Satson HDM-SDI-201 User manual

HDM-SDI-201HDM-SDI-201
HDMI to 3G/HD/SD-SDI Converter
rev: 130313
Made in Taiwan
7.1 CH
AUDIO
7.1 CH
AUDIO
User Manual

Safety and Notice
The HDM-SDI-201 HDMI to 3G/HD/SD-SDI Converter has been tested for conformance to
safety regulations and requirements, and has been certied for international use. However, like
all electronic equipments, the HDM-SDI-201 should be used with care. Please read and follow
the safety instructions to protect yourself from possible injury and to minimize the risk of damage
to the unit.
● Follow all instructions and warnings marked on this unit.
● Do not attempt to service this unit yourself, except where explained in this manual.
● Provide proper ventilation and air circulation and do not use near water.
● Keep objects that might damage the device and assure that the placement of this unit is on a
stable surface.
● Use only the power adapter and power cords and connection cables designed for this unit.
● Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device
before cleaning.
INTRODUCTION ..........................................................................................................
FEATURES ...................................................................................................................
PACKAGE CONTENTS ................................................................................................
SPECIFICATIONS ........................................................................................................
PANEL DESCRIPTIONS ...............................................................................................
SUPPORTED RESOLUTIONS .....................................................................................
CONNECTION DIAGRAM ............................................................................................
EDID LEARNING ..........................................................................................................
LIMITED WARRANTY ..................................................................................................
TABLE OF CONTENTS
1
1
1
2
3
4
4
5
5

1
INTRODUCTION
The HDM-SDI-201 provides a professional way to convert HDMI to 3G/HD/SD SDI in real time. The
conversion between SDI and HDMI is pure digital and guarantees no loss transformation for both
audio and video. Plus, with up to 8 channels audio support, 7.1 channel or 5.1 channel audio becomes
available. The HDM-SDI-201 also provides 2 low jitter SDI outputs for daisy chain or multiple monitors.
With the use of HDM-SDI-201, the most popular uncompressed video interface in the consumer world is
readily available for professional SDI equipments!
FEATURES
Supported high-denition (HD) formats:
NTSC [email protected], PAL 625@50, 720p@50,[email protected], 720p@60, 1080i@50, [email protected],
1080i@60, [email protected], 1080p@24, 1080p@25, [email protected], 1080p@30, 1080p@50,
[email protected], 1080p@60
Bit Rate: 2.97 Gbps, 2.967 Gbps, 1.485 Gbps, 1.4835 Gbps, 270 Mbps
●Auto 3G/HD/SD-SDI detection
●Support HDMI Deep Color
●Two SDI compliant outputs
●External DIP Switch Conguration
PACKAGE CONTENTS
● 1x HDM-SDI-201
● 2x DC 5V 2A wall wart
● 1x User Manual

2
SPECIFICATIONS
2
SPECIFICATIONS
Model Name HDM-SDI-CON-0612
Technical
SDI standards 3G-SDI & HD-SDI & SD-SDI
Auto HD/SD-SDI detection Yes
Video bandwidth [2.97Gpbs & 2.975/1.001Gbps]
Video support
[3G] 1080p50/59.94/60 (4:2:2)
[HD] – 720p @50/59.94/60Hz,1080i @50/59.94/60Hz,
[email protected]/24/25/29.97/30Hz
[SD] – NTSC @59.94Hz, PAL @50Hz
Input signal HDMI
Output signal SDI
Output impedance 75Ω
Synchronization mode Internal synchronization or external synchronization
Eye pattern characteristics Extra low alignment jitter 0.05UI at HD
Cable equalization [3G-SDI] up to 90m (300ft), [HD-SDI] up to 150m (500ft),
[SD-SDI] up to 300m (1000ft)
Audio support Yes
PCB stack-up 6-layer board [impedance control — differential 100Ω; single 50Ω]
Input 1x HDMI
Output 2x BNC [SDI]
BNC connector 75Ω inter-locked socket
HDMI connector Type A [19-pin female]
DIP switch 2-pin [for EDID use]
Mechanical
Housing Metal enclosure
Dimensions
[L x W x H]
Model 79 x 84 x 27mm [3.1” x 3.3” x 1.2”]
Package 140 x 200 x 75mm [5.5” x 7.9” x 3”]
Carton 420 x 400 x 300mm [1’8” x 1’4” x 11.8”]
Weight Model [TX] – 250g [8.8oz]
Package 780g [1.7 lbs]
Fixedness Inter-locked power supply
Power supply 5V 2A DC
Power consumption 3 Watt [max]
Operation temperature 0~40°C [32~104°F]
Storage temperature -20~60°C [-4~140°F]
Relative humidity 20~90% RH [no condensation]
Model Name HDM-SDI-201

3
PANEL DESCRIPTIONS
Front Panel
1
HDMI INPUT
2
Signal LED:
<green> signal active
<red> power
3
Interlocked +5V power jack
Rear Panel
4
3G/HD/SD-SDI output #1
5
3G/HD/SD-SDI output #2
6
DIP switch
3
Front Panel
1
HDMI input
2
Signal LED:
<green> signal active
<red> power
3
Interlocked +5V power jack
Rear Panel
4
3G/HD/SD-SDI output #1
5
3G/HD/SD-SDI output #2
6
DIP switch
Pin #1 Pin #2 EDID feature
OFF (

)OFF (

)3G/HD/SD-SDI with multi-channel audio except DTS-HD Master & Dolby TrueHD
OFF (

) ON (

)3G/HD/SD-SDI With stereo PCM audio
ON (

)OFF (

)HD/SD-SDI With stereo PCM audio
ON (

) ON (

)EDID Learning Mode
Factory default: OFF-OFF [-]
