Sanyo AVM-3259G User manual

AS
AS
AVM-3259G
“As an ENERGY STAR®Partner,
Sanyo has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.”
Printed in U.S.A. SMC, September 2001/Impreso en U.S.A. SMC, Septiembre 2001
Part No. / No. de Parte : 1AA6P1P2589A–
Service Code/Código de Servicio : 610 289 2949
Color TV Owner’s Manual
Color TV Manual
Del Propietario
TV screen image / Imagen de la Pantalla del
Televisor © 2001 PhotoDisc, Inc.
AS
CONTENTS
Important Safety Tips . . . . . . . . . . . . . . . . . . . . 2
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Basic Hookup Methods . . . . . . . . . . . . . . . . . . . 4
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Multimedia Remote Control . . . . . . . . . . . . 5 ~ 8
TV Adjustment and Setup . . . . . . . . . . . . 9 ~ 10
Resetting the TV . . . . . . . . . . . . . . . . . . . . . . . 11
Setting the Sleep Timer . . . . . . . . . . . . . . . . . 11
Using the Audio Output Jacks . . . . . . . . . . . . 11
Using the Audio/Video Input Jacks . . . . . . . . 12
Closed-Captioning . . . . . . . . . . . . . . . . . . . . . 13
V-Guide Information . . . . . . . . . . . . . . . . . . . . 14
V-Guide Operation (Parental Control) . . 14 ~ 15
Troubleshooting . . . . . . . . . . . . . . . . . . . 16 ~ 18
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . 18
Warranty and Service . . . . . . . . . . . . . . . . . . . 19
Child Safety Matters . . . . . . . . . . . . . Back cover
ESPAÑOL . . . . . . . . . . . . . . . . . . . . . . . . 20 ~ 39
Contenido . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Welcome to the World of Sanyo
Thank you for purchasing a Sanyo Color Television. You made
an excellent choice for Performance, Reliability, and Value. The
TV is designed with easy on-screen set-up instructions and
operating features. To meet the growing needs of our cus-
tomers, this television has a “V-Chip” for parental controlled
viewing. “Read this manual before assembling (or using) this
product.” Need assistance? Visit our web site at
www.sanyoctv.com.

2
Positioning the appliance
1. Do not place your appliance on an unstable cart, stand, shelf or table.
Serious injury to an individual, and damage to the appliance, may result
if it should fall. Your salesperson can recommend approved carts and
stands or shelf and wall mounting instructions. An appli-
ance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may
cause the appliance and cart combination to overturn.
2. Slots and openings in the cabinet and in the back or bottom are
provided for ventilation. To ensure reliable operation of the appliance and
to protect it from overheating, these openings must not be blocked or
covered. The openings should never be covered with a cloth or other
material, and the bottom openings should not be blocked by placing the
unit on a bed, sofa, rug, or other similar surface. This appliance should
never be placed near or over a radiator or heat register. This appliance
should not be placed in a built-in installation such as a bookcase unless
proper ventilation is provided.
3. Do not expose the appliance to rain or use near water . . . for example,
near a bathtub, swimming pool, kitchen sink, in a wet basement, etc.
Hooking Up Outdoor Antenna
LIGHTNING PROTECTION FOR YOUR ANTENNA AND SET AS PER
NATIONAL ELECTRICAL CODE INSTRUCTIONS.
4. If an outside antenna is connected to the receiver, be sure the antenna
system is grounded so as to provide some protection against voltage
surges and built up static charges. Article 810 of the National Electrical
Code, ANSI/NFPA 70, provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead in
wire to an antenna discharge unit, size of grounding conductors,
location of antenna discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
An outside antenna system should not be located in the vicinity of over-
head power lines or other electric light or power circuits, or where it can
fall into such power lines or circuits. When installing an outside antenna
system extreme care should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.
Plug in the power cord
5. This product should be operated only from the type of power source indi-
cated on the marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or local power
company. This product is equipped with a polarized alternating current
line plug (a plug having one blade wider than the other). This plug will fit
into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to replace your obso-
lete outlet. Do not defeat the safety purpose of this polarized plug. Do not
overload wall outlets, extension cords, or integral convenience recepta-
cles as this can result in a risk of fire or electric shock.
6. Power-supply cords should be routed so that they are not likely to be
walked on or pinched by items placed upon or against them, paying par-
ticular attention to cords at plugs, convenience receptacles, and the point
where they exit from the product.
Cleaning
7. Before cleaning,unplugtheunit fromthe walloutlet. Donot applyliquid clean-
ers or aerosol cleaners directly to the unit. Use a damp cloth for cleaning.
Service & Repair
8. Unplug the appliance from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
A. If the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the appliance.
C. If the appliance has been exposed to rain or water.
D. If the appliance has been dropped or the cabinet has been damaged.
E. If the appliance exhibits a distinct change in performance.
F. If the appliance does not operate normally by following the operating
instructions, adjust only those controls that are covered in the oper-
ating instructions. Improper adjustment of other controls may result
in damage and will often require extensive work by a qualified tech-
nician to restore the appliance to normal operation.
9. Upon completion of any service or repair, request the service techni-
cian’s assurance that only Factory Authorized Replacement Parts that
have the same characteristics as the original parts were used, and that
routine safety checks have been performed to determine that the appli-
ance is in safe operating condition. Unauthorized substitutions may
result in fire, electrical shock, or other hazards.
10. Never add accessories that have not been specifically designed for use
with this appliance as they may cause hazards.
11. For added protection during a lightning storm, or when the set is left
unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna. This will prevent damage to the set
due to lightning or power line surges.
12. Never push objects of any kind into this product through openings as
they may touch dangerous voltage points or short-out parts that could
result in a fire or electric shock. Never spill liquid of any kind on the
product.
EXAMPLE OF ANTENNA GROUNDING ACCORDING TO NATIONAL
ELECTRICAL CODE, ANSI/NFPA 70
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THIS SYMBOL INDICATES THAT DANGEROUS VOLTAGE CONSTITUTING
A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT.
THIS SYMBOL INDICATES THAT THERE ARE IMPORTANT OPERATING
AND MAINTENANCE INSTRUCTIONS IN THE LITERATURE ACCOMPANY-
ING THIS UNIT.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE ADHERE TO ALL WARNINGS ON THE PRODUCT AND IN THE OPERATING INSTRUCTIONS. BEFORE
OPERATING THE PRODUCT, PLEASE READ ALL OF THE SAFETY AND OPERATING INSTRUCTIONS. RETAIN THIS
LITERATURE FOR REFERENCE. Follow all instructions...
“Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Article 820-40
of the NEC that provides guidelines for proper grounding and, in particular, specifies that
the cable ground shall be connected to the grounding system of the building, as close to
the point of cable entry as practical.”
NEC - NATIONAL ELECTRICAL CODE
ANTENNA
LEAD IN
WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

SPECIFICATIONS
PICTURE TUBE SIZE
(Measured Diagonally) . . . . . . . . . . 32-inch screen
PICTURE RESOLUTION . . . . . . . . . 330 Lines
. . . . . . . . . . . . . . . . . . . . . . . . . . . Video Input 600 Lines
ANTENNA INPUT . . . . . . . . . . . . . . UHF/VHF/CATV 75Ω
POWER REQUIREMENT . . . . . . . . . 120VAC 60Hz
POWER . . . . . . . . . . . . . . . . . . . . . 89 watts
HORIZONTAL DIM. (Width) . . . . . . . 30.0 in. (762mm)
VERTICAL DIM. (Height) . . . . . . . . 27.8 in. (707mm)
DEPTH DIM. (Thickness) . . . . . . . 21.2 in. (538mm)
WEIGHT (Approx.) . . . . . . . . . . . . . 108.6 lbs. (49.3 Kg.)
SOUND . . . . . . . . . . . . . . . . . . . 2 Speakers, Size 10 cm
AMPLIFIER . . . . . . . . . . . . . . . . . . Built-in with 3.0W
A/V INPUT JACKS . . . . . . . . . . . . . Video Input and Audio Input
. . . . . . . . . . . . . . . . . . . . . . . . . . . (2 sets-R/L), S-Video Input
AUDIO OUTPUT JACKS . . . . . . . . . Audio Output (R/L-Fixed)
. . . . . . . . . . . . . . . . . . . . . . . . . . . (RCA Connectors)
3
◆Trilingual On-Screen Menu
◆Automatic Channel Search
◆Auto Shut Off
◆Closed-Captioning/QuikCap
◆Comb Filter
◆Digital picture controls
with on-screen display
◆MTS stereo/dbx®/SAP
Decoder
◆Color Enhancer
◆Auto Flesh Tone
◆XDS (Extended data service)
station call letters, title of
show, ratings
◆Factory preset adjustments
for picture/sound
◆Initial Channel
◆Bass/Treble
◆Audio/Video Input Jacks
(2 sets-R/L)
◆S-Video Input Jack
◆Audio Output Jacks
(Fixed levels)
◆V-Guide (Parental Control)
◆Clock
◆Sleep Timer (3 hours)
◆TV Reset
181 Channel Tuning System
VHF Channels 2-13
UHF Channels 14-69
Cable TV (CATV) 1, 14-125
Automatic Fine Tuning
VHF and Cable Channels
Remote Control
Multimedia/Universal
VCR/TV/AUX
Large Glow-in-the-Dark basic
operating keys
Numbered Channel
Selection
Channel Scanning
Volume Mute
Power Recall
Display Sleep
Caption Reset
Menu V-Guide
VCR keys Input
FEATURES
dbx®is a registered trademark of
Carillon Electronics Corporation
CAUTION: FCC Regulations state that improper modifications or
unauthorized changes to this unit may void the user’s
authority to operate the unit.
QuickTips
■
Do not position the TV
in a confined area.
Allow normal air cir-
culation for electronic
parts.
■
Position your TV at
least 2 feet from stereo
speakers. The magnets
in the speakers may
affect the picture
quality.
■ The TV will automati-
cally select the correct
Antenna mode for the
type of signal you
connect.
UHF/VHF/CATV
75 Ω
First
Please connect
cable system or
an antenna to the
terminal on the back
Then press the MENU key
POWER
MENU +
VOLUME +
+
AS
RECALL
DISPL
MUTE
PLAY
PAUSE
V-GUIDE
RECSTOP
MENU
CAPTIONSLEEP
RESET
INPUT
CH
VOLVOL
POWER
VCR TVAUX
123
456
789
0
Please wait
TV is searching
for your channels
MENU
❷❸
❹
BASIC SETUP
❺
➊
(See Hookup page 4.)
(Install batteries, see page 5.)
(Switch on Power.)

4
CATV FRANCHISE NOTE:
Cable companies, like public
utilities, are franchised by local
government authorities. To
receive cable programs, even
with equipment which is
capable of receiving cable
channels, the consumer must
subscribe to the cable
company’s service.
QuickTips
■
The TV will automat-
ically select the
correct Antenna
mode for the type of
signal you connect.
■
TV will switch off
automatically after
15 minutes if there is
no signal reception
(cable out or station
not broadcasting).
Exception—When the
Video mode is selected,
the TV will not auto-
matically switch off
when signal reception
has stopped for 15
minutes.
++
FROM ANT.
OUT TO TV.
IN
OUT
FROM ANT.
OUT TO TV.
IN
OUT
IN OUT
FROM ANT.
OUT TO TV.
IN
OUT
IN FROM
SAT.
CATV IN
OUT TO TV S-VIDEO
CH3
CH4 R- -LAUDIOVIDEO
R- -LAUDIOVIDEO
FROM ANT.
OUT TO TV.
IN
OUT
L
L
L
R
R
R
AUDIO
AUDIO
S-VIDEO IN -1
S-VIDEOIN -1
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
1
VIDEO
VIDEO
(MONO)
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
2AUDIO
AUDIO
VIDEO
VIDEO
AUDIO
AUDIO
OUTPUT
OUTPUT
(MONO)
UHF/VHF/CATV
75Ω
L
L
L
R
R
R
AUDIO
AUDIO
S-VIDEO IN -1
S-VIDEOIN -1
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
1
VIDEO
VIDEO
(MONO)
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
2AUDIO
AUDIO
VIDEO
VIDEO
AUDIO
AUDIO
OUTPUT
OUTPUT
(MONO)
UHF/VHF/CATV
75Ω
L
L
L
R
R
R
AUDIO
AUDIO
S-VIDEO IN -1
S-VIDEOIN -1
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
1
VIDEO
VIDEO
(MONO)
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
2AUDIO
AUDIO
VIDEO
VIDEO
AUDIO
AUDIO
OUTPUT
OUTPUT
(MONO)
UHF/VHF/CATV
75Ω
L
L
L
R
R
R
AUDIO
AUDIO
S-VIDEO IN -1
S-VIDEOIN -1
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
1
VIDEO
VIDEO
(MONO)
AUDIO
AUDIO
VIDEO
VIDEO
INPUT
INPUT
2AUDIO
AUDIO
VIDEO
VIDEO
AUDIO
AUDIO
OUTPUT
OUTPUT
(MONO)
UHF/VHF/CATV
75Ω
RECEIVER VCR
CABLE BOX
TV BACK ❸
BASIC HOOKUP METHODS
Use one of these methods to connect a signal to your TV. Select 1a—if you have cable
service and a VCR, 1b—if you have a cable box and a VCR, 1c—if you have an outdoor or
indoor antenna and a VCR, or 1d—if you have a satellite dish and a VCR. Connect your
cable or antenna directly to the TV if you don’t have any optional accessories.
❷
➊
d
➊
b
➊
a
75 OHM Terminal
Use the 75 ohm terminal to
connect a VCR, cable, cable box,
outdoor/indoor antenna or
satellite receiver directly
to the TV.
Cable with VCR and TV
Cable with Cable Box, VCR and TV
Satellite Dish with Receiver, VCR and TV
➊
cOutdoor or Indoor Antenna with VCR and TV
❷
❷
VCR
VCR
VCR ❷
TV BACK
TV BACK
TV BACK
❸
See page 12, Using the
Audio/Video jacks.

5
QuickTips
■
Make sure all cable
connectors are fully
seated on jacks.
See pages 11 and 12
before connecting
external audio/video
equipment.
■
Cables are not
supplied for connect-
ing your external
equipment.
■
A solid Blue screen
with the word Video1
or Video2 displayed
means that the Video
mode is selected, but
no signal is being
detected at the
Video jack. Check
connection, and
turn on external
equipment.
■
Be sure batteries are
installed correctly.
■
Point the remote
control toward the
equipment you want
to operate. Objects
between the remote
control and the
equipment may cause
misoperation of the
remote control
function.
REAR PANEL
INSTALLING BATTERIES (2 AA not included)
1. Remove the battery cover by pressing the tab and tilting
the cover upward. Insert batteries. Make sure you match
/ signs on the batteries with marks inside the
remote control.
2. Replace battery cover. The remote control is ready!
Notes:
– Do not mix old batteries with new ones or mix
different types of batteries together.
– Remove the batteries if the remote control will not be
used for a month or more. Weak batteries may leak and
cause damage.
+
MULTIMEDIA REMOTE CONTROL
Operates your TV, VCR, DVD, and Cable converter box. To familiarize yourself with this
remote control, see page 6. To program the remote control, see pages 7~8.
IMPORTANT NOTE: Spent or discharged batteries must be recycled or
disposed of properly in compliance with all applicable laws. For detailed
information, contact your local County Solid Waste Authority.
Cable /Antenna Input
Terminal (75 ohms)
Audio/Video Input Jacks (A/V1)
Connect external video equipment
here (see pages 12).
Audio Output Jacks (Fixed)
Connect external audio
equipment here (see page 11).
UHF/VHF/CATV
75Ω
R L
R
L
R L
AUDIO
S-VIDEO IN -1
AUDIO
VIDEO
INPUT
1
VIDEO
(MONO)
AUDIO
VIDEO
INPUT
2AUDIO
VIDEO
AUDIO
OUTPUT
(MONO)
Audio/Video Input Jacks (A/V2)
Connect other external video equip-
ment here (see pages 12).
S-Video (Super-Video) In-1 Terminal
To enhance video detail use the
S-Video In-1 jack instead of the A/V1
Video jack, if available on your exter-
nal video equipment. (S-Video 1
connection will override a Video1
connection.)
