sauter FK Series User manual

Instruction Manual
FK
AS, 03.04.2008 FK GB.doc Page 1 of 3
S
S
T
i
w
Thank you for buying a SAUTER force gauge. We hope
you are pleased with your high quality force gauge with its
big functional range. If you have any queries, wishes or
helpful suggestions, do not hesitate to call our service
number.
„Sensor Inside“ means the measuring cell is inside the
housing.
1.
Included in delivery
- SAUTER FK
- Charger
- Standard Attachments as shown below
Terms:
Track = continuous measurement
Peak = Capture of the maximum value
Data in mm
2.
Working Conditions
10°C to 30°C / 15% up to 80% humidity
3.
Electrical Power Supply
Either by recharchable battery or current power supply
Current power supply:
- Connection by power adapter
- Recharchable batteries are charged
simultaneously
Recharchable battery pack for mobile applications:
- Type: AA Size 6 Batteries
- Charging time: approx 1 hour
4.
Technical Data
- Accuracy: ± 0,5 % of Capacity
- Data Sampling Rate: 1.000 Hz
Model Capacity Resolution
FK 10 10 N 0,005 N
FK 25 20 N 0,010 N
FK 50 50 N 0,020 N
FK 100 100 N 0,050 N
FK 250 200 N 0,100 N
FK 500 500 N 0,20 N
FK 1k 1 000 N 0,50 N
Se nsor
I nside
LCD
Force Sensor
195 mm
83 mm

Instruction Manual
FK
AS, 03.04.2008 FK GB.doc Page 2 of 3
S
S
T
i
w
5.
Operation
a. Display
(1) Measuring Result
(2) Measuring Units
(3) Measuring Direction
(4) Indication of PEAK Mode
b. Operating keys
ON / OFF:
ON / OFF key
(For ON, press 1 sec.)
MAX:
Changes between Track and Peak mode (capture of
maximum values)
UNIT:
- Press short: Select unit:
N, kg, lb, ou
ZERO:
- Zeros the measuring result (Tara function)
- Cleans the peak value (in Peak mode)
c. Display Return
When the instrument itself is turned so that the head faces
down, the display returns automatically.
d. Measurement (Track Modus)
Display (1) shows the continuous force in a defined
direction (3)
To zero the display, press:
e. Peak-Hold Function (Peak Mode)
Please press:
6.
Backside Fixing to a test stand
Fixing by 4 x M3 scres.
7.
CE Declaration of Conformity
(1)
(2)
(3)
(4)

Instruction Manual
FK
AS, 03.04.2008 FK GB.doc Page 3 of 3
S
S
T
i
w
8. Warning
2.1 Intended use
The instrument you have acquired serves to determine the
measuring value of the material to be measured. It is
intended to be used as a “non-automatic“ instrument, i.e.
the material to be measured is manually and carefully
attached at the instrument. The measuring value can be
read off after a stable measuring value has been obtained.
2.2 Inappropriate use
Do not use the instrument for dynamic measuring. In the
event that small quantities are removed or added to the
material to be
measured, incorrect measuring results can be displayed
due to the “stability compensation“ in the instrument.
(Example: Slow draining
off of liquid from a container suspended from the
instrument). Do not attach a continuous load. This can
damage the measuring
unit as well as the parts, relevant to safety.
Prevent jolts, torsion and oscillation (e.g. by appending
slopingly) of all kinds. Be sure to prevent overloading the
instrument in excess of the stated maximum load (max.),
minus any tare weight that may possibly exist. This could
damage the instrument (risk of breakage).
Important:
• Always make sure that there are no people or materials
below the load that could be injured or damaged!
• The instrument is not suitable for measuring people. Do
not use as baby scales!
• The instrument does not comply with the medical product
law (MPG).
Never operate the instrument in hazardous locations. The
series design is not explosion-proof. Structural alterations
may not be
made to the instrument. This can lead to incorrect
measuring results, faults concerning safety regulations as
well as to destruction
of the instrument. The instrument may only be used in
compliance with the described guidelines. Varying areas of
application/
planned use must be approved by SAUTER in writing.
2.3 Guarantee
The guarantee is not valid following
• non-observation of our guidelines in the operating
instructions
• use outside the described applications
• alteration to or opening of the device
• mechanical damage and damage caused by media,
liquids
• natural wear and tear
• inappropriate erection or electric installation
• overloading of the measuring equipment
2.4 Monitoring the test substances
The metrology features of the instrument and any possible
available adjusting weight must be checked at regular
intervals within the scope of quality assurance. For this
purpose, the answerable user must define a suitable
interval as well as the nature and scope of this check.
Information is available on
the home page (www.KERN-sohn.com) with regard to the
monitoring of instrument test substances and the test
weights required for this. Test weights and instruments can
be adjusted quickly and at a reasonable price in KERN’s
accredited DKD calibration laboratory (return to national
normal).
3. Fundamental safety information
Do not use the hanging instrument to transport loads.
Prevent jolts, torsion and oscillation (e.g. by appending
slopingly) of all kinds.
Never use the hanging instrument over the maximum
permitted weight (!!Danger of breaking!!).
Always make sure that there are no living beings or
materials below the load that could be injured or damaged.
The hanging electronic instruments from the SAUTER
instrument are only suitable for hand-held use or use in a
test stand.
They are not suitable for hanging from a mechanical hook,
e.g. a crane hook.
3.1 Observe the information in the operating instructions
Please read the operating instructions carefully before
erecting
and commissioning, even if you already have experience
with SAUTER instruments.
3.2 Staff training
The device may only be operated and looked after by
trained members of staff.
