SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
SanyoCompanyNovember,2009
SecurityProductsDivision
21605PlummerStreet
Chatsworth,CA91311
Phone:888.818.2597
Fax:818.717.27162239180
http://us.sanyo.com/security

ProductGuideSpecification












SECTION 28 23 29
VIDEO SURVEILLANCE REMOTE DEVICES AND SENSORS
Sanyo VCC-HD4600 4 MEGAPIXEL DAY/NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
PART 1 - GENERAL
1.1 SUMMARY
A. Section Includes
1. Video Surveillance Remote Devices
B. Related Sections
1. Section 28 23 13 – Video Surveillance Control and Management
Systems
2. Section 28 23 16 – Video Surveillance Monitoring and Supervisory
Interfaces
3. Section 28 23 19 – Digital Video Recorders and Analog Recording
Devices
4. Section 28 23 23 – Video Surveillance Systems Infrastructure
1.2 REFERENCES
A. Federal Communications Commission (FCC) (www.fcc.gov)
1. FCC CFR 47 part 15 Class B – Telecommunications – Radio
Frequency Devices – Digital Emission
B. International Electrotechnical Commission (IEC)
1. IEC 60529 Degrees of Protection provided by enclosures (IP Code)
SpecifierNotes:ThisproductguidespecificationiswrittenaccordingtotheConstructionSpecifications
Institute(CSI)3‐PartFormat,basedonMasterFormat2004andTheProjectResourceManual—CSIManual
ofPractice.TheManufacturerisresponsiblefortechnicalaccuracy.Byremovingthereferencestospecific
Sanyoproductnamesorpartnumbers,thetextmaybeusedalsoinperformance‐basedspecifications.

ThesectionmustbecarefullyreviewedandeditedbytheArchitectorEngineertomeettherequirementsof
theprojectandlocalbuildingcode.Wordsandsentenceswithinbrackets[]arechoicestoincludeor
excludeaparticularitemorstatement.Coordinatethissectionwithotherspecificationsectionsandthe
Drawings.

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
2. IEC 60950 Information Technology Equipment –Safety
C. Institute of Electrical and Electronics Engineers, Inc. (IEEE) (www.ieee.org)
1. IEEE 802.3af Power Over Ethernet
D. International Organization of Standardization (ISO)
1. 9001 – Quality System
E. Underwriters Laboratories, Inc. (UL) (www.ul.com)
1. UL 2043 Fire Test for heat and Visible Smoke Release for Discrete
Products and their Accessories Installed in Air-Handling Spaces
UL 2044 Commercial Closed-Circuit Television Equipment
1.3 SYSTEM DESCRIPTION
A. Video Surveillance Remote Devices
1. 4 Megapixel 1080p Full High Definition Day/Night Network CMOS
Camera with Audio.
B. Performance Requirements
1. Provide surveillance with high definition detail images – day or
night.
2. Possesses advanced intelligence features.
3. The camera shall be of manufacturer’s official product line,
designed for commercial/industrial continuous 24/7 use.
4. The camera shall be based upon standard components and proven
technology.
1.4 SUBMITTALS
A. Submit under provisions of Section [01 33 00.]
B. Product Data:
1. Manufacturer’s data, user and installation manuals for all
equipment and software programs including computer equipment
and other equipment required for complete video system.
C. Shop Drawings; include
1. System device locations on architectural floor plans.
2. Full Schematic of system, including wiring information for all
devices.
D. Closeout Submittals
1. User manual.
2. Parts list.
3. System device locations on architectural floor plans.
4. Wiring and connection diagram.
5. Maintenance requirements.
1.5 QUALITY ASSURANCE
A. Manufacturer:
1. Minimum of 10 years experience in manufacture and design Video
Surveillance Devices.
2. Manufacturer’s quality system: Registered to ISO 9001 Quality
Standard.
B. Video Surveillance System

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
C. Listed by UL and FCC specifically for the required loads. Provide evidence
of compliance upon request.
D. Installer:
1. Minimum of 5 years experience installing Video Surveillance
System.
2. All camera installation, configuration, setup, program and related
work shall be performed by electronic technicians thoroughly
trained by the manufacturer in the installation and service of the
equipment provided.
1.6 DELIVERY, STORAGE AND HANDLING
A. Comply with requirements of Section [01 60 00]
B. Deliver materials in manufacturer’s original, unopened, undamaged
containers; and unharmed original identification labels.
C. Protect stored materials from environmental and temperature conditions
following manufacturer’s instructions.
D. Handle and operate products and systems according to manufacturer’s
instructions.
PART 2 - PRODUCTS
2.1 MANUFACTURERS
A. Acceptable Manufacturer
Sanyo Company
Security Products Division
21605 Plummer Street
Chatsworth, CA 91311
Phone: [phone]
Fax: [phone]
http://us.sanyo.com/security
B. Substitutions: Under provisions of Division 1
1. All proposed substitutions must be approved by the Consultant, or
Architect/Engineer professional.
2. Proposed substitutions must provide a line-by-line compliance
documentation.
2.2 4 Megapixel 1080p Full High Definition Day/Night 10x AF Network Camera with
Audio
A. General Characteristics:
1. Be designed to provide advanced image support resolutions up to 4
Megapixels of effective picture elements 2320 2288(H) x 1728
1712(V).
2. Provide dual Codec for simultaneous H.264 and JPEG
transmission.
3. Be designed to provide 1080p H.264 compressed video at 30
frames per second.
4. Use a high quality 1/2.5” CMOS progressive scan image sensor
5. 10x Optical Zoom Auto Focus 4-Megapixel Rated Lens
6. Provide color pictures in light down to 2.0 lux at F 1.8
7. Provide B/W pictures in light down to 0.1 lux at F 1.8

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
8. Provide for Audio input and output directly to and from the camera
9. Be capable of accepting power from 12V DC, 24V AC or IEEE
802.3af Power-over-Ethernet (PoE)
10. Be capable of transmitting analog NTSC video for setup and
installation purposes
11. Be capable of storing images on-camera via SDHC storage
B. Camera shall be capable of the following adjustments and features:
1. Support the following connections/interfaces
a. 2 alarm inputs (NC/NO)
b. 2 alarm outputs (NC/NO)
c. 12V DC, 24V AC Power Input
d. Ethernet Port (Data and IEEE 802.3af PoE)
e. HDMI Output (1080p @ 30 ips)
f. Audio Mic In
g. Audio Line Out
h. USB 2.0 for External HDD (* requires dedicated HDD case)
i. SDHC Card Slot
j. BNC Analog Output for setup, 75 ohm, approx.1 volt peak to
peak
2. Ensure that any setup or instructional commands required to
program the camera, fine tune the camera or adjust any special
settings of the camera will be accomplished by using a simple on
screen display menu operated by control buttons on the side of the
camera.
3. Provide image stabilization.
4. The camera will provide a sixteen (16) character camera ID.
5. Provide selection of languages from English, French, German,
Japanese and Spanish.
6. Progressive Scan CMOS technology for image clarity.
7. Four (4) Megapixels maximum resolution
8. FourFive levels of operator privileges shall be available.
a. Admin level shall have full access to all functions.
b. Operator1 level shall have access to all functions except
Network settings.
c. Operator2level shall have access to all functions except
configuration settings.
d. Download level shall be restricted to downloading recorded
images only.
e. Guest will be restricted to monitoring live video only.
9. Provide Day & Night function allowing automatic changeover from
color mode to B&W mode as well as removal of an IR cut filter
during low light operation.
10. Automatic mechanical back-focus that provides Focus Assist
functionality to ensure images are always in focus and to remove
the need for IR-corrected optics for low-light use.

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
11. Camera shall have advanced programmable motion detection.
Selectable modes include
a. Motion Detection
b. Motion Masking
c. Off.
12. Human Face Detection shall be available in both Detection and
Masking modes selectable by area.
a. Up to 32 faces shall be detectable at once.
b. The camera shall tune its focus, BLC gain and other image
optimization controls via detected faces
c. The camera shall be able to transmit an alarm based on
detecting one or more faces and motion detection at the same
time in the scene.
13. The camera shall support digital trip wire functionality at no
additional cost
a. Up to 8 digital tripwires shall be configurable with independent
controls for length, angle, vector (left to right, right to left or
both) and tripwire sensitivity.
b. Up to 4 areas shall be configurable.
14. The camera shall support Back Light Compensation (BLC) circuitry
15. Provide HD image recording to an on-board SD memory card slot
(card optional)
16. Provide flexible on-board recording capability allowing recording by
Alarm (motion or input 1/2) including programmable pre-alarm
recording, or Back-up in the event of loss of network.
17. Provide internal verification whether or not any electronic alteration
was made to original images.
18. When image data is output on a conventional SD output
The camera shall reduce or eliminate “smearing” associated
caused by vertical noise associated with bright spots (such as
headlights).
C. Video Requirements and Adjustments:
1. Minimum Adjustments and Requirements
a. Imager: Progressive Scan 1/2.5"1/3” inch CMOS.
b. Pixels: 23202288(H) x 17281712(V) effective picture
elements.
c. Image Size: H.264 – 16:9 HD: 1920 x 1080p, 30 ips. H.264
HD: 1280 x 720p30 ips; 960 x 540p 30 ips; 640 x 360p30
ips; 320 x 180p30 ips. H.264 4:3: 1600x1200 30 ips; 1280 x
960p30 ips; 1024 x 768 30 ips; 720 x 480p 30 ips; 640x480
30 ips; 320 x 240p30 ips.
d. Image Size: MJPEG 16:9 HD: 1920 x 1080; HD 1280 x 720;
1024 x 576; 640 x 360. JPEG 4:3 4M: 2288 x 1712, 2M: 1600
x 1200, 1280 x 960; 1024 x 768; 800 x 600; 640 x 480; 320 x
240.

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
e. Iris Control: Selectable Auto/Manual. Selectable electronic
shutter in manual mode.
f. Shutter: Electronic range of 1/30, 1/60, 1/100, 1/250, 1/500,
1/1000, 1/2000, 1/4000, 1/10000. Long shutter: x1, x2, x4, x8,
x16, x32.
g. Synchronization: Internal synchronization.
h. Aperture Compensation: Selectable On/Off.
i. Minimum Color Illumination: 2.01.0 lux at F 1.81.2 Minimum
B/W Illumination: 0.1 lux at F 1.81.2
j. Signal to Noise Ratio: more than 50 dB (AGC off).
k. The camera shall provide selectable White Balance settings
include Auto-tracing White (ATW), AWC for technical support
adjustments; Outdoor, Indoor, Fluorescent and Manual control
(MWB). MWB allows individual red and blue adjustments.
l. The camera shall support Backlight Compensation: Selectable
Multi-spot metering, Center-zone metering, Face and Off.
Mask settings available.
m. Light Control: Optical auto iris lens or Electronic iris.
n. Auto-focus: Selectable Auto/Manual/One push. Selectable
focus area.
o. Day/Night: Selectable Auto/Color/Black and White.
p. AGC Gain: Selectable Normal/Middle/High/Off. Adjustable
gain control in Off mode.
q. Gamma: 0.45/1, other settings available.
r. Electronic Sensitivity Boost: Selectable Auto/Off. Max. 32x.
D. Operating Environment:
1. PC: IBM PC/AT or compatible.
2. Operating System: Windows XP Professional SP2 or Windows
Vista
3. CPU: Core2Duo E67008500 2.663.16 GHhz or higher.
4. Memory: Windows XP : 1 GB or more. Windows Vista: 2 GB or
higher.
5. Network Interface: 10/100Base-TX (RJ-45 connector).
6. Display Card: 1920 x 1200 pixels or higher.
7. Graphics Chip: ATI Radeon HD2600 series or higher; nVidia
GeForce 8600 series or higher; nVidia Quadro FX550 series or
higher.
8. Web Browser: Internet Explorer Ver 6.0 SP2 or higher, or Ver 7.0
E. IP Interfaces:
1. The camera shall use a dedicated video compression chip
(CODEC) and be equipped with a minimum of 8MB memory.
2. Protocols supported include TCP/IP, HTTP, HTTPS, UDP, SMTP,
FTP, DHCP, DDNS, NTP, RTP, RTSP.
3. Camera IP interface at 10 Base-T/100 Base-TX/PoE compatible.
4. The camera shall interface to Microsoft Internet Explorer ver 6.0
SP2 or higher or ver. 7.0 and higher via Plug-in module software

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
making video images and configuration menus available in a
standard browser environment using HTTP.
5. When accessed from a browser on-line, context sensitive help shall
be provided.
6. The camera shall provide an integral E-mail function for up to five
(5) E-mail addresses. E-mails can be automatically sent as an
alarm notification or at regular intervals. An image can be attached
to the e-mail in either case.
7. Web access protected by user ID and password. A maximum of
2016 users shall be assignable.
8. Camera shall maintain a transactional log when accessed via the
network containing the most recent 100 times and IP addresses of
those given access.
9. Camera shall maintain an “Up Log” showing power on time; SD
Memory record time; External HDD record time and a Camera High
Temperature warning.
10. Up to 200users may access a camera via the web server
simultaneously.
11. Two alarm inputs (NO/NC) shall be provided.
12. Two alarm output (NO/NC) shall be provided.
13. The camera shall support both fixed IP addresses and dynamically
assigned IP addresses provided by a Dynamic Host Control
Protocol (DHCP) server.
14. The camera shall be able to interface with SANYO Video Pilot
software. Video Pilot shall support full functionality when operating
on Windows Vista or Windows XP Professional Edition with
SP2/SP3.
15. Third party application integration of the camera is supported via
two (2) Development Kits which provide the necessary information
for interfacing. Contact SANYO for details.
16. Image quality selectable at Basic, Normal, Enhanced (default), Fine
and Super Fine.
17. Resolutions may be set for Live, Recorded and Transmitted modes.
18. Recording Time Examples:
CODEC Resolution Pic Quality Recording Bit Rate Record Hrs
16:9 Rate (max) (approx) Per 80GB
H.264 1920 x 1080 Enhanced 30 ips 6.0 Mbps 19.2
1280 x 720 Enhanced 30 ips 4.6 Mbps 25.0
640 x 360 Enhanced 30 ips 0.98 Mbps 115.6
1920 x 1080 Basic 30 ips 4.0 Mbps 28.7
1280 x 720 Basic 30 ips 2.5 Mbps 45.7

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
640 x 360 Basic 30 ips 0.46 Mbps 239.1
MJPEG 1920 x 1080 Enhanced 5 ips 8.96 Mbps 12.9
1280 x 720 Enhanced 10 ips 9.36 Mbps 12.3
1024 x 576 Enhanced 15 ips 9.00 Mbps 12.8
1920 x 1080 Basic 5 ips 3.4 Mbps 21.3
1280 x 720 Basic 10 ips 4.8 Mbps 24.0
640 x 360 Basic 30 ips 3.84 Mbps 29.9
* without audio recording
19. Selectable IP resolutions include:
a. 1920x1080 H.264
b. 1280x720 H.264
c. 640x360 H.264
d. 320x180 H.2645
e. 1920x1080 MJPEG
f. 1280x720 MJPEG
g. 1024x576 MJPEG
h. 640x360 MJPEG
i. 1600x1200 H.264
j. 1280x960 H.264
k. 1024x768 H.264
l. 640x480 H.264
m. 320x240 H.264
n. 2288x1712 MJPEG
o. 1600x1200 MJPEG
p. 1280x960 MJPEG
q. 1024x768 MJPEG
r. 800x600 MJPEG
s. 640x480 MJPEG
t. 320x240 MJPEG
F. Electrical:
1. Main supply input voltage:
a. 115VAC, 60Hz.
2. Camera input voltage/power requirements: 24V AC, 60Hz, 12-15V
DC, IEEE 802.3af PoE
3. Power Consumption: 15W(AC/DC) 12.3 W(PoE).
G. Mechanical:
1. Weight: 14.81 oz. (420430g).
2. Dimensions: 62.8 W x 64.2 H x 114.7 D mm (2.47” W x 2.53” H x
4.52” D)
H. Environmental:

SANYO VCC-HD4600 1080p 4 MEGAPIXEL DAY-NIGHT 10x AF NETWORK CAMERA WITH
AUDIO
Project Name/Project Number 28 23 29 - 20 Video Surveillance Remote Devices and Sensors
1. Operating Temperature: 14°F to 122°F (-10° to +50°C) within 90%
relative humidity.
2. Storage Temperature: -4°F to 158°F (-20°C to +70°C) within 70%
maximum relative humidity.
PART 3 - EXECUTION
3.1 EXAMINATION
A. Examine areas to receive devices and notify adverse conditions affecting
installation or subsequent operation.
B. Do not begin installation until unacceptable conditions are corrected.
3.2 PREPARATION
A. Protect devices from damage during construction.
3.3 INSTALLATION
A. Install devices in accordance with manufacturer’s instruction at locations
indicated on the floor drawings plans.
B. Perform installation with qualified service personnel.
C. Install devices in accordance with the National Electrical Code or applicable
local codes.
D. Ensure selected location is secure and offers protection from accidental
damage.
E. Location must provide reasonable temperature and humidity conditions,
free from sources of electrical and electromagnetic interference.
3.4 FIELD QUALITY CONTROL
A. Test snugness of mounting screws of all installed equipment.
B. Test proper operation of all video system devices.
C. Determine and report all problems to the manufacturer’s customer service
department.
3.5 ADJUSTING
A. Make proper adjustment to video system devices for correct operation in
accordance with manufacturer’s instructions.
B. Make any adjustment of camera settings to comply with specific customer’s
need.
3.6 DEMONSTRATION
A. Demonstrate at final inspection that video management system used with
devices functions properly.
END OF SECTION
