Saxby 54414 Manual

Instruction leaflet
PIR Sensor
54414
www.saxbylighting.com Saxby Lighting. BH23 3PE

•Voltage: 220 -240VAC 50 Hz
• Maximum Load Wattage: Max. Max. 2000W incandescent bulb (resister-load) or 600W
fluorescent load
• Detection range: 360°, radius 4.5 meters with installation height of 2.8 metres
• Duration time: From (10±5) seconds to (4±1) minutes adjustable
•Lux control level: From daylight to total darkness
Thank you for purchasing this light fitting.
Please read the instructions carefully before use to ensure safe and satisfactory operation of this product.
Please retain these instructions for future reference.
Warning
Layout
• Thisproductissuitableformountinginaceiling.
The optimum mounting distances are shown in the
diagram on the right.
• Avoidpointingatorpositioningclosetoheat
sources such as flues or heat extraction units, which
may cause false triggering.
• Avoidpointingatbrightlightsasunitwillnot
functionwhenyousetLuxcontrolleveltodark
• Avoidlocatingnearelectromagneticfields
Installation
• Takingcarenottodamageanyconcealedwiringor
pipes, cut a 60mm diameter hole.
• Removetheplasticcoverfromtheterminals.
Removecableclampscrewsandcableclap(A)and
setasideforlater.Pull-offtheplasticterminalcover.
Connectthecablestotheterminals:Livemains
supply to terminal marked (L up arrow) Neutral
mainssupplytoterminalmarkedN.Connectthelive
wire of the output cable to the terminal marked (L
down arrow) Connect the neutral cable of the output
cable to terminal marked N.
Ensureallconnectionsaretight.Routecables
through cable clamp and refit clamp ensuring cables
are held securely.
•Refittheplasticcover.
•AdjustthePIRsensorasdetailedbelow.
•Pushthefittingintotheceilingtosecureinplace.
•Replacefuseorcircuitbreakerandswitchon.Your
light is now ready for use.
This product is Double Insulated and does
not require connection to an Earth circuit.
Please read these instructions carefully before
commencing any work.
This unit must be fitted by a competent and qualified
electrician.
Install in accordance with IEE Wiring regulations and
currentBuildingRegulations.
Topreventelectrocutionswitchoffatmainssupply
before installing or maintaining this fitting. Ensure
other persons cannot restore the electrical supply
without your knowledge.
This unit should be connected to a fused circuit.
If replacing an existing fitting, make a careful note of
the connections.
This product is not suitable for dimming.
Waste electrical products should not be disposed of
with household waste. Please recycle where facilities
exist. Check with your local authority or retailer for
recyclingadvice.
This unit is only suitable for indoor use.
PIR Adjustment
The PIR sensor has a fixed detection field of 9m
diameter at a distance of 2.8m. It can be adjusted
for duration the lamp stays on ("TIME" screw) and
thelightlevelthattheswitchactivates("LUX"screw).
To adjust when the switch activates, rotate the
"LUX"screwbetweenthe and symbols.
indicates the PIR sensor will operate at all times
during daylight and darkness. indicates that the
PIRsensorwilloperateintotaldarknessonly.
To adjust the duration the lamp stays on, rotate the
"TIME" screw between + and - . Minimum time on
is 10+/-5 seconds maximum time on is 4+/- 1
minutes
We recommend cleaning with a soft dry cloth.
Donotusesolventsorabrasivecleanersasthesecoulddamagethefinish.
Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist.CheckwithyourLocalAuthorityorretailerforrecyclingadvice.
Recycling advice
Safety information
Care and Cleaning
For your safety, always switch off the supply before changing lightbulbs, or cleaning. Iss.1 26062015
Specification
