1250 ANSI LUMENS zTRUE SVGA zMULTIMEDIA PROJECTOR
Issued 10/03 ©2003 SANYO
PLC-SW30
SVGA Ultraportable Multimedia Projector
LIGHT AND BRIGHT!
The PLC-SW30 weighs in at only 4.6 pounds yet produces
an amazing 1250 ANSI lumens of brightness.
1:1.2 STANDARD ZOOM LENS
Equipped with a 1:1.2 zoom lens, the PLC-SW30 is capable
of producing a 100” diagonal image from a distance of 10.6’
to 12.6’.
PRESENTATION KIT
Besides the standard I/R remote control, the PLC-SW30
also comes with a Presentation Kit featuring a small
Presentation Remote Control and a USB Infrared Receiver.
The Presentation Remote works as a wireless mouse to
control your PC and presentation, and also controls various
presentation-related projector functions such as Freeze, No
Show, Presentation Timer, and Computer/Video Input
Selection.
DIGITAL PROGRESSIVE SCANNING
SANYO’s proprietary Digital Progressive Scanning doubles
the video information being sent to the projector,
substantially increasing video-image detail and resolution.
CUSTOMIZABLE START-UP LOGO
Logo and image files can be captured for display during the
projector’s countdown sequence at startup.
DIGITAL KEYSTONE CORRECTION
With the touch of a button, Sanyo’s Digital Keystone
Correction easily compensates for angled projector
placement by mathematically interpolating an image’s
pixels and correcting trapezoidal images.
HDTV COMPATIBLE
The PLC-SW30 is High Definition Television compatible
accepting the 480i, 480p, 575i, 575p, 720p, 1035i and
1080i HDTV resolution standards.
DUAL USE D-SUB15 INPUT
The PLC-SW30 features a D-Sub15 input terminal that can
be used as both a VGA input for computer signals, or as an
input for component video (using the optional Component
Video/VGA cable POA-CA-COMPVGA).
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 818.998.7322 ext. 288
Fax 818.717.2719
www.sanyolcd.com
Specifications
Resolution SVGA (800 x 600)
Brightness (typical) 1250 ANSI Lumens
Uniformity 85%
LCD Panel System 0.5” TFT Poly w/Micro Lens x 3
Number of Pixels 1,440,000 (480,000 x 3)
Contrast Ratio 300:1 (Full On/Off)
Projection Image
(diagonal)
34”-200”
Aspect Ratio 4:3
Throw Distance 4.3’-21.3’
Zoom/Focus Manual (1:1.2 zoom)
Up/Down Ratio 9:1
Digital Keystone
Correction
Vert. +/- 20°
Projection System Polarized Beam Splitter optical system
Projection Lens F1.6-1.8 / f.72”-.86”
Lens Throw Ratio 1.6-1.9:1
Projection Lamp 160W UHP
Scanning Frequency H 15-80kHz; V 50-100Hz
Dot Clock 100 MHz
Color System PAL/PAL-M/PAL-
N/SECAM/NTSC/NTSC4.43
Computer Compatibility SXGA, XGA, SVGA, VGA
Sound Output One-piece, 0.8-watt Mono
Voltage 100-240V AC; 50/60/Hz (auto sense/select)
BTU Rating 833
dB Rating N/A
Power Consumption 244W (169W in Eco mode)
Dimensions (WxHxD) 10.6” x3.1”x7.5”
Net Weight 4.6 lbs.
User Maintenance Clean air filters, replace lamp assembly
PC Input Terminals D-Sub15 x 1 zAudio (stereo mini-jack)
Video Input Terminals Composite Video (RCA x 1) zS-Video (mini-
DIN 4-pin) zComponent Video (D-Sub15
input w/optional cable) zAudio (stereo mini-
jack)
Service / RS-232 Port Mini DIN 8-pin
USB / Mouse Port USB type B x 1
Included Accessories I/R remote control z2 AAA batteries z
Owner’s manual zPresentation Kit (Remote
Control w/USB Infrared Receiver) zVGA
cable zLens cap
zSoft Carry Bag zAC power supply cord
Optional Accessories zPOA-CA-COMPVGA –VGA/Component
Video cable
zPOA-MACAP –VGA / MAC Adapter
Warranty Three years parts and labor; 90 days lamp;
Quick Repair Program under warranty
Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any
obligations.
Presentation Kit with Remote PLC-SW30 Terminal
and USB Infrared Receiver Input Panel
