Saxco RG-AT40S-I/O User manual

RG-AT40S-I/O
MANUAL
P
R
E
S
S

1 Technical Parameters
2Components
3Installation step
3.1 Installation of bottom plate
3.2 Installation of bottom plate
3.3 Installation of pull bar
3.4 Installation of pull bar
3.7 Finished installation
3.8 Machanism and cover installation
4.1 Terminal details
of controller
4.2 Date setting
4.3 Connection of commonly used and special function
3.5 Installation of push bar
4Wired digram
5
1
2
3-11
3
4
5-6
7
10
11
12-15
12
12
13-15
16
Content
8
3.6 Installation of push bar 9
6Trouble shooting 16
LED display feedback

1
1.Technical Parameters
Dimensions:515*80*115mm(LWH)
Weight:8kgs
Ambient temperature:-20 ~ +50℃
Operation voltage:AC 200V -250V
Power supply external consumer:24V DC (±10%),3A
Door opening angle:Max 115°
Opening speed:45°/S
Closing speed:45°/S
Hold-open time:0-60S
Protection class:IP21
mm=Door width
kg=Door weight
Suitable range
Limit range
mm
kg
1500
2000
1000
80
100 140 180
200120 160

1. Components
2
RG-AT40S-I/O
Bottom plate
Pull bar
Cover
Pull guider
Mechanism
Leftside cover
Motor
Transformer
220V input
Pull bar
Controller
Rightside cover

3.
3.1
Operator at right position.
Operator at left position.
71.4
Installation of bottom plate
Pull bar type
Installation step
As the picture showing, fix the bottom plate on the frame
with eight countersunk head screw.
As the picture showing, fix the bottom plate on the frame
with eight countersunk head screw.
frame
bottom plate
power liner
power liner
sensor liner
sensor liner
3
35
35

3.
3.2
Operator at right position.
Operator at left position.
4
71.4
71.4
Installation of bottom plate
Push bar type
Installation step
As the picture showing, fix the bottom plate on the frame
with eight countersunk head screw.
As the picture showing, fix the bottom plate on the frame
with eight countersunk head screw.
frame
bottom plate
sensor liner
sensor liner
power liner
power liner
35
35

5
3.3 Installation of pull bar guider
3.Installation step
1.Open the door to 90 degree before installation,put the slider of pull bar into groove
2.Fix the pull bar installation plate according to the picture
3. Adjust the the position of slider installation plate,make sure the wheel is at the
middle of groove as the picture shown
4.Keep the position of installation plate,tighten the first screw at the axis of door
5.Close the door,repeat the step 3,tighten the second screw at another side
6.Manually open and close several times,make sure the pull bar is working perfect,
If there is resistance please adjust the installation plate of pull bar again
7.Tighten the last screw

3.
6
3.3
170
Installation step
Installation of pull bar guider
A. Right position
Fix the pull bar on door leaf with
3 pcs self-tapping screw.
Door leaf
position stopper
Adjust the opening angle
by position stopper.
230 230 20

3.
7
3.4
170
Installation step
Installation of pull bar guider
B. Left position
Fix the pull bar on door leaf with
3 pcs self-tapping screw.
Door leaf
position stopper
Adjust the opening angle
by position stopper.
20 230230

3.
8
3.5
53
50 450
Installation step
Installation of push bar
Adjust the push bar lenght by two screw according to the door frame’s depth(L).
Fix the bottom of push bar to door leaf
L

3.
9
3.6
Installation step
Installation of push bar
B. Left position
Adjust the push bar lenght by two screw according to the door frame’s depth(L).
450 50
35
Fix the bottom of push bar to door leaf
L

3. Installation step
10
Finished installation
Pull bar: Door leaf open toward inside (same direction as operator)
Push bar: Door leaf open toward outside (same direction as operator)
operator
operator
3.7

3. Installation step
11
3.8 Mechanism installation
Hang the mechanism on the fixed base cover with screws.
Assemble and disassemble of the mechanism up cover.

12 3
LED
LEARN +
-
SET
code value
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
+24V
GND
+12V
GND
OPEN-A
COM
FULL LOCK
COM
OPEN-B
COM
20
21
22
23
24
4.1 Terminal details
4.2 Date setting
12
4. Wired diagram
Synchronous(in)
Synchronous(out)
COM
Interlock(in)
COM
Interlock(out)
E-lock+
GND
UPS+
1: LED on/off
2: Master door selector
3: L/R switch
+24V
+12V
GND
Press button"+" or "-" to find the code you want to adjust.
Press button"SET", LED will flash. Then press button"+" or
"-" to adjust value of the code. At last, press button "SET",
LED will stop flash. Date setting is finished.
TEST Test: In double open mode,test
button is disabled on salve
controller
code Setting range Default description
03 1-30
02 30-99
01 30-99
06 10-50
05 10-50
04 1-30
Bu er opening speed
07 0-60
08 2...8
2Hold-open time 0-60s
1-4s 1=0.5s when lock function
working
09 0,1,2...8 Locking delay time 0-4s 1=0.5s
10 0,1 1 Locking type 0 lock by remote; 1
11 0,1 1 Push and go function 0 working 1 not working
12 1,2,3,4,5 3 Obstacle detection optimized for exterior(wind loads)
13 1,2,3,4,5 3 Auto-locking force
14 1,2,3,4,5 3 Anti-collision force
15 5-30 15 Auto-learning speed
16 0,1,2...10 2 Working interval between master and slave door 0-1s
1=0.1s
On master door the setting is working when closing
On slave door the setting is working when opening
60
50
10
10
30
30
3
2
Note: Funcions of dip switch 2 and 3 are active when power is on. Then restart the power.
The dip switch selection is done.
Opening speed(velocity open)
Closing speed(velocity close)
Buffer closing speed
Buffer opening angle
Buffer closing angle
Starting delay time
auto lock when
closed
Anti-clamp(close)
Anti-clamp(open)

13.Synchronous IN
16.inter-lock signal IN
14.inter-lock signal OUT
16.inter-lock signal IN
14.inter-lock signal OUT
11.Synchronous OUT
13.Synchronous IN
11.Synchronous OUT
Inter-lock
brown
green
yellow
white
1. 24V
2. GND
9. OPEN-B
10. COM
19.
18. GND
13
Synchronous
Door A
Door A Door B
Door B
24G Microwave sensor
UPS
UPS+
Wired Diagram
In single open mode:bridge connect terminal 11 and 13
13.Synchronous IN
11.Synchronous OUT
COM
COM COM
COM
COM
COM

Anti-clamp sensor when opening
NO
COM
GND
+24V
24. Anti-clamp
22. GND
22. GND
20. +24V
Anti-clamp sensor when closing
NO
COM
GND
+24V
23. Anti-clamp
22. GND
22. GND
20. +24V
Access keypad
AK04
14
Wired Diagram
0 (black)
12V red
18. GND
17.
Wiring connection of electronic bolt lock
(Attention:Dont connect magnetic lock directly without Transformer or Ups)
Electronic lock+
9.OPEN-B
3. +12V
4. GND
10.COM
COM
NC
NO
OPEN
GND
+12V
D-IN
ALARM
D1
D0

15
1. Receiver has been built-in.
2. Lock grades:open A>full lock>open B.
It means when full lock function working, it lock accessories connected to
open B, but can't lock accessories connected to open A.
3. Exit only function:
Connect outside sensor or button to terminal"Open-B", connect inside sensor or
button to terminal "Open-A".Then press "full lock" button on remote.
Notes:
Wired Diagram
Add the remote :press the learning button on controller till the indicator turn from green to red,
then release the learning button and press A button on remote,the indicator
turn from red to green alternately 3 times,learning successful.
delete the remote:press and hold the learning button,after 5seconds,the indicator turn from green
to red and trun to green again,press A button on te remote,the he indicator turn
from red to green alternately 3 times,all the remote memory is deleted (attention,
pls hold he learning button when you delet the remote memory).
Operation of remote control
4.When double open, the transmitter should learn both operators together.
5.In double open mode,accessories should connect to both controller(parallel connection)
1 2 3 4
ON
Wirless push button :Added and deleted wireless push button is same as remote.
Please check the DIP switch if it‘s same as the image
shown(during setting process).
AB
DC
D:
Full lock
FC04B:
A:
Always open
B:
Close door & Unlock
C: Open and close one time

Symptoms
Causes
Items Checked Remedies
Door opened
or closed
un-smoothly
Hit the door frame
suddenly when
closing, door stop
suddenly when
opening
Door doesn't work
Opening/closing speed
is set too slow
learning speed is too fast
check the opening/closing
speed
speed up the opening/
closing speed
check the learning speed slow down the learning
speed
Too much resistance
Buffer speed when
opening/closing is too fast
slow down the buffer speed
when opening/closing
Fix the stopper.Position stopper is loosen.
No power
learning speed is too slow
Door is locked
Obstacle in the pull bar's
guider.
Resistance force is too
stronge.
check whether there is
someting on the door's
working way
clear the obstacle away
check the power switch,
connection terminal
from motor to controller
connect the power
speed up the learning
speed.
check the pull bar guider
check whether the door is
locked.
remove the obstacle
un-lock the door
Power off, push the door
leaf. Make sure the door
work smoothly.
16
Single opening
LED display Details
Dr11 No problem.
Terminal 11 and 13 are not
connected.(They should be
connected when single
opening)
Over current prote on for
controller.
Er02 Motor has problem.
Double opening
LED display Details
Dr12 Master door
Dr13 Slave door
Over current prote on for
controller.
Er02 Motor has problem.
Er03 Synchronous wired problem.
Master door and slave door
se ng problem.
5. LED display feedback
6. Trouble shooting
Er01
Dr12 or Dr13 Er01
Er04
