LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
3200
1800
687
8 x 75mm SCREW BOLT
OR 10mm TRU-BOLT
2 PER BRACKET
SUPPORT BRACKET
(MAY BE CUT DOWN TO SUIT)
PURLIN/CLADDING INSTALLATION
CONCRETE INSTALLATION

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [e-mail]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
Allow 750mm
for ladder
GUTTER
3200
400 MAX
PLATFORM SUPPORT CHANNELS
PLATFORM
POSITION AND FIX PLATFORM SUPPORT CHANNELS TO ROOF DECK
EPDM SEAL UNDER
QTY 4 x 8mm BULB TYPE
RIVETS PER BATTEN
EPDM SEAL
GUIDE FOR POSITIONING OF CHANNELS

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [e-mail]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
ASSEMBLE KOMBI PLATFORM FRAME
KOMBI 80 EXTRUSION
KOMBI PLATFORM CROSS SUPPORT
KOMBI 80 ANGLE BRACKET
650
KOMBI T-BOLTS
300mm WIDE
NARROW MESH
30mm TEK SCREW &
WALKWAY DISC
WALKWAY EDGE BAR
REFER TO KOMBI INSTALLATION DETAILS
https://kombiaccess.com/wp-
content/uploads/2018/10/KOMBI_Stair_and_
Platform_Install_Manual.pdf

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [e-mail]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
ADJUST PLATFORM HEIGHT THEN
FIX OFF WITH TEK 20mm SCREWS
KOMBI T-BOLT
20mm TEK SCREWS INTO BATTEN
POSITION AND FIX PLATFORM
INSERT SPLICE INTO POST
STEP 1
STEP 2
STEP 3

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [e-mail]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
KOMBI T-BOLTS
KOMBI 60 BRACE
BRACE SUPPORT
AL732 - 100 x 50 x 6 ANGLE
KB017 - KOMBI BRACE PLATE
M10 x 75 BOLT
QTY 4 x 14G TEK SCREW INTO PURLIN
(2 AT THE TOP & 2 AT THE BOTTOM)
ATTACH ANGLE SUPPORTS AND BRACES
SUPPORT MAY BE BOLTED
ANYWHERE ON ANGLE
MIN 45°
14G TEK

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [e-mail]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
ATTACH HANDRAIL, KNEERAIL AND TOEBOARD
ATTACH HANDRAIL KNEERAIL AND TOEBOARD
AS PER SENTRY INSTRUCTION MANUAL

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [e-mail]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
FIX ALL HANDRAIL, KNEERAIL & TOEBOARD SECTIONS
AS PER SENTRY INSTRUCTION MANUAL
CONNECT KNEERAIL TO
SIDE OF LADDER STILE
MOUNT LADDER BRACKET
USING T-BOLTS
ATTACH LADDER FIXING BRACKET
ENSURE NO GAPS
GREATER THAN 100mm

THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
1029 MOUNTAIN HWY BORONIA VIC 3155
T [phone]
E [e-mail]
F [phone]
E sayfa.com.au
DRG No.
DATE
Code
REV
DESCRIPTION
LD429T - LADDER HEAD CANTILEVER
PLATFORM INSTALLATION DETAILS
D9369
28/6/2021
LD429T
2
300
290
VERTICAL
HEIGHT
MAX 6000
5800
DISTANCE BETWEEN LANDINGS
MUST BE IN INCREMENTS OF 290mm
GUIDE FOR DISTANCE BETWEEN LANDINGS
75°
80°
295
PREFERRED ANGLE
