4 SATEL User Manual
If you select one camera label for editing, the cursor will be flashing in the label line on the
screen. The cursor position can be changed by means of the arrow buttons ◄and ►. The
▲button enables the characters preceding the cursor to be deleted. When one of the
buttons: OK, SEQ (-) or VCR (+) is depressed, the cursor moves from the label line to the
on-screen table of characters, which makes it possible to select a corresponding character
by means of the arrow buttons, SEQ (-) or VCR (+) buttons. Pressing the OK button will
confirm the selected character, and the cursor will re-appear in the label line. Having entered
a new name, you should save it in the unit memory. To do so you must move the cursor to
the SAVE item and press OK.
Sequence Settings
You have an option to define your own sequence of images displayed on screen, or to
restore the default sequence. By default, the following sequence has been programmed:
image from camera 1 for 2 seconds, image from camera 2 for 2 seconds, image from
camera 3 for 2 seconds, image from camera 4 for 2 seconds.
After the function is started, a list will be displayed, which can contain up to eight items, i.e.
full-screen images from cameras, or quad-mode views from cameras. The items which have
not been programmed will not be displayed. The maximum duration of an item display on
screen is 30 seconds. The items, to which display duration of 0 seconds is assigned, will not
be displayed.
You can move throughout the list using the arrow buttons. To select the signal source or to
change the display duration, use the buttons SEQ (-) and VCR (+). Having programmed a
sequence, save it in the unit memory by moving the cursor to the SAVE item and pressing
the OK button.
Time & Date
You should program the hour, minutes, day, month and year, as well as specify the date
format. The following date formats are available:
YYYY-MM-DD (default)
DD/MM/YYYY
DD.MM.YYYY
YYYY.MM.DD
Use the arrow buttons to move through the time parameters. Parameters can be modified by
means of the buttons SEQ (-) and VCR (+). The changes made are automatically saved in
the memory, no confirmation being necessary.
OSD Settings
An option is provided to define which elements are to be displayed on screen (camera
labels, date, clock) and sent to the VCR output (date and clock), select the clock position on
screen (left-hand or right-hand side), and specify the time lapse, for which a camera image
can be frozen in the real-time display mode (from 1 to 30 seconds, or undefined, i.e. until
any button is pressed, except MENU).
Note: The date and clock will not appear at the VCR output, unless their display on
screen is enabled.
You can move through the successive options by using the buttons ▼and ▲. The buttons
SEQ (-) and VCR (+) are used for switching between the option statuses and for defining the
still image time. Save the entered changes by moving the cursor to the SAVE item and
pressing OK.
