Sartorius Combics Series User manual

98648-018-24
Operating Instructions
Sartorius Combics Series
Indicator Models CAISL1, CAISL2, CAIS1, CAIS2

Contents
Notes on Using this Manual 3
Warnings and Safety Precautions 4
Device Description 6
Intended Use 6
General View of the Equipment 7
Installation 8
Getting Started 9
Connect Weighing Platforms: Combics 1 11
Connecting Weighing Platforms: Combics 2 12
Pin Assignment Chart 13
Configuring Weighing Platforms 17
Service Mode 17
Analog/Digital Converter (ADC) 19
Entering Adjustment and Linearization Weights 26
Function Allocation of the J Key 26
External Linearization 27
Setting the Preload 28
Clearing the Preload 29
Adjustment Without Weights 30
Operating Design 31
Turning on the Device 31
Menu Operating Design 35
Configuration 37
Setting up Password Protection 38
Operation 40
Weighing 40
Calibration, Adjustment 47
SQmin Function 50
Data ID Codes 51
Application Programs 53
Counting Z (Combics 2): 54
Neutral Measurement Z nM (Combics 2) 59
Averaging (Animal Weighing) V (Combics 2) 63
Weighing in Percent L (Combics 2) 67
Checkweighing H (Combics 2) 72
Classification W (Combics 2) 80
Totalizing s (Combics 2) 85
Net Total Formulation R (Combics 2) 89
Combining Application Programs 93
Configuring Printouts 96
Product Data Memory (Combics 2) 100
Data Interfaces 102
Configuring the Data Interface as a COM Port
(datprot) 105
Data Input Format 106
Data Output Format 107
Configuring the Data Interface as a Printer Port
(printer) 110
Configuring a Printout 110
GMP-compliant Printouts 111
Sample Printout 113
Error Codes 115
Care and Maintenance 116
Service 116
Repairs 116
Cleaning 116
Safety Inspection 117
Disposal 118
Specifications 119
Device Dimensions 121
Accessories 122
Documents List 125
Sartorius Services 125
Declarations of Conformity 126
EC Type-Approval Certificate 129
Test Certificate 130
Plates and Markings 131
Menu Structure 135
Index 153
Appendix:
Guide to Verification of Weighing Instruments 155
Appendix: General Password 157
Ex-Safety Information 160
2 Operating Instructions Combics Indicators
Contents

Notes on Using this Manual
t Please read this entire manual carefully and completely before using the device.
t Read the safety precautions carefully.
t This manual is part of the product. Keep it in a safe and easily accessible
location.
t If the manual should be lost or misplaced, please contact Sartorius for a
replacement or download the latest manual from our website: www.sartorius.
com
Symbols and Signs
The following symbols are used in this manual:
2 Warning symbol for various types of dangers.
These symbols are explained in more detail in Section “Safety Instructions."
hThis symbol indicates useful information and tips.
Dieses Symbol kennzeichnet Hinweise für den eichpflichtigen Verkehr im
Gültigkeitsbereich der EG-Richtlinie 2009/23/EG.
e,1, This and similar symbols mean that the respective key should be pressed.
T T ..., This means that this key must be pressed more than once.
t Indicates a required action
y Describes the result of an action
1. If a procedure has multiple steps...
2. ... the steps are numbered consecutively.
– Indicates an item in a list
Menu Descriptions
In some cases, text descriptions are used to describe menu settings and in other
cases only the number structure of the menu is used for faster orientation for
experienced users (e.g. “Menu item 1.9” contains the parameter settings for
calibration/adjustment). The Setup menu is shown on the display when “codes”
is selected as the language (see “Configuration” starting on page 37).
hTechnical advice/Hotline:
Phone: [phone]
Fax: [phone]
Operating Instructions Combics Indicators 3
Notes on Using this Manual

Warnings and Safety Precautions
Combics indicators comply with the European Council Directives as well as
international regulations and standards for electrical equipment, electromagnetic
compatibility, and the stipulated safety requirements. Improper use or handling can,
however, result in damage and/or injury.
t Read these operating instructions carefully before use.
This will prevent damage to the equipment.
3 The protective conductor must not be disconnected for any reason. Use only stand-
ard cables that have protective grounding conductors.
3 If there is visible damage to the equipment or power cord: unplug the equipment
and secure it against further use.
3 Make absolutely sure to unplug the indicator from power before you connect or
disconnect any electronic peripheral devices to or from the interface port.
3 The device should only be opened by personnel trained in accordance with Sartorius
guidelines.
3 If you use electrical equipment in installations and under ambient conditions
requiring higher safety standards, you must comply with the provisions as specified
in the applicable regulations for installation in your country.
3 The operator shall be responsible for any modifications to the equipment and for
any connections of cables or equipment not supplied by Sartorius and must check
and, if necessary, correct these modifications and connections.
Information on operational quality is available upon request from Sartorius (in line
with norms pertaining to immunity).
3 Do not expose the equipment to aggressive chemical vapors or to unnecessarily
extreme temperatures, moisture, shocks, or vibration.
3 Only clean the device as stipulated in the cleaning instructions: Refer to the “Care
and Maintenance" chapter.
3 The display value can be affected by extreme electromagnetic influences.
Once the disturbance has ceased, the instrument can be used again in accordance
with its intended purpose.
Danger of Explosion!
1 Do not use this equipment in hazardous areas.
4 Operating Instructions Combics Indicators
Warnings and Safety Precautions

Installation
3 Warning when using pre-wired RS-232 connecting cables: RS-232 cables purchased
from other manufacturers often have pin assignments that are incompatible with
Sartorius products. Be sure to check the pin assignments against the chart in this
manual before connecting the cable, and disconnect any lines identified differently
from those specified by Sartorius.
3 Connect only Sartorius accessories and options, as these are optimally designed for
use with your device. Therefore, do not use any proprietary solutions. The operator
shall be solely responsible for installation and testing of any modifications to
Sartorius equipment, including connection of cables or equipment not supplied by
Sartorius. Information on operational quality (in line with norms pertaining to
immunity) is available on request.
t If you have any problems with your device, contact your local Sartorius office,
dealer or service center.
IP Protection Rating
IP Rating: – All models are rated to IP44 (IP65 as an accessory).
– “IP65" models are rated to IP65.
– The IP65/IP69K protection rating is ensured only if the rubber gasket is installed
and all connections are fastened securely (including the caps on unused
sockets). Weighing platforms must be installed and tested by a certified
technician.
– If you install an interface port or battery connection after setting up your
indicator, keep the protective cap in a safe place for future use. The cap protects
the interface connector from vapors, moisture and dust or dirt.
Use in Legal Metrology
– When the indicator is connected to a weighing platform and this equipment is
to be verified, ensure that the applicable regulations regarding verification are
observed.
– When connecting Sartorius weighing platforms, observe the permitted weighing
range as listed in the “Guide to Verification of Weighing Instruments" and the
Declaration of Conformity.
– A sticker with the “Sartorius" logo was affixed to the indicator as a control seal
following verification. This seal will be irreparably damaged if you attempt to
remove it. This will nullify the verification's validity. In this case, re-verification
would be required in compliance with all relevant national regulations and laws.
Operating Instructions Combics Indicators 5
Warnings and Safety Precautions

Device Description
Combics indicators:
– Are robust and durable, thanks to their stainless steel housing
– Are easy to clean and disinfect
– Are easy to operate, thanks to the following features:
– Large, backlit display elements (14 segments)
– Large keys with positive click action
– Can be operated independently of the weighing platform location
– Have a range of interfaces for flexible use
– Have optional password protection for operating parameters
Combics 1 offers these practical functions:
– Easy calibration via a separate key
– Automatic tare for loading
– Alibi memory connection option available
– Internal rechargeable battery
– Automatic printing for loading
– Configurable printout
– Flex print
Combics 2 speeds up your routine procedures with:
– Integrated programs for applications (some can be combined):
– Counting
– Neutral measurement
– Averaging (animal weighing)
– Weighing in percent
– Checkweighing
– Classification
– Totalizing
– Net-total formulation
– Automatic initialization when the scale is switched on
– Automatic taring when a load is placed on the weighing platform
– Can be controlled via two external computers using various protocols
– Barcode scanner connection option for entering tare value or IDs (6 units)
– Possibility to input tare values via the number block
– LED for measurement range identification
– Connection option for a second weighing platform
– Alibi memory
– Internal rechargeable battery
– Product data memory
– Configurable printout
– Flex print
Intended Use
Combics 1 and 2 indicators are robust indicators for daily quality control in
industrial applications. They were designed for suitable scales or weighing platforms
that correspond to the described technical specifications. Any other use beyond this
is considered improper.
6 Operating Instructions Combics Indicators
Device Description

General View of the Equipment
Combics 1 and 2
1 Display (for a detailed diagram, please see the chapter
“Operating Design")
2 On/Off key
3 General function keys: Zero, Tare, Switch function,
Adjustment/Calibration, Print/Data output
(see “Operating Design")
Combics 2 only
4 10 digit keypad for entering values
5 LEDs (for checkweighing and classification)
6 Additional function keys (see “Operating Design")
7 Toggle between weighing platforms (WP)
Back
8 Connection options for
– COM1 standard
– 2nd UNICOM interface for additional, optional functions
(e.g. Ethernet, profibus etc.)
– CAIS2: a barcode scanner can be connected via a terminal
block
9 Power cord with country-specific plug
10 Vent valve: 1.5 Nm
11 Weighing platform WP-1 and/or WP-2 connection
12 Input for menu access switch (standard or legal-for-trade
mode) for WP-1 and/or WP-2
13 RS232C interface “COM1" (standard)
14 Second “UNICOM" interface (Combics 2 only)
15 Combics 2 only: PS/2 connection (barcode scanner, external
keypad)
Operating Instructions Combics Indicators 7
Device Description
13
9
10
8
14
15
12
11
12
11
12
11
CAIS1 | CAIS2
CAISL1
CAISL2
1
3
2
4
5
6
6
7

Installation
When a Combics indicator is ordered with special equipment, the desired options
come pre-loaded from the factory.
Storage and Shipping Conditions
3 Once the equipment has been removed from the packaging, it may lose accuracy
if subjected to strong vibration.
– Do not expose the equipment to unnecessarily extreme temperatures, moisture,
shocks, blows or vibration.
– Permissible storage temperature: –10°C to +40°C
Installation Location
Avoid adverse influences at the place of installation:
– Extreme temperatures (operating temperature: –10°C to +40°C)
– Aggressive chemical vapors
– Extreme moisture (according to IP protection class)
Unpacking
t After unpacking the device, check it for any visible damage as a result of rough
handling during shipment.
y If you detect any damage, proceed as directed in the chapter entitled “Care and
Maintenance" under “Safety Inspection."
t Save the original packaging for any future transport.
Unplug all connected cables before packing the equipment.
Checking Package Contents
– Indicator
– Operating instructions
– Options (special accessories) as listed on the bill of delivery
Acclimatizing the Device
Condensation can form on the surfaces of a cold device when it is brought into
a substantially warmer area.
t Allow the device to acclimatize for about 2 hours at room temperature, leaving
it unplugged from AC power.
Connecting Weighing Platforms (see Getting Started)
3 Make absolutely sure that the device is unplugged from the power supply before
connecting/disconnecting any peripheral device (printer, PC) to or from the data
interface.
8 Operating Instructions Combics Indicators
i Installation

Getting Started
Steps 1.) Connect weighing platform to the indicator.
2.) Configure the analog/digital converter (ADC): see page 19
3.) Carry out an alignment: for adjustment, see page 26, for linearization see
page 27
4.) Connect peripheral devices, e.g. printer to the COM1 or UNICOM interface:
see Data Interfaces chapter starting on page 102
Connecting Weighing Platforms to WP1
An analog Sartorius platform (CAPP, CAPS, IU or IF) or a commercially-available
DMS load cell can be connected to the Combics indicator WP1 input.
3 The load cell should be connected by a certified technician who has received
specialized training from Sartorius. Any installation work that does not conform
to the instructions in this manual results in forfeiture of all claims under the
manufacturer’s warranty.
3 Peripheral devices should be connected by a certified technician who has received
specialized training from Sartorius. Any installation work that does not conform to
the instructions in this manual results in forfeiture of all claims under the
manufacturer’s warranty.
3 Disconnect the equipment from the power supply before starting connection work.
t Set up the weighing platform (see Operating Instructions for the weighing plat-
form)
t Place the cable from the weighing platform next to the indicator
฀ t Open the Combics indicator:
Loosen the ten cap nuts on the front panel. Remove the front panel.
Installing Connection and Interface Cables
3 The cable gland (IP69K protection) is pre-mounted on the indicator. Please use
extreme caution when performing any work on the equipment that affects this
cable gland.
You must use a torque wrench to tighten the cable gland to 5 Nm.
Preparing Cables
t Strip approx. 14 cm from the end of the cable.
t Shorten the shielding to approx. 2 cm and pull back over the insulation.
t Strip approximately 5 mm of the insulation from the wires of the connecting
cable and affix ferrules to the wire ends.
Operating Instructions Combics Indicators 9
Getting Started

Attaching the Cable Entry
3 Please use extreme caution when performing any work on the equipment that
affects this cable gland.
You must use a torque wrench to tighten the cable gland to 5 Nm.
4
15
t Remove the protective cap from the bore hole on the indicator.
t Insert the included cable gland through the bore hole and secure from the
inside using the locknut (1).
2
3
t Insert the cable through the cable gland until the shielding (2) comes into
contact with the clamps (3). Tighten the screw-down nut (4) until the
gasket (5) inserted between the screw-down nut and cable forms a small
beaded rim.
t Check the shielding and clamps.
t Securely connect the wires of the connecting cable in accordance with the
terminal assignments.
t After you close the housing again, use a pressure gauge to check the
integrity of the IP69K protection. For details, contact the Sartorius Service
Center.
Connecting Cables
t Insert all cable wires through the ferrite case, wind them around the ferrite
case and then reinsert back through the ferrite case.
t Screw the wires tightly into the clamps.
See the following pages for terminal pin allocation
t Refer to the data sheet or operating instructions of the weighing platform
for details on the assignment of wire colors/signals. Ensure any lines that
are not assigned are insulated correctly.
t When connecting a load receptor that uses 4-conductor technology (the
cable of the weighing platform to be connected only has 4 lines), connect
clamp pairs 1 and 2 (EXC+ und SENSE+), and 5 and 6 (SENSE- und EXC-)
with a wire jumper.
10 Operating Instructions Combics Indicators
Getting Started

Connecting Weighing Platforms: Combics 1
Interface PCB for ADC 2*3000e (option A8)
COM1 terminal assignments
1 LOAD_PRINTER 11 Clear to Send (CTS)
2 RESET_OUT 12 Data Terminal Ready (DTR)
6 3: GND 13 Data Input (RXD)
4 GND 14 Data Output (TXD)
5 5V_OUT 15 GND
6 5V switched 16 Universal In
7 GND 17 Control Output: “lighter"
8 GND 18 Control Output: “equal"
9 n.c. 19 Control Output: “heavier"
10 LINE_OUT 20 Control Output: “set"
A8
1 EXC+ Bridge supply voltage (+)
2 SENSE+ Sense (+) for bridge supply voltage
3 OUT+ Measuring voltage positive
4 OUT- Measuring voltage negative
5 SENSE- Sense (-) for bridge supply voltage
6 EXC- Bridge supply voltage (–)
D connection of display and control unit
Interface PCB for ADC 10.000e (option A10)
COM1 terminal assignments, see above
A10
1 EXC+ Bridge supply voltage (+)
2 SENSE+ Sense (+) for bridge supply voltage
3 OUT+ Measuring voltage positive
4 OUT- Measuring voltage negative
5 SENSE- Sense (-) for bridge supply voltage
6 EXC- Bridge supply voltage (–)
D Display and control unit connection
Interface PCB for RS-232/485 (option A6/A7)
COM1 terminal assignments, see above
A6/7
1 CTS 11 TxD/RxD+
2 DTR 12 TxD/RxD-
3 RxD 13 LINE_OUT
4 TxD 14 LINE_OUT
5 GND 15 GND
6 Calibration Lock 16 GND
D connection of display and control unit
Com 1 A6/7
not assigned not assigned
D
Com 1 A10
not assigned not assigned
D
Com 1 A8
D
Operating Instructions Combics Indicators 11
Getting Started

Connecting Weighing Platforms: Combics 2
Interface PCB for ADC 2*3000e (option A8)
COM1 terminal assignments (applies to all PCBs) PS/2
1 LOAD_PRINTER 11 Clear to Send (CTS) 21 5 V switched
2 RESET_OUT 12 Data Terminal Ready (DTR) 22 PS2_Data
3: GND 13 Data Input (RXD) 23 PS2_Timer
4 GND 14 Data Output (TXD) 24 GND
5 5V_OUT 15 GND 31 Not assigned
6 5V switched 16 Universal In 32 Not assigned
7 GND 17 Control Output: “lighter" 33 Not assigned
8 GND 18 Control Output: “equal" 34 Not assigned
9 n.c. 19 Control Output: “heavier" 35 Not assigned
10 LINE_OUT 20 Control Output: “set" 36 Not assigned
A8 terminal assignments see Combics 1
D Display and control unit connection
LED (LED connection)
Interface PCB for RS-232/485 for IS weighing platform
(option A6/A7)
A6/7
1 CTS 11 TxD/RxD+
2 DTR 12 TxD/RxD-
3 RxD 13 LINE_OUT
4 TxD 14 LINE_OUT
5 GND 15 GND
6 Calibration Lock 16 GND
D Display and control unit connection
LED (LED connection)
Interface PCB for ADC 10.000e (option A20)
A20
1 EXC+
2 SENSE+
3 OUT+
4 OUT-
5 SENSE-
6 EXC-
D Display and control unit connection
LED (LED connection)
Interface PCB for RS-232/485 for IS weighing platform
(option A62/A72)
Interface PCB A6/7 and A62/72
1 CTS 11 TxD/RxD+
2 DTR 12 TxD/RxD-
3 RxD 13 LINE_OUT
4 TxD 14 LINE_OUT
5 GND 15 GND
6 Calibration Lock 16 GND
D Display and control unit connection
LED (LED connection)
Com 1 A62/72
D
LED
Com 1 A20
D
LED
Com 1 A6/7
D
LED
Com 1 A8
D
LED
12 Operating Instructions Combics Indicators
Getting Started

Pin Assignment Chart
Models CAISL1 and CAISL2 (IP44 protection)
COM1 female connectors:
25-pin D-Submini female connector (DB25S) with screw lock hardware for cable
gland
Recommended interface connector:
25-pin D-Submini (DB25) with shielded cable clamp assembly and shield plate
(Amp type 826 985-1C) and fastening screws (Amp type 164868-1)
COM1 pin assignments
Pin 1: Shield
Pin 2: Data output (TxD)
Pin 3: Data input (RxD)
Pin 4: GND
Pin 5: Clear to send (CTS)
Pin 6: Not assigned
Pin 7: Internal ground (GND)
Pin 8: Internal ground (GND)
Pin 9: Not assigned
Pin 10: Not assigned
Pin 11: +12V for printer
Pin 12: RES_OUT\
Pin 13: +5V Switch
Pin 14: Internal ground (GND)
Pin 15: Universal switch
Pin 16: Control output: “lighter"
Pin 17: Control output: “equal"
Pin 18: Control output: “heavier"
Pin 19: Control output: “set”
Pin 20: Data terminal ready (DTR)
Pin 21: Ground power supply (GND)
Pin 22: Not assigned
Pin 23: Not assigned
Pin 24: Power supply +15 to 25V (peripherals)
Pin 25: +5V
3
1
4
2
65
PS/2 socket pin assignment on Combics 2
Pin 1: Keyboard data (data interface cable)
Pin 2: Not assigned
Pin 3: GND (ground)
Pin 4: 5V switched
Pin 5: Keyboard clock
Pin 6: Not assigned
Connecting an IS Weighing Platform to a Combics 2
You can connect an IS weighing platform to WP2.
Features – IS weighing platforms process weighing data independently of the indicator.
– Internal calibration/adjustment option
– IS...-0CE models: have a separate approval number, printed on a tag that is
affixed to the cable.
– Please observe the conditions described in the manual for the weighing
platform you connect.
Operating Instructions Combics Indicators 13
Getting Started

Cabling Diagram - Connection to a PC
Use the following cables to connect a PC to the indicator in accordance with the
RS-232C/V24 standard (max. cable length 15 m):
Models CAISL1, CAISL2: connecting cable 7357312
Models CAIS1, CAIS2: connecting cable YCC02-D9F6
V24
Cable Diagrams
Connection assignments for the cable from the indicator to an RS-232 PC interface (COM1).
Indicator side PC side
Models CAISL1,CAISL2 DSUB connector
25-pin D-Sub male connector 9-pin or 25 pin
1
Sgn GND 7 5 GND 7 GND
TxD 2 2 RxD 3 RxD
RxD 3 3 TxD 2 TxD
DTR 20 8 CTS 5 CTS
CTS 5 4 DTR 20 DTR
Models CAIS1, CAIS2
Open cable end DSUB connector
9-pin or 25 pin
Sgn GND 15 5 GND 7 GND
TxD 14 2 RxD 3 RxD
RxD 13 3 TxD 2 TxD
DTR 12 8 CTS 5 CTS
CTS 11 4 DTR 20 DTR
14 Operating Instructions Combics Indicators
Getting Started

Closing the Combics indicator:
t Re-attach the front panel and secure it with 1 Nm the ten cap nuts.
Connecting the Device to AC Power
The device is powered through the installed power cord. The power supply is
integrated into the indicator. The device can be operated with a voltage of 100 V
to 240 V.
3 The power connection must be made in accordance with the regulations applicable
in your country.
The printed voltage rating (see type label) must match the voltage in the place of
installation. If the voltage specified on the label or the plug design of the AC adapter
do not match the rating or standard you use, please contact your Sartorius office or
dealer.
t Check the voltage rating and plug design.
t The device must be plugged into a properly installed wall outlet.
Protection Class 1 Device
t The device must be plugged into a properly installed wall outlet which has a
protective grounding conductor (PE).
Safety Precautions
3 If you use an electrical outlet that does not have a protective grounding conductor,
ensure that an equivalent protective conductor is installed by a certified electrician
(as specified in the applicable regulations for installation in your country).
The protective effect must not be negated by using an extension cord without
a protective grounding conductor.
Before using for the first time, any superstructure parts must be completely installed.
Avoid connecting the equipment to lines that have a heavy electrical load, e. g.
compressors, large machinery, etc.
Warm-up Time
To deliver exact results, the device must warm up for at least 30 minutes after
connection to AC power. Only after this time will the device have reached the
required operating temperature.
Using a Verified Device in Legal Metrology:
Ensure that there is a warm-up time of at least 24 hours after connection to the
power supply.
Operating Instructions Combics Indicators 15
Getting Started

Connecting a Barcode Scanner (Accessory, Order No. YBR02CISL)
t Disconnect the indicator from AC power (unplug the AC adapter)
For CAISL2 models:
t Connect the barcode scanner via PS/2.
For CAIS2 models:
t Please see “Pin Assignment Charts," page 13 (implemented via the YCC02-BR02
connecting cable or as option M8)
3NOTE: This equipment has been tested and found to comply with the limits pur-
suant to part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with
these instructions, may cause harmful interference to radio communications. For
information on the specific limits and class of this equipment, please refer to the
Declaration of Conformity. Depending on the particular class, you are either required
or requested to correct the interference. If you have a Class A digital device, you
need to comply with the FCC statement as follows: “Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.“
16 Operating Instructions Combics Indicators
Getting Started

Configuring Weighing Platforms
Service Mode
Purpose The Service mode enables access to additional menu items in the Setup menu
(setup) which are not displayed when the Service mode is not active. The most
important calibration and adjustment work for the indicator and for the connected
weighing platform can be carried out in the Service menu, e.g. ADC configuration.
When the Service mode is active, an “S” is shown in the top right-hand corner of the
display. To deactivate the Service mode, restart the indicator (turn the indicator off
and back on again).
In Service mode, the Setup menu is expanded with the following parameters after
entering the user password:
– S-DATE for entering the next service date
– SER.NO for entering the device serial number
– MODEL with the model description
– S-SQMIN
– ALIB.MEM for deleting the Alibi memory
The Setup menu for WP1 and WP2 can be extended to include the following setting
options:
param1
CAL./ADJ. Calibration, adjustment 1.9.
Internal linearization (for WP-2 only) 1.9.5
CAL.EXT External linearization with default weights 1.9.6
CAL.E.USR. External linearization with user-defined weights (entered under 1.18) 1.9.7
SET.PREL. Setting the preload 1.9.8
DEL.PREL. Clearing the preload 1.9.9
HND.XT / CAL./ADJ. Entering the adjustment and linearization weights 1.18.
LIN. WT.1 Entering the lin. weight 1 1.18.2
LIN. WT.2 Entering the lin. weight 2 1.18.3
LIN. WT.3 Entering the lin. weight 3 1.18.4
LIN. WT.4 Entering the lin. weight 4 1.18.5
ADJ.W/O.W Adjustment without weights (entering the characteristic data of the load cell(s)) 1.19.
NOM.LOAD Nominal load 1.19.1
RESOLUT Resolution 1.19.2
SENSIT.1 Sensitivity in mV/V for cell 1 (or average value for all load cells) 1.19.3
SENSIT.2 Sensitivity in mV/V for cell 2 1.19.4
SENSIT.3 Sensitivity in mV/V for cell 3 1.19.5
SENSIT.4 Sensitivity in mV/V for cell 4 1.19.6
SAVE Save values for 1. 19 1.19.7
GEOG.DAT Adjustment location (geographical data; or alternatively 1.20.
the gravitational acceleration at the place of installation)
LATITUD Latitude in degrees 1 20.1
ALTITUD Elevation in meters above sea level 1 20.2
GRAVITY. Gravitational acceleration 1 20.3
SAVE. Save values for 1. 20 1 20.4
ADC settings (menu see page 19) 11
Applying the serial number of the IS weighing platform 12.1
(verified weighing platform at WP2)
Apply the serial number 12.1.1
Inactive (standard WP) 12.1.2
Operating Instructions Combics Indicators 17
Configuring Weighing Platforms

Activating the Service Mode
e ... ) t Switch to the Menu mode (see page 35).
k k ... t Access the Setup menu.
) t Select Setup
If a password is requested at this point, enter the service password (see
Appendix) and continue with “Saving the service password."
k k ... t Access the U-Code menu item
) t Select U-Code
t Enter the service password (see Appendix).
) t Apply the service password
y The Service mode is active: an “S" appears in the top right-hand corner of the
display.
( ( t Return to Setup in the Service mode.
18 Operating Instructions Combics Indicators
Configuring Weighing Platforms

Analog/Digital Converter (ADC)
Purpose Adjust the parameters of the analog/digital converter to the connected load cell or
weighing platform. After ADC configuration, the ADC in connection with the load
sensor is defined as a scale.
3 Once the ADC configuration has been locked, the indicator can no longer be used
to influence weighing results. The scope of functions available in the weighing
instrument is defined by the A/D converter. Weighing functions that can be activat-
ed include reading weight values, taring, adjustment, reading the tare value, saving/
deleting the tare entry
Setup information – ADC configuration is only possible when the menu access switch is open.
Close the menu access switch after ADC configuration, as otherwise there will
not be any display of the conditions “overload” (“H”) and “underload” (“L”).
– Before ADC configuration, you must first set whether or not the weighing
platform will be used as a standard or verifiable weighing platform under menu
item 9.1.
– When the Service mode is activated, ADC configuration can be carried out in the
Setup menu under “WP-1" for the first weighing platform and COm1 / WP-2,
UNICOM / WP-2 or COm-WP for the second weighing platform.
3 If you return to the highest level of the Setup menu without saving the configura-
tion parameters beforehand (menu item 11.10) any settings that have been made
will be deleted.
– The settings are made in the corresponding Setup menu under menu item 11.
– Enter the maximum capacities in a suitable weight unit, without any decimal
places (decimal places will be truncated by the rounding function).
– Entries made in the ADC configuration will not be affected by a menu reset
(returning the setup parameters to their factory settings).
Factory settings/Reset menu 9.1
wt.para
STANDRD Standard configuration 9.1.3
RANGES Ranges 11.3
SINGLE Single-range scale 11.3.1
MULT.INT Multi-interval scale 11.3.2
MULT.RNG Multiple-range scale 11.3.3
SINGLE Single-range scale 11.4
d Scale interval d 11.4.1
MAX. Max. load 11.4.4
MULT.INT Multi-interval scale 11.5
d Scale interval d 11.5.1
RANGE 1 Range 1 11.5.4
RANGE 2 Range 2 11.5.5
RANGE 3 Range 3 11.5.6
max Max. load 11.5.7
MULT.RNG Multiple-range scale 11.6
d Scale interval d 11.6.1
RANGE 1 Range 1 11.6.4
RANGE 2 Range 2 11.6.5
RANGE 3 Range 3 11.6.6
max Max. load 11.6.7
WT.UNIT Available weight units 11.7
FREE User-defined / o 11.7.1
g Grams /g 11.7.2
kg Kilograms /kg 11.7.4
…
t Tons /t 11.7.21
lb Pound:ounces/ lb oz 11.7.22
CAL.UNIT Calibration / Adjustment unit 11.8
Operating Instructions Combics Indicators 19
Configuring Weighing Platforms

FREE User-defined / o 11.8.1
g Grams /g 11.8.2
kg Kilograms /kg 11.8.3
...
t Tons /t 11.8.21
SAVE Save configuration parameters 11.10
YES Yes 11.10.1
NO No 11.10.2
Factory settings/Reset menu 9.1
wt.para
VERIF. Verifiable configuration 9.1.4
CLASS Accuracy class 11.1
Class l / m 11.1.4
RANGES Ranges 11.3
SINGLE Single-range scale 11.3.1
MULT.INT Multi-interval scale 11.3.2
MULT.RNG Multiple-range scale 11.3.3
SINGLE Single-range scale 11.4
e Verification scale interval e 11.4.2
MIN. Min. load 11.4.3
MAX. Max. load 11.4.4
MULT.INT Multi-interval scale 11.5
e Verification scale interval e 11.5.2
MIN. Min. load 11.5.3
RANGE 1 Range 1 11.5.4
RANGE 2 Range 2 11.5.5
RANGE 3 Range 3 11.5.6
MAX. Max. load 11.5.7
MULT.RNG Multiple-range scale 11.6
e Verification scale interval e 11.6.2
MIN. Min. load 11.6.3
RANGE 1 Range 1 11.6.4
RANGE 2 Range 2 11.6.5
RANGE 3 Range 3 11.6.6
MAX. Max. load 11.6.7
WT.UNIT Available weight units 11.7
FREE User-defined / o 11.7.1
g Grams /g 11.7.2
kg Kilograms /kg 11.7.4
…
t Tons /t 11.7.21
lb Pound:ounces/ lb oz 11.7.22
CAL.UNIT Calibration / Adjustment unit 11.8
FREE User-defined / o 11.8.1
g Grams /g 11.8.2
kg Kilograms /kg 11.8.3
...
t Tons /t 11.8.21
SAVE Save configuration parameters 11.10
YES Yes 11.10.1
NO No 11.10.2
20 Operating Instructions Combics Indicators
Configuring Weighing Platforms
