Sanyo FWSB405F User manual

Soundbar
FWSB405F A
Owner’s Manual
Manual del Propietario
INSTRUCCIONES SIMPLIFICADAS INCLUIDOS EN ESPAÑOL.
To obtain a more detailed electronic copy of this
manual or much further contents, go to
www.sanyo-av.com
Para obtener una copia electrónica más detallada de este manual o mucho otras
contenido, visite
Need help?
Please call toll free 1 866 212 0436 or visit our web site above:
¿Necesita ayuda? Llame por favor sin costo al 1 866 212 0436 ó visite nuestro sitio web en:

–2 –
EN
Included accessories Contents
PRECAUTIONS
( AAA x 2 )(NC305UH)
• Setup Manual • Remote control
• Batteries (AAA, 1.5V x 2)
• Line-in cable
PRECAUTIONS
IMPORTANT SAFETY INSTRUCTIONS�������������������������������������������� 3
ABOUT SOUNDBAR
Soundbar�������������������������������������������������������������������������������������������� 6
Top / front panels of soundbar .................................................6
Back connectors on soundbar..................................................6
Remote control���������������������������������������������������������������������������������� 7
Installing the batteries for the remote control .........................7
Operating with the remote control...........................................7
CONNECTIONS
Connect to TV ..........................................................................8
Connect audio from other device.............................................8
USING YOUR SOUNDBAR
Turning on the soundbar���������������������������������������������������������������� 10
Adjust the volume��������������������������������������������������������������������������� 11
Choosing preset sound������������������������������������������������������������������� 12
MAKING MORE USE WITH YOUR SOUNDBAR
Using a Bluetooth compatible device ������������������������������������������� 13
Pairing a Bluetooth compatible device with this unit.............13
Playing back a music file through Bluetooth..........................13
USEFUL TIPS
Resetting to the factory default mode������������������������������������������ 15
Installing the soundbar on a wall�������������������������������������������������� 16
INFORMATION
Troubleshooting guide ������������������������������������������������������������������� 17
Specifications����������������������������������������������������������������������������������� 18
LIMITED WARRANTY ���������������������������������������������������������������������� 19
Español��������������������������������������������������������������������������������������������� 20

–3 –
EN
Register online at www�sanyo-av�com today to get the most benefits from your purchase.
Registering your model with SANYO makes you eligible for all of the valuable benefits such as software
upgrades and important product notifications. Register online at www�sanyo-av�com
The model and serial numbers of this unit may be found on the cabinet.
You should record and retain those letters / numbers for future reference.
Model No.:
Serial No.:
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPARATUS TO RAIN OR MOISTURE.
APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The important note and rating are located on the rear or
bottom of the cabinet.
The symbol for CLASS ll (Double Insulation)
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type
plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/ accessories specified by the
manufacturer.
12.
Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/ apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
FCC WARNING
This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful
interference unless the modifications are expressly approved in the manual. The user could lose the authority to operate this
equipment if an unauthorized change or modification is made.
RADIO-TV INTERFERENCE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and receiver.
3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4) Consult the dealer or an experienced radio / TV technician for help.

–4 –
EN
Disconnect the mains (AC) plug to shut off when find trouble or not in use. The mains (AC) plug shall remain readily operable.
CAN ICES-3 (B)/NMB-3 (B)
This device complies with Industry Canada’s applicable licence-exempt RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.
WARNING: Batteries (Battery pack or battery installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
Do not place the unit on the furniture that is capable of being tilted by a child and an adult leaning, pulling, standing or climbing on it.
A falling unit can cause serious injury or even death.
In order to avoid interruption of ventilation, this unit should not be placed in built-in equipment such as a book cabinet, rack, etc.,
and the vents of this unit should not be covered with anything such as a tablecloth, curtain, newspaper, etc.
Make sure to leave a space of 4 inches (10 cm) or more around this apparatus.
Never use a gas duster on this unit. The gas trapped inside of this unit may cause ignition and explosion.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
When installing this unit in a temperate environment, avoid a place with rapid temperature changes.
This unit should not be used in a tropical environment as it has not been evaluated under such conditions.
No objects should be placed directly on or under this unit, especially lighted candles or other flaming objects.
Disposal of used batteries
The batteries included do not contain the heavy metals mercury and cadmium, however in certain localities, disposing batteries
with household waste is not permitted. Please ensure you dispose of batteries according to local regulations.
Mounting soundbar on a wall
• The recommended screw (sold separately) allows the mounting of the soundbar on the wall.
• Funai is not liable for any accident, damage or injury due to any improper installation, lack of strength of installation or improper use.
• Drill screw holes into the wall. Depending on the wall material, use molly anchor inserts to make sure the screws will not fall out.
Although the soundbar weighs approximately 5.3 lb/2.4 kg, it is recommended that the wall be able to support 15.9 lb/ 7.2 kg (three
times the weight of the soundbar) for extra safety. Recommended measurements are as follows: wall thickness of 2”/5 cm or more,
screw diameter of 5/32”/4 mm and, screw length of 1-3/16”/30 mm or more.
• Screw and molly anchor are sold separately and are not included.
Funai is not liable for these types kinds of accidents or injury noted below.
• Install two screws on a sturdy vertical wall.
• If installed onto a ceiling or slanted wall, the soundbar and screws may fall which could result in a severe injury.
• Do not use screws that are longer or shorter than their specified length. If screws too long or short are used this may cause the
soundbar to fall.
• Do not fasten screw’s and molly anchor’s with excessive force, this may damage the wall causing the soundbar to fall, leading to an
injury.
• Do not mount the soundbar onto screws while the soundbar is plugged in or turned on. It may result in an electrical shock injury.
When installing the soundbar on a wall, allow this much space.
Top: 4”/10 cm Left and right sides: 4”/10 cm
Bottom: 4”/10 cm Space between mounting screw and wall: 9/64”- 5/32”/3.5 - 4 mm
To Avoid the hazards of electrical shock and fire
• Do not handle the AC power cord with wet hands.
• Do not pull on the AC power cord when disconnecting it from
an AC outlet. Grasp it by the plug.
• Do not put your fingers or objects into the unit.
Location and handling
• Do not install the unit in direct sunlight, near strong magnetic
fields, or in a place subject to dust or strong vibration.
• Avoid a place with drastic temperature changes.
• Install the unit in a horizontal and stable position. Do not place
anything directly on top or bottom of the unit.
Depending on your external devices, noise or disturbance of
the picture and / or sound may be generated if the unit is placed
too close to them. In this case, please ensure enough space
between the external devices and the unit.
• Depending on the environment, the temperature of this unit
may increase slightly. This is not a malfunction.
• Be sure to Unplug the AC power cord from the AC outlet before
removing the unit.
Dew condensation warning
• Dew condensation may form inside the unit in the following
conditions. If so, do not use this unit at least for a few hours
until its inside gets dry.
– The unit is moved from a cold place to a warm place.
– Under conditions of high humidity.
– After heating a cold room.
Note about recycling
• This unit’s packaging materials are recyclable and
can be reused. Please dispose of any materials in
accordance with your local recycling regulations.
• Batteries should never be thrown away or incinerated
but disposed of in accordance with your local regulations
concerning chemical wastes.
• For product recycling information, please visit -
www.sanyo-av.com
Click on

–5 –
EN
TRADEMARK INFORMATION
The Bluetooth®word mark and logos
are registered trademarks owned
by Bluetooth SIG, Inc. and any use
of such marks by Funai Electric
Co., Ltd. is under license. Other
trademarks and trade names are
those of their respective owners.
MAINTENANCE
Servicing
• Please refer to relevant topics on the “Troubleshooting
guide” on page 17. If you cannot find any solution there,
our service center is pleased to assist you.
• Even if this unit becomes inoperative, do not open the
cabinet to repair it by yourself. There are no user-serviceable
parts inside.
Turn off the unit, unplug the AC power cord and then call
our support center mentioned on the front page.
Before calling, please check model and serial number on
the unit.
Cleaning the cabinet
• Wipe the front panel and other exterior surfaces of the unit
with a soft cloth.
• Never use a solvent, thinner, benzene or alcohol to clean the
unit. Do not spray insecticide liquid near the unit.
Such chemicals may discolor the surface or damage the
unit.
SANYO is a registered trademark of SANYO Electric Co., Ltd.
and is used by Funai Electric Co., Ltd. and Funai Corporation,
Inc. under license from SANYO Electric Co., Ltd.
Any liability related to SANYO products, including design and
quality, is the sole responsibility of Funai Electric Co., Ltd. and
Funai Corporation, Inc.
Please contact Funai Corporation, Inc. for any questions or
claims related to SANYO products:
www.sanyo-av.com
© 2017 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be
reproduced, copied, transmitted, disseminated or transcribed,
in any form or for any purpose without the express prior
written consent of Funai. Furthermore, any unauthorized
commercial distribution of this manual or any revision hereto
is strictly prohibited.
Information in this document is subject to change without
notice. Funai reserves the right to change the content herein
without the obligation to notify any person or organization of
such changes.

–6 –
EN
ABOUT SOUNDBAR
Soundbar
Top / front panels of soundbar
LED indicators LED color Description
POWER
(Standby indicator) red On when soundbar is in standby mode.
Off when soundbar is turned on.
AUX(iliary) INPUT orange On up when you switch to analog input source.
LINE INPUT orange On when you switch to line-in source (3.5 mm jack).
OPTICAL INPUT orange On when you switch to optical input source.
PAIR(ing) INPUT
(Bluetooth) blue
On when you switch to Bluetooth mode and Bluetooth
compatible devices are paired.
Blinks when Bluetooth pairing is activated and pairing failed.
Back connectors on soundbar
4
1
2
3
OPTICALOPTICAL IN
LINE
LINE IN
AUX
AUX IN
Connectors Description
1AUX(iliary) IN(put) Connect to an analog audio output on the TV or an analog device.
2LINE IN(put) Connect to a TV or an MP3 player.
3OPTICAL IN(put) Connect to an optical digital audio output on the TV or a digital device.
4Wall mount hooks Install on a wall if desired.

–7 –
EN
Operating with the remote control
1
2
3
4
5
6
7
8
9
10
11
12
Buttons Description
1
Press to turn on the unit, or to switch the unit
into standby mode.
(To completely turn off the unit, you must
unplug the AC power cord.)
2Press to switch to the standard preset sound.
3Press to switch to the preset sound for music.
4Press to mute the sound and press again to
unmute the sound.
5Press to select optical input of the connected
device to this soundbar.
6Press to select line input of a connected device
to this soundbar.
7Press to select auxiliary input of a connected
device to this soundbar.
8Press to adjust volume up / down on the
soundbar.
9Press to switch to the preset sound for a
movie.
10
Press to switch to the preset sound for news
scene.
11
Press to select Bluetooth signal of a connected
device to this soundbar.
12
Press to disconnect the currently connected
Bluetooth compatible device and start pairing
mode to establish a new connection to another
Bluetooth compatible device.
If no Bluetooth compatible device is connected
within 2 minutes, press this button to restart
pairing mode. Pairing mode can only be started
when Bluetooth is selected.
Remote control
Installing the batteries for the remote control
Install 2 AAA (1.5V) batteries matching the polarity indicated inside battery compartment of the remote control.
1 2 3
• The maximum operable ranges from the unit are as follows.
– Line of sight: approx. 23 feet (7m)
– Either side of the center: approx. 16 feet (5m) within 30°
– Above: approx. 16 feet (5m) within 15°
– Below: approx. 10 feet (3m) within 30°
NOTE(S)
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh, Li-ion, etc) batteries.
• Do not mix old and new batteries.
• Always remove batteries from the remote control if they are dead or if the remote control is not to be used for an
extended period of time. This will prevent battery acid from leaking into the battery compartment.

–8 –
EN
CONNECTIONS
Included cables used in this connection are as follows:
• Line-in cable × 1
1Connect to a device
Connect to TV
Rear of TV
HEADPHONE
DIGITAL AUDIO
OUT (OPTICAL)
or
Rear of soundbar
OPTICALOPTICAL IN
LINE
LINE IN
Most modern digital TVs do not have red and white coaxial analog audio outputs, but do have red and white coaxial analog audio
inputs. If you plan to use red and white analog coaxial cables to connect your TV to this soundbar, please ensure that your TV
does indeed have red and white coaxial analog audio out. Refer to your TVs user manual for details.
To connect soundbar directly to other devices (Blu-ray player, game system, etc.), see your device's user manual.
Use a coaxial (RCA) to opticalToslink digital audio converter (not included) if your TV only has coaxial audio out.
Digital audio
optical cable
(not included)
Analog
line-in cable
included Good
Good
Best
Best
Connect audio from other device
R
AUDIO OUT
L
DIGITAL AUDIO
OUT (OPTICAL)
Analog audio cable
(not included)
e.g.) Video game HEADPHONE
e.g.) MP3 player
Analog line-in cable
included
e.g.) Blu-ray player
OPTICALOPTICAL IN
LINE
LINE IN
AUX
AUX IN
Rear of soundbar
Digital audio
optical cable
(not included)
NOTE(S)
• Make sure the soundbar is turned off when connecting cables.
• Check whether all connection cables are properly connected.
• If you connect from the headphone output on the device’s source to the line-input on the soundbar, make sure the
volume from the headphone output on the device’s source is set to an appropriate mid-level sound. Setting it too
low will produce weak output from the soundbar or setting it too high could cause distortion.
• If a line / optical / AUX connection fails when connected to a TV, check the audio settings on the devices.
Continued on next page.

–9 –
EN
2Connect AC power cord from soundbar to an electric outlet.
Rear of soundbar

–10 –
EN
USING YOUR SOUNDBAR
Turning on the soundbar
1Press on the remote control.
2Select input source.
e.g.) When was pressed.
• One of the INPUT indicators will light up when you switch to your connected source.
• For Bluetooth connections, refer to “Playing back a music file through Bluetooth” on page 13.

–11 –
EN
Adjust the volume
1To increase or decrease the volume, press VOL +/
- on the remote control.
Volume levels LED lighting patterns LED behavior
0 - 5
(6 levels)
Lights up for 3 seconds
(default: level 13)
6 - 11
(6 levels)
12 - 17
(6 levels)
18 - 23
(6 levels)
24 - 29
(6 levels)
• When pressing VOL+/ - , the indicator(s) will show the current volume. Pressing VOL+/ - while the current volume is
shown will increase/decrease the volume.
• Pressing and holding VOL+ or VOL
- will increase or decrease the volume and the Indicator(s) will blink. When the
volume has reached the maximum or minimum, the indicator(s) will stop blinking.
2To mute the sound, press on the remote control.
Volume levels LED lighting patterns LED behavior
Mute
e.g.) When OPTICAL was selected
Red indicator blinks continuously.
• To restore the sound, press again or press VOL +/
- .
NOTE(S)
• The volume might be influenced by MP3 or Bluetooth player. If the volume is too low, adjust the volume on the
connected device.
• If the volume level is set above 18 when the soundbar is turned off, the volume will automatically be reset to 18
when the soundbar is turned back on.

–12 –
EN
Choosing preset sound
1Press either , , , or on the remote control to select the desired preset
sound suitable for the audio that is playing.
2The OPTICAL LED blinks orange once.
3When the preset sound setting is set, LED indicators go back to the current input.
NOTE(S)
• Select any preset sound according to your preference, regardless of categories.
• The default preset sound is MOVIE.
• This setting will remain while the soundbar is in standby mode.

–13 –
EN
MAKING MORE USE WITH YOUR SOUNDBAR
Using a Bluetooth compatible device
Pairing a Bluetooth compatible device with this unit
1Press BLUETOOTH on the remote control to switch the soundbar to Bluetooth mode.
2Turn your Bluetooth compatible device on and activate the Bluetooth setting.
(See the user manual of the Bluetooth compatible device on how to enable Bluetooth.)
3On your Bluetooth compatible device search for and select “SANYO_FWSB405F” or “2.0ch
Soundbar” to pair (or register) your soundbar with your Bluetooth compatible device.
• If a passcode is requested, enter “0000”.
• If the soundbar name does not appear on the Bluetooth compatible device, press
PAIR on the remote control.
4When the pairing is complete, your Bluetooth compatible device may show “Connected” on
the display.
Playing back a music file through Bluetooth
1Press BLUETOOTH on the remote control to switch the soundbar to Bluetooth mode.
• The PAIR (Bluetooth) indicator will light up.
2Turn your Bluetooth compatible device on and activate the Bluetooth setting.
(See the user manual of the Bluetooth compatible device on how to enable Bluetooth.)
• If you have already paired your Bluetooth compatible device and the device’s Bluetooth is on then the soundbar should
connect to it automatically.
• If the soundbar name does not appear on the Bluetooth compatible device, press
PAIR on the remote control.
3Playback a music file on the connected Bluetooth compatible device.
• You may use, , and on the soundbar’s remote control once the Bluetooth compatible device is properly
connected to this soundbar.
4
To exit Bluetooth mode, press one of the other INPUT source buttons on the remote control.
Continued on next page.

–14 –
EN
The following chart describes behavior of the PAIR indicator and to-do’s for playback, according to each behavior sequence of
the PAIR indicator.
PAIR indicator behavior
(The arrow indicates the passage of time.)
The current status of Bluetooth and the procedures to
complete Bluetooth connection for Bluetooth playback.
1Blinks twice g
light off grepeats
Waiting for a new Bluetooth compatible device to connect (status:
pairing). On the Bluetooth compatible device to connect, select the
soundbar’s name (*1), then connect.
2Remains lit
A Bluetooth compatible device is connected.
Music can be played from the connected Bluetooth compatible
device (*2).
3Blinks slowly
No Bluetooth compatible device is connected. To reconnect with
the last connected Bluetooth compatible device, press
BLUETOOTH (*2).
4Blinks rapidly
Trying to connect with the last connected Bluetooth compatible
device. Enable Bluetooth on the last connected Bluetooth compatible
device and wait a moment (*2).
5Remains unlit
Either another audio input is selected or the soundbar is in standby.
If all indicators are off, press to turn on the soundbar. When all
indicators except the blue LED are lighting up or blinking, press
BLUETOOTH. The (Bluetooth) indicator will start blinking or light up.
Follow 1-4 in this chart.
*1 This soundbar’s name is “SANYO_FWSB405F” or “2.0ch Soundbar”. If this soundbar has already been registered to a
Bluetooth compatible device and the connection fails, delete it (or deactivate it), then press PAIR and select this
soundbar’s name to connect.
*2 To play music from a different Bluetooth compatible device, press
PAIR , then select this soundbar’s name on the
Bluetooth compatible device to connect (*1).
NOTE(S)
• If reconnecting the Bluetooth compatible device to the soundbar fails, delete the registered profile of this soundbar
from the Bluetooth compatible device, then perform pairing again.
This unit can store up to 4 device profiles.
• The music streaming may be interrupted by obstacles between the device and soundbar, such as wall, metallic
casing that covers the device, or other devices nearby that operate in the same frequency.
• If you want to connect your soundbar with another Bluetooth compatible device, press
PAIR to disconnect the
current connection.
• Depending on your Bluetooth compatible device, different behaviors may appear.
See your Bluetooth compatible device’s user manual for details.
• The operational range between the soundbar and a Bluetooth compatible device is approximately 30 feet (10 m), if
there is no interference or obstacles.

–15 –
EN
USEFUL TIPS
Resetting to the factory default mode
You can delete the Bluetooth profiles that are stored on the unit by resetting to the factory default mode.
1Press to turn the soundbar on.
2Press
PAIR 5 times within 3 seconds.
• All LED indicators will blink during resetting.
After completing resetting, the soundbar will be shut down and go into standby mode.
• All registered Bluetooth profiles will be deleted.
Pairing the Bluetooth setting to this unit again when you want to play back a music file through the Bluetooth compatible
device.

–16 –
EN
Installing the soundbar on a wall
1Purchase the screws (x 2) by length/diameter below, now make screw holes on the vertical
interior wall.
• There is a “Wall mounting template” on page 18 or in the setup manual.
9/64"~5/32"/3.5~4 mm
Molly anchor
>1-3/16"/30 mm
5/32"/4 mm
7-1/2"/190 mm
2Hang the soundbar over the screws.
~3/16"/5 mm
~3/8"/9 mm
NOTE(S)
• Use the “Wall mounting template” when you make the screw holes on the wall.
Print out the page 18 or use the setup manual and place “Wall mounting template” on the wall where the
soundbar is to be installed, to determine screw locations.
Funai is not liable for these types of accidents or injury noted below�
• Do not mount the soundbar onto the wall while your soundbar is plugged in or turned on.
It may result in an electrical shock injury.
• Install the screws on a sturdy vertical wall.
If installed onto a ceiling or slanted wall, the soundbar may fall which could result in a severe injury.
• Make sure that the wall where you are mounting the soundbar is appropriate.
Some mounts are not designed to be mounted to walls with steel studs or cinder block construction.
If you are unsure, contact a professional installer.
• Do not fasten the screws using excessive force.
This may damage the product or cause the product to fall, leading to an injury
.
• Never allow children to climb on or play on the soundbar.
(OPTIONAL)

–17 –
EN
INFORMATION
Troubleshooting guide
If the unit does not perform properly when operated as instructed in this owner’s manual, refer to the following.
Problem Corrective action
No power (no LED lights will be
seen)
– Check if the AC power cords are properly connected.
– Unplug AC power cords from soundbar, wait for 20 seconds. Then plug in the soundbar, immediately
turn the soundbar on using the remote control.
No sound – Make sure the TV, other devices and soundbar are all turned on.
– Make sure unit is connected to an audio output on your device.
– Press INPUT source buttons on your soundbar remote control to select the correct audio input.
– Confirm that the soundbar is not muted. Press the VOL +/
-
or button(s) on the remote control to
unmute the sound. (See “Adjust the volume” on page 11 )
– For optical audio connection, select another audio signal on the connected external device.
(This product supports LPCM)
– Depending on the usage and usage environment, chatter sound and distorted sound may be
generated. To reduce such sounds, lower the volume.
If input is optical sound make sure that the optical cable connector is completely inserted into the
terminal (Click sound is heard when properly inserted).
Distorted sound – Adjust the sound settings on your connected device.
– Adjust the headphone volume on some TV’s if you connect this unit to the headphone jack on your TV
using the included 3.5 mm line-in cable.
– Decrease the volume on the connected Bluetooth compatible device.
Abnormal noise is generated. – Be sure the cable(s) are plugged in all the way.
No reaction to the remote control. – Confirm that the soundbar AC power cord is plugged into a power outlet.
– Check the batteries in remote control and make sure they are properly Inserted using + or
-
symbols.
– Aim Remote at the Center of this unit.
– Use a digital or phone camera pointing the remote control at the camera lens and press any remote
button. If remote IR LED(s) flash on camera display, then the remote is transmitting a signal. Some
phone cameras have IR filter(s) in their lens, therefore you will not see the IR LED(s) flash.
– If the remote control does not work and all LEDs on the soundbar stay lit for over 30 seconds, there is
a failure in the electrical system. Unplug the AC power cord and contact the service center.
An external device cannot
connect with the soundbar via
Bluetooth.
– Confirm that the external device is compatible with the audio signals supported by the soundbar.
– Confirm that Bluetooth is enabled on the external device. See the user manual on the external device
on how to enable Bluetooth.
– If reconnecting the Bluetooth compatible device to the soundbar fails, delete the registered profile of
this soundbar from the Bluetooth compatible device, then perform pairing again.
This unit can store up to 4 device profiles.
– Another Bluetooth compatible device is already connected to the soundbar. Disconnect the connected
device, then try again.
Poor sound quality from the
connected Bluetooth compatible
device.
– The Bluetooth reception may be poor. Confirm that there is no obstacle between the Bluetooth
compatible device and the soundbar. If this does not improve the sound quality, move the Bluetooth
compatible device closer to the soundbar.
Unstable connection between the
Bluetooth compatible device and
the soundbar.
– The Bluetooth reception may be poor. Confirm that there is no obstacle between the Bluetooth
compatible device and the soundbar. If this does not improve the sound quality, move the Bluetooth
compatible device closer to the soundbar.

–18 –
EN
Specifications
Power requirements 120V AC +/- 10%, 60Hz +/ - 0.5%
Output power 26W
Dimensions (width x height x depth) 39.3 x 3.1 x 3.1 inches (999 x 77 x 77 mm)
Weight 4.41 lbs. (2.0kg)
Bluetooth Bluetooth profile: A2DP
Bluetooth version: 4.1
Optical input Linear PCM (LPCM) 96kHz/24bit Max
• Designs and specifications are subject to change without notice.
• If there is a discrepancy between languages, the default language will be English.
Center line
Wall mounting template
3-3/4” (95 mm) 3-3/4” (95 mm)

sanyo-av.com
This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.
FUNAI CORPORATION, Inc. 19900 Van Ness Avenue, Torrance, CA 90501
LIMITED WARRANTY
NINETY (90) DAY LABOR / ONE (1) YEAR PARTS
WARRANTY COVERAGE:
This warranty obligation is limited to the terms as set forth below.
WHO IS COVERED:
This product warranty is issued to the original purchaser or the
person receiving the product as a gift against defects in materials
and workmanship as based on the date of original purchase
(“Warranty Period”) from an authorized dealer.The original sales
receipt showing the product name and the purchase date from an
authorized retailer is considered such proof.
WHAT IS COVERED:
This warranty covers new products if a defect in material or
workmanship occurs and a valid claim is received within the
Warranty Period. At its option, the company will either (1) repair the
product at no charge, using new or refurbished replacement parts,
or (2) exchange the product with a new or refurbished product at
company’s option.
Replacement products or parts provided under this warranty are
covered against defects in materials and workmanship from the
date of the replacement or repair for ninety (90) days or for the
remaining portion of the original product’s warranty, whichever
provides longer coverage for you. When a product or part is
exchanged, any replacement item becomes your property and the
replaced item becomes company property.When a refund is given,
your product becomes company property.
Note: Any product sold and identified as refurbished or renewed
carries a ninety (90) day limited warranty.
Replacement product can only be sent if all warranty requirements
are met. Failure to follow all requirements can result in delay.
WHAT IS NOT COVERED - EXCLUSIONS AND LIMITATIONS:
This limited warranty applies only to new company manufactured
products that can be identified by the trademark, trade name, or
logo affixed to it. This limited warranty does not apply to any
hardware product or any software, even if packaged or sold with
the product, as manufacturers, suppliers, or publishers may
provide a separate warranty for their own products packaged with
the bundled product.
The company is not liable for any damage to or loss of any
programs, data, or other information stored on any media
contained within the product, or other additional product or part
not covered by this warranty. Recovery or reinstallation of
programs, data or other information is not covered under this
limited warranty.
This warranty does not apply (a) to damage caused by accident,
abuse, misuse, neglect, misapplication, or non-supplied product,
(b) to damage caused by service performed by anyone other than
company approved authorized service location, (c) to a product or
a part that has been modified without written company permission,
or (d) if any serial number has been removed or defaced, or (e)
product, accessories or consumables sold “AS IS” without
warranty of any kind by including refurbished product sold “AS IS”
by some retailers.
This LimitedWarranty does not cover:
• Shipping costs for returning defective product.
• Labor charges for installation or setup of the product,
adjustment of customer controls on the product, and installation
or repair of antenna/signal source systems outside of the
product.
• Product repair and/or part replacement because of improper
installation or maintenance, connections to improper voltage
supply, power line surge, lightning damage, retained images or
screen markings resulting from viewing fixed stationary content
for extended periods, product cosmetic appearance items due
to normal wear and tear, unauthorized repair or other cause not
within the control of the company.
• Damage or claims for products not being available for use, or for
lost data or lost software.
• Damage from mishandled shipments or transit accidents when
returning product.
• A product that requires modification or adaptation to enable it to
operate in any country other than the country for which it was
designed, manufactured, approved and/or authorized, or repair
of products damaged by these modifications.
• A product used for commercial or institutional purposes
(including but not limited to rental purposes).
• Product lost in shipment and no signature verification receipt
can be provided.
• Failure to operate per owner’s manual.
TO OBTAIN ASSISTANCE…
Contact the customer care center at:
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS
WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER,
WITHTHE ISSUING COMPANY NOT LIABLE FOR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE
EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN
DURATIONTO THE DURATION OFTHIS WARRANTY.
Some states do not allow the exclusions or limitation of incidental
or consequential damages, or allow limitations on how long an
implied warranty lasts, so the above limitations or exclusions may
not apply to you.
www.sanyo-av.com
1 866 212 0436
LIMITED WARRANTY

ES –20 –
Español
1Conexiones
Para conectar a una TV, consulte “CONNECTIONS
(CONEXIONES)” en la página 8 y verifique las
terminales de la TV, después conecte su barra de sonido
a la TV, y conecte el cable de energía CA. Para reproducir
audio a través de un dispositivo Bluetooth, consulte
“Playing back a music file through Bluetooth (Reproducir
audio a través de Bluetooth)” en la página 13 y conecte
el dispositivo Bluetooth a su barra de sonido.
2Instalación de las pilas en el control remoto
1 2 3
3Reproducción
1
2
1Presione para encender su
barra de sonido.
2Presione el botón de fuente
INPUT (entrada) y confirme que se
enciendan las luces del indicador
de fuente INPUT correctas.
ej.) Cuando se presiona.
• Uno de los indicadores de fuente se encenderá cuando
cambie a la entrada conectada.
4Control remoto
Botón Especificatión
Presione para encender la unidad, o para cambiar la
unidad en modo de espera.
(Para apagar completamente la unidad, debe
desconectar el cable de energía CA.)
Presione para cambiar el sonido preestablecido
estándar.
Presione para cambiar el sonido preestablecido
para música.
Presione para silenciar el sonido y recuperar el
sonido.
Presione para seleccionar óptico de los dispositivos
conectados a esta barra de sonido.
Presione para seleccionar línea de los dispositivos
conectados a esta barra de sonido.
Presione para seleccionar AUX de los dispositivos
conectados a esta barra de sonido.
Presione para subir / bajar el volumen da la barra de
sonido.
Presione para cambiar el sonido preestablecido
para películas.
Presione para cambiar el sonido preestablecido
para noticias.
Presione para seleccionar Bluetooth de los
dispositivos conectados a esta barra de sonido.
Presione para desconectar el dispositivo Bluetooth
conectado actualmente y comenzar el modo de
conexión para establecer una nueva conexión a
otro dispositivo Bluetooth. Si no se conecta un
dispositivo Bluetooth dentro de 2 minutos, presione
este botón para reiniciar el modo de conexión. El
modo de conexión sólo puede iniciar cuando se
selecciona Bluetooth.
