Functions
⑤⑦ ⑧
③
②
Front
Back
⑥
①Top controls and Indicators
②Zoom Ring
③Focus Ring
④Speaker
⑤Infrared Remote Receiver
⑥Projection Lens
⑦Lens Cap
 (Seepage60forattaching.)
⑧Air Intake Vent
⑨Lamp Cover
⑩Terminals and Connectors
⑪LAN Connection Terminal
⑫ Power Cord Connector
⑬ Exhaust Vents
CAUTION
Hotairisexhaustedfromtheexhaustvent.Donotput
heat-sensitiveobjectsnearthisside.
⑭Filters
⑮Adjustable Foot
Note:
⑪LANConnectionTerminalisfortheNetworkfunction.
Refertotheowner’smanualof“NetworkSet-upand
Operation”.
Kensington Security Slot
ThisslotisforaKensingtonlockusedtodetertheftof
theprojector.
KensingtonisaregisteredtrademarkofACCOBrands
Corporation.
CAUTION
Donotturnonaprojectorwithlenscapattached.High
temperaturefromlightbeammaydamagelenscapand
resultinfirehazard.
④
⑩
⑧
⑪
⑨

Bottom ⑮
①
⑭⑬⑬⑫
⑭

9
Part Names and Functions
Rear Terminal
② ③① ④⑥
⑦
⑤
⑦AUDIO IN
 Connecttheaudiooutputsignalfromcomputeror
videoequipmenttothisjack(pp.14-16).
⑤VIDEO IN
 Connectthecompositevideooutputsignaltothis
jack(p.15).
②COMPUTER IN 1 /S-VIDEO IN / COMPONENT IN
 ConnectanalogRGBoutputsignalfroma
computer,S-VIDEOoutputsignalfromvideo
equipment,orRGBscart21-pinvideooutputor
componentvideooutputtothisterminal(pp.14-16).
④AUDIO OUT (VARIABLE)
 Connectanexternalaudioamplifiertothisjack
(pp.14-16).
 ThisterminaloutputssoundfromAUDIOIN
terminal.
⑥LAN Connection Terminal
 ConnecttheLANcable(refertotheowner’s
manualof“NetworkSet-upandOperation”).
①CONTROL PORT
 WhencontrollingtheprojectorwithRS-232C,
connectthecontrolequipmenttothisconnectorwith
theserialcontrolcable.
③COMPUTER IN 2 / MONITOR OUT
 –ConnectanalogRGBoutputsignalfroma
 computertothisterminal(p.14).
 –Thisterminalcanbeusedtooutputtheincoming
 analogRGBandComponentsignalfrom
 COMPUTERIN1/S-VIDEOIN/COMPONENTIN
 terminaltotheothermonitor(pp.14,16).

10
Part Names and Functions
Top Control
⑦LAMP REPLACE indicator
 Lightsyellowwhentheprojectionlampreachesits
endoflife(pp.61,69).
⑧WARNING indicator
 –Lightsredwhentheprojectordetectsan
abnormalcondition.
 –Blinksredwhentheinternaltemperatureofthe
projectorexceedstheoperatingrange(pp.58,
69).
④ON/STAND–BY button
Turntheprojectoronoroff(pp.18-20).
⑤POWER indicator
 –Lightsredwhentheprojectorisinstand-bymode.
 –Lightsgreenduringoperations.
 –BlinksgreeninthePowermanagementmode
(p.50).
⑥MENU button
 OpenorclosetheOn-ScreenMenu(p.21).
②POINT ▲▼◄► (VOLUME +/–) buttons
 –Selectanitemoradjustthevalueinthe
On-ScreenMenu(p.21).
 –PantheimageintheDigitalzoom+/-mode
(p.35).
 –Adjustthevolumelevel(Point◄►buttons)
(p.24).
③AUTO SETUP button
ExecutethesettingofAutosetup(includesInput
search,AutoPCadj.andAutoKeystonefunctions)
inthesettingmenu.(pp.23,44).
①SELECT button
 –Executetheselecteditem(p.21).
 –ExpandorcompresstheimageintheDigital
zoommode(p.35).
①
②
③
④
⑤
⑥
⑦
⑧

11
Part Names and Functions
Note:
Toensuresafeoperation,pleaseobservethefollowingprecautions:
–Donotbend,drop,orexposetheremotecontroltomoistureorheat.
–Forcleaning,useasoftdrycloth.Donotapplybenzene,thinner,spray,
oranychemicalmaterial.
Remote Control
⑦
⑭
⑩
⑳
④
⑱
②
⑧
⑨
⑬
⑯
⑤
⑥
⑪
⑫
⑲
⑮
③
②AUTO SET button
ExecutethesettingofAutosetup(includesInputsearch,AutoPCadj.
andAutoKeystonefunctions)inthesettingmenu.
(pp.23,44)
⑤S-VIDEO button
 SelecttheS-VIDEOinputsource.(p.36)
⑥Point ▲▼◄►buttons
 –SelectanitemoradjustthevalueintheOn-ScreenMenu.(p.21)
 –PantheimageintheDigitalzoom+/-mode.(p.35)
⑬MUTE button
 Mutethesound.(p.24)
⑦SCREEN button
 Selectascreenmode.(pp.26,34-35,42)
⑮P-TIMER button
 OperatetheP-timerfunction.(p.26)
⑩NO SHOW button
 Temporarilyturnofftheimageonthescreen.(p.26)
⑯LAMP button
 Selectalampmode.(pp.25,52)
⑱KEYSTONE button
 Correctkeystonedistortion.(pp.23,45)
⑲SELECT button
 –Executetheselecteditem.(p.21)
–ExpandorcompresstheimageinDigitalzoommode.(p.35)
⑧MENU button
 OpenorclosetheOn-ScreenMenu.(p.21)
⑨FREEZE button
 Freezethepictureonthescreen.(p.25)
⑫VOLUME +/- buttons
Adjustthevolumelevel.(p.24)
①ON/STAND-BY button
 Turntheprojectoronoroff.(pp.18-20)
③COMPUTER 1/2 buttons
 SelecttheCOMPUTER1orCOMPUTER2inputsource.
(pp.27,37)
⑪D.ZOOM ▲▼buttons
 Zoominandouttheimages.(pp.25,35)
⑭IMAGE button
 Selecttheimagemode.(pp.26,32,39)
⑳COMPONENT button
 SelecttheCOMPONENTinputsource.(p.37)
④VIDEO button
 SelecttheVIDEOinputsource.(p.36)
⑰
⑰INFO. button
 Operatetheinformationfunction.(p.57)
①

12
Part Names and Functions
Toensuresafeoperation,pleaseobservethefollowingprecautions:
 ● Usetwo(2)AAAorLR03typealkalinebatteries.
 ● Alwaysreplacebatteriesinsets.
 ● Donotuseanewbatterywithausedbattery.
 ● Avoidcontactwithwaterorliquid.
 ● Donotexposetheremotecontroltomoistureorheat.
 ● Donotdroptheremotecontrol.
 ● Ifthebatteryhasleakedontheremotecontrol,carefullywipethecasecleanandinstallnewbatteries.
 ● Riskofanexplosionifbatteryisreplacedbyanincorrecttype.
 ● Disposeofusedbatteriesaccordingtotheinstructionsoryourlocaldisposalruleorguidelines.
Openthebattery
compartmentlid.
Installnewbatteries
intothecompartment.
Replacethe
compartmentlid.
Two AAA size batteries
Forcorrectpolarity
(+and–),besure
batteryterminalsare
incontactwithpinsin
compartment.
1 2 3
Point the remote control toward the projector (Infrared
Remote Receiver) when pressing the buttons. Maximum
operating range for the remote control is about 16.4'(5 m)
and60degreesinfrontoftheprojector.
Remote Control Operating Range
Remote Control Battery Installation
16.4'
(5m)
30° Remotecontrol
30°
The2 differentremote controlcodes (Code 1–Code2) are
assignedtothisprojector.Switchingtheremote
control codes prevents interference from other remote
controlswhenseveralprojectorsorvideoequipment
nexttoeachother are operatedatthesametime.Change
theremotecontrolcodefortheprojectorfirstbefore
changingthatforthe remote control.See"Remotecontrol"
intheSettingMenuonpage52.
PressandholdtheMENUandIMAGEbuttonsformore
thanfivesecondstoswitchbetweentheCode 1andCode
2.TheinitialcodeissettoCode 1.
Remote Control Code
MENU button
IMAGE button

13
Positioning the Projector
Forprojectorpositioning,seethefiguresbelow.Theprojectorshouldbesetperpendicularlytotheplaneofthe
screen.
Installation
Note:
 •The brightness in the room has a great influence on picture quality. It is recommended to limit ambient
lightinginordertoobtainthebestimage.
 •Allmeasurementsareapproximateandmayvaryfromtheactualsizes.
Adjustable Foot
AdjustableFoot
FootLockLatch
Projectionanglecanbeadjustedupto10.0degreeswith
theadjustablefoot.
Liftthefrontoftheprojectorandpushthefootlock
latchontheprojector.
Releasethefootlocklatchtolocktheadjustablefoot
androtatetheadjustablefoottoadjustthepositionand
tilt.
Toretracttheadjustablefoot,liftthefrontofthe
projectorandpushandundothefootlocklatch.
Keystonedistortionoftheprojectedimagecanbe
correctedbymenuoperation.(seepages23,44-45)
A
B
100"
150"
200" 250
167
125
83
300"(wide)
40"
300"(tele )
38.7'(11.80m)
32.3'(9.84m)
21.5'(6.55m)
16.1'(4.90m)
Max. Zoom Min. Zoom
A
: B = 6 : 1
(Inch Diagonal)
10.7'(3.26m)
(Center)
4.3'(1.30m)
Screen Size
(W x H) mm
4 : 3 aspect ratio
40”
Zoom (max)
813 x 610
4.3'(1.30m)
100”
2032 x 1524
10.7'(3.26m)
150”
3048 x 2286
16.1'(4.90m)
200”
4064 x 3048
21.5'(6.55m)
300”
6096 x 4572
32.3'(9.84m)
Zoom (min) 5.1'(1.55m) 12.9'(3.92m) 19.4'(5.90m) 25.8(7.87m)38.7'(11.80m)

14
Installation
Connecting to a Computer
Unplug the power cords of both the projector and external equipment from the AC outlet before connecting
cables.
Cables used for connection
• VGA Cables (Mini D-sub 15 pin) *(Only one cable is supplied.)
• Audio Cables
(*One cable is supplied; other cables are not supplied with the projector.)
Note:
• Input sound to the AUDIO IN terminal when using the COMPUTER IN 1/ S-VIDEO IN / COMPONENT IN
and the COMPUTER IN 2/MONITOR OUT terminals as input.
• When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available.
• When the cable is of the longer variety, it is advisable to use the COMPUTER IN 1 /S-VIDEO IN /COMPONENT IN and
not the COMPUTER IN 2/MONITOR OUT.
External Audio Equipment
Audio cable
(stereo)
Audio cable
(stereo)
Audio Output
AUDIO IN
AUDIO OUT
(stereo)
Audio Input
Monitor Input
or
Monitor Output
COMPUTER IN 2 /
MONITOR OUT
VGA
cable
COMPUTER IN 1
/ S-VIDEO IN
/COMPONENT IN
VGA
cable
Monitor
Output
This terminal is switchable.
Set up the terminal as
either Computer input or
Monitor output. (See Page
49.)

15
Installation
Connecting to Video Equipment
Cables used for connection
• Video Cable
• S-Video Cable
• S-Video-VGA Cable
• Audio Cables (Mini Plug: stereo)
(Cables are not supplied with the projector. )
External Audio Equipment
Audio cable
(stereo)
S-Video cable
Composite Video and Audio Output
S-Video Output
Audio Input
AUDIO IN
Note:
• When the AUDIO OUT is plugged-in, the projector's built-in speaker is not available.
• See page 72 for ordering optional cables.
Unplug the power cords of both the projector and external equipment from the AC outlet before connecting
cables.
S-Video-VGA
cable
Video cable
COMPUTER IN 1
/ S-VIDEO IN
/COMPONENT IN
AUDIO OUT
(stereo) VIDEO IN
Audio cable
(stereo)
Audio Output

16
Installation
Connecting to Component Video and RGB ( Scart) Equipment
Note:
 •WhentheAUDIOOUTisplugged-in,theprojector'sbuilt-inspeakerisnotavailable.
 •Seepage72fororderingoptionalcables.
Cables used for connection
•AudioCables(MiniPlug:stereo)
•Scart-VGACable
•ComponentCable
•Component-VGACable
(Cablesarenotsuppliedwiththisprojector.)
ExternalAudioEquipment
AUDIOIN
Audiocable
(stereo)
Audiocable
(stereo)
AudioInput
ComponentVideoOutput
(Y,Pb/Cb,Pr/Cr)
AudioOutput RGBScart
21-pinOutput
Scart-VGA
cable
Component-
VGAcable
AUDIO OUT
(stereo)
Component
cable
COMPUTERIN1/S-VIDEOIN/COMPONENTIN
UnplugthepowercordsofboththeprojectorandexternalequipmentfromtheACoutletbeforeconnecting
cables.

17
Installation
Connecting the AC Power Cord
This projector uses nominal input voltages of 100-120 V or
200–240VACanditautomaticallyselectsthecorrectinput
voltage. It is designed to work with single-phase power
systems having a grounded neutral conductor. To reduce
theriskofelectricalshock,donotplugintoanyothertypeof
powersystem.
If you are not sure of the type of power being supplied,
consultyourauthorizeddealerorservicestation.
Connect the projector with all peripheral equipment before
turningtheprojectoron.
Note:
UnplugtheACpowercordwhentheprojectorisnot
inuse.Whenthisprojectorisconnectedtoanoutlet
withtheACpowercord,itisinStand-bymodeand
consumesalittleelectricpower.
TotheACoutlet.
(200 - 240 V AC)
NOTE ON THE POWER CORD
ACpowercordmustmeetrequirementofthecountrywhereyouusetheprojector.
ConfirmtheACplugtypewiththechartbelowandproperACpowercordmustbeused.
IfsuppliedACpowercorddoesnotmatchyourACoutlet,contactyoursalesdealer.
Topowercord
connectoronyour
projector.
Projector side AC outlet side
Ground
TotheACoutlet.
(120 V AC)
For the U.S.A. and Canada
TotheACoutlet.
(200 - 240 V AC)
For the U.K.For Continental Europe
CAUTION
TheACoutletmustbenearthisequipmentandmustbe
easilyaccessible.
Connect theAC power cord (supplied) to the
projector.

18
Thepreparationdisplaywilldisappear
after30seconds.
(Seepage52forLampcontrolstatus.)
Turning On the Projector
Connecttheprojector’sACpowercordintoanAC
outlet.ThePOWERindicatorlightsred.Openthelens
cap(seepages8,60).
PresstheON/SYAND-BYbuttononthetopcontrolor
ontheremotecontrol.ThePOWERindicatorlights
greenandthecoolingfansstarttooperate.The
preparationdisplayappearsonthescreenandthe
countdownstarts.
2
3
1Completeperipheralconnections(withacomputer,
VCR,etc.)beforeturningontheprojector.
Selected Input Source and Lamp Control
Note:
 TheFilterwarningandLampreplacement
iconsmayappearonthescreen
dependingontheusagestateofthe
projector.
Basic Operation
Lampcontrolstatus
Video
4Afterthecountdown,theinputsourcethatwasselected
thelasttimeandthelampcontrolstatusicon(seepage
52)appearonthescreen.
Note:
 •WhentheLogoselectfunctionissettoOff,thelogowill
notbeshownonthescreen(p.46).
 •WhenCountdown offorOffisselected in the Display
function, the preparation display will not be shown on
thescreen(p.45).
 •WhentheInputSearchfunctionissettoOn2,theinput
signalwillbesearchedautomatically(p.44).
• WhenOffisselectedintheDisplayfunction,theVideo/
PC selection window and the input signal guidance
windowarenotshownonthescreen.(p.45)
5Ifthereisnosignalinputwhenstartontheprojector,
orthecurrentsignalismissedwhileoperatingthe
projector,theVideo/PCselectionwindowwillbe
displayedonthescreen,pleasemovethepointerto
inputsourcedesiredbypressingthePoint▲▼buttons
andpresstheSELECTbutton.Andthenfollowthe
inputsignalguidancewindowtocorrectthesignaland
connection.
IftheprojectorislockedwithaPINcode,PINcodeinput
dialogboxwillappear.EnterthePINcodeasinstructed
onthenextpage.
Video / PC selection window
Input signal guidance window
Video / PC selection window
Input signal guidance window
Project Video
Project Computer
Cancel
Project Video
Project Computer
Cancel
Project Computer
Nosignal
CurrentInputsetting:Video
Issignalprocessedcorrectly?
Iscableconnectedproperly?
Nosignal
CurrentInputsetting:RGB
Issignalprocessedcorrectly?
Iscableconnectedproperly?
16
http://www.eiki.com

19
What is PIN code?
PIN(PersonalIdentificationNumber)codeisasecurity
codethatallowsthepersonwhoknowsittooperatethe
projector.SettingaPINcodepreventsunauthorizeduseof
theprojector.
APINcodeconsistsofafour-digitnumber.RefertothePIN
codelockfunctionintheSettingMenuonpages53-54for
lockingoperationoftheprojectorwithyourPINcode.
Enter a PIN code
UsethePoint▲▼buttonstoenteranumber.Pressthe
Point◄►buttonstofixthenumberandmovethered
framepointertothenextbox.Thenumberchangesto“”.
Ifyoufixedanincorrectnumber,usethePoint◄►buttons
tomovethepointertothenumberyouwanttocorrect,and
thenenterthecorrectnumber.
Repeatthissteptocompleteenteringafour-digitnumber.
Afterenteringthefour-digitnumber,movethepointertoSet.
PresstheSELECTbuttonsothatyoucanstarttooperate
theprojector.
IfyouenteredanincorrectPINcode,PIN codeandthe
number()willturnredforamoment.Enterthe
correctPINcodealloveragain.
CAUTION ON HANDLING PIN CODE
IfyouforgetyourPINcode,theprojectorcanno
longerbestarted.Takeaspecialcareinsetting
anewPINcode;writedownthenumberina
columnonpage75ofthismanualandkeepit
onhand.ShouldthePINcodebemissingor
forgotten,consultyourdealerorservicecenter.
AftertheOKicondisappears,
youcanoperatetheprojector.
PIN Code Input Dialog Box
Note:
 •IfthePINcodenumberisnotenteredwithinthree
minutesafterthePINcodedialogboxappeared,the
projectorwillbeturnedoffautomatically.
 •The“1234”issetastheinitialPINcodeatthefactory.
Basic Operation
