9000 ANSI LUMENS TRUE XGA DIGITAL MULTIMEDIA PROJECTOR
Issued 11/06 © 2006 SANYO
PLC-XF42
XGA Digital Multimedia Projector
INCREDIBLY BRIGHT 9000 ANSI LUMENS
Utilizing four high-output 250 watt UHP lamps as its light
source, the PLC-XF42 delivers an incredible 9000 ANSI
lumens of brightness.
OUTSTANDING CONTRAST RATIO –1,100:1
Through its new high-contrast optical system, the PLC-XF42 is
able to achieve an outstanding contrast ratio of 1,100:1. A 10-
bit digital gamma correction circuit is employed to effectively
suppress overwhelming whites in bright images and excessive
blacks in dark images.
NETWORK CONTROL/ADMINISTRATION
An optional network board allows for simple control and
management of the projector via a CAT5 network connection.
The network board, which can memorize and store up to 55 PC
modes, can also be used in parallel with RS-232 controllers.
REAL COLOR MANAGER PRO
The Real Color Manager PRO System provides color
correction and gamma correction from a PC using the included
image adjustment software.
NEW ONE-TOUCH LENS REPLACEMENT
Attaching the included One-Touch lens mount adapters to your
projector and lenses makes installation and removal of our
optional lenses quick and easy.
24/7* OPERATION
A newly developed liquid crystal panel with an optical
compensator that creates linear polarization, together with
improved optical block cooling system, gives the PLC-XF42 the
capability of being operated on a 24/7* basis.
* In order to maintain a stable lamp condition, at least one hour of rest for the
projector is required in each 24-hour period.
* For appropriate care and use of the projector, regular cleaning of air filters is
necessary. Cleaning is recommended once a week. However, the frequency on
which cleaning is required depends upon the installation or operation environments
PRESENTATION TECHNOLOGIES
21605 Plummer Street
Chatsworth, CA 91311
Ph: 888-337-1215 (toll-free)
Fax [phone]
www.sanyolcd.com
S p e c i f i c a t i o n s
Resolution XGA (1024 x 768)
Brightness 9000 ANSI Lumens (4-Lamp mode)
4500 ANSI Lumens (2-Lamp mode)
Uniformity 90% (corner to corner)
LCD Panel System 1.8”TFT polysilicon type x 3
Number of Pixels 2,359,296 (786,432 x 3)
Contrast Ratio 1,100:1
Projection Lens Lens Sold Separately
Image Size Dependent on Lens
Aspect Ratio 4:3
Throw Distance Dependent on Lens
Zoom/Focus Dependent on Lens
Throw Ratio Dependent on Lens
Zoom Ratio Dependent on Lens
Power Lens Shift
(Dependent on lenses) Up/Down Ratio 10:0 –0:10 or 8:1 –1:8 Left/Right Ratio 3:2 –2:3
Digital Keystone Correction +/- 40(Vertical)
Projection Lamp 250W UHP x 4
Scanning Frequency H Sync: 15-120kHz, V Sync: 50-120Hz
Dot Clock 230MHz
Color System PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43
Computer Compatibility UXGA, SXGA/+, WXGA, XGA, SVGA, VGA, MAC
Voltage 120V, 200-240V AC; 50/60/Hz (auto sense/select)
BTU Rating 5118
dB Rating 51.0
Power Consumption 1500W
Dimensions (WxHxD) 22.9”x9.9”x30.8”(Not include adjustable feet)
Net Weight 80.5 lbs.
User Maintenance Clean air filters, replace lamp assembly
Detachable Input Panels
POA-MD18DVI
Digital Visual Interface (DVI-I w/HDCP) Left & Right
Audio (RCA x 2) Control (Min DIN 8-pin)
POA-MD16VD1 RGB & Component (5-BNC) Left & Right Audio (RCA x 2)
Control (Min DIN 8-pin)
POA-MD04VGA VGA (D-Sub 15) Left & Right Audio (RCA x 2)
Control (Min DIN 8-pin)
Fixed Input/Output Panel Serial in/out (D-Sub 9 x 2) Audio out (RCA x 2)
USB (type B) Wired RC jack (Stereo mini);
Included Accessories Wired/Wireless I/R Remote Control2 “AA”Batteries
AC power cord VGA Cables Light Block Sheets
Lens Mount Adapters (POA-LNA02 & POA-LNA01)
Real Color Manager PRO CD-ROM
Owner’s manual(CD-ROM and Quick Reference Guide)
Optional Accessories POA-MD03VD2A –Video Y,C and S-Video Board
POA-MD08HD - HD-SDI Input Panel
POA-MD13NET - Network Board
POA-MD15SDI - SD-SDI Board
POA-MD17SDID –HD-SDI & SD-SDI Input Board
POA-MD21WARP- Warp & Blending Board
POA-LNA02 - Lens Mount Adapter
(for LNS-W02, W02KS, M01, S01 lenses)
POA-LNA01 - Lens Mount Adapter (for all other lenses)
PLCCSE14 - Hard Shipping Case
6103000862 - Replacement Lamp
Warranty Three years parts and labor; 90 days original lamp;
Quick Repair Program under warranty
Because its products are subject to continuous improvement, SANYO reserves the right to modify
product design and specifications without notice and without incurring any obligations.
L e n s S p e c i f i c a t i o n s
Type Short
Fixed Short Zoom On-Axis Short Fixed
Short
Zoom Short Zoom Standard Zoom 1 Standard Zoom 2 Standard Zoom 3 Semi-Long Zoom Long Fixed
Long Zoom Long Zoom
Part No. LNS-W01Z LNS-W02Z LNS-W03 LNS-W04 LNS-W06 LNS-S01 LNS-S02Z LNS-S03 LNS-M01Z LNS-T01Z LNS-T02 LNS-T03
Zoom No Yes (power) No Yes (power) Yes (power) Yes (power) Yes (power)
Yes (power) Yes (power) NO Yes (power) Yes (power)
Throw Ratio 1.2:1 1.35 –1.8:1 0.8:1 1.5 –2.0:1 1.2 –1.5:1 1.8 –2.9:1 2.0 –2.6:1 2.6 –3.5:1 3.5 –4.6:1 7.0:1 4.6 –6.0:1 6.2 –9.0:1
F Stop 2.5 2.5 –2.9 2.6 1.7 –2.3 2.3 –2.8 2.6 –3.5 2.0 –2.3 1.7 –2.6 2.0 –2.6 2.0 2.0 –2.9 2.2 –2.5
Lens Shift 8:1 –1:8 8:1 –1:8 1:1 8:1 –1:8 8:1 –1:8 10:0 –0:10 10:0 –0:10 8:1 –1:8 8:1 –1:8 8:1 –1:8 8:1 –1:8 8:1 –1:8
Weight 12.8 lbs. 5.5 lbs. 6.6 lbs 6.2 lbs. 6.6 lbs. 3.7 lbs. 4.2 lbs. 8.2 lbs. 4.2 lbs. 8.4 lbs. 6.8 lbs. 16.1 lbs.
* Lens sold separately
