I - INTRODUCTION
Congratulations! You have just taken possession of
your IMPLANT CENTER 2.
Designed by SATELEC®, the IMPLANT CENTER 2 is a
multifunction device intended for:
• dental implantology, with its I-SURGE LED micro-
motor.
• surgical procedures (osteotomy, osteoplasty,
periodontal and implant surgery) with its PIEZOTOME
LED handpiece.
• mechanical ultrasonic treatment (prophylaxis,
periodontics, endodontics) with its NEWTRON LED
ultrasonic handpiece.
The I-SURGE LED micro-motor coupling developed by
SATELEC means that the IMPLANT CENTER 2 can be used
with most surgical contra-angles equiped with fiber
optics.
In order to get the most out of this high-technology
device and ensure it has a long working life, please
read this manual carefully before installing, using or
maintaining it.
Points preceded by the symbol should be given
particular attention.
II - WARNINGS
CAUTION:
United States Federal Law restricts the use of this
device solely to qualified, trained and competent
dental health practitioners or under their
supervision.
The tips designed for PIEZOTOME 2 and IMPLANT CENTER
2 are not compatible with PIEZOTOME and IMPLANT
CENTER, and vice versa.
To reduce the risk of accidents, the precautions
stipulated below must be taken:
Device users:
- Use of the IMPLANT CENTER 2 is restricted solely to
qualified, trained and competent dental health
practitioners in the normal context of their work.
- If you have received this device by error, please
contact the supplier so that it can be removed.
Interactions:
Interference may occur when used on
patients with cardiac pacemakers.
This system emits electromagnetic
fields, which means there are some
potential risks. The malfunctioning of implantable
devices such as cardiac pacemakers and ICDs
(implantable cardioverter defibrillator) is possible:
- Ask patients and users if they have an implanted
device before using this product. Explain the
circumstances to them
- Weigh the risks and benefits and contact your
patient's cardiologist or appropriate qualified
healthcare professional prior to performing the
treatment
- Keep this product away from implanted devices
- Make appropriate emergency provisions and take
immediate action if patients become ill
- Symptom including a raised heartbeat, irregular
pulse, and dizziness may signal problems with a
cardiac pacemaker or ICD.
- Do not attempt to connect to the IMPLANT CENTER 2
any other accessories than those supplied by
SATELEC.
Electrical connection:
- Your IMPLANT CENTER 2 must be connected to the
electric power supply by a certified dental
installation technician.
- Warning: To avoid any risk of electric shock, this
device must be connected to an electrical power
supply with a protective ground.
- The electric supply to which the device is
connected must comply with the standards in force
in your country.

- If loss of electrical power during use is likely to
generate an unacceptable risk, the device must be
connected to a suitable power source (e.g. UPS).
Using the device:
- Do not use the device if it appears to be damaged
or faulty.
- Turn the device off before unplugging the power
cord.
- To unplug the power cord, grip the cord plug and
hold the wall socket.
- Never use any other irrigation solution containers
than those intended for suspension from the
supplied brackets.
- The device must only be used with bottles or bags
of physiological saline or sterile water.
- The capacity of the irrigation solution containers
used must not exceed one litre.
- When the device is not to be used for a long period
of time, unplug the device from the electric supply.
- Do not exert excessive force on the screen.
- Do not move IMPLANT CENTER 2 during use.
Environment:
- Do not cover the device or obstruct the ventilation
vents.
- Do not immerse the device in liquid, and do not use
it outdoors.
- Do not tilt the device at an angle greater than 5°.
- Do not place the device near a heat source.
- Make sure that the cords are not in a traffic path.
- The device must be stored in its original packaging
in an appropriate and safe place.
- The device is not designed for use in the presence
of anesthetic gases or any other flammable gas.
- Do not expose the device to water vapor, or
splashes.
- Any condensation inside an electrical device is
potentially dangerous.
- If the device is to be moved from a cold
environment to a hot one, it must not be used until
it has reached room temperature.
- The device is not designed to work near ionizing
radiation.
- Do not insert metal objects into the device (risk of
electric shock, short-circuit or projection of
hazardous substances).
Maintenance:
- Before and after each use, your IMPLANT CENTER 2
must be disinfected with SATELEC-approved agents.
- Before each procedure, it is essential to make sure
that the accessories to be used have been cleaned,
disinfected and sterilized.
Accessories:
- The device has been designed and developed for
use only with SATELEC accessories to ensure
maximum safety and performance.
- Use of accessories from other manufacturers is a
potential hazard for you or your patients.
Repair:
- Warning: Do not repair or modify the device without
prior authorization from SATELEC.
- Warning: If the device is modified or repaired,
specific checks and tests must be performed to
ensure that the device can still be used safely.
- In the case of a fault, contact the supplier of your
device. Do not use unauthorized repairers, who
might make your device dangerous for you and your
patients.
If in any doubt, contact an approved dealer or our
customer support department:
- www.acteongroup.com
- E-mail: [email protected].
III - DESCRIPTION
3. 1 PHYSICAL DESCRIPTION
The IMPLANT CENTER 2 has the following components:
- a control unit (Fig. 1),
- a multifunction footswitch (Fig. 11),
- a micro-motor cord with connectors (Fig. 1-2),
- two brackets for irrigation solution (Fig. 1-3),
- an I-SURGE LED micro-motor (Fig. 1-4) without
contra-angle,
6

- a grounded power cord (Fig. 1-5),
- an LCD (Liquid Crystal Display) touch screen (Fig. 1-
6),
- a motor cord connector (Fig. 1-7),
- two peristaltic pump housings (Fig. 1-8),
- a cord connector for the two ultrasonic functions
(Fig. 1-9),
- a NEWTRON LED scaler cord (Fig. 1-10),
- a NEWTRON LED handpiece or a PIEZOTOME 2 LED
handpiece with its cord (Fig. 1-11) (according to
option).
Located at the back of the unit are:
- 1 power cord socket with ground pin (Fig. 2-1),
- 1 footswitch connector (Fig. 2-2),
- 1 fan (Fig. 2-3),
- 2 bracket holders (Fig. 2-4),
- 1 power switch (Fig. 2-5).
- 1 potential equalization connector (Fig. 2-6)
3. 2 TECHNICAL DESCRIPTION
a) LCD touch screen
The LCD touch screen (Fig. 3) is used to define the
settings of your IMPLANT CENTER 2.
The IMPLANT CENTER 2 is adjusted by applying moderate
pressure to the screen keys.
Identification of key areas common to all modes (Fig.
3):
- 4: Reduce irrigation flow rate.
- 5: Increase irrigation flow rate.
- 6: Reduce value.
- 7: Increase value.
Identification of information display areas common to
all modes (Fig. 3)
- 2: Irrigation flow rate value.
- 9: Operating fault indicator.
Identification of key areas common to all modes that
also display information (Fig. 3)
- 1: Flush/prime.
- 3: Irrigation ON/OFF.
- 8: Save, store data.
- 10: Select footswitch mode.
- 11: ON/OFF of light function on handpiece
- 12: Select mode (according to connected handpiece
type).
Key areas and displays specific to the selected mode
PIEZOTOME mode:
Identification of information display areas (Fig. 4)
- 13: Selected program power level.
Identification of key areas that also display
information (Fig. 4)
- 14: Select program: D1, D2, D3, D4.
NEWTRON mode:
Identification of information display areas (Fig. 5)
- 15: Selected program power level.
Identification of key areas that also display
information (Fig. 5)
- 16: Select program: Soft, Medium, High, Boost.
I-SURGE mode:
Identification of information display areas (Fig. 6)
- 17: Contra-angle ratio.
- 18: Motor speed value.
- 19: Motor delivered torque value.
Identification of key areas (Fig. 6)
- 20: Adjust contra-angle ratio.
- 21: Adjust motor speed.
- 22: Adjust motor delivered torque.
Identification of key areas that also display
information (Fig. 6)
- 23: Select micro-motor rotation (clockwise or
counterclockwise).
- 24: Select program: P1, P2, P3, P4.
7

Contra-angle, speed and torque setting
adjustment page
Identification of common information display areas
(Fig. 7)
- 25: Contra-angle ratio.
- 26: Maximum delivered speed.
- 27: Maximum delivered torque.
Identification of common key areas (Fig. 7)
- 28: Exit from the page without changes.
- 29: Delete last character entered.
- 30: Return to main page and save settings to screen
memory.
- 31: Numeric keypad.
Preprogrammed contra-angle adjustment page
Identification of information display areas (Fig. 8)
- 38: Contra-angle ratio.
- 39: Motor speed value.
- 40: Motor delivered torque value.
Identification of key areas (Fig. 8)
- 32: Exit from the page without changes.
- 33: Select custom contra-angle.
- 34: Return to main page and save settings to screen
memory.
Identification of key areas that also display
information (Fig. 8)
- 35: Select a multiplier contra-angle.
- 36: Select direct contra-angle.
- 37: Select a divider contra-angle.
Startup page
Identification of key areas (Fig. 9)
- 41: Enter TOOLBOX mode.
Toolbox
Identification of information display areas (Fig. 10)
- 43: Audio volume symbol.
- 44: Screen brightness symbol.
- 45: Light off time-out symbol.
- 48: Relative audio volume value.
- 49: Relative brightness level value.
- 50: Selected time-out value.
- 51: Software version.
Identification of key areas (Fig. 10)
- 42: Reset factory configuration.
- 46: Reduce value.
- 47: Increase value.
- 52: Validate the configuration.
b) Control unit back panel
The power receptacle (Fig. 2-1) with its grounding
pin is used to connect the IMPLANT CENTER 2 to the
power supply using a plug-in power cord.
The footswitch connector (Fig. 2-2) is used to
connect the IMPLANT CENTER 2 to the multifunction
control footswitch.
The fan (Fig. 2-3) protected by a metal grille, keeps
the IMPLANT CENTER 2 at its optimal performance level.
The bracket holders (Fig. 2-4) are used to install the
brackets.
The power switch (Fig. 2-5) is used to switch the
device ON or OFF.
The potential equalization connector (Fig. 2-6)
allows, if necessary, to connect devices together.
c) Control unit sides
The pump housings (Fig. 1-8) are designed to
accommodate SATELEC irrigation line cassettes.
The irrigation cassettes are installed by lifting the
pump covers and inserting the cassettes horizontally
into the cassette housings.
d) Front panel
- The left connector is designed to accept the
connector of the I-SURGE LED micro-motor cord. Only
a SATELEC micro-motor cord must be used.
- The right-hand connector is designed to accept the
connector of the NEWTRON LED cord or the connector
of the PIEZOTOME 2 LED handpiece cord.
8

e) Control footswitch
Having access to a large number of functions on the
control footswitch allows the practitioner to work in
a perfectly sterile environment, avoiding the risk of
cross-contamination.
Once the various settings have been adjusted, the
user has no further need to touch the keypad.
Depending on the mode, the control footswitch
buttons have different functions.
I-SURGE mode:
Footswitch button definitions (Fig. 11):
- 1: I-SURGE LED motor control (ON/OFF or
progressive).
- 2: Rotation direction.
- 3: Change program (P1 to P4).
- 4: Irrigation ON/OFF.
- 5: Select active handpiece.
PIEZOTOME mode:
Footswitch button definition (Fig. 11):
- 1: Ultrasonics control (ON/OFF or progressive).
- 2: Flush/prime.
- 3: Change program (D1 to D4).
- 4: Irrigation ON/OFF.
- 5: Select active handpiece.
NEWTRON mode:
Footswitch button definition (Fig. 11):
- 1: Ultrasonics control (ON/OFF or progressive).
- 2: Flush/prime.
- 3: Change program (Soft to Boost).
- 4: Irrigation ON/OFF.
- 5: Select active handpiece.
f) Technical characteristics
Manufacturer: SATELEC
Device name: IMPLANT CENTER 2
Electrical power supply:
- Voltage: 100 VAC to 230 VAC.
- Frequency: 50 Hz/60 Hz.
- Rated power: 250 VA at 230 VAC.
I-SURGE function
Operation:
Intermittent service: 20 sec. ON / 30 sec. OFF at 2
N.cm
Output characteristics:
I-SURGE LED micro-motor speed: 100 rpm to
40 000 rpm
I-SURGE LED micro-motor torque: max. 6 N.cm
Irrigation flow rate: 10 to 120 ml/min. (nominal
value).
Adjustment in 10 ml/min. steps
Flush/prime flow rate: 120 ml/min.
PIEZOTOME function
Operation:
Intermittent service: 10 min. ON / 5 min OFF
Output characteristics:
No-load voltage: 250 volts (nominal value without
handpiece)
Min. ultrasonic frequency: 28 kHz
Irrigation flow rate: 10 to 120 ml/min. (nominal
value)
Adjustment in 10 ml/min. steps (nominal value)
Flush flow rate: 120 ml/min. (nominal value)
NEWTRON function
Operation:
Intermittent service: 10 min. ON / 5 min. OFF
Output characteristics:
No-load voltage: 150 volts (nominal value without
handpiece)
Min. ultrasonic frequency: 28 kHz
Irrigation flow rate: 10 to 40 ml/min. (nominal value)
Adjustment in 1 ml/min. steps (nominal value)
Flush flow rate: 120 ml/min. (nominal value)
Protection
Electrical equipment class: Class 1
Electrical safety class:
Type BF in I-SURGE mode
Type BF in PIEZOTOME mode
Type BF in NEWTRON mode
9

Safety devices
Thermal safety shut off to avoid overheating of the I-
SURGE LED micro-motor
Safety shut off if internal malfunction
2 fuses (power cord receptacle): 5 mm x 20 mm - 2
AT for 100 VAC to 230 VAC
1 internal fuse not accessible to the user reference
F1: 5 mm x 20 mm – 10 AT / 250 VAC
Overall dimensions
Control unit:
Width: 472.9 mm
Height: 149.5 mm
Height with bracket: 471.1 mm
Depth: 339.9 mm
Weight: 5 kg without accessories
Footswitch:
Width: 311 mm
Depth: 209 mm
Height: 181 mm
Weight: approximately 3.5 kg
LCD screen:
Height: 86 mm
Width: 115 mm
Micro-motor cord: 2 000 mm
Scaler handpiece cord: 2 000 mm
PIEZOTOME handpiece cord: 2 000 mm
I-SURGE LED micro-motor:
Length: 93.1mm
Diameter: 23.2mm
Weight: 119g (without cord)
Coupling type: according to standard ISO 3964
Temperatures
Operation: +10°C to +40°C
Storage: -20°C to +70°C
Humidity
Operation: 30% to 75%
Storage: 10% to 100% including condensation
Atmospheric pressure
Between 500 hPa and 1060 hPa
Measuring units displayed and meaning
Ncm = torque (N.cm)
Rpm = speed (r/min.)
IV - INSTALLATION / FIRST
USE
4. 1 UNPACKING THE DEVICE
Upon receipt of the device, check for any damage
caused in transit.
Contact your supplier if necessary.
4. 2 RECOMMENDATIONS
Have your IMPLANT CENTER 2 connected to the power
electricity supply by a certified dental installation
technician.
The electrical connection of the IMPLANT CENTER 2 must
comply with the applicable standards in your country.
Warning:
To avoid any risk of electric shock, this device must
be connected to an electrical power supply with a
protective ground.
4. 3 INSTALLATION
Important:
Do not place the IMPLANT CENTER 2 close to or on top
of another device.
Do not place the power cord and the footswitch
cord in a wire cover or in a cable gland.
- Place the control unit in position on a fixed surface,
horizontal or with a slope of no more than 5°.
- Check that the power switch (Fig. 2-5) is in position
O (OFF).
10

- Connect the power cord to the receptacle of the
device.
- Connect the power cord to a power socket with a
ground pin.
- If necessary, connect the potential equilization
cable of your installation system to the unit
potential equalization connector (Fig. 2-6)
- Connect the control footswitch to the footswitch
connector (Fig. 2-2).
- Position the footswitch so that it is easily accessible
for your feet.
- Insert the brackets into the bracket holders (Fig. 2-
4).
- Connect the micro-motor cord to the connector
(Fig. 1-7).
- Align the I-SURGE LED micro-motor and cord
connector electrical contacts, then screw the motor
onto the connector.
- Connect the NEWTRON LED scaler cord or the PIEZOTOME
2LED handpiece cord to the connector (Fig. 1-9)
(according to option).
- Connect the NEWTRON LED handpiece to the scaler
cord (delivered according to option).
- Check that the device is close enough to the work
area to be used without pulling on the cords. If it is
not, move the device closer.
- Place the I-SURGE LED micro-motor on its rest.
- Place the NEWTRON LED or PIEZOTOME 2 LED handpiece
on the handpiece support.
- Suspend the bottles or bags of physiological saline
or sterile water from the brackets.
- Adjust the position of your device to suit your angle
of view.
4. 4 FIRST USE
Before using the IMPLANT CENTER 2 for the first time, all
the equipment must be given routine maintenance
and/or sterilized according to the procedures defined
in chapter 11.
V - IRRIGATION SOLUTION
IMPLANT CENTER 2 is not designed to administer drugs. It
must be used only with bottles or bags of
physiological saline or sterile water with an individual
capacity not exceeding one litre.
VI - IRRIGATION LINES
IMPLANT CENTER 2 must be used exclusively with
SATELEC irrigation lines.
VII - ADJUSTMENTS /
SETTINGS / MODES /
INTERFACE
7. 1 STARTUP
Important:
After stopping the device, wait four seconds before
restarting it.
Each time the device is switched on, the screen
displays program P1 of the I-SURGE function after
displaying the welcome page.
7. 2 SETTINGS
The settings are saved when each program is
configured and are retrieved whenever that program
is selected.
7. 3 IRRIGATION FUNCTION
a) Flush / prime
The flush / prime function is available on the LCD
screen and on the footswitch.
11

Press button (Fig. 3-1) or the footswitch button
(Fig. 11-2) (PIEZOTOME and NEWTRON modes) to switch
on the flush / prime function.
The flush / prime function stays on as long as the
button is pressed.
The flush can be switched on while the device is
being used.
b) Flow rate adjustment
The irrigation flow rate is adjusted using buttons
and (Fig. 3-4 and 5).
Each time the corresponding button is pressed, the
flow rate is adjusted.
The adjusted value is displayed on the LCD screen
(Fig. 3-2) and stored in the current program.
The flow rate can be adjusted while the device is
being used.
c) Irrigation ON/OFF
The irrigation is switched ON or OFF by pressing
button (Fig. 3-3) or the footswitch button (Fig.
11-4).
When irrigation is selected, the symbol is
highlighted.
When irrigation is not selected, the symbol
is darkened.
7. 4 LIGHT FUNCTION
The light function is displayed on the LCD screen.
Pressing button (Fig. 3-11) switches the light
function ON or OFF.
The light function has a default light-off time-out of
nine seconds.
Switching off the light function becomes effective
when the time-out has elapsed.
If necessary, you can lengthen the time-out (refer to
7.7).
7. 5 I-SURGE FUNCTION
a) Selecting the rotation direction
The rotation direction of the I-SURGE LED micro-motor
is controlled by the control footswitch button (Fig.
11-2).
When clockwise rotation is selected, the symbol
is displayed on the LCD screen (Fig. 6-23).
When counterclockwise rotation is selected, an
audible signal is emitted and the symbol is
displayed on the LCD screen (Fig. 6-23).
b) Program setting adjustment
Important:
When programming the maximum instrument end
speed, the entered value cannot exceed the pre-
programmed value.
Do not go below the minimum motor speed value
(100 rpm, 1:1 contra-angle).
Do not exceed the maximum pre-programmed
value of the instrument end torque, and do not go
below 10% of this value.
When setting the torque, please refer to the
contra-angle and implant system manufacturers’
recommendations.
Select the I-SURGE function by pressing button
(Fig. 3-12).
On the LCD screen, the I-SURGE tab must be
highlighted.
Select the program for which settings are to be
adjusted using buttons , , or (Fig. 6-
24) or using the footswitch button (Fig.11-3); the
various programmed parameter settings are
displayed.
The contra-angle (Fig. 6-20) value is displayed
(Fig. 6-17).
The speed (Fig. 6-21) value is displayed (Fig. 6-18).
12

The torque (Fig. 6-22) value is displayed (Fig. 6-
19).
c) Selecting a contra-angle
Selecting a pre-programmed contra-angle:
Press button (Fig. 6-20): the preprogrammed
contra-angle options are displayed (Fig. 8).
Select a multiplier contra-angle using the red buttons
(Fig. 8-35) or a direct contra-angle using the blue
button (Fig. 8-36) or a divider contra-angle using the
green buttons (Fig. 8-37).
The value of the selected contra-angle is displayed
(Fig.8-38).
The maximum permitted speed (Fig.8-39) and torque
(Fig.8-40) are displayed for each contra-angle.
Button (Fig. 8-32) is used to return to the main
screen without saving the changes.
Confirm the selected contra-angle by pressing button
(Fig. 8-34); the main screen is displayed.
Programming a user-defined contra-angle:
IMPLANT CENTER 2 enables specific contra-angles to be
used. A contra-angle value can be programmed.
On the main screen press button (Fig. 6-20); the
preprogrammed contra-angle options are displayed
(Fig. 8).
Press button (Fig. 8-33); the button is
highlighted.
Program the contra-angle using the numeric keypad
(Fig. 7-31).
The programmed contra-angle value is displayed (Fig.
7-25).
Press button (Fig. 7-29) to delete the last digit.
Press button (Fig. 7-28) to return to the main
screen without saving the changes.
Confirm your customization of the contra-angle by
pressing button (Fig. 7-30); the main screen is
displayed.
The maximum permitted speed (Fig. 6-18) and torque
(Fig. 6-19) are displayed for the programmed contra-
angle.
d) Speed adjustment
On the main screen, press button (Fig. 6-21); the
speed adjustment screen is displayed (Fig. 7).
Program the speed using the numeric keypad (Fig. 7-
31).
The programmed speed is displayed (Fig. 7-26).
Press button (Fig. 7-29) to delete the last digit.
Press button (Fig. 7-28) to return to the main
screen without saving the changes.
Confirm the speed adjustment by pressing button
(Fig.7-30); the main screen is displayed.
Note: The instrument speed can be adjusted directly
using buttons or (Fig. 3-6 and 3-7) for
programs , or even when the
multifunction footswitch is switched on.
To obtain a stable speed adjustment result, it is
recommended to press the footswitch fully (Fig. 11-
1).
Pressing buttons or (Fig. 3-6 and 3-7)
increases or reduces the speed value.
Pressing and holding buttons or (Fig. 3-6 and
3-7) for longer than 3 seconds causes faster increase
or reduction of the speed value.
If a torque or speed value outside the permitted
range is entered, !min! or !max! is displayed. The
maximum or minimum permitted value is then
displayed, depending on the case.
13

14
e) Torque adjustment
On the main screen, press button (Fig. 6-22); the
torque adjustment screen is displayed (Fig. 7).
Program the torque using the numeric keypad (Fig. 7-
31).
The programmed torque is displayed (Fig. 7-27).
Press button (Fig. 7-29) to delete the last digit.
Press button (Fig. 7-28) to return to the main
screen without saving the changes.
Confirm the torque adjustment by pressing button
(Fig. 7-30); the main screen is displayed.
Note: The instrument torque can be adjusted directly
using buttons or (Fig. 3-6 and 3-7) for
program , even when the multifunction
footswitch is switched on.
f) Selecting footswitch type
Change the footswitch type if necessary by pressing
button (Fig. 3-10) to toggle between ON/OFF
and progressive .
g) Light
If necessary, select light function ON/OFF by pressing
button (Fig. 3-11).
h) Completion of setting adjustment
Confirm the new settings by pressing button (Fig.
3-8).
The storing of the various settings is confirmed by an
audible signal.
Repeat this sequence if necessary in order to adjust
all the programs.
7. 6 PIEZOTOME FUNCTION
Important:
The PIEZOTOME function settings can be customized
by the user.
The PIEZOTOME function settings can be adjusted
when no PIEZOTOME 2 handpiece is connected to the
device.
The program giving the highest power is D1.
Select the Piezotome function by pressing button
(Fig. 3-12) or by pressing the footswitch
button (Fig. 11-5).
On the LCD screen, the PIEZOTOME tab must be
highlighted.
Select the program to be used by pressing button
, , or (Fig. 4-14) or using
the footswitch button (Fig. 11-3); the selected
program is highlighted on the LCD screen.
Adjust the programs and the power level according to
the tip data sheet recommendations.
If necessary, modify the irrigation function (flow rate
value, etc.) (refer to 7.3).
If necessary, modify the program power level (1 to 5)
using buttons (Fig. 3-6) and (Fig. 3-7).
The power level of the program concerned is shown
as a number and a bar-graph (Fig. 4-13).
Modify the footswitch type if necessary by pressing
button (Fig. 3-10) to toggle between ON/OFF
Program Main functions
Very powerful D1
Osteotomy, osteoplastyPowerful D2
Medium D3
Low D4 Soft tissue detachment

15
and progressive .
Important:
In progressive mode, for programs D1 to D3, the
delivered power ranges between power level 1 of
program D3 and the configuration defined by the
user (program and power level).
In progressive mode, the power delivered by
program D4 ranges only between levels 1 and 5,
according to the value defined by the user.
If necessary, select handpiece light function ON/OFF
by pressing button (Fig. 3-11).
Confirm the new settings by pressing button
(Fig. 3-8).
The saving of the various settings is confirmed by an
audible signal and a visual signal (button flashing).
Repeat this sequence if necessary in order to adjust
all the programs.
Caution: The tips designed for PIEZOTOME 2 and
IMPLANT CENTER 2 are not compatible with PIEZOTOME
and IMPLANT CENTER, and vice versa.
7. 7 NEWTRON FUNCTION
Important:
A scaler cord and its NEWTRON LED handpiece must
be connected to the device in order to be able to
configure the various settings.
The NEWTRON LED function settings can be
customized by the user.
Select the NEWTRON function by pressing button
(Fig. 3-12) or by pressing the footswitch
button (Fig. 11-5).
On the LCD screen, the NEWTRON tab must be
highlighted.
Select the program for which settings are to be
adjusted by pressing buttons , ,
or (Fig. 5-16) or by pressing the footswitch
button (Fig. 11-3).
Adjust the power level according to the TipBook
recommendations.
If necessary, modify the program power level (1 to
10) using buttons (Fig. 3-6) and (Fig. 3-7).
The power level of the program concerned is shown
as a number and a bar-graph (Fig. 5-15).
Modify the footswitch type if necessary by pressing
button (Fig. 3-10) to toggle between ON/OFF and
progressive.
If necessary, select handpiece light function ON/OFF
by pressing button (Fig. 3-11).
Confirm the new settings by pressing button (Fig.
3-8). The saving of the various settings is confirmed
by an audible signal and a visual signal (flashing
button).
Repeat this sequence if necessary in order to adjust
all the programs.
7. 8 TOOLBOX
Important:
IMPLANT CENTER 2 has a TOOLBOX function used to
make various adjustments, including screen
brightness, handpieces light off time-out, audio
volume and factory configuration reset.
To access the TOOLBOX function, switch OFF the
device, wait four seconds, switch the device ON
again, then press button (Fig. 9-41) on the
welcome screen (Fig. 9).

a) Audio volume adjustment
Adjust the audio volume value (Fig. 10-43) using
buttons and (Fig. 10-46 and 47). The audio
volume is adjustable from 0% to 100%.
The relative value of the audio volume is displayed
(Fig. 10-48).
b) Screen brightness adjustment
Adjust the brightness value (Fig. 10-44) using
buttons and (Fig. 10-46 and 47). The
brightness is adjustable from 30% to 100%.
The brightness level setting is displayed (Fig. 10-49).
c) Light off time-out adjustment
Adjust the time-out length value (Fig. 10-45) by
pressing buttons and (Fig. 10-46 and 47).
The length of the adjustable time-out (from nine
seconds to 18 seconds) is displayed (Fig. 10-50).
I-SURGE mode:
d) Storing the settings
To store the modified settings, press button (Fig.
10-52). The screen shown in Fig. 9 reappears.
e) Factory configuration reset
Press button (Fig. 10-42) to restore the
factory configuration settings.
The factory configurations for the PIEZOTOME and
NEWTRON functions are effective when button
(Fig. 10-52) is pressed. The screen shown in Fig. 9
reappears.
f) Software version
The version of the software is displayed at the
bottom of the screen (Fig. 10-51).
IMPLANT CENTER 2 is configured in the factory with the
following settings:
16
Program Contra-angle
ratio
Speed at
instrument end
Torque at
instrument end Irrigation Functions
P1 20:1 1200 rpm 80 N.cm 80 ml/min. Implant site marking
P2 20:1 800 rpm 80 N.cm 100 ml/min. Pilot drilling
P3 20:1 15 rpm 20 N.cm 100 ml/min. Boring / tapping
P4 20:1 30 rpm 20 N.cm 0 Screwing

PIEZOTOME mode:
NEWTRON mode:
VIII - SAFETY
The IMPLANT CENTER 2 is equipped with a self-diagnosis
system to detect malfunctions.
When an excessively high temperature of the I-SURGE
LED micro-motor is detected, symbol 1 (chap. XVII -
Symbol) is displayed in the error zone (Fig. 3-9) and
the device beeps four times.
The device switches to degraded mode so that it can
complete the dental procedure.
The available torque value is set at 25% in order to
protect the I-SURGE LED micro-motor.
It is recommended that the I-SURGE LED micro-motor
be allowed to cool down until symbol 1 (chap. XVII -
Symbol) disappears.
In the case of a motor malfunction, symbol 2 (chap.
XVII - Symbol) is displayed in the error zone and the
device beeps four times.
It is recommended that you check the connections of
your motor and your motor cord. If the fault persists,
switch the device off at the power switch (Fig. 2-5)
and switch it back on again.
In the case of an internal operation malfunction,
symbol 3 (chap. XVII - Symbol) is displayed in the
error zone and the device beeps four times.
It is recommended that the device be switched off
(Fig. 2-5) and switched back on again.
In the event of a handpiece detection fault, symbol
n°4 lights up in the error zone and four beeps sound.
It is recommended to check:
- The handpiece connection to the connector of the
device.
- The selected mode on the device (left / right)
should be on the same side as the handpiece
connector.
IX - USING THE DEVICE
Important:
- Do not disconnect the micro-motor cord or the
scaler cord when the device is switched on and
the footswitch is pressed.
- Do not disconnect the micro-motor or the
ultrasonic handpieces when the device is
switched on and the footswitch is pressed.
- Do not connect the instrument to, or disengage it
from, the contra-angle when the micro-motor is
running.
- Do not screw or unscrew tips when the
handpieces are on.
- All accessories must be cleaned, disinfected and
sterilized before use.
For your safety and that of your patient, IMPLANT
CENTER 2 must not be used with accessories other
than those supplied or recommended by SATELEC.
- Check the integrity of the device and its
accessories before and after each use in order to
detect any problem.
- If necessary, do not use the device and replace
any faulty component.
17
Program Power Irrigation Main functions
Very
powerful D1 3 60 ml/min.
Osteotomy,
osteoplasty
Powerful D2 3 60 ml/min.
Medium D3 3 60 ml/min.
Low D4 3 60 ml/min. Soft tissue
detachment
Program Power Irrigation Main functions
Green Soft P=5 15 ml/min. Periodontics
Yellow Medium P=5 15 ml/min. Endodontics
Blue High P=5 15 ml/min. Scaling
Orange Boost P=5 15 ml/min. Loosening

The IMPLANT CENTER 2 is prepared for use as follows:
- Make sure that the device is connected correctly
and properly insulated.
- Switch the power switch (Fig. 2-5) to position I
(ON).
- Suspend the bottles or bags of physiological saline
or sterile water from the brackets.
- Raise the irrigation pump covers.
- Insert the irrigation line cassettes horizontally into
their housings.
- Close the covers.
- Insert the irrigation line perforating pins into the
bottles or pouches of physiological saline and open
the cap on the pins.
- Make any necessary setting adjustments (irrigation
flow rate, speed, torque, power, power mode,
program, etc.) (refer to chapter 7).
Note: This sequence must be completed under
conditions of controlled asepsis for the safety of your
patients. An operating assistant may be needed.
Note: The data is saved automatically, in order to
maintain the display parameters as previously used
upon switchover from the various modes.
I-SURGE LED function
- Check that there are no traces of moisture on the I-
SURGE LED micro-motor or micro-motor cord
connections. If there are, remove by wiping and
drying with the multifunction syringe fed with
medical-quality filtered air.
- Connect the micro-motor cord to the lefthand
connector of the device (Fig. 1-7).
- Align the micro-motor and cord connector electrical
contacts, then screw the motor onto the connector.
- Connect a contra-angle to the I-SURGE LED micro-
motor.
- Fit an instrument (drill, bur, etc.) to the contra-
angle.
- Fasten the irrigation line to the cord using line
clips.
- Connect the end of the irrigation line to the contra-
angle.
- Run the motor fitted with its contra-angle and its
instrument without irrigation at moderate speed for
10 to 15 seconds in order to diffuse the lubricant
and eliminate excess.
- Prime the irrigation circuit by pressing the control
keypad flush/prime button (Fig. 3-1).
- When the irrigation solution reaches the end of the
contra-angle, release the footswitch.
- Use IMPLANT CENTER 2 in accordance with good dental
practice.
PIEZOTOME function
- Connect the PIEZOTOME 2 LED handpiece cord to the
righthand connector of the device (Fig. 1-9).
- Screw the selected tip onto the handpiece using a
tip wrench (according to the recommendations of
the clinical booklet).
- Fasten the irrigation line to the cord using line
clips.
- Connect the end of the irrigation line to the
PIEZOTOME 2 LED handpiece.
- Prime the irrigation circuit by pressing the
flush/prime button on the screen (Fig. 3-1) or the
multifunction footswitch (Fig. 11-2).
- When the irrigation solution reaches the end of the
tip, release the footswitch.
- Use the IMPLANT CENTER 2 in accordance with good
dental practice.
NEWTRON function
- Check that there are no traces of moisture on the
NEWTRON LED handpiece or the scaler cord
connections. Remove any moisture by wiping and by
drying with the multifunction syringe fed with
medical-quality filtered air.
- Connect the scaler cord to the righthand connector
of the device (Fig. 1-9).
- Align the electrical contacts of the NEWTRON LED
handpiece and the scaler cord, then plug the
handpiece into the cord.
- Screw the selected tip onto the handpiece using a
tip wrench (according to the TIPBOOK
recommendations).
- Fasten the irrigation line to the cord using line
clips.
- Connect the end of the irrigation line to the scaler
cord.
18

- Prime the irrigation circuit by pressing the
flush/prime button on the screen (Fig. 3-1) or the
multifunction footswitch (Fig. 11-2).
- When the irrigation solution reaches the end of the
tip, release the footswitch.
- Use the IMPLANT CENTER 2 in accordance with good
dental practice.
X - SHUTTING DOWN THE
DEVICE
Upon completion of the dental procedure:
- Remove the bottles or bags of physiological saline or
sterile water from the brackets.
- Remove the irrigation line perforating pins from the
bottles or bags.
- Immerse the irrigation line perforating pins in a
vessel containing distilled water.
- Rinse each irrigation line alternately, along with the
contra-angle and the handpiece, by running the
flush/prime function until the vessel and the
irrigation lines are completely empty.
- Remove the irrigation line clips.
- Disconnect the irrigation lines from the contra-
angle and from the handpieces.
- Remove the rotary instruments fastened to the
contra-angle and the tip screwed onto the
handpiece.
- Disconnect the contra-angle from the I-SURGE LED
micro-motor.
- Disconnect the micro-motor cord from the
I-SURGE LED.
- Disconnect the PIEZOTOME 2 LED handpiece or the
NEWTRON LED handpiece and the scaler cord.
- Switch the device OFF (O).
XI - ROUTINE MAINTENANCE /
STERILIZATION
Important:
The device must be switched OFF during cleaning
and disinfection procedures.
The only irrigation lines that can be sterilized are
those identified as sterilizable.
During sterilization, items made of different metals
must not come into contact. Any contact would
establish galvanic couples and cause localized
damage.
To avoid this happening, place the items in
individual sterilizable bags or in a sterilization box.
To maintain the sterility or asepsis of the
accessories (contra-angle, micromotor, micromotor
cord, cords, handpieces, etc.), store them in
sealed bags or containers suitable for medical
practice.
The maintenance and/or sterilization instructions
below must be applied before each use of the
device.
Avoid using cleaning and disinfection agents
containing flammable substances.
If this is not possible, make sure that all the agent
has evaporated and that there is no combustible
matter on the device or its accessories before it is
switched on.
Sterilized items must be allowed to dry and cool to
room temperature before they are reused.
Before sterilization, check that your autoclave is
clean and that the water used is of adequate
quality.
After each sterilization cycle, remove the items
from the autoclave immediately in order to
minimize the risk of metal corrosion.
19

11. 1 IRRIGATION LINE MAINTENANCE
Sterilizable irrigation line
Refer to the user's manual delivered with the
equipment.
The irrigation line delivered with the IMPLANT CENTER 2
unit are sterilizable. The perforaters are single-use
and delivered sterile.
Sterile irrigation line
Satelec can provide disposable irrigation lines which
must always be discarded, in safety container for
soiled medical items, after use. Re-use of a single-use
irrigation line may result in contamination of your
patients and expose you to de facto liability. Do not
attempt to resterilize the single-use irrigation lines.
Do not attempt to modify the irrigation lines.
11. 2 CONTRA-ANGLE MAINTENANCE
Refer to the manufacturer's instructions for your
contra-angle.
11. 3 ROTARY INSTRUMENT MAINTENANCE
Please refer to the manufacturer's instructions for
your instruments (burs, drills, etc.).
11. 4 DEVICE MAINTENANCE
Important:
Never use an abrasive cleaning agent on the
device.
Do not use sprays or liquids to clean and disinfect
the IMPLANT CENTER 2 control unit.
The device, the brackets and the multifunction
footswitch are not sterilizable.
The IMPLANT CENTER 2 control unit, the control
footswitch and the bracket must always be cleaned
and disinfected after each procedure, using alcohol,
disinfectant agents or disinfectant wipes for dental
practices, such as SEPTOL™ wipes.
Regular monitoring of the IMPLANT CENTER 2 unit is
necessary in order to detect any problem.
It is important to keep the control unit ventilation
vents clean in order to avoid abnormal heating.
11. 5 MICROMOTOR CORD AND SCALER CORD
MAINTENANCE
Important:
Never use an abrasive cleaning agent on the cords.
The cords must not be immersed or disinfected
using agents containing acetone, chlorine or
bleach.
The cords must not be cleaned in an ultrasonic
bath.
a) Cleaning and disinfection
The cords must always be cleaned, disinfected and
sterilized after each procedure, using alcohol,
disinfectant agents or disinfectant wipes for dental
practices, such as SEPTOL™ wipes.
b) Sterilization
The cords can be sterilized in an autoclave under the
following conditions:
- Autoclave: Class B
- Sterilization temperature: 134°C at 2 Bar.
- Time at sterilization temperature: 18 minutes.
CAUTION: Not all autoclaves can reach 134°C. Not
all autoclaves draw a pre-vacuum. Please refer to
your autoclave manufacturer for specific
sterilization instructions.
11. 6 I-SURGE LED MICRO-MOTOR MAINTENANCE
Refer to the user's manual delivered with the
equipment.
11. 7 ULTRASONIC HANDPIECE MAINTENANCE
After each use, the handpiece irrigation circuit must
be rinsed with distilled or demineralized water for 20
to 30 seconds.
Disconnect the NEWTRON LED handpiece from its cord
before cleaning, disinfection and sterilization.
20
