Savant CLI-W200 User manual

1
009-1593-02
SMART THERMOSTAT
QUICK START GUIDE
CLI-W200

2009-1593-02
What’s in the Box
Specifications
Optional Sensors
(1) Wi-Fi Thermostat (CLI-W200x)
(1) Installation Kit
(2) Drywall Anchors (039-0328-xx)
(2) #6 x 3/4 inch Pan Head Screws (039-0327-xx)
(1) Sheet of Wire Labels (080-0096-xx)
(1) Quick Start Guide (this document)
– SST-TEMP1 Remote Temperature (Flush Mount)
– SST-OTEMP1 Remote Temperature (Outdoor)
– CLI-THFM1 Temperature and Humidity (Flush Mount)
– CLI-PLEN1R/C Plenum Sensor
– CLI-SLAB1 Slab Sensor
Environmental
Temperature 32 to 104 F (0 TO 40 C)
Humidity 10% to 90% (non-condensing)
Power
Input 24V AC
Current Draw 70 mA typical, 250 mA maximum
Max Power 6 watts
Cable Requirements
Power #18 AWG
HVAC #18 AWG Thermostat Wire (solid)
Remote Sensors #24 AWG - 500 feet (152 m) max
Regulatory
Safety / Emissions FCC Part 15
FCC ID: ASU-CLIW200
IC: 10052A-CLIW200
RoHs Compliant
Standards
Wireless Wi-Fi (802.11 b/g/n 2.4 GHz)
IMPORTANT! 802.11r fast roaming
is not supported.
Security 70 mA typical, 250 mA maximum
Max Power 6 watts

3
009-1593-02
– Pencil
– #2 Phillips screwdriver
– Small slotted screwdriver
– Drill with / inch drill bit
– Wire stripper
– Needle-nose pliers
– Hammer (if wall anchors are used)
Welcome
Getting Started
Location and Mounting Overview
The following is needed for a trouble free installation:
This document describes how to:
1. Remove the old thermostat.
2. Mount your new CLI-W200 thermostat.
3. Wire your new CLI-W200 thermostat.
CAUTION! When replacing an older thermostat that
contains Mercury in a sealed tube, do not discard into trash.
Refer to the thermostat-recycle.org website for information
on how to properly dispose.
For new installations or when relocating the thermostat,
follow the guidelines below:
– Locate thermostat on an inside wall.
– Do not locate where air circulation is poor such as in a
corner or behind a door.
– Do not locate near windows or doors to reduce the expo-
sure to drafts.
– Install away from any heating conditions such as direct
sunlight, near a radiator register or vent, or near a fireplace.
– To adhere to ADA requirements, install thermostat 48 - 54
inches (1.22 - 1.37 meters) above the floor.
– Height requirements can be adjusted upward to 60 inches
(1.5 meters) if ADA requirements are not mandatory.
– The thermostat does not need to be level to operate cor-
rectly. Leveling the thermostat is for aesthetics only.
– Thermostat can be oriented in either a portrait or land-
scape layout.

4009-1593-02
Remove Old Thermostat
1. Before starting the process, scroll through the old thermo-
stat and record the current settings and schedules.
2. Switch OFF power at either the breaker panel or the
switch that controls your HVAC system.
3. Open the old thermostat so the wiring is accessible. Take
a photo of the existing thermostat and wiring. The photo
should reveal wire colors and terminal designations.
4. Using chart below, add a check and record the wire color
for each power wire. Not all terminals may be populated.
Terminal Color of Wire
R
C
RC
5. Remove each of the wires recorded above and attach a
label that matches the terminal designation from the old
thermostat. Label wires according to the terminal desig-
nation and NOT the wire color.
6. Again, using the chart below, add a check and record the
wire color for each signal wire.
Terminal Color of Wire
O
G
Y2
Y1
W2
W1
NOTE: Additional information on terminal designa-
tions and useful wiring diagrams are available in the
CLI-W200 Thermostat Deployment Guide located in
the pages of the Savant Customer Community.
7. With a screwdriver, remove the wires from each terminal.
TIP! Wrap wires around a pencil or similar to prevent
the wires from falling back into wall.
8. Remove the old thermostat from the wall.

5
009-1593-02
Install Thermostat Mounting Plate
1. To separate the thermostat from its mounting plate, grasp
the mounting plate in one hand and the thermostat in the
other (Grasp the end opposite the proximity sensor).
2. Rock the top and bottom halves until they separate.
3. Position the thermostat mounting plate onto the wall.
With a pencil, mark the two mounting holes onto the wall
(See image above).
– When mounting using a portrait layout, use the bubble
level installed in the center of the mounting plate to
level.
– When mounting using a landscape layout, remove
bubble level by pushing it out through the rear of the
mounting plate and reinstall it into the bubble level slot
on the right side of center cutout. See diagram above.
4. Drill a / inch hole on each mark made and tap the wall
anchor into wall until flush. In some installations that have
a sub wall to fasten to, wall anchors may not be required.
5. Pull the existing wires through the center cutout in the
mounting plate.
6. Screw the mounting plate to the wall using the supplied
#8 x / inch screws.
Bubble level slot
(Portrait)
Bubble level slot
(Landscape)
Pull wires through
the center opening
Install Anchors
into Drywall
#6 x 3/4 inch
screws
Install Anchors
into Drywall
UP

6009-1593-02
Making Connections
Connecting Power
The CLI-W200 does not run on batteries and requires a
separate power source to operate. To power the thermostat, a
voltage must be applied to the RH and 24C terminals.
If only the power wires removed were from the R and C
terminals of the old thermostat (See Remove Old Thermostat
section above), use the diagram below to make connections.
1. With small slotted screw-
driver, turn the screws on
connector counterclock-
wise (CCW) until silver
crimps open enough to
slide wire(s) into square
slots.
< 1/8 inch
bare wire
exposed
2. Strip back insulation on each wire to / inch and insert
the stripped wire into the proper connection.
3. Turn screws clockwise (CW) until the crimps tighten
around each wire. Tug on each wire a bit to verify they
are secure.
When connecting wires to the CLI-W200, follow the guide-
lines set below to ensure a safe and secure connection.
o
G
Y2 Y1
W2 W1
RC RH
TX+ TX-
24C
RH - Connect the wire
removed from R termi-
nal of old thermostat to
the RH terminal.
On a new install, RH
connects to the 24V
AC wire from the HVAC
transformer.
24C - Connect the wire
removed from the C
(common) terminal on
old thermostat to the
24C terminal.
On a new install,
24C connects to the
common wire from the
HVAC transformer.

7
009-1593-02
Two Power Source Wiring
o
G
Y2 Y1
W2 W1
RC RH
TX+ TX-
24C
Power wire (Rc)
from HVAC
cooling.
Common (C)
wire from HVAC.
Power wire (R)
from HVAC
heating.
RH Supplies power to the relays connected to terminals
W1, W2, and O.
RC Supplies power to the relays connected to terminals
Y1, Y2, and G.
24C Common terminal. The common (C) wire from HVAC
system is required for thermostat to run.
Additional Powering Schemes
Jumper Shunt - JP1
If the HVAC system uses separate power sources to run the
heating and cooling, you should have three wires labeled for
power (R, C, and RC). In this scenario, remove the jumper
shunt from JP1. The next section describes this.
Jumper JP1 on the thermostat board connects the RH and RC
terminals. The thermostat is shipped from the factory with a
jumper shunt installed. For systems with more than one power
source, remove the jumper shunt.
RH
REMOVE SHUNT
24C
RC
JP1
Powers Relays
W1, W2, and O.
Powers Relays
Y1, Y2, and G.
IMPORTANT! Remove
jumper shunt from JP1
if more than one power
source is used. Failure
to remove the shunt will
result in damage to the
thermostat.

8009-1593-02
HVAC Wiring
Temperature Sensors
Use the table below to connect the signaling wires from the
HVAC system. Depending on the type of system installed in
your home will determine which wires are connected. In some
installations, only the power wires described in the previous
sections are required.
There are connections for two temperature sensors.
–RS1 - The main temperature sensor. This sensor is shipped
already pre-installed between terminals RS1 and GND
–RS2 - A remote temperature sensor can be added between
terminals RS2 and GND. No polarity is observed on either
sensor.
TIP! Refer to the Making Connections section above to
ensure a safe and secure connection is made.
O Relay to control changeover valve on a Heat Pump
G Fan Relay
Y2 Relay for control of 2nd stage cooling
Y1 Relay for control of 1st stage cooling
W2 Relay for control of 2nd stage heating
W1 Relay for control of 1st stage heating
AUX OUT AUX IN
RS2 RS1
GND GND
RX- RX+
GND
1-WIRE
5V DC
Remote Sensor
(RS2)

9
009-1593-02
Network and Configuration Requirements
Network Configuration
Additional Information
Smart Sensor Connection
A 1-wire humidity/temperature (CLI-THFM1) sensor that sup-
ports measuring both humidity and temperature can also be
added to the system. Connect the sensor to the 1-Wire, 5V DC,
and GND terminals as shown in diagram below.
With the thermostat installed and wired, it can now be added
to the local network and once communicating with the Savant
Pro System Host an HVAC configuration can be created and
uploaded to the Host. Locate the CLI-W200 Thermostat De-
ployment Guide available on the Savant Customer Communi-
ty to finish installation of the thermostat.
To ensure the IP Address will not change due to a power
outage, Savant recommends DHCP reservation be configured.
Using this method, static IP Addresses for all devices can be
managed from a single User Interface, avoiding the need to
access devices individually.
Setting DHCP reservation varies from router to router. Refer
to the documentation for the router to configure DHCP
reservation.
– CLI-W200 Thermostat Deployment Guide (009-1636)
– SST-TEMP1 Remote Indoor Temp Sensor QRG (009-0800)
– SST-OTEMP Remote Outdoor Temp Sensor QRG (009-0989)
– CLI-THFM1-xx Temp and Humidity Sensor QRG (009-1064)
– CLI-SLAB1 Slab Sensor QRG (009-1097)
– CLI-PLEN1R Residential Plenum Sensor (009-1096)
– CLI-PLEN1C Commercial Plenum Sensor (009-1100)
AUX OUT AUX IN
RS2 RS1
GND GND
RX- RX+
GND
1-WIRE
5V DC
Remote 1-Wire
Sensor

10009-1593-02
Frequently Asked Questions
Does the CLI-W200 require batteries?
No, the CLI-W200 is powered using the power from the HVAC
system. If no common (C) wire was removed from the old
thermostat, a common wire must be added.
How does CLI-W200 get software updates?
Software is updated Over The Air (OTA). Whenever an update
is available on the Savant Cloud, the update will take place
automatically. The CLI-W200 must be connected to a local
network that has WAN access for the updates to occur.
Will CLI-W200 still work if the Wi-Fi connection is lost?
Yes, most thermostat functions will still function when not
connected to Wi-Fi. However, functions such as schedules and
OTA updates can not occur.
Are both Fahrenheit and Celsius supported?
Yes
Does the thermostat support setting both a heating and
cooling set point?
No, The CLI-W200 thermostat is a single set point thermo-
stat. However, the thermostat does support adding a +/-
range to the set point. For example, adjusting the set point to
70° with a range of +/- 3° will manage the temperature so it
stays between 67° and 73°.
Does the thermostat support measuring humidity?
Yes, Savant oers a 1-wire smart sensor (CLI-THFM1) that
measures both humidity and temperature.
My thermostat was received damaged. What should I do?
If the thermostat was purchased through a contractor or
retailer, contact the contractor or retailer to return it. If ther-
mostat was purchased from the Savant Store, contact Savant
through the Savant Customer Community.

11
009-1593-02
Regulatory
FCC Interference Statement
FCC Caution
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this equipment. This
transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with a minimum distance 20cm between the radiator & your body.
This device electronically displays the FCC declaration of conformity logo as
well as the FCC and IC identifier. This information can be found on the device
by accessing:
HVAC Mode menu Swipe Left About.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interferences that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for CLASS
B digital device, pursuant to Part 15 of FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio
communications, However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equip-
ment o and on, the user is encouraged to try correct the interference by one
or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and the receiver
– Connect this equipment into an outlet on a circuit dierent from that to which
the receiver is connected.
– Consult the dealer or experienced radio/TV technician for help.
The following statements are applicable to the CLI-W200x
FCC and IC Identifier for Savant Thermostat
Radiation Exposure Statement

12009-1593-02
Industry Canada Statement
Radiation Exposure Statement
Declaration d'exposition aux radiations
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may
cause undesired operation of the device.
– This Class B digital apparatus complies with Canadian ICES-003.
– This device and its antenna(s) must not be co-located or operating in conjunc-
tion with any other antenna or transmitter, except tested built-in radios. The
County Code Selection feature is disabled for products marketed in the US/
Canada.
Cet équipement est conforme aux limites d’exposition aux rayonnements IC
établies pour un environnementnon contrôlé. Cet équipement doit être installé
et utilisé avec un minimum de 20 cm de distance entre la source de rayonne-
ment et votre corps.
Savant.com
© 2018 Savant Systems, LLC,
45 Perseverance Way, Hyannis Ma. 02601
Telephone: [phone]
04/13/2018
HDH6A009010
For product
information
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operate with
minimum distance 20cm between the radiator and your body.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée aux deux
conditions suivantes:
1. L'appareil ne doit pas produire de brouillage, et
2. L'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d'en compromettre le fonctionnement.
– Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
– Cet appareil et son antenne ne doivent pas être situés ou fonctionner en con-
jonction avec une autre antenne ou un autre émetteur, exception faites des ra-
dios intégrées qui ont été testées. La fonction de sélection de l'indicatif du pays
est désactivée pour les produits commercialisés aux États-Unis et au Canada.
Ce périphérique par voie électronique ache le logo de déclaration de confor-
mité FCC ainsi que l’identificateur de la FCC et d’IC. Cette information peut être
trouvée sur le terminal en accédant à:
menu du mode HVAC Balavez vers la gauche (A propos de).
Identificateur de la FCC et d’IC pour Savant Thermostat
