Sanyo SC-R166 User manual

FILE NO.
SPECIFICATIONS
Specifications subject to change without notice
SERVICE MANUAL
SM0906001
REFERENCE No.
SC-R166Rechargeable Stick
Vacuum Cleaner
Model  Product Code Barcode AC Specification Destination Remark
SC-R166 1-326-818-01 49-94334-18805-2 240V, 50Hz, O3 Australia
Power source: 240V/50Hz
Dimension  : 250(L)x180(W)x1075(H)
Net Weight  : Approx. 2.7kg

2
SCHEMATIC DIAGRAM

EXPLODED VIEW
3
1. Main Body Assembly
117

EXPLODED VIEW
4
2. Charging Base Assembly

EXPLODED VIEW
5
3. Floor Brush Assembly
115
116

    
REF.NO. PARTS CODE DESCRIPTION Q'TY REMARK MOQ.*
1 TJ-SCR166/001 UPPER BODY 1  30pcs
2 N.S.P. SCREW 11 
3 TJ-SCR166/003 FILTER CLOTH FRAME 1  30pcs
4 TJ-SCR166/004 MESH FILTER FRAME PACKING 1  30pcs
5 TJ-SCR166/005 MESH FILTER FRAME 1  30pcs
6 TJ-SCR166/006 MESH FILTER COVER 1  30pcs
7 N.S.P. SCREW 1 
8 TJ-SCR166/008 DUST CUP 1  30pcs
9 TJ-SCR166/009 LEVER FIXING PLATE 1  30pcs
10 N.S.P. SCREW 2 
11 TJ-SCR166/011 DUST LEVER SPRING 1  30pcs
12 TJ-SCR166/012 DUST LEVER 1  30pcs
13 TJ-SCR166/013 FUSE 1  30pcs
14 TJ-SCR166/014 L/W,BLUE 1  30pcs
15 TJ-SCR166/015 SHRINKABLE TUBE 1  30pcs
16 TJ-SCR166/016 MOTOR HOLD SEALING 1  30pcs
17 TJ-SCR166/017 L/W, 10515 #18 WHITE 1  30pcs
18 TJ-SCR166/018 DC MOTOR(FAN) 1  30pcs
19 TJ-SCR166/019 FAN BRUSH 1  30pcs
20 TJ-SCR166/020 MOTOR FIXING FRAME 1  30pcs
21 N.S.P. SCREW 2 
22 TJ-SCR166/022 FAN-A 1  30pcs
23 TJ-SCR166/023 FAN-B 1  30pcs
24 N.S.P. NUT 1 
25 TJ-SCR166/025 FAN COVER 1  30pcs
26 TJ-SCR166/026 FAN COVER SEALING 1  30pcs
27 TJ-SCR166/027 MOTOR COVER 1  30pcs
28 TJ-SCR166/028 INLET FILTER 1  30pcs
29 TJ-SCR166/029 GRIP SWITCH 1  30pcs
30 TJ-SCR166/030 SLIDE SWITCH 1  30pcs
31 TJ-SCR166/031 GRIP LOCK BUTTON 1  30pcs
32 TJ-SCR166/032 GRIP LOCK SPRING 1  30pcs
33 N.S.P. SCREW 4 
34 TJ-SCR166/034 ORNAMENT SCREW 1  30pcs
35 TJ-SCR166/035 PIPE PACKING 1  30pcs
36 TJ-SCR166/036 NOZZLE PIPC COVER 1  30pcs
37 TJ-SCR166/037 GRIP CENTER SHAFT 1  30pcs
38 TJ-SCR166/038 PIPE PACKING 1  30pcs
39 TJ-SCR166/039 NOZZLE PIPE-B 1  30pcs
40 TJ-SCR166/040 BLOW PIPE 1  30pcs
41 TJ-SCR166/041 L/W,RED 1  30pcs
42 TJ-SCR166/042 L/W,WHITE 1  30pcs
43 TJ-SCR166/043 CONTACT PLATE-A 3  30pcs
44 TJ-SCR166/044 NOZZLE PIPE-A 1  30pcs
45 TJ-SCR166/045 RUBBER SPONGE PLATE -B 1  30pcs
46 TJ-SCR166/046 ELBOW CUP 1  30pcs
47 TJ-SCR166/047 L/W,RED 1  30pcs
48 TJ-SCR166/048 PIN TERMINAL 1  30pcs
49 TJ-SCR166/049 PLUG HOUSING 1  30pcs
50 N.S.P. CONNECTOR FRONT 1 
51 N.S.P. SCREW 2 
52 TJ-SCR166/052 BATTERY COVER 1  30pcs
53 TJ-SCR166/053 OUTLET FILTER 1  30pcs
54 N.S.P. SHRINKABLE TUBE 1 
55 N.S.P. BATTERY 14.4V 1 
56 N.S.P. SPONGE PLATE 1 
PARTS LIST
6
Main Body Assembly
*MOQ: Minimum Order Q'ty

REF.NO. PARTS CODE DESCRIPTION Q'TY REMARK MOQ.*
57 TJ-SCR166/057 LOWER BODY 1  30pcs
58 TJ-SCR166/058 GRIP PANEL 1  30pcs
59 TJ-SCR166/059 STABLE NUT 1  30pcs
60 TJ-SCR166/060 GRIP-L 1  30pcs
61 TJ-SCR166/061 NOISE ABSORBING FELT 1  30pcs
62 TJ-SCR166/062 SWITCH PCB 1  30pcs
63 TJ-SCR166/063 DIODE 1  30pcs
64 TJ-SCR166/064 GRIP-R 1  30pcs
65 TJ-SCR166/065 CREVICE TOOL 1  30pcs
66 TJ-SCR166/066 EXTENSION HOSE JOINT-B 1  30pcs
67 TJ-SCR166/067 FLEXIBLE HOSE 1  30pcs
68 TJ-SCR166/068 EXTENSION PIPE 1  30pcs
69 TJ-SCR166/069 EXTENSION HOSE JOINT-A 1  30pcs
70 TJ-SCR166/070 STAND HANDLE 1  30pcs
71 TJ-SCR166/071 ACCESSORY STAND 1  30pcs
117 TJ-SCR166/117 ASSY, BATTERY 14.4V 1  30pcs
    
REF.NO. PARTS CODE DESCRIPTION Q'TY REMARK MOQ.*
72 TJ-SCR166/072 FRONT STAND 1  30pcs
73 TJ-SCR166/073 REAR STAND 1  30pcs
74 TJ-SCR166/074 CHARGING BASE UPPER BODY 1  30pcs
75 TJ-SCR166/075 CHARGING BASE BOTTOM PLATE 1  30pcs
76 TJ-SCR166/076 SPRING TERMINAL PLATE 2  30pcs
77 N.S.P. SCREW 19 
78 TJ-SCR166/078 TRANSFORMER 1  30pcs
79 TJ-SCR166/079 PCB 1  30pcs
80 TJ-SCR166/080 FOOT RUBBER 4  30pcs
PARTS LIST
7
Charging Base Assembly
*MOQ: Minimum Order Q'ty
*MOQ: Minimum Order Q'ty

    
REF.NO. PARTS CODE DESCRIPTION Q'TY REMARK MOQ.*
81 TJ-SCR166/081 FLOOR NOZZLE BODYA 1  30pcs
82 TJ-SCR166/082 FLOOR NOZZLE BODY B 1  30pcs
83 TJ-SCR166/083 ROTARY BRUSH LTD 1  30pcs
84 TJ-SCR166/084 NOZZLE JOINTA 1  30pcs
85 TJ-SCR166/085 NOZZLE JOINT B 1  30pcs
86 TJ-SCR166/086 NOZZLE JOINT C 1  30pcs
87 TJ-SCR166/087 BRUSH COVER 1  30pcs
88 TJ-SCR166/088 CONTACT PLATE B 2  30pcs
89 TJ-SCR166/089 LEAD WIRE 1  30pcs
90 TJ-SCR166/090 LEAD WIRE 1  30pcs
91 TJ-SCR166/091 LEAD WIRE 1  30pcs
92 TJ-SCR166/092 LEAD WIRE 1  30pcs
93 TJ-SCR166/093 LEAD WIRE 1  30pcs
94 TJ-SCR166/094 NOZZLE LOCK BUTTON 1  30pcs
95 TJ-SCR166/095 NOZZLE LOCK SPRING 1  30pcs
96 TJ-SCR166/096 ROLLER 2  30pcs
97 TJ-SCR166/097 ROLLER SHAFT 2  30pcs
98 TJ-SCR166/098 WHEEL 2  30pcs
99 N.S.P. BRUSH ROTOR 1 
100 N.S.P. ROTOR HOLDER A 1 
101 N.S.P. ROTOR HOLDER A 1 
102 N.S.P. OIL IMPREGNATED BEARING 1 
103 N.S.P. NEW BEARING HOLDER 1 
104 N.S.P. ROTOR SHAFT 1 
105 N.S.P. POLYSLIDER 1 
106 TJ-SCR166/106 TIMING BELT 1  30pcs
107 N.S.P. DC MOTOR 1 
108 N.S.P. MOTOR GEAR 1 
109 TJ-SCR166/109 PCB 1  30pcs
110 TJ-SCR166/110 CONTACT PIN 3  30pcs
111 TJ-SCR166/111 PTC THERMISTOR 1  30pcs
112 TJ-SCR166/112 SHRINKABLE TUBE 1  30pcs
113 N.S.P. SCREW 1 
114 N.S.P. SCREW 13 
115 TJ-SCR166/115 ASSY, DC MOTOR 1  30pcs
116 TJ-SCR166/116 ASSY, BRUSH ROTOR 1  30pcs
PARTS LIST
Dec./'04 SANYO Electric Co., Ltd.
Osaka, Japan
8
Floor Brush Assembly
*MOQ: Minimum Order Q'ty
